Gpacers Poseidon Operating instructions

Usage Mode
■Transmitter mode
–Carried by individual
–By hand or independently floating on the water.
–Transmits data to a receiver : ID, status, coordinates.
■Receiver mode
–Fixed at a higher altitude on the vessel or on the
shore.
–Transmits the received data mobile device via Wi-Fi.
■Repeater mode
–Placed at a higher altitude or in a drone
–to overcome communication obstacles of various
terrain features

3
TX RX

4
200 km
70 km 10 km
RX
RX
RX
TX
Altitude 300 m
Amazing performance even when used in the simplest way

200 km
200 km
TX
TX RX
RP
Extend the tracking range to hundreds of km
•Private satellite-like
safety surveillance
systems can be easily
established with repeater
mode.
•Long range searching capability
is extremely important in rescue
missions

Outer waterproof housing
To protect internal circuits
Transparent waterproof
housing
To protect internal circuits
Inner housing
To protect internal circuits
and battery
LED : Light indicator
OLED : Display
Bottom nut : 1/4-inch
nut for mounting
L _sw
LED indicator switch
R_sw
Switch ON to set to
Receiver mode
T_sw
Switch ON to set to
Transmitter mode
!_sw
Activate DISTRESS
Function in Transmitter
mode
C_sw
Activate Call Function in
Transmitter mode
GPT
Appearance

Before Use 1
Check the
Batteries
•Check the
batteries of the
transmitter,
receiver, and
mobile device.
•Use a wireless
charger
2
Set the receiver
•Open receiver
mode, fixed at a
higher altitude.
•For very long
distance search
and rescue, you
can set the
repeater, fixed at a
higher altitude or
attached to a drone.
3
Check the System
•Turn on the
transmitter
•Enable Wi-Fi
connection for
receiver/mobile
device
•Open GPT App on
mobile device
•Select the relevant
transmitter for the
members on the
App

Receiver Transmitter
Usage
Mode
Setting

Distress Call(Show Location)
Functions
of
Transmitter

Repeater Mode
–placed at a higher altitude or attached to a drone
to overcome communication obstacles of various
terrain features.
–the receiver can be placed on the ground or at
any location where relay signals can be received.
–This application is similar to a satellite system.
–The repeater is similar to a surveillance satellite.
–The receiver connects to the App installed on a
mobile device, similar to a ground station.

Startup
Hard reset
Note :
[1] GPT will standby for 30 minutes then shutdown
[2] After a DISTRESS function is triggered only
swapping between DISTRESS and DISTRESS
TERMINATING is allowed.
–Once the rescued is complete, the system will
automatically issue a 60-minutes rescue
termination notification to end the search.
–During the entire Distress function period, all
other function switching actions are invalid.
Deactivation:
Set all switches to OFF

Please refer to : Gpacers GPT App User's Manual
1. Wi-Fi connection :
Mobile device/Receiver
2. Open GPT App
3. Select members
on the App

When there’s no power supply,
you can use a power bank.

A
1
7
6
%
C
u
r
9
3
2
m
A
T
e
m
p
3
7
C
Charging Current
System Temperature
Model
Battery Level
Charging Display
Battery level increment cyclic display
until full charged ➔stable

OLED
display

Receiver Mode
icon -1
Transceiver Status
icon -2
Battery Level
icon -3
GPS/SOS
icon -4
Wi-Fi
ID, latitude, longitude

Repeater Mode
icon-1
Transceiver Status
icon -2
Battery Level
icon -3
GPS(disable)
icon -4
RF
ID, Model

Transmitter Mode
icon-1
Transceiver Status
icon -2
Battery Level
icon -3
GPS
icon -4
RF
ID, latitude, longitude

Transceiver Status Icon Usage Mode
Sleep Status All
Standby Status All
Call Status Transmitter
Distress Status Transmitter
Distress terminating Status
Transmitter
Unknown Status Transmitter
Receiver Status Receiver
Repeater Status Repeater
!
!
?
Icon-1
Transceiver
Status

Switch
L_
sw
An independent switch not related to transceiver function control or display
R_
sw
OFF OFF ON OFF OFF OFF
any
ON
Other
Combination
s
T_
sw
OFF OFF OFF ON ON ON ON
!_sw
ON OFF any OFF OFF ON OFF
C_
sw
ON OFF any OFF ON OFF OFF
icon
OLED NA
App NA NA NA
Description Hard
reset
Standby
➔
Shut
down[1]
Receiver TX_
Unknown
TX_
Call
[2]
TX_
Distress
TX_
Distress_
Terminating
[3]
Repeater TX_
Unknown
Other Status Other Status
!
!
Switches and corresponding transceiver status
