Gorenje GV63315UK User manual

GV63315UK

With each wash cycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Turn on the water tap ,close the door . The machine will start working after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unload the appliance, starting from the lower basket.
Changing the programme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the Programme Button until the selected programme lights up.
( See the section entitled Operation instruction )Ā ā
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the On/Off Button.
If the appliance is switched
off during a wash cycle.
Open the doo r carefully.
Hot steam may esc ape
when the door is opened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Open the door,press the On/Off button to switch on the appliance .
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again after 10 seconds.
For detailed operating method read the corresponding content on the instruction manual.
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the for more than 3 seconds to cancel the running programme.
3. Select a new programme.
4. Restart the dishwasher.
Programme Button
A B

To review the section on troubleshooting Tips
will help you to solve some common problems
by yourself .
Dear Customer,
Please carefully read this manual before using the
dishwasher, it will help you t o us e and maintain the
dishwasher properly.
Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions,
Operating Instructions, Installation Instructions and
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
development and updating of the product, may
make modifications without giving prior notice.
Keep it as a refer in the later days.
If you can not solv e the problems by yourself ,
please ask for the help of professional technicians.
This appliance is in tended to be used in household
and similar applications such as:
-staff kitch en areas in shops, offices and other
working environments;
-farm hous es;
-by clients in hotels, motels and othe r residential
type environments;
-bed and breakfast type environments.
Dishwasher Features.................................... ...3
A Water Softener...........................................4ǃ
Attention before or after loading the Dishwasher
Baskets..........................................................9
Filtering System.............................................13
Caring for the Dishwasher.... ................. .........14.
B Loading the Salt into the Softener.................5ǃ
C Fill the Rinse Aid Dispenser.........................5ǃ
D Function of Detergent .................................6 ǃ
Loading the upper .............................. .10Basket
Loading the Lower ............................ ...10Basket
Wash Cycle Table...........................................11
Turning on th e Appliance................................11
Change the Programme.............. ................12....
At the end of the Wash Cycle...........................12
Be fore calling for service........ ................... .....22.
Error codes.................................... ..............23.
Tech nical information... ........................... .....24..
Control Panel................... ............... .................3
.................................. 15Install ation preparation
...16Aesthetic panel's dimensions and installation
..............18Tension adjustment of the door spring
.............................. 18Conne ction of drain hoses
......................... 19Dishwasher installation steps
About Electricity Connecting...........................20
Cold Water Connection.................................. 21

Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren
Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
(This instruction is only applicable to machines
with a visual heating element.)
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only deterge nt and rinse additives
designed for an autom atic dishwasher.
Never use soap, laun dry detergent, or hand
washing detergent in your dishwa sher. Keep
these products out of the reach of children.
During installatio n, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
Do not place any heavy objects the
door when it is open. The appliance could tip
forward.
on or stand on
When loading items to be washed:
1) Locate sharp items so that they are not likely
to damage the door seal;
2 Warning: Knives and other utensils with
sharp points must be loade d in the basket
with their points down or placed in a
horizontal position.
)
When using your dishwasher, you should
prevent plastic items from coming into contact
with the heating element.(This instruction is only
applicabl e to machines with a visual heating
element. )
If the s upply cord i s damaged, it must be replaced
by the man ufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Dishwasher detergents are strongly alkaline, they
can be extremely dangerous if swallowed. Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent compartment is empty
after completion of th e wash cycle.
The appliance is to be connected to the water
mains using new hose sets and that old hose-sets
should not be reused.
The maximum number of place settings to be
washed is 14.
The maximum permissible inlet water pressure is
1Mpa.
The minimum permissible inlet water pressure is
0.04Mpa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
)
When using your dishwasher, follow the precautions listed below:
The door should not be left open,
since this could increase the risk of tripping.
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce
the risk of anelectric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
earthing conductor and a plug.
The plug must be plugged into an appropriate outlet
that is installed and earthed in accordance with
all local codes and ordinances.
earthing
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly earthed. Do not modify the
plug provided with the appliance; If it does not fit
the outlet. Have a proper outlet installed by a
qualified electrician.

