Grieve LO-201C User manual

LABOVENS.INS.7-18.wpd 1 of 23 07/18
INSTRUCTIONS
LABORATORY OVENS
MAXIMUM
MODEL OPERATING TEMPERATURE
LO-201C 200EC
LR-271C 270EC
LW-201C 200EC

LABOVENS.INS.7-18.wpd 2 of 23 07/18
LABORATORY OVEN GENERAL INSTALLATION, OPERATION AND
MAINTENANCE INSTRUCTIONS FOR
MODELS LO-201C, LR-271C & LW-201C
TABLE OF CONTENTS
1 SHIPPING DAMAGE & HANDLING
2 PROPER OVEN APPLICATION
2-1 General
2-2 Flammable Solvents
2-3 Combustible Material
2-4 Personnel Hazards
2-5 Maintenance and Inspection
3 INSTALLATION
3-1 Location
3-2 Building Considerations
3-3 Clearances
3-4 Ventilation
3-5 Exhaust Ductwork
3-6 Thermometer
3-7 Electrical
4 PRIOR TO PLACING OVEN IN SERVICE
5 PROCESSING
6 SAFETY EQUIPMENT
7 MAINTENANCE
8 TROUBLE SHOOTING
9 APPENDIX A - REFERENCES
10 APPENDIX B - MINIMUM PERIODIC MAINTENANCE REPORT
11 APPENDIX C - PARTS LIST
12 APPENDIX D - WARRANTY AND LIMITATIONS OF REMEDIES
These GENERAL INSTRUCTIONS have been written for three models of ovens,
therefore, some components referred to may not be present on your particular piece of
equipment.

LABOVENS.INS.7-18.wpd 3 of 23 07/18
1 SHIPPING DAMAGE AND HANDLING
DO NOT RETURN DAMAGED MERCHANDISE TO US.
FILE YOUR CLAIM AS OUTLINED BELOW
This merchandise has been thoroughly inspected and carefully packed before leaving
our plant. Responsibility for its safe delivery was assumed by the carrier at the time of
shipment. Claims for loss or damage to the contents must be made with the carrier, as
follows:
1-1 VISIBLE LOSS OR DAMAGE
Any external evidence of loss or damage must be noted, at the time of delivery, on
the freight bill or express receipt and signed by the carrier's agent. Failure to
adequately describe such external evidence of loss or damage may result in the
carrier refusing to honor a damage claim. Make a written request for inspection by
the carrier's agent within fifteen days of the delivery date. Review the inspection
report and do not sign it unless it adequately describes the damage.
A claim must be filed with the carrier since such damage is the carrier's
responsibility.
1-2 CONCEALED LOSS OR DAMAGE
Concealed loss or damage means loss or damage which does not become
apparent until the merchandise has been unpacked. The contents may be
damaged in transit due to rough handling even though the carton may not show
external damage. When the damage is discovered upon unpacking, contact the
carrier and make a written request for inspection by the carrier's agent within
fifteen days of the delivery date. Review the inspection report and do not sign it
unless it adequately describes the damage.
A claim must be filed with the carrier since such damage is the carrier's
responsibility. By following these instructions carefully, we guarantee our full
support of your claims to protect you against loss from concealed damage.
1-3 RETURNING DAMAGED EQUIPMENT
Damaged equipment will not be accepted at our factory unless we have been
advised and instructions provided on how it should be returned. A copy of the
freight claim must be provided prior to returning the equipment.
1-4 HANDLING
After inspection, store and handle all equipment and components in their original
crates until ready for installation. Handle with care. The equipment may be heavy
but some components are of a delicate nature. If the equipment is to be stored,
keep it in the original crates and store in a location free from excessive dust, heat
and moisture until ready for installation.

