Goodmans GLCD15M User manual

GLCD15M
15’’ LCD MONITOR
INSTRUCTION MANUAL
Goodmans Product Information Helpline：
0870 873 0080

Contents
Introduction........................................................................................................... 1
Features ..................................................................................................................... 1
For safe use of this product ....................................................................................... 2
Installation.................................................................................................................. 3
Unpacking the Display ................................................................................................ 3
Locations and Functions of Controls .......................................................................... 3
Making the Connections .............................................................................................. 4
Using The Display .................................................................................................... 6
Turning the Display On and Off .................................................................................. 6
Setting the Video Mode (PC only) ............................................................................... 7
Setting the Refresh Rate (PC only) ............................................................................. 7
Minimizing Power Consumption (PC only)................................................................... 7
Caring for and Cleaning the Display ........................................................................... 8
Adjusting The Display .............................................................................................. 9
Summary of Control Buttons........................................................................................ 9
Displaying the OSD “Main Menu” ................................................................................ 9
Selecting Items in the OSD Menu ............................................................................... 10
Making Adjustment Via the OSD Menu........................................................................ 10
Direct Function Access using the Left or Right Buttons ............................................... 14
Troubleshooting ....................................................................................................... 15
Technical Information................................................................................................ 16
Display Information...................................................................................................... 16
Video Modes ............................................................................................................... 17
Unknown Video Modes................................................................................................ 18

1
ENGLISH
Introduction
This latest LCD monitor has a 15-inch active matrix TFT (thin film transistor) liquid
crystal display module. It can be used with set top boxes, DVD players, VCR’s
and also windows based PC’s .
Features
Important features include:
ÖAutomatic configuration to the PC video settings with maximum XGA
resolution.(1024 x 768)
ÖThree control buttons plus OSD (on-screen display) for monitor settings
adjustment and configuration with ease and instant feedback.
ÖSupports analogue video input for direct and immediate replacement of CRT
displays.
ÖSupports composite video input for TV signal.
ÖBuilt-in speakers.
ÖAnti-glare coating on the panel to reduce the reflection of ambient light.
ÖFlicker-free performance across all recommended video modes.
ÖSupport for high refresh rates up to 75 Hz for PC use.
ÖVESA DDC2B Plug-and-Display compliant.
ÖPower-saving feature that is compatible with Microsoft® Windows
ÖCompliance with Swedish MPR II guidelines for reduced electromagnetic
emissions.

2
ENGLISH
Warning
To completely disconnect power from the display, remove the
power cord from the wall outlet and then remove the power cable
from the display.
For Safe use of this product
For safe use and the protection of the monitor,please follow these precautions:
ÖUse only the factory-supplied power adaptor shipped with the monitor.
ÖTo prevent electrical shock, do not disassemble the display. The cover should
be removed only by qualified service personnel.
ÖDo not cover the air vents.
ÖTo avoid the risk of damage to the display and electrical shock, do not expose
the display to rain or moisture.
If any of the following conditions occur, unplug the display and contact qualified
service personnel:
ÖThe power cord or plug is frayed or damaged.
ÖLiquid has been spilled into the display.
ÖThe display has been exposed to rain or water.
ÖThe display does not operate correctly when the operating instructions are
followed.
ÖThe display has been dropped or the cabinet has been damaged.

3
ENGLISH
Installation
Please follow the instructions in this chapter to install the LCD Monitor.
Note:Before connecting the display, first read through the instructions in
this chapter and the safety precautions on the previous page.
Unpacking the Display
When unpacking the display, make sure that the following items are present:
ÖThe LCD monitor
ÖAC power adapter with attached power cable
ÖPower cord with 3 pin mains plug
ÖAnalogue video signal cable
ÖScart video signal cable.
ÖThe User’s Manual
Note:Place the display on a flat, sturdy surface. Choose an area free from
excessive heat, moisture, and sunlight.
Locations and Functions of Controls
There are three control buttons and one power button on the front panel of the
display, as well as an LED indicator for power status indication.
① Power button
② Select button
③ Right navigation button
④ Left navigation button

