GreenWorks GS 100 User manual

82V BRUSHLESS POLE SAW
GS 100
Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE: 1-855-470-4267
www.greenworkstools.com/82v-Commercial/
比例
1.00
0

2
CONTENTS
Contents .............................................................................................................................. 2
......................................................................................................... 2
Important Safety Instructions............................................................................................... 3
Symbols ............................................................................................................................... 9
Know Your Pole Saw...........................................................................................................11
Assembly .......................................................................................................................... 12
Operation............................................................................................................................15
Maintenance........................................................................................................................... 20
Environmentally Safe Battery Disposal..................................................................................27
Troubleshooting.......................................................................................................................28
Limited Warranty.................................................................................................................... 30
Exploded View ................................................................................................................... 31
Part List ..................................................................................................................................32
PRODUCT SPECIFICATIONS
82V BRUSHLESS POLESAW
Type ............................................................................................... Cordless, battery-powered
Motor ..................................................................................................................................82 V
Bar Length .............................................................................................................10" (254mm)
Chain Pitch .......................................................................................................1/4"LP (6.3 mm)
Chain Type ................................................................................................25AP058X (Oregon)
Guide Bar Type ......................................................................................100SDAA041(Oregon)
Length with Extension Pole...................................................................................................12'
Length without Extension Pole...............................................................................................8'
Weight .............................................................................................................11.25 lbs (5.1 kg)

3
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Read and understand all instructions before using this product. Failure to follow all
instructions listed below may result in electric shock, re, and/or serious personal injury.
When using electric gardening appliances, basic safety precautions should always be followed to
reduce the risk of re, electric shock, and personal injury, including the following:
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
ammableliquids,gases,ordust.Power tools create sparks which may ignite the dust or
fumes.
• Keep all children, bystanders, visitors, and animals out of the work area while starting or
cutting with the power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
• Do not expose the power tools to rain or wet locations. Water entering a power tool will
increase the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a residual current
device protected supply. Use of an RCD reduce the risk of electric shock.
• A battery-operated tool with integral batteries or a separate battery pack must be
rechargedonlywiththespeciedchargerforthebattery.A charger that may be suitable
for one type of battery may create a risk of re when used with another battery.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a power
tool.Donotuseapowertoolwhileyouaretiredorundertheinuenceofdrugs,alcohol
or medication. A moment of inattention while operating power tools may result in serious
personal injury.
• Usesafetyequipment.Alwaysweareyeprotection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will
reduce personal injuries.
• Avoid accidental starting. Ensure the switch is in the off-position before plugging in.
Carrying power tools with your nger on the switch or plugging in power tools that have the
switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situation.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
• If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of these devices can reduce dust-
related hazards.

4
IMPORTANT SAFETY INSTRUCTIONS
BATTERY USE AND CARE
• Ensure the switch is in the off position before inserting battery pack.
• Rechargeonlywiththechargerspeciedbythemanufacturer. A charger that is suitable for
one type of battery pack may create a risk of re when used with another battery pack.
• Usepowertoolsonlywithspecicallydesignatedbatterypacks. Use of any other battery
packs may create a risk of injury and re.
• When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws, or other small metal objects, that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns or a re.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
SERVICE
• Haveyourpolesawservicedbyaqualiedrepairpersonusingonlyidenticalreplacement
parts. This will ensure that the safety of the polesaw is maintained.
POWER USE AND CARE
• Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the battery pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
• Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the
power tool for operations different from those intended could result in a hazardous situation.
FOR ALL APPLIANCES
• Avoid Dangerous Environment. Don’t use appliances in damp or wet locations.
• Don’t Use In Rain.
• Keep Children Away. All visitors should be kept at a distance from work area
• Dress Properly. Do not wear loose clothing or jewelry. They can be caught in moving parts.
Use of rubber gloves and substantial footwear is recommended when working outdoors. Wear
protective hair covering to contain long hair.
• Don’t Overreach. Keep proper footing and balance at all times.
• Stay Alert. Watch what you are doing. Use common sense. Do not operate appliance when
you are tired.

