Granit FarmCam 360S User manual

QUICK GUIDE

Page 3
Sida 48
Seite 33
Page 18

Article number: 1110
Video
Video Resolution: 1080p HD at 15 frames/sec
Field of View: 105° diagonal
Pan/Tilt Angle: Horizontal 355°/ Vertical 140°
Night Vision: Up to 10.6m
Digital Zoom: 6x
PIR Detection & Alerts
PIR Detection Distance: Adjustable up to 10.5m
PIR Detection Angle: 90° horizontal
Audio Alerts: Customized voice-recordable alerts
Other Alerts: Instant email alerts and push notications
General
Audio: Speaker and microphone
DC Power: 5V/2A
Local Storage: Micro SD card, max 64 GB
Battery: 6500 mAh rechargable battery
Solar Option: 1091 SolarCharger FCM
Operating Frequency: 2.4 GHz
Wi Standard: IEEE 802 11b/g/n
Operating Temperature: -10° to 55°C
Weather Resistance: IP65 certied weatherproof
Size: 142x129 mm
Weight: (Battery included): 580g
TECHNICAL SPECIFICATION

English
4
Speaker
Status LED
Daylight Sensor
Built-in PIR Sensor
Built-in Mic
Micro SD Card Slot
* Rotate the lens of the camera to nd the reset
hole and the SD card slot.
Reset Hole
* Press the reset button for several seconds
with a pin to restore camera to factory settings.
Battery Status LED
Micro USB Port
Power Switch
Dierent states of status LED:
Red Light: WiFi connection failed
Blue Light: WiFi connection succeeded
CAMERA FUNCTIONS

English
5
WHAT’S INCLUDED
FarmCam 360 Antenna Reset Needle 5m Power Adapter Mounting
Hole Template
Surveillance Sign Quick Installation
Guide
Pack of Screws 16 GB SD Card

English
6
SET UP CAMERA
12
34
Turn on the power switch.
- +
Download and install
the FarmCam 2.0 app.
Open the app. Click the
button on the top right
corner to add the camera.
Screw the antenna to the camera.

English
7
6
78
Scan the QR code
on the back of the camera.
5
SET UP CAMERA
Click“Connect to Wi-Fi”.
Place the QR code on your phone
towards the lens of the camera at a
distance of about 30cm.
(Remove protective lm from lens).
Write the name of your WiFi
network and its password.
A QR code will be generated
on the phone.

English
8
SET UP CAMERA
Create a password for your camera
9Name your camera and follow
the steps on the phone to nalize
setup.
10
Touch the image on the screen
to start live video.
11

English
9
Name your camera and follow
the steps on the phone to nalize
setup.
APP OVERVIEW
- +
Menu
Add New Device
Enable/Disable PIR
Motion Sensor
Device Settings
Access the Live View
Battery Status
Pause Camera
Take a screenshot
Record
High/low resolution
Color/Black and white
Full Screen
Multi view
Trigger alarm in the camera
Camera mic On/O
Communicate via camera
Pan & Tilt
Playback recordings
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
- +
TIP!
Use the camera in your phone and scan the QR code
to get a complete guide/video of all functions in the app.

English
10
HOW TO ACTIVATE ALERTS
- +
Press the arrow to get to the main menu.
1
- +
Click on the setting symbol, BUT before
you do, please make sure that the PIR
motion detector symbol to the left of the
setting symbol lights up orange. If it is
white, please click until it turns orange.
Orange = activated; White = deactivated.
2
- +
With PIR and Push activated you will be
notied if motion is detected in front of the
camera. Perfect when you want to use FarmCam
360 for security purposes.
3
Push on Push o