4
ENGLISH
The power button is located on the lower right of the panel.
The functions of the three control buttons, which are located at the lower
middle-left side of the front panel of the display, are described as below:
Button Function Description
Select (1) Bring-up OSD Main Menu.
(2) Select item for user adjustment.
Right ( )
(3) Item selection move upward or user-adjustable value
increasing (in main menu).
(4) Bring-up Audio/Video Menu (Direct-key function).
Left ( )
(5) Item selection move downward, user-adjustable value
decreasing (in Main Menu) .
(6) Auto Setup (Direct-key function, PC input signal only).
Making the Connections
Before connecting any cables, make sure that the computer and display are
turned off.
To connect the power and video signal cables:
1. Locate the AC power adapter with attached power cable.
2. Connect the power cable to the DC input socket on the rear of the display (“DC
IN” as shown below).
3. Plug the three-pin power cord into a power outlet, and plug the other end into
the AC power adapter.

5
ENGLISH
When using with a PC:
4. Plug the analogue video signal cable into the Analogue Video Input port on
the back of the display (“ANALOG IN” as shown above).
5. Connect the other end of the video cable into the computer’s video port.
(Please check the computer’s documentation if you’re not sure where the port
is located.)
Note: For best display performance, it is strongly recommended that Auto
Setup is used to automatically configure the display’s settings (only
for Analogue input).
Connecting a set top box / DVD players
6. Locate the scart to composite video/video cable.
7. Insert the scart plug into the scart socket of the set top box / DVD player.
8. Connect the larger RCA plug to the composite video in socket on the rear of
the panel.
9. Connect the smaller 3.5 mm jack plug of the audio in socket on the rear of the
panel.

6
ENGLISH
Using The Display
Turning the Display On and Off
Use the power button located at the lower right side of the front panel of the
display to turn the display on and off. When the display is on, the LED near the
Power button is illuminated. The indicator will illuminate green when both the
display is active and amber when the display is in reduced power mode.(PC only)
Note：For PC use only.
If the PC supplies power saving signals to the display, the display’s power
management features reduce power consumption to low levels when the PC
goes into its power-saving mode. See “Minimizing Power Consumption” on page
7 for more information.
If the PC doesn’t use industry standard power-save signaling techniques, power
consumption can be reduced by turning off the display when not in use.
Note: Because of the technology used in LCD panels, screen savers will
not prolong the life of the display. So if the display will not be used for
an extended period, be sure to turn it off.
Warning
To completely disconnect power from the display, you must
remove the power cord from the wall outlet and then remove the
power cable from the display.

7
ENGLISH
Setting the Video Mode (PC only)
Since the inherent format of this display is 1024 pixels by 768 lines, the display
will perform best when a PC is set to a screen resolution of 1024 x 768. If using a
lower resolution (such as 640 x 480), the image is expanded to fill the screen
The display supports many common video modes, as shown in “Video Modes” on
page 17 Check the documentation supplied with the PC and video adapter card
to find out which modes they support.
To check the video mode of the PC, please check the Windows’ settings feature.
Setting the Refresh Rate (PC only)
The image refresh rate is the number of times per second that the image is
refreshed; it is also known as the vertical frequency.
On standard CRT displays, we recommend that the highest possible refresh rate
supported by your PC at the current screen resolution should be used. This is
necessary to avoid screen flickering and to minimize eyestrain. However, with an
LCD Monitor, flicker is not an issue. It is flicker-free at all supported refresh rates.
The table in “Video Mode” on page 17 shows the image refresh rates supported
by the display at different screen resolution. Although this LCD monitor supports
up to 75 Hz for analogue video input, we recommend that is used at 60 Hz refresh
rate for best performance.
To set the refresh rate with a standard Windows installation, follow the steps
mentioned in the Windows’s or graphic card’s user’s manual.
Minimizing Power Consumption (PC only)
Many PCs support industry standard power-save signaling techniques. Power
management features reduce the display’s power consumption after a period of
keyboard inactivity.
When the display is in a power-saving mode, the screen is blank and the power
indicator is amber. Pressing a key on the keyboard or moving the mouse restores
the image in several seconds. Consult the PC documentation for information
about setting the power-saving modes.
The display accepts the signals for the three standard power-saving modes –
Standby, Suspend, and Sleep. For any of these conditions, the display will go into
Sleep mode.