Dispose of the dishwasher packaging material correctly.
All packaging materials can be recycled.
Plastic parts are marked with the standard international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polysty rene, e.g. padding material
POM po lyoxymethylene, e.g. pla stic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control Panel .
Packaging material could be dangerous for children!
Fo r disposing of package and the a ppliance ple ase go to a recycling cen tre. Therefore cut
off the pow er s upply cable and make the door closing device unusable.
Cardboard packaging is manufactured from recycled paper and should be disposed in the
waste paper collection for recycling .
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriate waste han dling of this prod uct.
For more detailed information about rec ycling of this product, please contact your local
city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.






before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
11 12
Back View
1
2
3
4
5
7
8
910
Front view
Lower basket
Salt container
Dispenser
Cup shelf
Spray arms
Filter assembly
Inlet pipe conne ctor
Drain pipe
Upper basket
Cutlery rack
Top spray arm
1
Inner pipe
5
6
7
8
9
10
12
11
3
2
4
6
13
Adjuster
13
2.Extra drying function choose Button: To choose
Extra drying function
Note: only intensive,normal,ECO,glass, 1hour
programs have extra drying function
3. Alt Button: Dual zone wash function, Press the
button to select either upp er basket or lower basket
loaded.
4.Delay Button : To press the button to delay.
5.Program Button : To press the butt on to select a
wash Program.
6.On/off Button:
and the response indicator will light.
5P UVSO POPGG UIF QPXFS TVQQMZ
1. Display screen: to show the error code,delay time etc.
Program indicators:
Delay time or error codes in dicator:
Alt functions indicator:
Rinse Aid indicator:
Indicates when the dispenser needs to be refilled.
Ad d salt indicator:
Indicates when the dispenser needs to be refilled.
Extra dryin g indicators:

The water softener must be set manually, using the water hardness dial.
The wat er softener is designed to remove minerals and salts from the water, which would have
a detrimental or adverse effect on the operation of the appliance.
The higher the content of these minerals and salts, the harder your water is.
The softener should be adjusted according to the hard ness of the water in your area. Your local Water Authority
can advise you on the hardness o f the water in your area.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of salt co nsumed based on the ha rdness of
the water used. This is intended to optimise and customise the level of salt consumption.
1. Open the door ,Switch on the appliance;
2. Press the Program button for more than 5 seconds to start the water softener
set model within 60seconds after the a ppliance was switched on( The Salt and
Rinse aid warning lights will be on periodically when it g et in the set model );
3. Press the Program button to select the proper set according to your local environment,
the sets will change in the follo wing sequence: H1->H2->H3->H4->H5->H6;
4. Press the Power button to end the set up model.
WATER SOFTENER
The hardness of the water varies from place to plac e. If hard water is used in the dishwasher, deposits will
form on the dish es and utensils.
The applian ce is equipped with a special softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardness of your water supply.
Please follo w the steps below for adjustment in salt consumption.
If your model does not have any water softener, you may skip this section.
Clark: British degree
fH: French degree
dH: German degree
dH=1.25 Clarke=1.78 fH=0.178mmol/l
1
The manufactory setting: H4 (EN 50242)
dH mmol/l
0~90~5 0~0 .94 H1 0
10-20
6-11 1.0-2.0 H2 9
21-30
12-17 2.1-3.0
H3
12
H4 20
fH
0~6
7-14
15-21
Clarke
WATER HARDNESS
Selector Position Sa lt consumption
(gram/cycle)
18-22 31-40 22-28 3.1-4.0
41-60
23-34 4.1-6.0 H5 3 0
H6 60
29-42
35-55 61-98 43-69 6.1-9.8
Before using your dishwasher for the first time:
A. Set the water softener
B. Add 1.5Kg dishwasher salt and then full fill the salt con tainer with water
C. Fill the rinse aid dispenser
D. Fill in detergent