5
• Use Safety Glasses. Always use face or dust mask if operation is dusty.
• Use Right Appliance. Do not use appliance for any job except that for which it is intended.
• Don’t grasp the exposed cutting blades or cutting edges when picking up or holding
the appliance.
• Don’t Force Appliance. It will do the job better and with less likelihood of a risk of injury at the
rate for which it was designed.
• Maintain Appliance With Care. Keep cutting edge sharp and clean for best performance and
to reduce the risk of injury. Follow instructions for lubricating and changing accessories. Inspect
appliance cord periodically, and if damaged, have it repaired by an authorized service facility.
Inspect extension cords periodically and replace if damaged. Keep handles dry, clean, and free
from oil and grease.
• Check Damaged Parts. Before further use of the appliance, a guard or other part that is
damaged should be carefully checked to determine that it will operate properly and perform its
intended function. Check for alignment of moving parts, binding of moving parts, breakage of
parts, mounting, and any other condition that may affect its operation. A guard or other part that
is damaged should be properly repaired or replaced by an authorized service center unless
indicated elsewhere in this manual.
• Store Idle Appliances Indoors – When not in use, appliances should be stored indoors in dry,
and high or locked-up place – out of reach of children.
• Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
battery pack, picking up or carrying the appliance. Carrying the appliance with your nger on
the switch or energizing appliance that have the switch on invites accidents.
FOR BATTERY-OPERATED APPLIANCES
• Do not charge appliance in rain, or in wet locations.
• Do not use battery-operated appliance in rain.
• When replacing batteries, all batteries should be replaced at the same time. Mixing
fresh and discharged batteries could increase internal cell pressure and rupture the discharge
battery(ies).
• When inserting batteries into this product, the proper polarity or direction must be
observed. Reverse insertion of batteries can result in leakage or explosion.
• Remove or disconnect battery before servicing, cleaning or removing material from the
gardening appliance.
• For use only with (GL 200, GL 250, GL 300, GL 400, GL 500, GL 900) battery. For use only
with GC 400 charger.
• Donotdisposeofthebattery(ies)inare.The cell may explode. Check with local codes for
possible special disposal instructions.
• If electrolyte contacts the skin, wash it off immediately with water.
• If electrolyte contacts the eyes, ush thoroughly and immediately with water. Seek
medical attention.
• Wear full eye protection and protective clothing.
• Do not open or mutilate the battery(ies). Released electrolyte is corrosive and may cause
damage to the eyes or skin. It may be toxic if swallowed.
IMPORTANT SAFETY INSTRUCTIONS

6
IMPORTANT SAFETY INSTRUCTIONS
SPECIFIC SAFETY WARNINGS
• Do not operate near electrical power lines. The unit has not been designed to provide
protection from electric shock in the event of contact with overhead electric lines. Consult local
regulations for safe distances from overhead electric power lines and ensure that the operating
position is safe and secure before operating the saw chain pole pruner.
• Use pole saw for cutting wood only. Do not use for cutting non-wood items.
• Make sure that the area in which you are cutting is free from obstructions. Do not let
the nose of the guide bar contact a log, branch, fence, or any other obstruction while you are
operating the unit. Have a planned retreat path.
• Keep all parts of the body away from the saw chain. Make sure the switch is off when
clearing jammed material. Saw chain continues to move after the switch is turned off. A
moment of inattention while operating the pole saw may result in serious personal injury.
• Carry the pole saw by the handle with the saw chain stopped. When transporting or storing
the pole saw, always t the saw chain device cover. Proper handling of the pole saw will reduce
possible personal injury from the saw chain.
• Hold the pole saw by insulated gripping surfaces only, because the cutter blade may
contact hidden wiring or its own cord. A saw chain contacting a "live" wire may make
exposed metal parts of the pole saw " live " and could give the operator an electric shock.
• Keep cable away from cutting area. During operation the cable may be hidden in shrubs and
can be accidentally cut by the saw chain.
• Do not operate the saw with one hand! Serious injury to the operator, helpers, bystanders,
or any combination of these persons may result from one hand operation. This saw is intended
for two-handed use.
• To reduce the risk of electrocution, never use near any electrical power lines. Contact
with or use near power lines may cause serious injury or electric shock resulting in death.
• Do not use the extended-reach pruner in bad weather conditions, especially when there
is a risk of lightning. This decreases the risk of being struck by lightning.
• To protect yourself from falling branches, do not stand directly under the branch or lamb
being cut. This unit should not be held at an angle over 60° from ground level.
• Use extreme caution when cutting small sized brush and saplings because slender
material may catch the saw chain and be whipped toward you or pull you off balance.
• When cutting a limb that is under tension, be alert for spring back so that you will not be
struckwhenthetensioninthewoodbersisreleased.
• Toavoidaccidentalstarting,nevercarrypluggedinproductwithngeronswitch.Be
sure switch is off when plugging in.
• Always use two hands when operating the pole saw. Hold the pole saw with both hands to
avoid loss of control.

