Gram MO 1770 GS User manual

FI Käyttöohje 22
MO 1770 G
MO 1770 GS
EN Instruction Manual 2

3
CONTENTS
PRECAUTIONS 4
SPECIFICATION 4
SAFETY INSTRUCTIONS FOR USE 5
INSTALLING THE PROTECTIVE CIRCUIT 10
COOKWARE 11
SETTING UP YOUR MICROWAVE OVEN 13
INSTALLATION INSTRUCTIONS 14
OPERATION 15
TROUBLESHOOTING 19

4
PRECAUTIONS
TO AVOID POSSIBLE OVER-EXPOSURE TO MICROWAVE ENERGY
(A) Do not attempt to operate the oven with the door open, because it
may cause harmful exposure to microwave energy. Do not disable
the safety interlocks, or attempt to circumvent them.
(B) Do not place anything between the front surface of the oven and
the door or allow dirt or detergent residue to gather on sealing
surfaces.
(C) Do not operate the oven if it is damaged. It is particularly important
that the oven door is properly closed and that there is
no damage to:
(1) DOOR (dent)
(2) HINGES AND LOCKS (broken or loose)
(3) DOOR SEALS AND THE SEALING SURFACE
(D) Any adjustments or repairs should only be entrusted to the
 manufacturer’sproperlyqualiedservicepersonnel.
Specication
Model MO 1770 G / MO 1770 GS
Power supply 230V~ 50Hz
Microwave Frequency 2450MHz
Sound level 54 [dB (A) re 1pW]
Power Consumption 1200W
Nominal output power of microwaves 700W
Nominal output power of grill 900W
Oven capacity 17 litres
Turntable diameter 245mm
External dimensions (height x width x depth) [mm] 262 × 452 × 335
Net weight ~11,3

5
SAFETY INSTRUCTIONS FOR USE
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
1. WARNING: When the appliance is used in a combined mode,
children can use the microwave oven only under adult supervision
due to the high temperatures generated;
2. WARNING: If the door or door seals are damaged, the oven must
 notbeuseduntilitisrepairedbyaqualied
technician;
3. WARNING: Performing any maintenance or repairs which require
removing any shielding protecting against microwave energy is
 dangerousandshouldonlybeentrustedtoaqualiedtechnician;
4. WARNING: Liquids and other foodstuffs may not be heated in
sealed containers as the containers could explode;
5. WARNING: Only give the child permission to use the oven without
supervision when the child has been given appropriate guidance to
use the microwave safely and is aware of the risks of misuse;
6. The minimum required clearance above the top of the microwave
oven is 20 cm;
7. Use only cookware that is suitable for use in microwave ovens;
8. When heating food in plastic or paper containers, pay special
attention to the microwave oven as containers may ignite;
9. If you see smoke, turn off the appliance or unplug it from power
 andkeepthedoorcloseduntiltheamesaresmothered;
10. Microwave heating of beverages can cause delayed boiling,
therefore care should be taken when handling the container;
11. The contents of feeding bottles and jars with food for children
should be stirred or shaken and the temperature checked before
serving to prevent burns;
12. Eggs in the shell and whole hard-boiled eggs should not be heated
in microwave ovens since they could explode even after the
microwave heating;
13. For details on how to clean door seals and adjacent parts please
refer to page 19.

6
SAFETY INSTRUCTIONS FOR USE
14) The oven must be cleaned regularly. Remove any deposits of food
and leftovers;
15) Neglecting to keep the oven clean can damage the surface, which
may adversely affect the durability of the appliance and cause
dangerous situations;
16) Important! If the power cord is damaged, it should be replaced by
 themanufacturerorspecialistrepaircentreoraqualiedpersonin
order to avoid danger.
17) Before using the oven, test heat the grill heater (smoke can be
given off through ventilation grid):
• Switchontheventilationintheroomoropenawindow,
• Settheoventoheatthegrillheateronlyforabout3minutes
without heating food.
18) Microwave oven should not be placed in a cabinet.