1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves, the salt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (for some Mode ls),you can estimate when to fill
the salt into the softener by the cycles that the dishwasher has run.
2. If there are spills of the salt, a soak or a rapid program should be run to remove the excessive sa lt.
Always use the salt intended for use with dishwasher.
The salt container is located beneath the lower basket and should be filled as explained
in the following:
Attention!
Only use salt specifically desi gne d for the use in dishwashers! Every other type of
salt not speci fically designed for the use in a dishwasher, espe cially table salt, will
damage the water softener. In case of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is liable for any damages caused.
Only fill wi th salt just b efore starting one of the co mp let e washing programs.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any period of time, which may cause
corrosion.
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can
leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is
designed to use liquid rins e aids. The rinse aid dispenser is located inside the door next to the detergent dispense r.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume of the rinse aid container is about 110ml.
Rinse Aid Dispenser
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spo t and streak free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the app liance.
Fu ll fill the salt container with wa ter,It is normal for a small amount of water to come out of the
salt container.
AAfter the lower basket has been removed, unscrew and remove the cap from the salt container.
B Pl ace the end of the funnel (supplied) into the hole and introduce about 1.5kg of dishwasher salt.
C
DAfter filling the container , screw the cap tightly back clockwise.
EThe salt warning light will stop being after the sa lt contain er has been filled with sa lt.
FImmediately after filling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pump or other important parts of the machine may be damaged
by salty water. This is out of warranty.
(We su ggest to use a short
).

To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid int o the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow.
Adjusting Rinse Aid Dispenser
Th e rinse aid dispenser has six or four settings. Always start with the dispenser
set on "4". If spots and poor drying are a p roblem, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properly or are show spots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory value is "4".)
Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish stains on your dishes o r a bluish film on glassware or
knife blades.
1
2
3
As the rinse aid diminishes, the size o f the black dot
on the rinse aid level indicator changes, as illustra ted b elow.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
When to Refill the Rinse Aid Dispenser
If th ere is no rinse-aid warning light in the control panel, you can estimate the amount from the colour
of the optical level indicator C located next to the cap. When th e rinse-aid container is full, the whole
indicator will be dark .As the rinse -aid diminishes, the size of the dark dot decreases. You should never let
the rinse aid leve l fall 1 / 4 full.
during the next wash. Don't forget to re place the cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt an d transport it out of the di shwasher.
Most of the commercial qu ality detergents are suitable for this purpose.
 
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdered detergent into the dispenser u ntil you're re ady to wash dishes.
Attention!

Amount of Detergent to Use
Dishwasher detergent is corrosive! Take care to keep it out of reach of children.
Based on their chemical composition, detergents can be split in two basic types:
Detergent tablets of diffe rent brands dissolve at di fferent speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programs. Therefore please use long programs when using deterg ent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the w ash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always ad d the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
co nventional, alkaline detergents with caus tic comp onents
low alkaline co ncentrated detergents with n atural enzymes
Normally new pulverised detergent is with out phosphate. Thus the water softener fu nction of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If dete rgents witho ut phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case pl ease add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.

Detergents
There are 3 sorts of detergents
1.With phosphate and with ch lorine
2.With phosphate and without chlorine
3.Withou t phosphate and without chlorine
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will sp ring open.

Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrate d on the righ t:
The place of main wash cycle detergent placed.
The place of pre-wash cycle detergent placed.
Please o bserve the manufacturers dosing and storage
Recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an a dditional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
A
B
Fill in Detergent
You find information about the amo unt of detergent for the single programme on the last page .
Please aware, tha t according to the level soiling and the specific hardness of water d ifferences are possible.
Please observe th e manufacturer's rec ommendations on the detergent packaging.
AB

Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery ite ms or dishes
Pewter or copper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types of glasses can become
dull after a large number of washes
Silver and aluminum parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Dishes and items of cutlery must not lie ins ide one another, or cover each other.
To avoid damage to glasses, th ey must not touc h.
Load large ite ms which are most difficult to clea n into the lower bask et.
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items o f cutlery such as carving kniv es must be positioned
horizontally in the upper b asket.
Please do not overload yo ur dishwasher. T his is important for good results and for
reasonable consumption of energy.
Load hollow items suc h as cup s, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep b ase.
Consider buying utensils which are identified as dishwasher-proof.
Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further
information from the detergent manufacturers.
For particular items, select a program with as low a temperature as possible.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the programme h as ended.
(For best performance of the dishwasher, follow these loading guide lines.
Features and appearance of baskets and cutlery baskets may vary from your model.)
Scrape off any larg e amounts of leftover food. Soften remnants of burnt food in pans.
It is not necess ary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots /pans, etc. a re faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.

The u pper basket is designed to hold more delicate
and lighter dishware such as glasses, coffee and
tea cups and saucers, as well as plates, small bowls
and shallow pans (as l ong as they are not too dirty).
Position the dishes and co okware so that they will
not get moved by the spray of water.
We suggest that you place large items and the most
difficult to clea n items are to be placed into the lower
basket: such as pots, pans, lids, se rving dishes and
bowls, as shown in the figure below. It is preferable to
place serving dishes and lids on the side of the racks
in order to avoid blocking the ro tation of the top spray
arm.
Pots, serving bowls, etc, must always be placed top down.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Botto m Basket features folding spikes so that larger or more pots and pans can be loaded.
Folding Spikes of Lower Basket
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Folding back the cup shelives
Fo r better stacking of pots and pans,
the spikes can b e folded down as
sho w in the picture right.
Cutlery should be pla ced in the cutlery rack separately
from each other in th e ap propriate positions, and do
make sure th e utensils do not nest together, this may
cause bad performance.
Adjusting the Upper Basket
The h eight of the upper ba sket can be adjusted in order to
create more space for larg e utensils both for the upper
/lower basket. The height of the upper basket can be
adjusted by l ift up the basket for the upper position , and up
press the handle to lower the upper basket, see the picture
below:

*EN 50242 : This programme is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 14 setting
Position Upper basket: upper wheels o n rails
Rinse aid setting: 6
Pl:0.49w; Po:0.45 w.
Starting a cycle wash
1 Draw out the lower and upper b asket, load the dishes and pu sh them back.
It is co mmended to load the lower basket first, then the upper one (see the section entitled
Loading the Dishwasher ).
2 Pour in the detergent (see the section e ntitle d Salt, Detergent and Rinse Aid ).
3 Insert the plug into the socket. The power su pply is 220-240 VAC /50 HZ, the specification
of the socket is 10A 25 0VAC. Make sure that the wa ter supply is turn ed on to full pressure.
4 Open the door, press the ON/OFF Button.
5 Press the prog ram Button , the wash program will be changed as follows dire ction:
Auto
If a program is selected, the response light will light. Then clo se the door, the dishwasher
begins to start.
Ā ā
Ā ā
Means: need to fill rinse into the Rinse-Aid Dispenser.
( )
Normal
Rapid
Glass
5/30g
5/30g
5/30g
For normally soiled loads,
such as pots plates
glasses and lightly
soiled pans.
ǃ ǃ
For heaviest soiled crockery,
and normally soiled pots
pans dishes etc with dried
on soiling.
᱃
᱃
A shorter wash for lightly
soiled loads and quick
wash.
Pre-wash(50 )
Wash (65 )
Rinse
Rinse
Rinse(65 )
Drying
ć
ć
ć
Pre-wash(45 )
Wash (55 )
Rinse
Rinse (65 )
Drying
ć
ć
ć
Pre-wash
Wash (50 )
Rinse(65 )
Drying
ć
ć
Wash (40 )
Rinse
Rinse (45 )
ć
ć
185
175
175
40
1.3
0.93
1.6
0.6
17
14
10
10
(50 )
Wash(60 )
Rinse (60 )
Drying
Pre-wash
ć
ć
ć
60 101.15
5/30g
30g
For lightly soiled loads that
do not need excellent
drying efficiency.
To rinse dishes that you plan
to wash later that day.
Pre-wash
8 0.01 4
5/30g
For lightly soiled cr ockery
and glass.
115 0.87 14
Pre-wash
Wash (40 )
Rinse
Rinse(60 )
Drying
ć
ć
8.4~1 2.70.9~1.3 150
5/30g
Pre-wash (45 )
Autowash(45-55 )
Rinse
Rinse(62 )
Drying
ć
ć
ć
Auto sensing wash, lightly,
normally or heavily soiled
crockery, with or with out
dried-on food
Intensive
1Hour
Soak
ECO
( *E N 502 42)
This is standard programme, it is
suitable to clean normally soiled
tableware and it i s the most efficient
programme in terms of its combined
ener gy and water consumption for
that type of tableware.