7
• Always use head protection when operating the pole saw overhead. Falling debris can
result in serious personal injury.
• DANGER - Keep hands away from blades.
• When using in direct sunshine, keep out of water and don’t exposure to rain.
• Store indoors, and do not expose to rain or water, avoid direct sunshine.
• Use appliances only with specially designated battery packs. Use of any other battery
packs may create a risk of injury and re.
• Donotuseabatterypackorappliancethatisdamagedormodiedbatteriesmayexhibit
unpredictablebehaviorresultinginreexplosionorriskofinjury.
• Donotexposeabatterypackorappliancetoreorexcessivetemperature. Exposure
to re or temperature above 130°C may cause explosion. The temperature of 130°C can be
replaced by the temperature of 265°F.
• Follow all charging instructions and do not charge the battery pack or appliance
outsideofthetemperaturerangespeciedintheinstructions.Charging improperly or at
temperatures outside of the specied range may damage the battery and increase the risk of
re.
• Haveservicingperformedbyaqualiedrepairpersonusingonlyidenticalreplacement
parts. This will ensure that the safety of the product is maintained.
• Do not modify or attempt to repair the appliance or the battery pack (as applicable)
except as indicated in the instructions for use and care.
• Savetheseinstructions.Refertothemfrequentlyandusethemtoinstructotherswho
may use this product. If you loan someone this product, loan them these instructions also to
prevent misuse of the product and possible injury.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS

8
IMPORTANT SAFETY INSTRUCTIONS
W A R N I N G (PROPOSITION 65)
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically treated lumber.
Your risk of exposure to these chemicals varies depending on how often you do this type of work.
To reduce your exposure to these chemicals, work inven a well-ventilated area, and work with
approved safety equipment, such as dust masks that are specially designed to lter out microscopic
particles.
CHILD SAFETY
Tragic accidents can occur if the operator is not aware of the presence of children.
• Keep children out of the working area and under the watchful care of a responsible adult.
• Do not allow children under the age of 14 to operate this polesaw. Children who are 14
years of age and older must read and understand the operating instructions and safety
rules in this manual and must be trained and supervised by a parent.
• Stay alert, and turn the polesaw off if a child or any other person enters the working area.
• Use extreme care when approaching blind corners, doorways, shrubs, trees, or other
objects that may obscure your view of a child who may run into the path of the polesaw.
Kickback may occur when the moving chain contacts an object at the upper portion of the tip of the
guide bar or when the wood closes in and pinches the saw chain in the cut. Contact at the upper
portion of the tip of the guide bar can cause the chain to dig into the object and stop the chain for
an instant. The result is a lightning fast reverse reaction which kicks the guide bar up and back
toward the operator. If the saw chain is pinched along the top of the guide bar, the guide bar can
be driven rapidly back toward the operator. Either of these reactions can cause loss of saw control
which can result in serious injury. Do not rely exclusively upon the safety devices built into the saw.
As a polesaw user, you should take several steps to keep your cutting jobs free from accident or
injury.
CAUSES AND OPERATOR PREVENTION OF KICKBACK
• Maintainarmgrip,withthumbsandngersencirclingthepolesawhandles,with
both hands on the saw and position your body and arm to allow you to resist kickback
forces. Kickback forces can be controlled by the operator, if proper precautions are taken. Do
not let go of the polesaw.
• Onlyusereplacementbarsandchainsspeciedbythemanufacturer.Incorrect
replacement bars and chains may cause chain breakage and/or kickback.
• Follow the manufacturer’s sharpening and maintenance instructions for the saw chain
Decreasing the depth gauge height can lead to increased kickback.
• Push and Pull — This reaction force is always opposite to the direction the chain is moving
where contact is made with the wood. Thus, the operator must be ready to control the PULL
when cutting on the bottom edge of the bar, and the PUSH when cutting along the top edge.
KICKBACK