7
SAFETY INSTRUCTIONS FOR USE
1. Ovenmustbeplacedonatasurface.
2. Turntable and rotating ring assembly should bein the oven during
cooking. Carefully put cooked food on the turntable, and handle it
carefully to avoid any breakage.
3. Improper use of the browning plate may cause cracking of the turntable
due to the high temperature.
4. Only use bags for cooking in microwave ovens, which are correct size.
5. Microwave oven has several in-built circuit breakers to prevent emission
of radiation, while the door is open. Do not tamper with these circuit
breakers.
6. Do not operate the oven when empty. Operating the oven without food
 ordishwithverylowwatercontentmayresultinre,carbonization,
arcing and damage to the internal chamber shell.
7. Do not cook food directly on the turntable. Excessive local heating
of turntable may cause its rupture.
8. Do not heat baby bottles or baby food in the microwave. Uneven heating
may occur and cause physical injury.
9. Do not use narrow-necked containers such as bottles for syrups.
10. Do not fry in deep fat in the microwave.
11. Do not do home canning in a microwave oven because not always the
entire contents of pot reaches boiling point.
12. Do not use microwave oven for commercial purposes. This microwave
oven is designed for household use only.
13. In order to avoid delayed boiling of hot liquids and beverages and the risk
of burns, stir the liquid before placing the container in the oven and again
in the middle of cooking time. Then leave the container in the oven for a
short time and stir again before removing from oven chamber.
14. Do not forget that there is a dish in the microwave oven to avoid burning
due to excessive cooking.
15. When the appliance is used in a combined mode, children can use the
microwave oven only under adult supervision due to the high
temperatures generated;
16. Neglecting to keep the oven clean can damage the surface, which may
adversely affect the durability of the appliance and cause dangerous
situations;
17. This appliance is not intended for use by persons (including children)
with physical, mental or sensory handicaps, or by those who are
inexperienced or unfamiliar with the appliance, unless under
supervision or in accordance with the instructions as communicated to
them by persons responsible for their safety.

8
SAFETY INSTRUCTIONS FOR USE
To reduce the risk of re, injury to people or exposure to excessive
microwave energy when using the appliance, please observe the fol-
lowing basic safety rules:
1. Read the user manual before using the appliance.
2. Observe all „PRECAUTIONARY MEASURES TO AVOID POSSIBLE OVER-
EXPOSURE TO MICROWAVE ENERGY.”
3. Aswithmostovens,closesupervisionisneededtoreducetheriskofreinside
the oven chamber.
If ignition occurs:
1. Leave the oven door closed.
2. Switch off the appliance and pull out the plug from the wall socket
3. Disconnect the power by removing or disconnecting the fuse on the
distribution board.
Always bear in mind the following principles:
1. Do not overcook dishes. Carefully observe the appliance when paper,
plastic or other combustible materials are inserted into the oven in order to
facilitate cooking.
2. Do not use the oven for storage. Do not store combustible items inside
the oven, such as bread, biscuits, paper products, etc. If lightning strikes in the
supply line microwave may switch on automatically.
 3.Removethewireclampsandmetalxturesfromcontainers/paperor
plastic bags before placing them in the oven.
4. Microwave oven must be grounded. Only connect to a wall socket with the
proper protective conductor. See „Installing the protective circuit.”
5. Install or position the oven strictly in accordance with the instructions.
6. Some products, such as whole eggs, water, oil or grease, sealed containers
and closed glass jars may explode and therefore should not be heated in the
oven.
7. Use this appliance only for its intended purpose as described in the manual.
 Donotusecorrosivechemicalsintheappliance.Ovenisspecicallydesignedfor
heating or cooking food. It is not intended for industrial or laboratory use.
8. Operating the microwave oven should be done with adult supervision at all
times. Do not allow children to play with the appliance or have access to the
controls.
9. Do not operate the oven when its terminal strip or plug is damaged, it is not
working properly, or if it has been damaged or dropped.
 10.TheapplianceshouldbeservicedonlybyqualiedAmicaservicetechnicians.
11. Do not cover or block the air vents on the oven.
12. Do not store or use the oven outdoors.

