Godox TT685II-O User manual

TT685II-O
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch

2
English
3 –36
Čeština
37 –70
Slovenčina
71 –104
Magyar
105 –139
Deutsch
140 –174

3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆[phone]
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Prague 7, www.alza.cz

4
Foreword
Thank you for purchasing this product.
This TT685IIO camera flash applies to Olympus/Panasonic series cameras and is
compatible with TTL autoflash. With this TTL compatible flash, your shooting will become
simpler. You can easily achieve a correct flash exposure even in complex light-changing
environments. This camera flash features:
•Approx. GN60 (ISO 100, @200mm), 81 steps from 1/1 to 1/256.
•Fully support Olympus/Panasonic TTL camera flash. Workable as Transmitter or
Receiver unit in a wireless flash group.
•Use dot-matrix LCD panel to make clear and convenient operations.
•With built-in 2.4GHz wireless remote system to support transmitting and
receiving.
•Provided multiple functions, include HSS (up to 1/8000s) FEC, FEB, etc.
•Stable consistency and color temperature with good even lighting.
•Support with firmware upgrade.
Warning
•Always keep this product dry. Do not use in rain or in damp conditions.
•Do not disassemble. Should repairs become necessary, this product must be sent
to an authorized maintenance center.
•Keep out of reach of children.
Stop using this product if it breaks open due to extrusion, falling or strong hit.
Otherwise, electric shock may occur if you touch the electronic parts inside it.
•Do not fire the flash directly into the eyes (especially those of babies) within short
distances. Otherwise, visual impairment may occur.
•Do not use the flash unit in the presence of flammable gases, chemicals, and
other similar material. In certain circumstance, these materials may be sensitive
to the strong light emitting from this flash unit and fire or electromagnetic
interference may result.
•Do not leave or store the flash unit if the ambient temperature reads over 50°C.
Otherwise the electronic parts may be damaged.
•Turn off the flash unit immediately in the event of malfunction.

5
Name of Parts
1. Flash Head
2. Built-in Wide Panel
3. Wireless Sensor
4. Focus Assist Beam
5. Sync Cord Jack
6. Type-C USB Port
7. Battery Cover
8. Hotshoe
9. LCD Panel
10. Hotshoe Fixing Buckle
11. External Charging Port

6
Control Panel
11. <MENU> Flash Menu Button
12. Wireless Selection Button
13. Select Dial
14. Set Button
15. ON/OFF Power Switch
16. Test Button/Flash Ready Indicator
17. <ZOOM> Focus Length Setting
18. <MODE> Mode Selection Button
19. Lock Setting
20. <+/->Power Output
21. Function Button 1
22. Function Button 2
23. Function Button 3
24. Function Button 4

7
LCD Panel
TTL Autoflash
Zoom: zoom display
•The display will only show the settings currently applied.
•The functions displayed above function button 1 to 4, such as SYNC and
<M/A/B/C>, change according to settings status.
•The LCD panel will lighten on when buttons and dials are operated.
•When the Function Button 1 displays TCM above short press it can switch
between TTL mode and M mode.
M Manual Flash
Automatic zoom
Manual zoom
TTL: TTL
autoflash
Flash exposure
compensation amount
Effective
Flash Range
Distance indicator
display
High-speed sync
Focus length
M: Manual flash
Manual flash output

8
Multi Flash
Radio Transmission Shooting
•Transmitter Unit (TX)
•Receiver Unit (RX)
Multi: Stroboscopic flash
Number of flashes
Flash frequency
Flash mode
: Radio transmission
wireless shooting
Firing group
Channel
: Receiver icon
Receiver

9
LCD Panel in Three Modes
Attached to the Camera
2.4G Radio Transmission: As a Transmitter Unit
2.4G Radio Transmission: As a Receiver Unit

10
What’s in the Box of TT685IIO Kit?
Flash Unit
Mini Stand
Protection Case
Instruction Manaul
Separately Sold Accessories
The product can be used in combination with the following accessories sold separately,
so as to achieve best photography effects: XProC, X2T-C & X1C TTL wireless flash trigger,
etc.

11
Loading and Unloading the Battery
To unload the battery hold down the battery press compartment and push the battery
downwardly to take it out.
Put 4 batteries in with the correct polarity after opening the battery compartment, then
close and push it to the top.
Tips: When collocated with the optional Godox Flash Power Box PB960, TT685IIO will
have more flash times, shorter recycle time and longer duration.
Attaching to a Camera
Attach the Camera Flash
Rotate the hotshoe fixing
buckle to the left and insert
the camera flash into the
camera’s hotshoe.
Secure the Camera Flash
Rotate the hotshoe fixing
buckle to the right until it
locks up.
Detach the Camera Flash
Press the button and
rotate the hotshoe fixing
buckle to the left until it is
loosened.