9
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.
SYMBOLS
SYMBOLS DESIGNATION EXPLANATION
V Volts
Voltage.
A Amperes Current.
Hz Hertz Frequency (cycles per second).
W Watts Power.
hrs Hours Time.
no No Load Speed Rotational speed, at no load.
/min Per Minute Revolutions, strokes, surface speed, orbits
etc., per minute.
Direct current Type or characteristic of current.
Safety Alert Symbol Precautions that involve your safety.
Read the Instruction
Manual.
To reduce the risk of injury, user must read
and understand the Instruction manual
before using this product.
Eye Protection
Wear Ear Protection
Eye and Head Protection Wear eye and head protection when
operating this equipment.
Gloves Wear non-slip, heavy-duty protective gloves
when handling the polesaw and the blade.
Safety Footwear Wear non-slip safety footwear when using this
equipment
Kickback DANGER! Beware of kickback.
One Handed Do not operate the saw using only one hand.
Risk of Electrocution DANGER! Risk of electrocution!
Keep Bystanders Away Keep all bystanders at least 50’ (15 m) away.
Wet Conditions AlertDo not expose to rain or use in damp
locations.
Wear eye protection when
operating this equipment.
Wear ear protection when
operating this equipment.

The following signal words and meanings are intended to explain the levels of risk associated
with this product.
SERVICE
Servicing requires extreme care and knowledge and should be performed only by a qualied
service technician. For service we suggest you return the product to your nearest AUTHORIZED
SERVICE CENTER for repair. When servicing, use only identical replacement parts.
DANGER Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.
SYMBOLS
SAVE THESE INSTRUCTIONS
10
SYMBOL SIGNAL MEANING
WARNING
The operation of any power tool can result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before operating a power tool, always wear safety goggles,
safety glasses with side shields, or a full face shield when needed. We recommend a Wide Vision
Safety Mask for use over eyeglasses or standard safety glasses with side shields. Always use eye
protection that is marked to comply with ANSI Z87.1.
WARNING
To avoid serious personal injury, do not attempt to use this product until you have read this
Owner’s Manual thoroughly and understand it completely. If you do not understand the warnings
and instructions in this Owner’s Manual, do not use this product. Call the Toll-free Helpline (1-
855-470-4267) for assistance.

11
KNOW YOUR POLE SAW
Read this operator's manual and safety rules before operating your polesaw. Compare the
illustration in Figure 1 to your polesaw in order to familiarize yourself with the location of various
controls and adjustments. Save this manual for future reference.
Fig.1
Polesaw
Extension Pole
Polesaw Handle
Scabbard
比例 1.000

12
ASSEMBLY
UNPACKING
This product requires assembly.
• Carefully remove the product and any accessories from the box. Make sure that all items
listed in the package contents section are included.
• Inspect the product carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily
operated the product.
• If any parts are damaged or missing, please call 1-855-470-4267 for assistance.
PACKING LIST
PART NAME FIGURE QTY
Power Head Pole 1
Extension Pole 1
Handle Pole 1
Wrench 1
Scabbard 1
Operator’s
manual 1
82V BURSHLESS POLE SAW
GS 100
Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE: 1-855-470-4267
www.greenworkstools.com/82v-Commercial/
比例
1
.0
00

13
WARNING
If any parts are damaged or missing, do not operate this product until the parts are replaced.
Using a product with damaged or missing parts could result in serious personal injury.
WARNING
Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modication is misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING
Do not insert the battery until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
ASSEMBLY
CONNECTING THE POLES
Before using the pole saw, assembly is required. When removed from the box, there are the
three poles as shown below.
• Set the unit on a at, level surface.
• Loosen the screw cap (1) on the coupler (2).
• Push in the button (3) located on the right shaft (4). Align the release button with the
positioning hole (5) with the direction of the arrow (6) and slide the two shafts together. Rotate
the lower shaft until the button locks into the positioning hole.
Fig.2
Fig.3
1
2
3
4
5
6