LABOVENS.INS.7-18.wpd 4 of 23 07/18
2 PROPER OVEN APPLICATION
2-1 GENERAL
2-1.1 W hile ovens are extremely versatile, they are usually purchased with a specific
application in mind. If your process has changed significantly or if you should have
reason to doubt that a specific application is a proper use of the equipment, consult
the factory before proceeding.
2-1.2 Explanatory Material (Annex A1.1) of the National Fire Protection Association
Publication 86 "Standard for Ovens and Furnaces" states; in part:
"Explosions and fires in fuel-fired and electric heat utilization equipment constitute
a loss potential in life, property and production.@
AMost failures can be traced back to human error. The most significant failures
include inadequate training of operators, lack of proper maintenance, and improper
application of equipment."
2-1.3 To protect the oven, oven contents, property and personnel, a responsible person
should be in attendance during operation. Do not operate oven unattended.
Special attention must be paid to:
-Setting correct temperature.
-Placing flammable solvents in oven; these ovens are not designed for that
purpose.
-Placing combustibles in an oven that does not have adequate fire protection.
-Allowing the product to remain in the oven too long, thereby encouraging
combustion.
-Using an oven for a process other than that for which it was designed.
2-2 FLAMMABLE SOLVENTS
2-2.1 This oven is not equipped for handling flammable solvents. Do not place items
that produce flammable solvents or vapors in the oven, such as, but not limited to,
paint, ink, solder mask, adhesives or other coatings. Introduction of such items
into the oven may result in fire and/or explosion.
2-2.2 It shall be the user's responsibility to insure that flammable solvents are not placed
in the oven and the operating temperature does not exceed the maximum rated
temperature of the oven.
2-2.3 In areas outside of the oven where flammable solvents are given off by material
prior to entering the oven, provisions shall be made to exhaust these vapors to
atmosphere to prevent them from being pulled into the oven or collecting and
creating a flammable mixture.

LABOVENS.INS.7-18.wpd 5 of 23 07/18
2-3 COMBUSTIBLE MATERIAL
2-3.1 Introduction of combustible materials (such as paper, cardboard or wood) into the
oven should be avoided because it might cause a fire. Do not use combustible
racks, trays, holders, spacers, etc. Periodically, clean all combustible material
from non-combustible racks, trays, holders, spacers, etc. If combustible products
must be processed in an oven, extreme care must be taken to ensure that the
operating temperature does not exceed the ignition temperature of the product.
2-3.2 Ovens containing or processing sufficient combustible materials (including
consideration for combustible drippings or deposits) to sustain a fire shall either be
located in an area where a fire would not do damage or be equipped with an
automatic fire protection system including areas in exhaust ducts that could
accumulate combustible material. Fire protection systems should be installed in
accordance with the applicable National Fire Protection Guidelines:
-Sprinkler Systems in accordance with NFPA 13
-Water Spray Systems in accordance with NFPA 15
-Carbon Dioxide Extinguishing Systems in accordance with NFPA 12
-Foam Extinguishing Systems in accordance with NFPA 11
-Dry Chemical Extinguishing Systems in accordance with NFPA 17
-Water Mist Systems in accordance with NFPA 750
The extent of protection required will depend upon the construction and
arrangement of the oven as well as the materials handled. Fixed protection, such
as automatic sprinklers or other types of fire extinguishing systems, should be
designed and installed by a qualified contractor.
2-3.3 Drip pans shall be provided to collect any combustible materials that may
accumulate beneath the product. Drip pans must be a minimum of 2" above
perforated bottom of oven work space and allow 2" clearance around the edges. A
maintenance program must be developed to remove any such accumulation before
a dangerous build up occurs. If you cannot acquire drip pans locally, contact us for
a quotation.
2-4 PERSONNEL HAZARDS
1-3.1 Heat processing equipment must always be used with caution. Proper equipment
such as insulated gloves, safety goggles and tongs should be used for loading hot
equipment. Proper supervision is essential and only trained personnel should be
allowed to operate the oven.
Always remember you are working with elevated temperatures.
-Do not touch surfaces - they could be hot and burns could result.
-Do not breathe hot oven air. Heated air could burn lungs.
-Many items become dangerous when heat is applied. Explosion or fire
could result. Make sure you know what you are putting in the oven
can be heated safely at the oven operating temperature.
2-4.2 Disconnect power before servicing equipment by unplugging from electric outlet.
Ovens operate under high voltage and electrical shock is possible. Proper lockout
procedures should be followed.
2-4.3 Do not operate mechanical or electrical equipment with guards removed.
Operating with guards removed could result in bodily injury.