8
ENGLISH
Warning
Don’t use liquid, aerosol, or abrasive cleanin
g
solutions to clean the
screen.
Caring for and Cleaning the Display
To maximize screen life and prevent damage to the LCD panel, we recommend
to:
ÖUse the display power management system (if available on the PC).
ÖIf a power management system is not used, turn off the display when it won’t
be used for an extended period.
ÖDon’t press, rub, or poke the display with fingers or other objects.
ÖHandle the display with care.
The LCD module is a high-quality optical device that requires special care when
cleaning.
To clean the screen:
1. Turn off and unplug the display.
2. Gently dust the screen with a dry, soft, line-free cloth.
Note: If the screen is still dirty, a dampened cloth with several drops of
distilled water can be used. Make sure the LCD panel is completely
dry before turning back on.

9
ENGLISH
Adjusting The Display
Summary of Control Buttons
There are three control buttons located at the lower part of the front panel of the
display:
ÖSelect：Display the On-Screen Display (OSD) “Main Menu” and selects items
for user adjustment.
ÖRight (Z)：Move upwards through the options in the OSD submenu. If an
adjustment bar is displayed, this button increases the setting value.
Note：This key is also used as ‘direct key’ to bring-up OSD “AUDIO/VIDEO”.
ÖLeft (Y)：Move downward through the options in the OSD submenu. If an
adjustment bar is displayed, this button decreases the setting value.
Note：This key is also used as ‘direct key’. When the OSD “Main Menu” is
inactive, press this key will bring-up ‘AUTO SETUP’ submenu.(PC
only)
Displaying the OSD “Main Menu”
To display the OSD “Main Menu”, please press the ‘Select’ button.
Brightness
－＋100

10
ENGLISH
The following table briefly describes each of the items in the OSD “Main Menu”.
Item Description
Brightness Controls the brightness of the display. The default setting of
brightness is maximum.
Contrast Adjust the level of difference between light and dark areas
of the image.The default setting of contrast is at 50.
Display
(PC mode only)
Open the “Display” submenu where you can select
horizontal (H.) or vertical (V.) position for further
adjustment.
Color Open the “Color” submenu where Color Temperature,
Luminance, Hue, Color and Sharpness can be adjusted.
See “Making Adjustments Via the OSD Menu” on page 10.
Clock/Phase
(PC mode only)
Open the “Clock/Phase” submenu to select Auto Setup or
Clock or Phase for further adjustment.
Management Open the “Management” submenu to select display mode
information (Mode Info), OSD Display, select input signal
(source), and recall factory settings for further adjustment.
See “Making Adjustments Via the OSD Menu” on page 10.
Selecting Items in the OSD Menu
To select items in the OSD “Main Menu”, use the ‘Select’ button on the front
panel of the display.
To select items in the OSD submenus, use all three control buttons. To select a
specific submenu, use the ‘Select’ button to locate the required option. Then
choose any item in the selected submenu by using ‘Right’ or ‘Left’ buttons, and
then select it by press ‘Select’ button.
Making Adjustments Via the OSD Menu
Adjusting Brightness
zPress the SELECT button to show the OSD menu.
zThe brightness icon will be highlighted (RED)
zUsing the left and right control buttons increase or decrease the brightness
level as required between the limits of “0” and “100”.

11
ENGLISH
Adjusting Contrast
zPress the SELECT button to show the OSD menu..
zThe brightness icon will be highlighted (RED)
zPress the SELECT button again the contrast icon will now change to RED to
indicate it is the active function.
zUse the left and right control buttons increase or decrease the brightness
level as required between the limits of “0” and “100”.
Adjusting Display Properties (only available when
connected to a PC)
Press the SELECT button to show the OSD menu
The brightness icon will be highlighted (RED)
Press the SELECT button twice the Disply icon will now change to RED to
indicate it is the active function,
Using the left and right control buttons select the required feature from the sub
menu H.Position or V.Position or to exit this menu select EXIT, press the
SELECT button to confirm the required option.
Using the left and right control buttons adjust the image position, in H.Position
mode the left button shifts the image left and the right button shifts the image
right.
In V.Position mode the left button shifts the image DOWN and the right button
shifts the image the image UP.
Display
EXIT
H. POSITION
V. POSITION