12
Power Management
Use ON/OFF Power Switch to power the flash unit on or off. Turn off it will not be used
for an extended period of time. Setting as transmitter flash, it will turn the power off
automatically after a certain period (approx. 90 seconds) od idle use. Pressing the
camera shutter halfway or pressing any flash button will wake up the flash unit. Setting
as a receiver flash, it will enter sleep mode after a certain period (adjustable, 60 minutes
by default) od idle use. Pressing any flash button will wake it up.
Disabling Auto Power Off function is recommended when the flash is used off
camera. (C.Fn-STBY)
Receiver Auto Power Off Timer is set to 60 minutes by default. Another option “30
minutes” is available (C.Fn-RX STBY)
Flash Mode—TTL Autoflash
This flash has three flash modes: E-TTL, Manual (M) and Multi (Stroboscopic). In E-TTL
mode, the camera and the flash will work together to calculate the correct exposure for
the subject and the background. In this mode, multiple TTL function are available: FEC,
HSS, second curtain sync, control with Olympus/Panasonic camera’s menu screen.
* Press <MODE> Mode Selection Button and three flash modes will display on the LCD
panel one by one with each pressing.
ETTL Mode
Press <MODE> Mode Selection Button to enter E-TTL mode. The LCD panel will display.
•Press the camera release button halfway to focus. The aperture and effective
flash range will be displayed in the viewfinder.
•When the shutter button is fully pressed, the flash will fire pre-flash that the
camera will use to calculate exposure and flash output the instant before the
photo is taken.
FEC: Flash Exposure Compensation
With FEC function, this flash can adjust from -3 to +3 in 1/3 stops. It is useful in situations
where minor adjusting of the TTL system is needed based on the environment.

13
Press the <+/-> button.
The flash exposure
compensation amount will
be highlighted on the LCD
panel.
Set the flash exposure
compensation amount.
•Turn the Select Dial
to set the amount.
•“0.3” means 1/3
step, “0.7” means
2/3 step.
•To cancel the flash
exposure
compensation, set
the amount to “+0”.
Press Set Button again to
confirm the setting.
High-Speed Sync
High Speed Sync (FP flash) enables the flash to synchronize with all camera shutter
speeds. This is convenient when you want to use aperture priority for fill-flash portraits.
Setting the flash to High-speed Sync mode when it is on the camera:
Press the <SYNC> button to turn on high-speed sync flash and < > is displayed. Then,
adjust the camera’s shutter to achieve high-speed sync flash.
•With high-speed sync, the faster the shutter speed, the shorter the effective flash
range.
•Multi flash mode cannot be set in high-speed sync mode.
•Over-temperature protection may be activated after 15 consecutive high-speed
sync flashes.
•Try not to use high-speed sync flash, for using this function will reduce flash
tube’s service life.
Note: In the wireless remote control mode, suing high-speed sync flash with Panasonic
camera may occur out of sync.

14
Second-Curtain Sync
With a slow shutter speed, you can create a light train following the subject. The flash
fires right before the shutter closes.
Setting second-curtain sync:
Second-curtain sync function shall be set on the camera’s menu. More details please
refer to camera’s instruction menu.
M: Manual Flash
The flash output is adjustable from 1/1 full power to 1/256th power in 1/10th stop
increments. To obtain a correct flash exposure, use a hand-held flash meter to
determine the required flash output.
Press <MODE> button so
that <M> is displayed.
Press <+/-> to choose
power, then turn the
Select Dial to choose a
desired flash output
amount.
Press Set button again to
confirm the setting.
Optic S1 Secondary Unit Setting
In M manual flash mode, press <S1/S2> button so that this flash can function as an optic
S1 secondary flash with optic sensor. With this function, the flash will fire synchronously
when the main flash fires, the same effect as that by the use of radio triggers. This helps
create multiple lighting effects.
Optic S2 Secondary Unit Setting
Press <S1/S2> button so that this flash can also function as an optic S2 secondary flash
with optic sensor in M manual flash mode. This is useful when cameras have pre-flash
function. With this function the flash will ignore a single “preflash” from the main flash
and will only fire in response to the second, actual flash from the main unit.
•S1 and S2 optic triggering is only available in M manual

15
Multi: Stroboscopic Flash
With stroboscopic flash, a rapid series of flashes is fired. It can be used to capture
multiple images of a moving subject in single photograph.
You can set the firing frequency (number of flashes per sec. expressed as Hz), the
number of flashes, and the flash output.
Press <MODE> button so that <MULTI> is displayed.
Set the flash frequency and flash times.
•Press the Function Button 2 <Times> to select the flash times. Turn the Select Dial
to set the number.
•Press the Function Button 3 <Hz> to select the flash frequency. Turn the Select
Dial to set the number.
•Turn the Select Dial to choose desired flash output. After you finish the setting,
press Set Button and all the settings will be displayed.