9
13. Do not use the microwave oven near water, near the kitchen sink, in a
damp room or near a swimming pool.
14. Do not immerse the power cord or plug in water.
15. Keep cord away from heated surfaces.
16. Do not allow the connection cord hanging over the edge of a table
or counter.
17. Cleaning:
Before cleaning, make sure the oven is disconnected from the power
source.
a) After use, clean the inside of the oven using a slightly damp cloth.
b) Clean the accessories in the normal way in soapy water.
c) Dirty door frame, seal and adjacent elements should be cleaned gently with
a damp cloth. When cleaning the surface of the oven door, use only mild
soap or detergent applied with a sponge or soft cloth.
SAFETY INSTRUCTIONS FOR USE
The appliance was protected
from damage at the time of
transport. After unpacking,
please dispose of all elements
of packaging in a way that will
not cause damage to the envi-
ronment.All materials used for packaging the
appliance are environmentally friendly; they
are 100% recyclable and are marked with the
appropriate symbol.
Important! Packaging materials (bags, poly-
ethylene, polystyrene, etc.) should be kept
away from children during unpacking.
UNPACKING WITHDRAWAL FROM USE
At the end of its useful life, this
product must not be disposed
of with normal municipal waste.
Instead, it should be taken to an
electronic waste collection and
recycling point. It is indicated by
the symbol on the product itself,
or on the Operator’s Manual or packaging.
The materials used in making of this applian-
ce can be reused, as indicated. By reusing or
recycling the materials or parts, you will be
playing an important part in protecting our
environment.
Information about the relevant disposal points
for worn-out electrical goods is available from
your local authorities.

10
INSTALLING THE PROTECTIVE CIRCUIT
DANGER
Danger of electric shock when
touched, some internal components
may cause serious injury or death. Do
not disassemble this appliance.
WARNING
Electric shock hazard. Improper use of
earthing can cause electric shock. Do
not insert the plug into the socket be-
fore the appliance is properly installed
and grounded.
This appliance must be grounded. In the
event of a short-circuit, earthing reduces
the risk of electric shock. The appliance is
equipped with earthing wire with an appro-
priate plug. The plug should be inserted
into a properly installed and grounded
outlet.
If you do not completely understand
earthing instruction or you are unsure
whether the appliance is properly groun-
ded,pleasecontactaqualiedelectrician
or service technician. If you must use
an extension cord, use only a three-wire
extension with an earthing connector. The
manufacturer shall not be liable for dama-
ge or injury resulting from connecting the
microwave oven to a power source without
a protective circuit or with a malfunctioning
protection circuit.
1. A short power cord is provided to
reduce the risk resulting from
becoming entangled or tripping
over a long cord.
2. If you use the extension cord:
1) Extension cord must be
capable of withstanding nominal
current required by the appliance.
2) Extension cord must be
3-wire with earthing,
Extension cord should be so arranged
as not to be hung by the table top where
it could be pulled by children, or caught
inadvertently.

11
COOKWARE
WARNING
Risk of injury. Tightly closed con-
tainers may explode. Closed con-
tainers must be opened and plastic
bags pierced before cooking.
Materials that can be used and materials to
be avoided in the microwave oven.
The use of some non-metallic cookware
may not be safe in the microwave oven.
If in doubt, you can check the cookware
following this procedure.
Testing the cookware:
1. Fill the microwave-safe cookware with 1 cup of cold water (250 ml), and do the same
with the test cookware.
2. Operate the oven with the maximum power for 1 minute.
3. Carefully touch the test cookware. If the test cookware is hot, do not use it in the micro-
wave oven.
4. Do not exceed 1 minute cooking time.
Cookware Comments
Aluminium tray May cause an electric arc. Transfer food to microwave-safe
cookware.
Cardboard carton with metal
handle
May cause an electric arc. Transfer food to microwave-safe
cookware.
Metal or cookware with
metal frame
Metal shields the food from microwave energy. Metal frame
can cause an electric arc.
Metal closure - tightened Maycauseanelectricarcandreintheoven.
Paper bags Maycauseareintheoven.
Plastic foam Plastic foam may melt or contaminate the liquid in it when
exposed to high temperatures.
Wood Wood dries out when it is heated in the microwave oven and
can crack or break.
Materials that cannot be used in a microwave oven
Materials that can be used in a microwave oven
Cookware Comments
Aluminium foil Only as shielding. Small and smooth pieces can be used for the coating of thin
pieces of meat or poultry, to prevent excessive cooking. Arc discharge may
occur if the foil is too close to the oven walls. Film must be at least at a distance
of 2.5 cm from the oven walls.

