Granit 7306510 User manual

Operating Instructions
Pneumatic impact wrench
7306510/7306515/7306520
These operating instructions must be read thoroughly before use and followed. These
operating instructions must be retained for future reference.
Translate of the original operating instructions

Operating Instructions
7306510/7306515/7306520
2
Table of contents
About these operating instructions and symbol descriptions...................................... 3
Safety and accident prevention rules ..................................................................... 4
2.1 General safety advice for pneumatic tools ........................................................ 4
Operation of the pneumatic tools........................................................................... 7
3.1 Intended use ................................................................................................ 7
3.2 Operating instructions.................................................................................... 7
Maintenance and care .......................................................................................... 9
EU Declaration of Conformity ...............................................................................10
UKCA Declaration of Conformity ...........................................................................11
Disposal ............................................................................................................12
Warranty...........................................................................................................12
Addresses .........................................................................................................12
Technical data....................................................................................................13
Legal notice .......................................................................................................14

Operating Instructions
7306510/7306515/7306520
3
About these operating instructions and symbol
descriptions
Incorrect operation can lead to serious injury or death.
Incorrect operation or negligence may result in personal injury,
damage to the equipment or faulty measurements.
Instructions and tips for operation.
Numbers in illustrations (1, 2, 3 ...) refer to the corresponding numbers in brackets
(1), (2), (3) ... in the text next to the item numbers in the tables.
Instructions for which the order must be followed are numbered (1, 2, 3, ...).
Lists are marked with bullet points (●, ●, ...).
Symbol description warning information
Read the
instructions
before use.
Wear eye
protection.
Wear
professional
hearing
protectors.
Wear a half
mask.
Wear a breathing
protection mask
Lubricate daily
Correct position of
a static torque
support.
Risk of trapping
Risk of trapping
Rotation direction

Operating Instructions
7306510/7306515/7306520
4
Safety and accident prevention rules
The pneumatic tool is mainly intended for professional users. The user or the employer must
assess the specific risks which can arise during each application. These instructions contain
information which you must be aware of and understand. This information relates to YOUR
SAFETY and AVOIDING PROBLEMS WITH THE DEVICE. To make it easier for you do identify
this information, we use the symbols shown on the following pages. Please read these
instructions and note these sections.
READ AND FOLLOW ALL INSTRUCTIONS
This tool was developed for specific applications. We urgently recommend
NOT to modify this equipment and/or to use it for an application other than that
intended. If you have any doubts about the use of the tool, please do NOT use the tool
before you have contacted the dealer and they have advised you.
IMPORTANT SAFETY INSTRUCTIONS
Improper operation or maintenance of this product can lead to severe injuries and property
damage. Read and understand all warning information for operation before using this
device. Basic safety precautions must always be taken when using pneumatic tools to
reduce the risk of injuries.
2.1 General safety advice for pneumatic tools
General safety rules
Read and understand the safety information before installing, operating, maintaining
or changing parts of the pneumatic tool. Failure to act accordingly can lead to severe
injuries.
Only qualified and trained operators should install, adjust and use the pneumatic tool.
Do not carry out any modifications on this pneumatic tool. Modifications may reduce the
effectiveness of the safety measures and increase the risks for the operator.
Do not throw these operating instructions and appendices away, but instead provide
them to the operator.
Do not use the pneumatic tool if it is damaged.
The tools must be checked regularly, to ensure that the rated values and markings
on the tool are legible. The employer/user must contact the manufacturer as
required to receive replacement markings.
To counteract the reaction torque and to reduce the risk of vibrations, it is
recommended to fix the tool on a strong support fixture.
Do not touch socket inserts or accessories during the impact process, since this
increases the risk of cuts, burns and vibration injuries. Only use approved socket
inserts in good condition for the impact wrench, since socket inserts and accessories
which are used with impact wrenches break if in poor condition, leading to them
becoming flying projectiles.