12
ENGLISH
Adjusting Colour Properties
zPress the SELECT button to show the OSD menu.
zThe brightness icon will be highlighted (RED)
zPress the SELECT button until the colour icon changes to RED to indicate it is
the active function.
zUsing the left and right control buttons highlight the required option and then
press SELECT button to access the adjustment options.
Note：With the exception of COLOR TEMP all other options can be adjusted to
values between “0” and “100”, with regard to COLOR TEMP this can be changed
between COOL, NEUTRAL or WARM, neutral is the default setting .
All changes made are live and require no additional confirmation.
COLOR
EXIT
COLOR TEMP
LUMINANCE
HUE
COLOR
SHARPNESS
Adjusting Clock/Phase Properties (only available
when connected to a PC)
Press the SELECT button to show the OSD menu
The brightness icon will be highlighted (RED)
Press the SELECT button until the Clock/Phase icon changes to RED to indicate
it is the active function,
Using the left and right control buttons select the required feature from the sub
menu AUTO SETUP, CLOCK or PHASE or to exit this menu select EXIT, press
the SELECT button to confirm the required option.
If AUTO SETUP is selected the Auto setup function will operate for more detail
see later in this manual.
For CLOCK and PHASE options use the left and right control buttons to adjust
the clock and phase values, before this is attempted it is strongly recommended
that Auto Setup is used.

13
ENGLISH
Adjusting Management Preferences
zPress the SELECT button to show the OSD menu.
zThe brightness icon will be highlighted (RED)
zPress the SELECT button until the management icon changes to RED to
indicate it is the active function.
zUsing the left and right control buttons highlight the required option and then
press SELECT button to access the adjustment options.
MANAGEMENT
EXIT
MODE INFO
OSD DISPLAY
SOURCE
RECALL FACTORY SETTING
zThe options available are：
Mode info - displays the horizontal and vertical frequency information – no
adjustment is possible.
OSD Display – Allows the default position of the OSD menu to be changed
using the left and right buttons.
SOURCE – The input source can be selected as either Analogue(PC) or
Video (composite video Set top box , DVD player etc)
RECALL FACTORY SETTINGS – selecting this option resets all adjusted
values back to their default positions as set at the time of first manufacture.
COLOK/PHASE
EXIT
AUTO SETUP
CLOCK
PHASE

14
ENGLISH
Direct Function Access using the Left or Right Buttons
As a short cut to accessing some features the left and right buttons can be used
to call up a shortened menu as follows.
Monitor connected to a PC
Press the left button when the main menu OSD is not on screen this calls up the
Auto setup menu
AUTO SETUP
YES NO
Use the left and right buttons to highlight yes and then press the select button to
activate Auto Setup
Press Select to confirm the image looks correct.
Press the right button when the main menu OSD is not on screen this calls up the
Audio/Video menu.
AUDIO/VIDEO
EXIT
SOURCE
VOLUME
Use the left and right buttons to select the required function and then press the select
button to activate it.
Select EXIT to cancel the menu.
Monitor connected to a Set top box, DVD player or VCR
With the monitor connected to a set top box, DVD player or VCR ONLY the right
button has any function , it’s function being as above.
AUTO SETUP
DOES THIS IMAGE
LOOK CORRECT?
YES NO

15
ENGLISH
Troubleshooting
This chapter contains information about how to troubleshoot your LCD Monitor. If
you have tried all of the items listed below, please contact a qualified service
personnel.
A. My display doesn’t work, even though the computer appears to work.
1. Make sure the power cable is securely plugged into the display.
2. Make sure the display is turned on.
3. Try turning the display off and then turning it on again.
4. Make sure the display’s power cord is plugged into a power outlet and into
the AC power adapter. Check to see whether the outlet works by plugging
another device (such as a lamp) into the outlet. (If the light on the front of
the display is lighted, it is getting power. Try the next item on this
procedure.)
5. Check the cable connection between the display and the computer. The
cable connectors must be pushed in all the way.
B. The message “No Sync” appears on my display.
This message appears when there is no video signal from the computer with
cable already connected.
1. Make sure that the computer's power is turn on.
2. Make sure that your graphic card has its output already.
C. The message “Signal Out of Range” appears on my display.
This message appears when the input signal is beyond the display's
capability.
Set your PC to a supported video mode, preferably 1024 x 768 at 60 Hz. See
“Setting the Video Mode” on page 7.
D. The image is very unstable.
1. Set your PC to a supported video mode, preferably 1024 x 768 at 60 Hz.
See “Setting the Video Mode” on page 7.
2. Restore the original factory settings by choosing Recall Factory Setting
in the OSD “Management” submenu.
3. Perform the Auto Setup function. See “Direct Function Access using the
Left and Right Buttons” on page 15.
Note:Even if your PC’s setting is out of the range of video modes that
are supported by your LCD monitor, it may still be displayed with
reduced quality. This provides you with an opportunity to change
your PC’s setting to a correct one.

