GPX BI108P User manual

INSTRUCTION MANUAL
BI108B
BI108P
Contents
Warnings and Precautions.................................................... 2
Important Safety Instructions .............................................3-4
In the Box & Features .......................................................... 4
Powering the Unit & Battery Information................................. 5
Docking an iPod & Playing a docked iPod shufe or iPod .....6-7
Tuning the AM/FM Radio.................................................. 8
Using the Auxiliary Input....................................................... 9
Locations of Controls& Control Denitions....................... 10-11
Service Information............................................................ 12

This symbol, located on back or bottom
of the unit, is intended to alert the user to
the presence of uninsulated “dangerous
voltage” within the product’s enclosure
that may be of sufcient magnitude to
constitute a risk of electric shock to
persons.
This symbol, located on back or bottom
of the unit, is intended to alert the user
to the presence of important operating
and maintenance (servicing) instructions
in the literature accompanying the
appliance.
CAUTION: TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY
INSERT.
To reduce the risk of electric shock, do
not remove cover (or back). There are
no user-serviceable parts inside. Please
refer any servicing to qualied service
personnel.
WARNING: Changes or modications
to this unit not expressly approved by the
party responsible for compliance could
void the user’s authority to operate the
equipment.
NOTE: This equipment has been
tested and found to comply with the
limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and
can radiate radio frequency energy and,
if not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio
or television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Warnings and Precautions
TO PREVENT FIRE OR SHOCK HAZARDS,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
32

• The apparatus shall not be exposed to dripping or
splashing and that no objects lled with liquids, such as
vases, shall be placed on apparatus.
• Main plug is used as disconnect device and it should
remain readily operable during intended use. In order
to disconnect the apparatus from the mains completely,
the mains plug should be disconnected form the mains
socket outlet completely.
• Battery shall not be exposed to excessive heat such as
sunshine, re or the like.
• Excessive sound pressure from earphones and
headphone can cause hearing loss.
1. Read Instructions - All the safety and operating
instruction should be read before the product is
operated.
2. Retain Instructions - The safety and operating
instruction should be retained for future reference.
3. Heed Warnings - All warning on the product and in
the operating instructions should be adhered to.
4. Follow instructions - All operating and use
instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners or aerosol
cleaners. Clean only with dry cloth.
6. Attachments - Do not use attachments not
recommended by the product manufacturer as they may
cause hazards.
7. Water and Moisture - Do not use this product near
water - for example, near a bath tub, wash bowl, kitchen
sink, or laundry tub; in a wet basement, or near a
swimming pool, and the like.
8. Accessories - Do not place this product on an
unstable cart, stand tripod, bracket, or table. The product
may fall, causing serious injury to a child or adult, and
serious damage to the product. Use only with a cart,
stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting
of the product should follow the manufacturer’s
instructions, and should use a mounting accessory
recommended by the manufacturer.
9. A product and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart combination
to overturn.
10. Ventilation - Slots and openings in the cabinet are
provided for ventilation and to ensure reliable operation
of the product and to protect it from overheating,
and these openings must not be blocked or covered.
The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instruction
have been adhered to.
11. Power Sources - This product should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or
local power company. For products intended to operate
from battery power, or other sources, refer to the
operating instruction.
12. Grounding or Polarization - This product may be
equipped with a polarized alternating-current line plug
(a plug having one blade wider than the other). This
plug will t into the power outlet only one way. This is
a safety feature. If you are unable to insert the plug fully
into the outlet, try reversing the plug. If the plug should
still fail to t, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the
polarizes plug.
Alternate Warnings - This product is equipped with
a three-wire grounding-type plug, a plug having a
third (grounding) pin. This plug will only t into a
grounding-type power outlet. This is a safety feature. If
you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
13. Power-Cord Protection - Power supply cords should
be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience
receptacles, and point where they exit from the product.
14. Protective Attachment Plug - The product is
equipped with an attachment plug having overload
protection. This is a safety feature. See Instruction
Manual for replacement or resetting of protective
device. If replacement of the plug is required, be
sure the service technician has used a replacement
plug specied by the manufacturer that has the same
overload protection as the original plug.
15. Outdoor Antenna Grounding - If an outside antenna
is connected to the receiver, be sure the antenna system
is grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of
the National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast
and supporting structure, grounding of the mast and
supporting structure, grounding of the lead-in wire to an
antenna-discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the
grounding electrode.
See gure:
16. Lightning - For added protection for this product
during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system.
This will prevent damage to the product due to lightning
and power-line surges.
17. Power Lines - An outside antenna system should
not be located in the vicinity of overhead power lines
or other electric light or power circuits, or where it can
fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken
to keep from touching such power lines or circuits as
contact with them might be fatal.
18. Overloading - Do not overload wall outlets,
extension cords, or integral convenience receptacles as
this can result in a risk of re or electric shock.
19. Object and Liquid Entry - Never push objects of any
kind into this product through openings as they may
touch dangerous voltage points or short-out parts that
could result in a re or electric shock. Never spill liquid
of any kind on the product.
20. Servicing - Do not attempt to service this product
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualied service personnel.
Important Safety Instructions
32