LABOVENS.INS.7-18.wpd 6 of 23 07/18
2-5 MAINTENANCE AND INSPECTION
2-5.1 Regularly scheduled inspection and maintenance of all safety devices shall be
performed by user. Failure to do this may result not only in fire or explosion
damage, but also contribute to accidental shutdowns and loss of production.
See Section 7 - AMaintenance@and Appendix B - AMinimum Periodic
Maintenance Report@.
2-5.2 Regularly scheduled inspection of the oven interior, heat chamber and
ductwork shall be performed by user to determine need for cleaning and repair.
Failure to do this may result in internal fires or component failure resulting in
oven damage and loss of production.
2-5.3 t shall be the sole responsibility of the user to establish, schedule and enforce
the frequency of and the extent of the inspection/maintenance program (as well
as the corrective action to be taken) because only the user can know what the
actual operating conditions are. Contact your insurance authority, Factory
Mutual or the National Fire Protection Association, whose addresses are listed
in Appendix B, for more information on inspection/maintenance programs.
2-6 RETROACTIVITY
This equipment has been designed and manufactured in accordance with applicable
National Codes in effect as of the date of manufacture. It is the responsibility of the end
user to update equipment as necessary to comply with future code changes. If you are in
doubt, contact manufacturer to review your equipment design against current National
Codes.

LABOVENS.INS.7-18.wpd 7 of 23 07/18
3INSTALLATION
3-1 LOCATION
3-1.1 Ovens shall be located to protect them from damage by external heat, vibration
and mechanical hazards.
3-1.2 Ovens shall be located to minimize exposure to power equipment, process
equipment and sprinkler risers. Unrelated stock and combustible materials shall
be maintained at a fire-safe distance but not less than 2-1/2 feet from an oven or
ductwork.
3-1.3 Ovens shall be located to minimize exposure to people from the possibility of injury
from fire, explosion, asphyxiation, and hazardous materials and shall not obstruct
personnel travel to exit ways.
3-1.4 Ovens shall be located to prevent an ignition source to flammable coating dip
tanks, spray booths, storage and mixing rooms for flammable liquids, or exposure
to flammable vapor or combustible dust clouds. Ovens should not be located in
hazardous (classified) locations unless they are designed to comply with the
applicable requirements of NFPA 70 ANational Electrical Code@(see Appendix A).
3-1.5 Equipment shall be protected from corrosive external processes and environments,
including fumes or materials from adjacent processes or equipment that produces
corrosive conditions when introduced into the oven environment.
3-1.6 The oven is not intended for outdoor installation and must be sheltered from
weather. Unheated shelters may result in non-uniform temperatures or insufficient
heat to attain maximum operating temperature. Condensation may also occur
which would be detrimental to the steel structure and electrical components.
3-1.7 Suitable portable fire extinguishers should be available and operators trained in
their use. All such fire protection equipment should be inspected periodically in
accordance with appropriate standards. Reference NFPA 10 AStandard for
Portable Fire Extinguishers@(see Appendix A).
3-2 BUILDING CONSIDERATIONS
3-2.1 When selecting the location for an oven, consideration must be given to the
possibility of fire, building damage and personal injury. Hazards to be considered
include overheating of material in the oven and escape of exhaust into the work
place.
3-2.2 Ovens should be placed on non-combustible surfaces.
3-3 CLEARANCES
3-3.1 Ovens shall be located with adequate space above and on all sides to allow
inspection and maintenance. Provisions also shall be included for the installation
of automatic sprinklers, if applicable.
3-3.2 Do not place the oven up against a wall. A minimum air space of 3" must be
provided on all sides to allow for air circulation, with additional space being
provided for ovens operating over 450EF (232EC) to keep temperature at adjacent
structures and materials below 160EF (71EC).