Operating Instructions
7306510/7306515/7306520
5
Risk from flying components
Be aware that failure of the workplace, the accessories or even the tool head used
can produce high speed projectiles.
During operation of the pneumatic tool always wear impact-resistant eye protection.
The required degree of protection should be assessed for every specific application.
When doing so danger to other persons must also be considered.
Make sure that the workpiece is securely fixed.
Entanglement hazards
Risk of asphyxiation, degloving injuries and cuts, if loose clothing personal jewellery,
necklaces, hair or gloves are not kept away from the tools and accessories.
Gloves can become caught in the rotating drive leading to severed or broken fingers.
Keep the hands away from the rotating drives.
Rotating drive bushings and drive extensions can be easily caught on rubber-coated
or metal-reinforced gloves. Never hold the drive or the drive extension.
Operating hazards
Operation and maintenance personnel must be physically able to handle the mass,
the weight and the force of the tool.
Hold the tool correctly; be ready to counteract normal or sudden movements and
keep both hands available.
Maintain a balanced body position and secure footing.
Only use the lubricants recommended by the manufacturer.
It is recommended to use personal safety glasses and protective clothing.
If the pneumatic tool is hung within a holding fixture, make sure that the fixture is
firmly in position.
In cases where means of counteracting the reaction torque are required, it is
recommended where possible to use a hook-on arm. If this is not is not possible,
side handles for tools with a straight housing and pistol grip are recommended. In
any case it is recommended, with straight tools to use a means of counteracting the
torque if above 4 Nm, for pistol grip tools above 10 Nm and with angle wrenches,
above 60 Nm. The fingers may be trapped with open crowfoot wrenches. Do not use
the tool in tight spaces, and pay attention to potential trapping of the hands between
tool and workpiece, especially when undoing screws.
Hazards from repeated movements
When using a pneumatic tool to carry out work-related activities, the operator may
identify problems in the hands, arms, shoulders, in the neck or another part of the
body.
When using a pneumatic tool, the operator must have a relaxed body position, while
maintaining a secure footing and avoiding unfavourable or unbalanced body
positions. During long periods of work the user must change their body position from
time to time, to avoid injuries and fatigue.
If the user experiences symptoms such as continuous or repeated feeling unwell,
pain, throbbing, tingling, numbness, burning or stiffness, then these warning signs
must not be ignored. The user must inform the employer, and seek assistance from
a qualified doctor.

Operating Instructions
7306510/7306515/7306520
6
Hazards associated with accessories
Only use accessories of the sizes and types recommended by the manufacturer of
the pneumatic tool, as well as consumables; do not use other types or sizes of
accessories and consumables.
During and after use avoid direct contact with the tool, since it may be hot or sharp.
Hazards in the workplace
Slips, trips and falls are the main causes of workplace accidents. Watch out for
slippery surfaces, which arise when using the tool, as well as tripping hazards,
caused by the air line or the hydraulic hoses.
The pneumatic tool is not designed for use in explosion hazard areas and is not
insulated against contact with electrical power.
Make sure that no electrical cables, gas pipes and similar are present, which could
present a hazard when using the tool if they are damaged.
Risks from dust and vapours
The risk assessment should take into account the dust and the possibility of stirring
up existing dust when using the tool.
Point the exhaust in such a way that dust being stirred up in dusty environments is
minimised.
Hazards from noise
The noise level when using the pneumatic tool is 96.0 dB (A)
Always wear professional hearing protectors when working with pneumatic tools.
If working regularly in noisy areas, according to the workplace safety regulations, a
preventative investigation for working in noisy areas should be offered.
Long-term exposure to high noise levels can cause permanent, disabling hearing
damage and other problems such as tinnitus (ringing, buzzing, whistling or humming
in the ears). For this reason a risk assessment and the implementation of suitable
controls for these hazards is essential.
Suitable controls for reducing the risk can include measures such as for example
using damping materials to prevent workpieces vibrating.
Operate and maintain the pneumatic tool as recommended in the operating
instructions, in order to avoid an unnecessary increase in the noise level.
Select maintain and replace the consumables/inserts as recommended in the
operating instructions, to avoid unnecessary increase of the noise level.
Vibration hazards
The effects of vibration can cause nerve damage and impaired blood supply to the
hands and arms.
When working in cold environments wear warm clothing and keep your hands warm
and dry.
If you feel numbness, prickling, pain will see a white appearance of the skin in
fingers or hands, stop the use of the pneumatic tool, inform your employer and seek
medical advice.
Operate and maintain the pneumatic tool as recommended in the operating
instructions, in order to avoid an unnecessary increase of the vibration values.

