GOsingGO GS-TS001 User manual

User’s Guide
Please read this user’s guide before using your new
tower speaker.
GS-TS001
TOWER SPEAKER

Package Contents
󼰥Tower speaker 󼰥 AC Adapter
󼰥 RCA Cable 󼰥 Remote Control
󼰥 Pedestad 󼰥 User's Guide
LINE-IN Cable Screws
Features
Provides powerful sound to enhance your listening
experience
Easy to connect to your devices
Remote for convenient controlling from a distance
Note: The power source must supply 16V DC .
Its center tip must be set to positiveand its plug must
fit the DC IN jack. Using an adapter that does not meet
these specifi cations could damage the tower speaker
or adapter.
Important Safety Instructions
1. Read these instructions. Keep these instructions.
2. Heed all warnings.
3. Follow all instructions.
4. Do not use this tower speaker near water.
5. Clean only with dry cloth.
6. Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
7. Do not install near any heat sources such as
radiators,heat registers,stoves,or other apparatus
(including amplifi ers) that produce heat.
8. Use only attachments/accessories specified by the
manufacturer.
2

Protect the power cord from being walked on or
pinched, particularly at plugs, convenience
receptacles,and the point where they exit the tower
speaker.
Unplug this during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the has
been damaged in any way, such as if the power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the
, it has been exposed to rain or moisture, it
does not operate normally, or it has been dropped.
To reduce the risk of electric shock, do not remove
cover(or back). There are no user - serviceable
parts inside.
Do not expose the to dripping or
splashing liquids. Do not place objects filled with
liquids (such as water-cup or glass) on the
.
The mains plug is used as the disconnect device.
It shall remain readily operable and should not be
obstructed during intended use. To completely
disconnect the from supply mains,
the main plug of the product shall be disconnected
from the mains socket outlet completely.
Using the near fluorescent lighting
may cause interference with the remote. If the
is behaving erratically, move away
tower speaker
tower speaker
tower
speaker
tower speaker
tower
speaker
tower speaker
tower speaker
tower speaker
Warnings and Precautions
9.
10.
11.
3

Connections
4
Display
POWER/MODE
Power On/Off
MODE(Bluetooth,Usb,
FM Radio,AUX In)
PRV Song
Next Song
Play/Pause
POWER
V-/+

5
Mic SD card port
LINE IN
(For TV Sets,DVD,
Computer,Mobile
Phone and so on)
USB port
FM Radio
AUX IN
Use the supplied RCA cable
to connet to the audio output
jacks on your device(TV,DVD,
game system,ect.).
DC IN
Connect the AC adapter
to the DC IN jack,then
plug it into a wall outlet.
Mobile phone
charging socket

Installing the pedestal to the Tower
Speaker
For installing the pedestal to the tower speaker,you
may need twist drill,several screws(supplied).
1.Place the pedestad under the tower speaker.Make
sure the holes of tower speaker is exact to match the
holes of the pedestal.
2.Install the screws on the punched holes already in
the tower speaker.
Using the
After you connect the AC adapter, the tower speaker
enters standby mode.
1. Turn on your device and turn down its volume.
2. The tower speaker enters to "BLUETOOTH" mode.
3. Press LINE or AUX or mp3(MIC-SD/USB)on the
remote mode to switch to LINE or AUX mode or BT
mode or mp3 mode(MIC-SD/USB).
4. After starting playback on your device, adjust the
device and tower speaker volume to a comfortable
level.
Note:
󼯀 The tower speaker enters standby mode if you pause
it for more than 15 minutes.
Tower speaker
6

7
Instructions of Remote
MUTE :Mute Control KEY
BT: Bluetooth Control Key
POWER:Standby
MP3:USB &SD Control key
Next song
MOVIE:Sound Mode
Control for movie
BASS+
VOICE:Sound Mode
Control for Music
AUX:AUX In control
FM:FM Radio Control
CH+:FM Channel Key
of upward searching
CH-:FM Channel Key
of downward searching
VOLUME+
TREBLE- VOLUME-
BASS-
TREBLE+
PRE song
Play/Pause for Mp3 playing
Auto memory for FM Radio
MUSIC:Sound Mode
Control for music