LABOVENS.INS.7-18.wpd 8 of 23 07/18
3-3.3 Do not store material on top of oven. The oven is not designed to carry exterior
loads. Also, material may get hot, ignite and cause a fire.
3-3.4 The oven doors have spring loaded latches which will allow the doors to open if
pressure develops in the oven. The door travel must not be restricted and should
face away from main aisles, work areas and automatic sprinkler risers, feeds and
cross mains.
3-4 VENTILATION
3-4.1 Where ovens are located in basements or enclosed areas, sufficient room
ventilation shall be supplied to prevent the hazardous accumulation of vapors from
processing.
3-4.2 Fresh air inlets and exhaust outlets must never be restricted.
3-5 EXHAUST DUCTWORK
3-5.1 The oven has vent holes in the top. If the oven vented air is to be collected and
ducted from the area, it must be in accordance with local codes and requirements.
Exhaust gas temperature is the same as internal oven temperature. Caution must
be taken to protect combustible building materials from coming in contact with the
hot exhaust stack.
3-5.2 Wherever oven ducts or stacks pass through combustible walls, floors or roof, non-
combustible insulation or clearance, or both, shall be provided to prevent
combustible surface temperatures from exceeding 160EF (71EC).
3-5.3 Where ducts pass through non-combustible walls, floors or partitions, the space
around the duct shall be sealed with non-combustible material to maintain the fire
resistance rating of the barrier. Ducts that pass through fire walls should be
avoided.
3-5.4 Ducts shall be constructed entirely of sheet steel or other non-combustible material
capable of meeting the intended installation and conditions of service. The
installation shall be of adequate strength and rigidity and shall be protected where
subject to physical damage.
3-5.5 Ducts handling fumes that leave a combustible deposit shall be provided with
clean-out doors and such doors should be equipped with tight fitting doors or
covers. It is important that ovens and ducts be kept clean if they are subjected to a
build-up of flammable deposits of dust or other combustible debris. The build-up of
condensed vapors or combustible debris is a major cause of fires. Frequency of
cleaning should be based on never allowing build-up to exceed 1/8" thickness in
any location.
3-5.6 No portions of the building shall be used as an integral part of the duct.
3-5.7 Ducts handling combustible solids shall be designed to minimize the accumulation
of solids within the ducts.
3-5.8 Exhaust ducts that will contain combustible deposits of any type require automatic
sprinklers.
3-5.9 Clearance between metal ducts and stored combustible material should be at least
2-1/2 feet. Guards should be installed to assure this clearance.

LABOVENS.INS.7-18.wpd 9 of 23 07/18
3-6 THERMOMETER
3-6.1 On all standard models a dial thermometer is included. Insert it into its spring steel
holder so that it extends at least three inches (3") into oven work space. The
thermometer can be installed through any of the vent ports in the top of the oven.
3-7 ELECTRICAL
3-7.1 All electrical connections should be made in accordance with the appropriate local
and national codes. Refer to NFPA 70 ANational Electric Code@(see Appendix A).
3-7.2 Properly size the electrical supply using information provided on the oven
nameplate. Electric supply must include a safety shut off such as a circuit breaker
or disconnect switch between your power supply and the equipment.
3-7.3 Where a plug is provided, it must not be removed or changed. A properly sized
circuit and receptacle must be installed.
3-7.3.1 120 Volt Units - Plug into grounded (3 prong) 120 volt outlet. Do not
remove ground prong from plug. If no grounded outlet is available,
have one installed prior to using this equipment.
3-7.3.2 240 Volt Units - A plug suitable for use with your existing 240 volt
receptacle must be installed on the cord provided. Make sure that
your existing receptacle and the plug installed provide a secure
ground.
3-7.4 The oven must be adequately grounded. Where a plug is provided, do not remove
the ground prong. Grounding wire must be sized in accordance with local codes.
Where more strict codes do not exist, refer to the NFPA 70 ANational Electrical
Code@(see Appendix A).

LABOVENS.INS.7-18.wpd 10 of 23 07/18
4PRIOR TO PLACING THE OVEN IN SERVICE
4-1 Read instruction manual completely.
4-2 After the installation is completed, replace all covers and guards that had been
removed for installation. At no time should equipment be operated if covers or
guards are open, removed or partially closed.
4-3 Check incoming voltage against that shown on the nameplate.
4-4 Check operating current against nameplate rating.
4-5 All ovens will produce smoke and odors when first heated. The smoke and odors
come from three sources:
1) Surfaces that have not been heated during test such as shelves
2) Binders that remain in the insulation
3) Moisture that has been absorbed by the insulation.
If during the initial run of the oven, the smoke and odors become objectionable, set
the temperature at 300EF and allow the oven to remain at 300EF until the smoke is
no longer generated. Increase the temperature in steps until you=ve reached the
maximum operating temperature. It may take several days of running at the
maximum operating temperature to eliminate all smoke and odors.
If the oven is not heated for an extended time period, moisture may accumulate in
the insulation. When heated, this moisture will be driven out and the above process
may have to be repeated.
4-6 Personnel operating, maintaining or supervising shall be instructed and trained in
their job functions and be required to demonstrate an understanding of the
equipment, its operation and safe operating procedures including emergency
shutdown.
4-7 Equipment shall be operated in accordance with original design parameters.
4-8 Personnel operating, maintaining or supervising shall be informed of the danger of
removing, or rendering ineffective, safety devices.