Operating Instructions
7306510/7306515/7306520
7
Hold the tool with a loose, but secure grip - when doing so take into account the
necessary hand reaction forces, since the risk of vibration is generally higher when
the gripping force is higher.
Additional safety information for pneumatic tools
Compressed air can cause serious injuries.
Always switch off the compressed air supply, release the air pressure from the hose,
and disconnect the tool from the compressed air supply, if it is not being used,
before replacing accessory parts, or before carrying out repairs.
Never point compressed air at yourself or other persons.
Whipping hoses can cause severe injuries. Always check hoses and screw fittings for
damage and secure seating.
Cold compressed air should be pointed away from the hands.
For impact and impulse wrenches do not use quick close couplings on the tool input.
Use hose screw fittings in hardened steel (or material with comparable impact
resistance).
If universal rotary couplings (claw couplings) are used, locking pins must be installed
and anti-whipping safety cables used, to prevent possible failure of the connection
between hose and tool and hose and hose.
Never use worn or a poorly fitting socket inserts or extensions, since this can cause a
significant increase in vibrations. If possible use ferrule-type couplings.
Support the weight of the tool, where possible in a stand, clamp or stabiliser.
Do not exceed the maximum air pressure indicated on the tool.
Never carry a pneumatic tool by the hose.
Operation of the pneumatic tools
3.1 Intended use
The intended use for this pneumatic tool is for tightening/undoing or installing/removing
fastening elements with a thread with corresponding impact wrenches or chiseldrivers.
Any use other than the intended use of the specific pneumatic
tool is prohibited.
3.2 Operating instructions
Before every use:
Only operate, inspect and maintain the tool in accordance with all regulations (local,
regional, national), which apply for handheld pneumatic tools.
Drain off water from the air compressor tank and condensate from the air lines. The
operating instructions for the air compressor.
Disconnect the tool from the compressed air supply, before
lubricating, installing, removing or adjusting it.
Lubricate the tool, see section "maintenance" within this manual.

Operating Instructions
7306510/7306515/7306520
8
Connect the tool to the compressed air hose of the recommended size.
NOTE: Using a quick-coupling set makes connection easier.
Using compressed air filters and compressed air line
lubricators is recommended.
For use:
Switch on the air compressor and allow it to fill up the reservoir tank.
Set the regulator of the air compressor to 6.2 bar (90 psi). This tool works with a
maximum pressure of 6.2 bar (90 psi).
When using rotary tools check for correct direction of rotation before using the tool.
Make sure that the inserted tool is sitting firmly on the square drive (impact/ratchet
socket)
Adjust the direction of rotation if necessary:
Move the switch/lever as marked on the tool.
「F」（Forwards）- Clockwise direction of rotation as viewed from the user’s position.
「R」（Backwards）- Anticlockwise direction of rotation as viewed from the user’s
position.
Note: On some tools this may be marked with the combination of 「L」and「R」. In this case 「
R」(right) stands for the forward direction and 「L」(left) for the reverse direction.
Set the rotation/oscillation speed, if applicable:
Using numbers: a larger number indicates a higher setting and vice versa.
Using symbols: larger size of the symbol indicates a higher setting and vice versa.
Note: Always start operation with a low setting.
Allow the tool to come to a complete stop, before changing the direction of rotation.
To start or stop.
The tool is fitted with a trigger/lever for stopping. Pull the trigger (or press the lever down),
to start the tool. The tool stops running, when the trigger/lever is released.
Note: With certain types of pneumatic tools, due to inertia it can take a few seconds until
the tool comes to a complete standstill.
The energy transmitted by the tool varies depending on the size
of the air compressor and on the quantity of air delivered by the air compressor.
Do not use damaged, fretted or worn air hoses and screw fittings.

Operating Instructions
7306510/7306515/7306520
9
Always disconnect the compressed air supply before lubricating, installing, removing or
adapting the tool.
Once the work has finished, switch off the air compressor and store it as described in
the operating instructions of the air compressor.
Always use clean, dry air with a maximum air pressure of 6.2 bar (90 psi). Dust,
corrosive vapours and excessive moisture can destroy the internal parts of a pneumatic
tool.
Do not remove any markings. Replace a marking if damaged.
Keep hands, loose clothing and long hair away from the moving parts of the tool.
Maintenance and care
General tips
Hold the tool and allow it to run without load to check the vibration level before using
the tool. If an excessive level of vibration is noticed, then this is a sign that maintenance
or repair may be required.
Before use check the idle speed of the tool if you hear noise being produced by the tool.
It is recommended to check the idle speed of the tool regularly and after every
maintenance activity using a tachometer and stroboscope.
Keep the tool clean after each use, to avoid the risk of exposure to hazardous
substances which may be deposited on the tool during working processes.
Follow the locally applicable regulations regarding waste disposal.
Always use the accessories recommended by your dealer.
Before carrying out maintenance work on the tool always disconnect the compressed air
supply first.
Lubrication
Pneumatic tools must be lubricated regularly during their complete service life. The
pneumatic motor and the bearing use compressed air to drive the tool. Since moisture in
the compressed air causes the pneumatic motor to rust, the motor
must be lubricated daily. An inline-oiler is recommended.
The pneumatic motor is lubricated manually as follows:
Disconnect the tool from the air supply and hold it so that the air
inlet points upwards.
Press the trigger and put one to two drops of pneumatic tool oil into the air inlet.
Connect the tool to a compressed air source, cover the outlet with a cloth and let is run
for a few seconds.
Do not lubricate tools with flammable of volatile liquids such as paraffin, diesel or jet
fuel.