12
Materials that can be used in a microwave oven
Cookware Comments
Browning plate
Observe the manufacturer’s instructions. The bottom of the browning plate must
be at least 5 mm above the turntable. Improper use may cause cracking of the
turntable.
Dinner dishes Suitable for microwave ovens only. Observe the manufacturer’s instructions. Do
not use cracked or chipped cookware.
Glass jars Always remove the lid. Use only for heating food to a suitable temperature.
Most glass jars are not heat resistant and may explode.
Glassware Use only heat-resistant glassware in the microwave oven. Make sure that there
are no metal frames. Do not use cracked or chipped cookware.
Bags for microwave
cooking Observe the manufacturer’s instructions. Do not seal with metal clamps.
Paper plates and
cups
Cut through to allow the steam to escape. Use only for short cooking / heating.
Do not leave the oven unattended while cooking.
Paper towels Use to cover food to be heated to absorb fat. Use only for short cooking under
constant surveillance.
Parchment paper Use as a cover to prevent splashing or as a container for evaporation.
Plastics
Suitable for microwave ovens only. Should be labelled "for use in microwave
ovens." Some plastic containers soften when the content is warmed up. Bags
for microwave cooking and sealed plastic bags must be pierced or incised, or
vented according to the directions on the package.
Plastic packaging Suitable for microwave ovens only. Use to cover food during cooking in order to
maintain moisture. Do not let plastic packing touch the food.
Thermometers Suitable for microwave ovens only (thermometers for meat and sugar).
Wax paper Used as a covering to prevent splashing and to keep moisture.
Cookware material Microwaves Grill Combi Mode
Heat-resistant glass YES YES YES
Regular glass NO NO NO
Heat-resistant ceramics YES NO NO
Microwave-safe plastic utensils YES NO NO
Kitchen paper YES NO NO
Metal container NO YES NO
Metal rack (provided for the oven) NO YES NO
Aluminium foil and foil containers NO YES NO
COOKWARE

13
SETTING UP YOUR MICROWAVE OVEN
Microwave oven accessories
Remove all packaging, both inside and outside the oven, before using the oven.
The oven comes with the following accessories:
Turntable 1
Turntable support 1
Operator’s Manual 1
A) Control panel
B, C) Spindle
D) Turntable
E) Door glass panel
F) Door assembly
G) System security lock -
disconnects power to the
oven when the door is
opened during operation.
TURNTABLE INSTALLATION
1. Never compress or place the
turntable upside down.
2. When cooking always use the
turntable and its ring support.
3. For cooking or heating always
put the food on the turntable.
4. If the turntable breaks, please
contact GRAM service.
* Note: The grilling rack supplied with the appliance should only be used
when the appliance is set to „GRILL”.
* Grilling
rack
Turntable
Spindle
F
G
A
CB
ED

14
1. Selectalevelsurfacetoensuresufcientspacefortheinletandoutlet
ventilation openings.
The required distance between the oven outer surfaces and adjacent walls (or
appliances)ispresentedontheabovegure.Donotremovethelegslocatedin
the bottom of the appliance.
Blocking the inlet and outlet openings may damage the microwave oven. Place
the oven as far away from radio and television as possible. Operating microwave
oven may cause interference to radio and television reception.
2. Insert the oven power plug into a standard household wall socket. Make
sure beforehand whether voltage and frequency are the same as on the oven’s
rating plate.
WARNING: Do not install the oven on the gas hob or other heat producing
appliance. In the event of such installation, the oven may be damaged and
void the warranty.
INSTALLATION INSTRUCTIONS
- Remove all packaging materials and components.
- Check the oven for damage such as dents or door misalignment
or breakage.
- Removeanyprotectivelmfromthesurfaceofthecabinet.
- Do not install the oven if it is damaged.
Do not remove the light brown mica cover bolted into the recess in
order to shield the microwave magnetron.
Installing
Accessible surfaces
may become hot during
oven operation.
5cm
10cm
20cm
5cm