1 h 2
Specifications
Power Input DC 16V
Output (RMS) 18w×2+30w
Frequency Response 60-20k(Hz)
Speaker Units 5.25"subwoofer+3"Mid-Tweeter×4
Audio Input aux in/line in/usb/mic sd
/bluetoot
Other Functions FM Radio/Power charge for cell
phone
Specifications are subject to change and improvement
without notice. Actual product may vary from the images
found in this document.
8
Troubleshooting
Problem Solution
No sound
Make sure the AC adapter is plugged
into a working outlet and firmly
connected to the tower speaker.
Check the connection of your device to
the tower speaker.
Distorted
sound
Check your source device to see if it is
causing the distortion. Set the device and
volume to a low level.tower speaker
Unbalanced
sound
If the volume remains low even when
the ’s volume is turned
all the way up, check the source device
to make sure it is connected via a
variable output. Make sure the output
is not turned down too low.
tower speaker
v2.1

9
Limited Warranty
Gosinggo warrants this product against defects in
materials and workmanship under normal use by the
original purchaser for one(1) year after the date of
purchase. GOSINGGO MAKES NO OTHER EXPRESS
WARRANTIES.This warranty does not cover: (a)
damage or failure caused by or attributable to abuse,
failure to follow instructions, improper installation or
maintenance, alteration, accident, Acts of God (such
as floods or lightning), or excess voltage or current; (b)
improper or incorrectly performed repairs by persons
who are not a Gosinggo Authorized Service Facility;
(c) consumables such as fuses or batteries;(d)
ordinary wear and tear or cosmetic damage; (e)
transportation, shipping or insurance costs;(f) costs of
product removal, installation, set-up service,
adjustment or reinstallation; and (g) claims by persons
other than the original purchaser.
Should a problem occur that is covered by this
warranty,take the product and the sales receipt as
proof of purchase date to the place of purchase.
Gosinggo will, at its option, unless otherwise provided
by law: (a) repair the product without charge for parts
and labor; (b) replace the product with the same or a
comparable product; or (c) refund the purchase price.
All replaced parts and products, and products on
which a refund is made, become the property of
Gosinggo.
New or reconditioned parts and products may be used
in the performance of warranty service. You will be
charged for repair or replacement of the product made
after the expiration of the warranty period.

10
GOSINGGO EXPRESSLY DISCLAIMS ALL WARRANTIES
AND CONDITIONS NOT STATED IN THIS LIMITED
WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE
IMPOSED BY LAW, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY AND, IF
APPLICABLE, THE IMPLIED WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE, SHALL EXPIRE ON THE
EXPIRATION OF THE STATED WARRANTY PERIOD.
EXCEPT AS DESCRIBED ABOVE, GOSINGGO SHALL
HAVE NO LIABILITY OR RESPONSIBILITY TO THE
PURCHASER OF THE PRODUCT OR ANY OTHER
PERSON OR ENTITY WITH RESPECT TO ANY
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR
INDIRECTLY BY USE OR PERFORMANCE OF THE
PRODUCT OR ARISING OUT OF ANY BREACH OF THIS
WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY
DAMAGES RESULTING FROM INCONVENIENCE AND
ANY LOSS OF TIME, DATA, PROPERTY, REVENUE, OR
PROFIT AND ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES, EVEN IF GOSINGGO
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
Some states do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of
incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also
have other rights which vary from state to state. You may
contact Gosinggo:
Gosinggo,
1 of 3/F(NO.50 Chengnan 4th Road,Soutn District),No.3
Factory,Yuanshangzai Industrial Zone, the side of NO.105
Nationl Road,Hengmei Village,South District,Zhongshan
City
For product support, call
0086-760-88858903

Federal Communications Commission (FCC) Interference
Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generate, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment.
RF exposure warning
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment.
This equipment must not be collocated or operating in conjunction with
any other antenna or transmitter.