When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off the water supp ly and open the door of the dishwasher.
Wait for a few minutes before unlo ading th e dishwasher to avoid handlin g the dishes and utensils while they
are still hot and more susceptible to breakage. The y will also dry better.
Switch Off the Dishwasher
The program light is off, only in this case the programme has ended.
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turn off the water tap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloading the dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
If you open the door , the machine will pause.
the buzzer will mooing every minute unless you close the door . After
you close the door ,the machine will keep on working after 10 seconds.
dur ing a wash cycle
Premise:
A cycle that is underway can on ly be modified if it has only been running for a short time. Otherwise, the
detergent may have already been released, and the appliance may have already drained the wash water.
If this is the case , the detergent dispenser must be refilled (see the section entitled " Loading the
Detergent " ).
Open the door ,press the Program button , the machine will be in standby state,
then yo u can change the program to the desired cycle setting (see the section entitled " Starting a
wash cycle. . ." ).
more than 3 seconds
1
2
A forgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Open the door a little .
14
5
The dishwasher will run after 10 seconds.
Wash the arms in soapy and warm water and u se a soft brush to
clean the jets. Replace them after rinsing them thoroughly.
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.
It is dangero us to open the do or when washing, because the hot water may scald you.

The filter prevents larger remnants of food or other objects from getting inside the pump.
The residues may block the filter, in this case they must be removed .
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilter(Fine filter).
Fo od and soil particles trap ped in this filter are pulverized by a
special jet on the lower spray arm and washed down to drain.
La rger items, such as pieces of bones o r glass, that could block
the drain are trapped in the coarse filter. To remove the items
caught by the filter, gently squeeze the tap on th e top of this
filter and lift out.
This filter holds soil and food residues in the sump a rea and
prevents it from being deposited on the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filter assembly
The filter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it is a good idea to
remove the larger food particl es trapped in the filter aft er each was h cycle by rinsing the semicircular filter and
cup under running water. To remove the fil ter device, pull the cup handle in the upward d irection.
removes f ood particle s from the wa sh water, allowing it to be rec ycled during the cycl e.
For
The d ishwash er must never b e used without the filters.
Improper replacement of the filter may reduce the performance level of the appliance
and dama ge dishes and utensils.
1
2
Step 1 Turn the filter in anti-clockwise direction,˖
Step 2 lift the filter assy up˖
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Protect Against Freezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottom of the tub and use a sponge to soak up water in the sump.
please take frost protection measures on the dishwasher in winter. Every fter washing cycles,
please operate as follows
time a
˖
Cleaning the Filter
Cleaning The Door
To clean the coarse filter and the fine filter, use a cleaning brush. R eassemb le the filter parts as show n in the figures
on the last page and reinsert the entire assembly in the dis hwa sher, positioning it in its seat and pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted and the performance of the dishwasher could be decreased.
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid pene tration of wa ter into the door lock and electrical components, do not
use a spray cleaner of any kind.
Never use a spray cleaner to clean the door panel as it may damage the door lock
and electrical components.
Abrasive agents or some paper towels should not be used becau se of the risk of
scratching or leaving spots on the stainless steel surface.
Cleaning the Spray Arms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms re gularly fo r hard
wate r chemicals will clog the sp ray arm jets a nd bearings.
- Inspect the filters for blocking a fter every time the dishwa sher has been used.
- By unscrewing the coar se fi lter, you can remove the filter system. Remove any foo d remna nts and
clean the filters under running water.
Remarks:
The entire filter assembly should be cleaned once a week.
To remove the lower spray arm, pull out the spray arm u pwa rd.
To remove the upper spray arm, hold the nut, rotate the arm
clockwise to remove i t.
Wash the arms in soapy and warm water and use a soft brush to
clean the jets. Replace them after rinsing them thoroughly.