15
Display - it displays: time, cook time, power,
indicators and current time
Microwave power - Press this button to set
microwave heating power.
Grill - Press the button to set the oven in grill
mode with cook time up to 60 minutes.
Combi Mode - Press the button two or three times
to set the oven in the combined mode of microwave
and grill heating.
Setting the clock - Press this button to set the
clock.
Adjustment knob (TIME / WEIGHT, MENU START)
- turn the knob to adjust current time or cook time
- turn the knob to adjust food weight and select Auto
Menu cooking programmes.
- pressing the knob to start the oven with the
previously chosen settings,
- press the knob again and again to add cook time
shown on the display. When the desired cook time
is set, oven starts automatically.
Start / quick start - Press to start the cooking
program. Press this button a number of times to
begin express cooking without previously set power
level and cooking time.
Auto cook - Press this button for instant setting to
cook popular food
STOP / CANCEL
- Press this button to reset the appliance settings.
- Press this button to stop the appliance or press
 twicetoerasethespeciedprogram.Pressonceto
stop to cooking, or twice to cancel cooking
altogether.
- This button is also used when using the Child Lock
function.
OPERATION
This microwave oven has a modern electronic programmer to adjust the
parameters of cooking or reheating.
Control Panel
AUTO
1
2
3
4
5
6
7
8
9
AUTO

16
1. SETTING DIGITAL CLOCK
With the oven ready for input, touch the
button once or twice to set the
digital clock in 12 or 24 hours cycle.
Suppose you want to set the oven clock
time to 8:30.
1. In standby mode, press button
once or twice.
2. Turn to indicate the hour digit 8.
3. Press button.
4. Turn dial to indicate the
minute digits until the screen shows 8: 30.
5.Press toconrmthesetting.
Note: To check clock time during cooking,
press the button once.
2. MICROWAVE COOKING
To cook with microwave power alone,
press the button a number of
times to select a cooking power level,
and then use the dial to set
a desired cooking time. The longest
cooking time is 60 minutes. You can
select power level by pressing the
button:
Press POWER Button Cooking Power
Once 100%
Twice 80%
3 times 60%
4 times 40%
5 times 20%
6 times 0%
OPERATION
For example, suppose you want to cook for
1 minute at 60% of microwave power.
1. Press button repeatedly to select
power level.
2. Rotate to enter cooking time.
3. Press button.
Note:
1. If you want to temporarily stop a cooking
session, press the once and then
you can start the cooking again by press
START/QUICK START; or press the STOP/
CANCEL twice to cancel the cooking pro-
gram altogether.
2.Aftercookingprogramhasnished,the
buzzer will sound beeps once every 2 mi-
nutes with END showing on screen, press
STOP/CANCEL or open oven door to clear
that before setting another function. (Both
note 1 and 2 are also available for other
cooking program.)
3. GRILL/COMB.
Grill/comb. Cooking has three cooking
mode: grill, combination 1, and combination
2. You can press the button circularly
to select one. The longest cooking time is
60 minutes.
- The grill cooking is particularly useful for
thin slices of meat, steaks, chops, kebabs,
sausages or piece of chicken. It is also
suitable for hot sandwiches and au gratin
dishes.
- Combination 1: 30% time for microwave
cooking,70%forgrillcooking.Useforsh
or au gratin.
- Combination 2: 55% time for microwave
cooking, 45% for grill cooking. Use for
puddings omelettes, baked potatoes and
poultry.

