Gradient 6.0 Instruction manual

6.0
Quick User Guide
Thank you for choosing the Gradient 6.0. This product is state-of-the-art loudspeaker, handcrafted
and individually tested in Finland using the best possible materials available. It will provide you
with enjoyable musical experiences for years to come.
Positioning from walls
Gradient 6.0 can be placed close to the wall. Such a placement is not usually possible with floor-
standing loudspeakers due to the increased bass response. This feature is taken account in
Gradient 6.0 design. Therefore the Gradient 6.0 is easy to place for many kind of interior.
Orientation to the listener
The most accurate stereophonic image is produced when
the speakers are placed equidistant from the listener. It is
suggested that the speakers are oriented so the drivers are
directed towards a point in front of the listener.
Connections to amplifier
On the back of Gradient 6.0 attach the positive lead to the
red connector and the negative lead to black connector.
Choice of amplifier
The required amplifier power output depends on the
listening level, room size, among other factors. For the
Gradient 6.0 an amplifier of 20 - 150W is recommended.

Care and cleaning
The cabinet of the Gradient 6.0 is made of 20mm thick solid birch. The back and front wall of the
speaker cabinet are rigid Finnish birch plywood coated in Italian Fenix NTM® nano-tech matt
material. For cleaning the wood surface use a barely damp cloth.
For cleaning the Fenix NTM® use a damp cloth with warm water or mild detergents. Almost all
normal household cleaning products or disinfectants are perfectly well tolerated. It is suggested
to use a melamine foam sponge - also known as magic sponge - for the normal cleaning and
maintenance of the surface.
TECHNICAL SPECIFICATIONS
Make and model: Gradient 6.0
Drivers: 176mm fibreglass midrange,
coaxial aluminium dome 25mm,
140mm x 200mm passive radiator.
Frequency response: 35-25 000Hz ; 100-25 000Hz +/- 2 dB
Sensitivity: 86dB / 2.83V / 1m
Impedance: 8 Ohms
Crossover frequencies: 2800Hz
Connections: Binding posts
Dimensions: 202 x 900 x 173mm
Weight: 12kg
MADE IN FINLAND BY GRADIENT LABS LTD.
www.gradient.fi