It is recommend that you run a was h cycle with the
dishwasher empty an d then remove the plug from the
socket, turn off the water supp ly and leave the door of
the appliance slightly open. This will help the d oor
seals to last longer and prevent odours from forming
within the appliance.
If the appliance must be moved, try to keep it in the
vertical position. If absolutely necessary, it can be
positioned on its back.
One of the factors that cause odours to form in the
dishwasher is food th at remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
Before cleaning or performing maintenance, always
remove the plug from the socket.
To clean the exterior a nd rubber parts of the dishwasher,
do not use solvents or abrasive cle ani ng products.
Only use a clo th with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth da mpened wit h water an a little
vinegar, o r a cleaning pro duct made specifical ly for
dishwashers.
Remove the Plug
No Solvents or Abrasive Cleaning
Moving the Appliance
Seals
After every wash, turn off the water supply to the
appliance and leave the door slightly open so that
moisture and odours are not tra pped inside.
After Every Wash
When not in Use for a LongTime
The installation of the pipes
and electrical equipments
should be done by professionals.
Electrical Shock Hazard
Disconnect electrical power before
installing dishwasher.
Failure to do so can result in death or
electrical shock.
The installation position of dishwasher should be near the existing inlet and drain hoses and
power cord.
One side of the cabinet sink should be chosen to facilitate the connection of drain hoses of
the dishwasher.
Installation preparation
Note: please check the accompanying installation accessories(hook for aesthetic panel,
screw)
ƽ

Please carefully read the installation instruction.
ʎ Illustrations of cabine t dimensions and installation position of the dishwasher
Preparations should be made before moving the dishwasher to the installation place.
Choose a place near the sink to facilitate the installation of inlet and drain hoses
(see figure 1).
If dishwasher is installed at the corner of the cabinet, there should be some space
(illustrated in figure 2) when the door is opened.
2
1
16
Minimum space when
the door is opened
ʧ ʨFigure2
Cabinet dimensions
ʧ ʨFigure1
Cabinet
Dishwasher
Do or of
dishwashe r
Minimum space of 50mm
1 The aesthetic wooden panel could be processed according to the Figure 3.
The aesthetic panel should
be processed in accordance
with the illustrated dimensions
ʧ ʨFigure3
ʎAesthetic panel's dimensions and installation
Less than 5mm
between the top
of dishwasher and
cabinet and the
outer door aligned
to cabinet.
90 
90 
600 mm
820mm
100
580mm
80
Space between cabinet
bottom and floor
Electrical, drain and
water supply line
entrances
(Unit: mm)

*OTUBMMBUJPO PG BFTUIFUJD QBOFM
ʧ'JHVSFBʨ
 *OTUBMM UIF IPPL PO UIF BFTUIFUJD XPPEFO QBOFM BOE QVU UIF IPPL JOUP UIF TMPU PG UIF PVUFS EPPS PG
EJTIXBTIFSTFF GJHVSF B "GUFS QPTJUJPOJOH PG UIF QBOFM  GJY UIF QBOFM POUP UIF PVUFS EPPS CZ
TDSFXT BOE CPMUT4FF GJHVSF C 
*OTUBMMBUJPO PG BFTUIFUJD
XPPEFO QBOFM
ʧ'JHVSFCʨ
 UBLF BXBZ UIF GPVS
TIPSU TDSFXT
 QJO VQ UIF GPVS MPOH
TDSFXT