17
Suppose you want to set combination 1
cooking for 25 minutes.
1. Press button twice.
2. Turn to 25:00.
3. Press button.
OPERATION
4. AUTO DEFROST
The oven allows the defrosting of food
based on the weight you entered. The time
and the defrosting power are adjusted au-
tomatically once the weight is programmed.
The range weight of frozen foods varies
between 100g and 1800g.
Suppose you want to defrost 600g of
shrimp.
1. Place the shrimp to be defrosted into
the oven and close the door.
AUTO
2. Turn dial to indicate food weight.
3. Press button.
3. Press button.
Note: During defrosting process, the oven
will pause to remind you to turn over food.
5. AUTO COOK
For food or the following cooking mode, it is
not necessary to program the duration and
thecookingpower.Itissufcienttoindicate
the type of food that you wish to cook as
well as the weight of this food.
1. Press the button repeatedly
to select corresponding food code.
2. Rotate dial to choose a weight
600g.
Code Food 1. For coffee/soup, potatoes, parameters
on display are not weight but number of
servings.
2. For food coded 7~9, the oven will pause to
remind user to turn over food during cooking.
3. The result of Auto Cook depends on fac-
tors such as the shape and size of food, your
personal preference as to the doneness of
certain foods and even how well you happen
toplacefoodintheoven.Ifyoundtheresult
at any rate not quite satisfactory, please ad-
just the cooking time a little bit accordingly.
4. *Add boiled water before cooking.
1 Coffee/Soup (200ml/cup)
2 Rice (g)
3 Spaghetti (g)*
4 Potatoes (230g/share)
5 Auto Reheat (g)
6 Fish (g)
7 Chicken (g)
8 Beef/Mutton (g)
9 Skewered Meat (g)

18
6. QUICK START
This feature allows you to start the oven
quickly. The longest cooking time is 12
minutes.
Press the button a number of times to
set the cooking time, the oven starts wor-
king at full power level immediately.
7. CHILD LOCK
Use to prevent unsupervised operation of
the oven by little children. The child lock
indicator will show up on display screen,
and the oven can not be operated while the
Child Lock is set.
- To set the Child Lock: In standby mode,
press and hold the button for 3 se-
conds, a beep sounds and lock indicator
lights.
- To cancel the Child Lock: Press and hold
the button for 3 seconds until lock indi-
cator on display turns off.
OPERATION

19
TROUBLESHOOTING
Microwave oven interfe-
res with the TV reception
Radio and television reception may be disrupted when the
microwave oven operates. The same applies to small
household appliances such as a blender, vacuum cleaner
and electric fan. This is normal.
Dimmed oven lighting. When cooking with low microwave power, oven light may be
dimmer. This is normal.
Condensation forms on
the door, hot air comes
out through vents.
When cooking, steam can be released from food. Most of the
steam escapes through the vents. However some steam can
collect in the form of condensation on cooler parts, such as
oven door. This is normal.
Fault Possible cause How to correct
Oven does not start.
(1) power cord unplug-
ged or not plugged pro-
perly into the socket
Pull the plug and put it
back in after 10 seconds.
(2) Blown fuse or tripped
circuit breaker.
Replace the fuse or turn
on the circuit breaker
(contact GRAM service)
(3) No voltage in the
socket
Check the outlet by plug-
ging in other appliance.
The oven does not heat. The door is not closed
properly. Close the door fully.
Turntable makes noise
when oven operates
Rotating ring or bottom
of the oven dirty.
See "Microwave oven
maintenance"

20
FINAL REMARKS
Before using the microwave, please carefully read this manual. Store it
in such a place, so that it may be used in future. Do not repair the oven
yourself, please contact GRAM service. The contents of feeding bottles and
jars with food for children should be stirred or shaken and the temperature
checked before serving to prevent burns; Regularly check the oven and its
power cord for damage. If there is any damage, do not use the oven
WARNING:
1. Performing any maintenance or repairs which require removing any
shielding protecting against microwave energy is dangerous and
 shouldonlybeentrustedtoaqualiedtechnician;
2. Only give the child permission to use the oven without supervision
when the child has been given appropriate guidance to use the
microwave safely and is aware of the risks of misuse;
3. If the power supply cable is damaged, it should be replaced by the
manufacturer or at an authorized servicing outlet.
Do not attempt to operate the oven with the door open, because it may
cause harmful exposure to microwave energy. Do not disable the safety
interlocks, or attempt to circumvent them.
Thoroughly clean the door gasket and sealing surfaces. Do not operate the
oven if it is damaged. It is particularly important that the oven door is proper-
ly closed and that there is no damage to: (1) door (bent), (2) hinges and lat-
ches (broken or loosened), (3) gaskets and the door sealing surface. Check
cookware and make sure that it is suitable for use in microwave ovens.
When heating food in plastic or paper containers, pay special attention to
the microwave oven as containers may ignite;
Microwave heating of beverages can cause delayed boiling, therefore care
should be taken when handling the container;