16
Calculating the Shutter Sped
During stroboscopic flash, the shutter remains open until the firing stops. Use formula
below to calculate the shutter speed and set it with the camera.
Number of Flashes / Flash Frequency = Shutter Speed
For example, if the number of flashes is 10 and the firing frequency is 5 Hz, the shutter
speed should be at least 2 seconds.
To avoid overheating and deteriorating the flash head, do not use stroboscopic flash
more than 10 times in succession. After 10 times, allow the camera flash to rest for at
least 15 minutes. If you try to use stroboscopic flash more than 10 times in succession,
the firing might stop automatically to protect the flash head. If this camera happens,
allow at least 15 minutes rest for the camera flash.
•Stroboscopic flash is most effective with a highly reflective subject against a dark
background.
•Using a tripod and remote control is recommended.
•A flash output of 1/1 and 1/2 cannot be set for stroboscopic flash.
•Stroboscopic flash can be used with “bulb”
•If the number of flashes is displayed as “--”, the firing will continue until the
shutter closes or the battery is exhausted. The number of flashes will be limited
ah shown by the following table:
Maximum Stroboscopic Flashes
Flash Output / Hz

17
Flash Output / Hz
Wireless Flash Shooting: Radio (2.4G) Transmission
•You can set up five receiver groups for TTL autoflash shooting. With TTL
autoflash, you can easily create various lighting effects.
•Any flash settings for the receiver units on the transmitter flash in
TTL/Manual/Multi mode will be automatically sent to the receiver units. So the
only things you need to do is to set the transmitter unit for each receiver group
without any operation for the receiver units at all during the shooting.
•This flash can work in TTL/M/Multi OFF flash modes when set as transmitter unit.
•The TT685IIO attach to the camera is called the transmitter unit, and a TT685IIO
that is wirelessly controlled is called the receiver unit.
•You can also wirelessly control the TT685IIO set as the receiver unit with the
transmitter X1T-C (sold separately). For details on setting the transmitter unit
functions, see the transmitter’s intrucstions.

18
Positioning and Operation Range (Example of wireless flash shooting)
•Autoflash Shooting with One Receiver Unit
•Use the supplied mini stand to position the Receiver unit.
•Before shooting, perform a test flash and test shooting.
•The transmission distance might be shorter depending on the conditions such as
positioning of Receiver units, the surrounding environment and whether
conditions.
Wireless Multiple Flash Shooting
You can divide the Receiver units, into two or three groups and perform TTL autoflash
while changing the flash ratio (factor). In addition, you can set and shoot with a different
flash mode for each firing group, for up to 4 groups.
Auto Shooting with Two Receiver Groups
TRANSMITTER
RECEIVER
Transmission distance is about
100m.

19
Auto Shooting with Three Receiver Groups
Wireless Settings
You can switch between normal flash and wireless flash. For normal flash shooting, be
sure to set the wireless setting to OFF.
Transmitter Unit Setting
Press < > button so that < > is displayed on the LCD panel.
Receiver Unit Setting
Press < > button so that < > or < > displayed on the LCD panel.

20
Setting the Communication Channel
If there are other wireless flash systems nearby, you can change the channel IDs to
prevent signal interference. The channel IDs of the Transmitter unit and the Receiver
unit(s) must be set to the same.
Press <MENU> Buton to
enter C.Fn CH setting.
In C.Fn CH, turn the Select
Dial to choose channel ID
from 1 to 32.
Press the Set Button to
confirm.
Wireless ID Settings
Change the wireless channels and wireless ID to avoid interference for it can only be
triggered after the wireless IDs and channels of the Transmitter unit and the Receiver
unit are set to the same. Press the <MENU> button to enter C.Fn ID. Press the Set Button
to choose OFF channel expansion shutdown, and choose any figure from 01 to 99.
Scan the Spare Channel
To avoid the interference of using the same channel by others, this function can be
used: enter the C.Fn settings and find the SCAN option. When setting it to START, it will
scan from 1% to 100%. And 8 spare channels will be displayed after the scan is
completed.