14
ASSEMBLY INSTRUCTION
WARNING
Do not allow familiarity with this product to make you careless. Remember that a careless fraction
of a second is sufcient to inict serious injury.
WARNING
Always wear safety goggles or safety glasses with side shields when operating power tools. Failure
to do so could result in objects being thrown into your eyes, resulting in possible serious injury.
WARNING
Do not use any attachments or accessories not recommended by the manufacturer of this product.
The use of attachments or accessories not recommended can result in serious personal injury.
Fig.4
APPLICATIONS
You may use this product for the purposes listed below:
• Limbing
• Pruning
Powerhead Pole
Extension Pole
Handle Pole

15
OPERATION
ADDING BAR AND CHAIN LUBRICANT
Use GREENWORKS Bar and Chain Lubricant. It is designed for chains and chain oilers, and is
formulated to perform over a wide temperature range with no dilution required.
NOTE: Pole saw comes from the factory with no bar and chain oil added. Level should also be
checked after every 30 minutes of use and relled as needed.
NOTE: It is normal for oil to seep from the saw when not in use. To prevent seepage, empty the oil
tank after each use then run for one minute. When storing the unit for a long period of time (three
months or longer) be sure the chain is lightly lubricated; this will prevent rust on the chain and bar
sprocket.
IMPORTANT
To preserve natural resources, please recycle or dispose of oil properly. Consult your local waste
authority for information regarding available recycling and/disposal options.
• Remove oil cap.
• Carefully pour the bar and chain oil into the tank.
• Wipe off excess oil.
• Check and ll the oil tank when there is no oil in the oil tank.
• Repeat as needed.
NOTE: Do not use dirty, used or otherwise contaminated oils. Damage may occur to the bar or
chain.
Fig.5
Oil Reservoir Cap

16
OPERATION
BATTERY PACK (See Figure 6)
IMPORTANT
The battery pack is not charged when it is purchased. Before using the pole saw for the rst
time, place the battery pack in the battery charger and charge it fully. Be sure to read all safety
precautions, and follow the instructions in the section entitled Charging Procedure. With regular
use, the battery will require shorter charging times. When storing the pole saw for a prolonged
period of time, remove the battery. When the pole saw is going to be used again, charge the battery
pack for at least a full charging period. This product has no memory effect.
REMOVING THE BATTERY PACK
• Press the latch button on the battery pack down and hold.
• Grasp the pole saw rmly, and pull the battery pack out of the handle.
NOTE: The battery pack ts into the handle snugly in order to prevent accidental dislodging. It may
require a strong pull to remove it.
INSTALLING THE BATTERY PACK
• Align the tongue of the battery pack with the cavity.
• Grasp the pole saw rmly.
• Push the battery pack into the handle until the latch locks into place.
• Do not use force when inserting the battery pack. It should slide into position and “click”.
Fig. 6

17
OPERATION
WARNING
• Replace the battery pack or the charger immediately if the battery case or charger cord is
damaged.
• Verify that the switch is in the OFF position before inserting or removing the battery pack.
• Verify that the battery pack is removed and the switch is in the OFF position before inspecting,
adjusting, or performing maintenance on any part of the pole saw.
• Read, understand, and follow the instructions contained in the section entitled Charging
Procedure.
Follow these instructions in order to avoid injury and to reduce the risk of electric shock or re:
IMPORTANT
This Lithium-ion battery pack is equipped with an internal circuit breaker which will automatically
shut off the power to the tool and then reset itself once cooled.
Follow these steps if an overload occurs while under heavy use:
1. Release the power switch and restart tool by depressing switch.
2. The battery may need to be removed for approximately 1 minute, allowed to cool and then
reinstalled for use.
STARTING AND STOPPING (See Figure 7)
TO START THE MOTOR:
• Fit the battery pack into the pole saw.
• Press and hold the switch lock. This makes the switch trigger operational.
• Press and hold the switch trigger, release the switch lock and continue to squeeze the switch
trigger for continued operation.
TO STOP THE MOTOR:
• Release the switch trigger.
Fig.7
Switch lock
Switch Trigger