16
ENGLISH
Technical Information
This chapter contains technical information about your LCD Monitor.
Display Information
LCD Module 15-in (38.1 cm), active matrix TFT，anti-glare coating, 0.297 mm pixel
pitch
Display Size 304.1 mm x 228.1 mm
Viewing Angle
Left/Right
Up/Down
-70°~ 70°
-60°~ 65°
Luminance 250 cd/m2(Typical)
Contrast Ratio 450：1 (Typical)
Display Colors 16.2Million
Power Input 100 ~ 240 VAC Full Range，50/60 Hz，< 1.2 A @ 110V；< 0.6 A @ 230V
Maximum power
consumption < 35W
Signal Input
Video Signal
Sync signals
Analog：RGB positive 0.7VPP，75Ω
Separate, TTL Level
Video：NTSC/ PAL Composite
Line(horizontal)
frequency
Analog：31.5 kHz ~ 60 kHz
Video：15.625 kHz / 16.734 kHz
Raster(vertical)
frequency
Analog：56 Hz ~ 75 Hz
Video：50Hz / 60 Hz
Pixel dot clock 79 MHz (maximum)
Recommended mode 1024 x 768 @ 60 Hz
Dimensions
(W x H x D) 376 mm x 395.5 mm x 143 mm
Net weight
Grass weight
4.2 kg
6.2 kg
Operating Conditions
Temperature 5°~ 40°C at altitude 0 ~ 2000m；5°~ 30°C at altitude 2000 ~ 3000m
Humidity 20% ~ 85% RH，non-condensing
Altitude 3000m Max.
Storage Conditions
Temperature -20°~ 60°C
Humidity 5% ~ 95% RH
Altitude 10000m Max.

17
ENGLISH
Video Modes
Your LCD monitor supports the following industry-standard combinations of
screen resolution and refresh rates. Other combinations are possible, but may
require adjustments to the image.
For optimum performance, set your PC to a screen resolution of 1024 x 768 at a
60 Hz refresh rate.
Analog：
Supported Resolution
(dots x lines)
Vertical Frequency
(Refresh Rate)
640 x 350 70 Hz
640 x 480 60 Hz
640 x 480 72 Hz
640 x 480 75 Hz
VGA
640 x 350 70 Hz
800 x 600 56 Hz
800 x 600 60 Hz
800 x 600 72 Hz
800 x 600 75 Hz
SVGA
800 x 600 56 Hz
1024 x 768 60 Hz
1024 x 768 70 Hz
1024 x 768 75 Hz
XGA
1024 x 768 60 Hz
US TEXT 720 x 400 70 Hz
832 x 624 75 Hz
Power MAC
640 x 480 67 Hz
Video：
Supported Resolution
(lines x horizontal frequency)
Vertical Frequency
(Refresh Rate)
NTSC M 525 x 15.734 kHz 60 Hz
PAL
B/G/H/I/D/K 625 x 15.625 kHz 50 Hz
Note: The display is capable of going beyond these recommended modes.

18
ENGLISH
Unknown Video Modes
Like all other monitors, the your LCD monitor is designed to work with standard
video modes. However, not all video/graphic cards use only standard display
modes.
Your LCD monitor uses state-of-the-art technology, which is designed to
synchronize to any display mode. We recommend choosing one of the supported
modes listed above. If you choose an unknown mode, you will need to manually
adjust the clock, phase, and image position.
If you must use an unknown mode, you can run Auto Setup at first. If Auto Setup
doesn’t provide adequate image adjustment, then you must manually adjust the
clock, phase, horizontal position, and vertical position.