Operating Instructions
7306510/7306515/7306520
10
EU Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
declares under their sole responsibility that the pneumatic impact wrench
Type/series identification: 7306510, 7306515, 7306520
conforms to the provisions of
2006/42/ECMachinery Directive
The product was developed in accordance with the following standards:
DIN EN ISO 12100:2011-03
DIN EN ISO 11148-6:2013-05
EN ISO 15744
EN ISO 28927-2+A1
Authorised person for documentation:
Mr Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
The serial number and model year are shown on the type plate of the equipment.
Heeslingen, 24.06.2021
Translation of the original EU declaration of conformity
__________________________________
Holger Wachholtz, Executive Board

Operating Instructions
7306510/7306515/7306520
11
UKCA Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
declares under their sole responsibility that the pneumatic impact wrench
Type/series identification: 7306510, 7306515, 7306520
conforms to the provisions of
The Supply of Machinery (Safety) Regulations 2008/1597
The product was developed in accordance with the following standards:
BS EN ISO 12100:2011-03
BS EN ISO 11148-6:2013-05
BS EN ISO 15744
BS EN ISO 28927-2+A1
Authorised person for documentation:
Mr Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
The serial number and model year are shown on the type plate of the equipment.
Heeslingen, 24.06.2021
Original UKCA Declaration of Conformity
__________________________________
Holger Wachholtz, Executive Board

Operating Instructions
7306510/7306515/7306520
12
Disposal
The separate, environmentally friendly disposal of materials encourages recycling of
materials. Therefore, after expiry of the normal service life, the equipment itself and all related
components, including the lubrication, packaging and wear parts, should be disposed of at a
recyclables collection point.
Packaging, equipment and accessories are made of recyclable materials and should be
disposed of accordingly.
If the unit is no longer serviceable, make sure it is unusable before disposal.
If you do not have the necessary technical knowledge, engage a
specialist to dismantle and dispose of the unit. RISK OF INJURY!
!!! Always observe local disposal regulations!!!
Warranty
The warranty terms of Wilhelm Fricke SE, as can be found in the sales documents and the
current version of the Terms and Conditions, apply.
In case of questions, please contact the company’s customer service line.
Addresses
Sales/customer service/ Tel.: [phone]
Spare parts sales: Fax: [phone]
Postal and shipping address: Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen

Operating Instructions
7306510/7306515/7306520
13
Technical data
Model no.
7306510
7306515
7306520
Dimensions (mm)
6” extending anvil
105.5x58.6x157.3
184x68x2051
215.9x84x232.5
367.5x84x232.5
Own weight (kg)
6” extending anvil
1.4
1.82
3.48
4.07
Maximum allowable operating
pressure (bar)
6.2
6.2
6.2
Recommended operating
pressure (bar)
6.2
6.2
6.2
Air requirement (l/min)
135.9
130.3
195
Attachment size
1/2"
1/2”
3/4”
Max. tightening torque (Nm)
678
1054
1763
Idle speed (rev/min)
10000
7200
6800
Min. connection cross-section
(mm)
10
10
13
Standard screw size (mm)
16
16
38
Noise values according to EN ISO 15744
A-weighted sound pressure level
at workplace (dB)
96
92.8
102.5
A-weighted sound power level
(dB)
107
103.8
113.5
C-weighted instantaneous peak
sound pressure level at
workplace (dB)
<130
<130
<130
Measurement error (dB)
3
3
3
Vibration value according to EN
ISO 28927-2 (m/s²)
6” extending anvil
12
4.8
19.7
13.1
Measurement error (m/s²)
6” extending anvil
1.68
0.97
2.44
1.8

Operating Instructions
7306510/7306515/7306520
14
Legal notice
Translation of the original operating instructions for a pneumatic impact wrench
Manufacturer: Wilhelm Fricke SE - DE-27404 Heeslingen
1st Edition June 2021
©2021 Wilhelm Fricke SE
Reproduction in whole or in part is prohibited without the written consent of the Wilhelm Fricke SE company.
All product names mentioned in these operating instructions are trademarks of their respective companies.
Printed on paper made of chlorine-free and acid-free bleached cellulose.