18
OPERATION
PREPARATION FOR CUTTING (See Figure 8-9)
• Wear non-slip gloves for maximum grip and protection.
• Maintain a proper grip on the unit whenever the motor is running. Use your right hand to rmly
grip the rear handle while your left hand has a rm grip on the pole shaft.
• Hold unit rmly with both hands. Always keep your left hand on the pole shaft and your right
hand on the rear handle, so your body is to the left of the chain line. Never use a left-handed
(cross handed) grip, or any stance that places your body or arm across the chain line.
• Never stand directly under the limb you are cutting.
• Be certain the collars are fully tightened before operating equipment; check them periodically
for tightness during use to avoid serious injury.
BASIC CUTTING PROCEDURE
Follow the steps below to prevent damage to tree or shrub bark. Do not use a back-and-forth
sawing motion.
• Make a shallow rst cut (1/4 of limb diameter) on the underside of the limb close to the main
limb or trunk.
• Make a second cut from the top side of the limb outboard from the rst cut. Continue the cut
through the limb until the limb separates from the tree. Be prepared to balance the weight of
the tool when the limb falls.
• Make a nal cut close to trunk.
NOTE: For second and nal cuts (from top of limb or branch), hold front cutting guide against the
limb being cut. This will help steady the limb and make it easier to cut. Allow chain to cut for you;
exert only light down-ward pressure. If you force the cut, damage to the bar, chain, or motor can
result.
• Release the trigger as soon as the cut is completed. Failure to follow proper cutting
procedures will result in the bar and chain binding and becoming pinched or trapped in the
limb. If this should happen:
• Stop the motor and remove the battery from the pole saw.
• If the limb can be reached from the ground, lift the limb while holding the saw. This should
release the “pinch” and free the saw.
• If the saw is still trapped, call a professional for assistance.
Fig. 9Fig. 8
Second Cut
LOAD
Final Cut
First Cut
1/4 Diameter Cutting Guide

19
LIMBING AND PRUNING
This unit is designed for trimming small branches and limbs up to 6 in. (15.2 cm) in diameter. For
best results, observe the following precautions:
• Plan the cut carefully. Be aware of the direction in which the branch will fall.
• Branches may fall in unexpected directions. Do not stand directly under the branch being cut.
• The most typical cutting application is to position the unit at an angle of 60° or less, depending
on the specic situation. As the angle of the pole saw shaft to ground increases the difculty
of making the rst cut (from underside of limb) increases.
• Remove long branches in several stages.
• Cut lower branches rst to allow the top branches more room to fall.
• Work slowly, keeping both hands on the saw with a rm grip. Maintain secure footing and
balance.
OPERATION
• Keep the tree between you and the chain while limbing. Cut from the side of the tree opposite
of the branch you are cutting.
• Do not cut from a ladder; this is extremely dangerous. Leave this operation for professionals.
• Do not make the ush cut next to the main limb or trunk until you have cut off the limb further
out to reduce the weight.
• Following proper cutting procedures will prevent stripping the bark from the main member.
• Do not use the pole saw for felling or bucking.
• To prevent electrocution, do not operate within 50 ft. (15 m) of overhead electrical lines.
• Keep bystanders at least 50 ft. (15 m) away.
(15 m)

20
MAINTENANCE
WARNING
When servicing, use only identical replacement parts. Use of any other parts may create a hazard
or cause product damage.
WARNING
Always wear safety goggles or safety glasses with side shields during power tool operation or when
blowing dust. If operation is dusty, also wear a dust mask.
WARNING
Before inspecting, cleaning or servicing the unit, stop the motor, wait for all moving parts to stop,
and remove the battery. Failure to follow these instructions can result in serious personal injury or
property damage.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean cloths to
remove dirt, dust, oil, grease, etc.
WARNING
Do not at any time let brake uids, gasoline, petroleum-based products, penetrating oils, etc., come
in contact with plastic parts. Chemicals can damage, weaken, or destroy plastic, which may result
in serious personal injury.
All pole saw service, other than the items listed in the instruction manual maintenance instructions,
should be performed by competent pole saw service personnel. (For example, if improper tool is
used to hold the ywheel in order to remove the clutch, structural damage to the ywheel could
occur and subsequently could cause the ywheel to burst).