5
In the Box
• BI108
• iPod Shufe Dock Cover
• AC Power Cable
• Documentation
• Docking Station for iPod
• Certied iPod Connector installed
for iPod docking
• Recharge Circuit for iPod/mini/
nano/photo/video
• Controls connected iPod players
• Direct Tuning AM/FM Radio
• Built-In Speakers with metal
speaker grill
• Line-In Jack for other Audio
Players, 3.5mm-type
• Shufe Jack, 3.5mm type
• Headphone Jack, 3.5mm type
• AC/DC Dual Power
• AC: 110V AC Line Cord
• DC: Uses 6 -”C” size Batteries,
(not included)
Features
21. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualied service
personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper adjustment of other controls may result in damage and will often
require extensive work by a qualied technician to restore the product to its normal operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for service.
22. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement
parts specied by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions
may result in re, electric shock, or other hazards.
23. Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks to determine that the product is in proper operating condition.
24. Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling only as recommended by the
manufacturer.
25. Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including ampliers) that produce heat.
4

5
Powering the Unit
Power the unit by connecting it to a standard AC outlet (120V ~
60Hz) via the included AC cord.
The unit can also be powered by inserting 6 C batteries into the
Battery Compartment.
6 x “C” SIZE BATTERY
Battery Information
4

Playing a docked iPod
1. After the iPod is docked, adjust the Off/Radio/iPod/Aux
Switch to “iPod” to play any iPod besides the shufe.
2. Press the Play/Pause Button on the docked iPod to begin
playing the iPod.
Use the docked iPods native controls to browse through and
play music from the docked iPod.
Docking an iPod
1. Turn the dial in the Docking
Station to the desired iPod
model.
The dial will rise from the
unit to create the necessary
depth for the selected iPod
model.
When inserting an iPod
nano (rst or second
generation), slide the Dock
connection on the unit so
that it matches the opening
on the iPod nano (rst or
second generation).
76

Docking an iPod
1. Turn the dial in the Docking
Station to the desired iPod
model.
The dial will rise from the
unit to create the necessary
depth for the selected iPod
model.
When inserting an iPod
nano (rst or second
generation), slide the Dock
connection on the unit so
that it matches the opening
on the iPod nano (rst or
second generation).
Docking an iPod shufe
1. Remove the plastic cover from the top of the Docking
Station.
2. Connect an iPod shufe to the exposed headphone type pin.
7
Playing a docked iPod shufe
1. After the iPod is docked, adjust the Off/Radio/iPod/Aux
Switch to “Aux” to play a docked iPod shufe.
2. Press the Play/Pause Button on the docked iPod shufe to
begin playing.
Use the docked iPod shufe’s native controls to browse
through and play music from the docked iPod shufe.
6

Tuning the AM/FM Radio
1. Adjust the Off/Radio/iPod/Aux Switch to “Radio”.
2. Adjust the FM/AM Switch to FM or AM radio mode.
3. Turn the Tuning Dial to adjust the AM or FM radio
frequency.
98

Using the Auxiliary Input
1. Plug one end of a 3.5 mm mini-phono cable (not included) or
a 3.5 mm mini-phono to RCA cable (not included) into the
Aux Input on the unit.
2. Plug the other end of the cable into the audio output/
headphone output on an Mp3 Player or Other Audio Source.
3. Adjust the Off/Radio/iPod/Aux Switch to “Aux”.
4. Audio played from the Mp3 Player or Other Audio Source
will now be heard on the unit.
If connecting to the headphone output of an audio source, the
source’s volume controls may need to be adjusted for optimal
sound.
98

11
Locations of Controls
1
2
3
7
8
4
5
6
9
10

Control Denitions
11
1 DockforiPodshufe
Use the Dock for iPod shufe to dock an iPod shufe to the unit.
2 Off/Radio/iPod/Aux Switch
Adjust the Off/Radio/iPod/Aux Switch to switch between off, radio,
iPod, and aux mode.
When docking and playing an iPod shufe, the unit must be switched to
Aux mode.
3 Docking Station
Use the Docking Station to dock any iPod except for an iPod shufe.
4 VolumeDial
Turn the Volume Dial to adjust the volume of audio output from the unit.
5 Auxiliary Input
Use the Auxiliary Input to connect an MP3 player or other audio device
to the unit.
6 HeadphoneJack
Use the Headphone Jack to connect a set of earbuds or headphones to the
unit.
7FM/AM Switch
Adjust the FM/AM Switch to switch between FM and AM radio mode.
8 Tuning Dial
Turn the Tuning Dial to adjust the AM and FM radio frequency.
9 BatteryCompartment(Requires6CBatteries,NotIncluded)
7
8
9
10

Service Information
Address 2116 Carr Street, St. Louis MO, 63106
Phone 1-314-621-2881
Fax [phone]
Email [email protected]
Website www.gpx.com
To download this Instruc-
tion Manual in English,
Spanish, or French visit
the Support section at
www.gpx.com.
Para descargar este man-
ual de instrucción en in-
glés, español, o francés
visite la sección de la
ayuda en www.gpx.com.
Pour télécharger ce
manuel d’instruction en
anglais, espagnol, ou le
Français visitez la section
de soutien à www.gpx.
com.
© 2007 DPI, Inc. All trademarks appearing herein are the property of their respective owners. All products
subject to change without notice.