LABOVENS.INS.7-18.wpd 11 of 23 07/18
5PROCESSING
5-1 DO NOT LEAVE THIS EQUIPMENT IN OPERATION UNATTENDED
When using any heat processing equipment there is always the risk of overheating
due to a component malfunction. A trained operator should always be present. If
this is not possible, the oven should be located where overheating will not cause
damage to the building, adjacent stock or endanger personnel. Special
consideration should be made for the potential of smoke damage should a fire
ensue. Fire suppression equipment should be installed to protect the oven and
building.
5-2 When loading an oven care must be taken to avoid touching or insulating the
thermocouple or temperature sensor. Free air movement around this sensor is
essential for safe and correct temperature control.
5-3 Do not overload the oven. Air circulation is very important to the proper operation of
an oven. For maximum uniformity, the work should be placed in the middle of the
oven work space and room (1" to 1-1/2") left around the work for vertical air
movement.
5-4 The inside walls of the oven are equipped with perforated strips and clips to adjust
the shelf height to the most desirable height for your process. However, do not place
the bottom shelf closer than 2" from the perforated oven bottom.
5-5 This oven is designed for shelf loading, parts must not be placed on heat chamber
guard at bottom of work space. This surface could be hotter than air temperatures
and it is not designed to support a load. Do not cover heat chamber guard at bottom
of work space as this will trap heat in the heat chamber and result in excessive
temperature in heat chamber.
5-6 Leave space between articles on each shelf to allow air to move between parts.
5-7 Parts should be staggered from one shelf to another, to prevent dead spots in the air
pattern.
5-8 For drying applications, the air circulation damper should be fully open to allow
moisture to escape and be replaced by dry room air. For maximum temperature,
close the air circulation damper to reduce heat losses. In the medium and lower
temperature ranges of the oven, better temperature uniformity will be obtained with
the circulation damper open.
5-9 To turn oven on, push top of on-off switch in. When the oven is not in use, the on-off
switch must be turned OFF - bottom pushed in. Do not rely on the thermostat to
interrupt power to the heating elements indefinitely.
5-10 EMERGENCY SHUT DOWN:
-press power switch to "OFF" - bottom pushed in
-unplug oven
-disconnect power to oven at disconnect switch or circuit breaker

LABOVENS.INS.7-18.wpd 12 of 23 07/18
5-11 TEMPERATURE CONTROL
5-11.1 The thermostat is marked with numbers for reference only and does NOT indicate
the oven temperature. To obtain the desired temperature, make a trial setting of
the thermostat and observe the actual oven temperature as shown by the
thermometer. Allow the oven to cycle several times, as indicated by the red pilot
light, before making a new trial setting of the thermostat. A few trial settings will
show you the approximate position of the thermostat for various temperatures.
5-11.2 Do not attempt to operate your laboratory oven at temperatures above the
maximum rating of the oven. Higher temperature units are available Cplease
contact the factory for information.
5-12 OVER TEMPERATURE PROTECTION
5-12.1 Units rated up to 200EC are equipped with a one time excess temperature limit
interlock. Operating these ovens at temperatures above their maximum rating or
restricting free movement of the heated air from the heat chamber (located below
the perforated bottom of the oven work space) will result in these devices opening
the circuit to the heating elements. These devices are NOT resettable and must
be replaced. They are located within the heat chamber (under the heat chamber
guard at the bottom of the workspace) connected to one terminal of the thermostat.
5-12.2 Units rated to 270EC have a manual reset excess temperature limit interlock. This
interlock is reset by pushing in the red button located at the rear of the oven. This
excess temperature limit interlock will NOT reset until oven temperature is well
below maximum operating temperature.
5-12.3 Do not operate oven without a functional heat limiter or an excess temperature
interlock. Do not bypass or otherwise defeat the excess temperature interlock.

LABOVENS.INS.7-18.wpd 13 of 23 07/18
6SAFETY EQUIPMENT
6-1 Practically all explosions and fires in ovens can be traced back to human error. It
should be noted that:
6-1.1 For the protection of personnel and property, careful consideration should be given
to the supervision and monitoring of conditions that could cause, or could lead to, a
real or potential hazard on any installation.
6-1.2 The presence of safety equipment on an installation cannot, in itself, ensure
absolute safety of operation.
6-1.3 There is no substitute for a diligent, capable, well-trained operator.
6-1.4 Highly repetitive operational cycling of any safety device can reduce its life span.
6-2 Thermostats, switches and electric relays should not be used as substitutes for
electrical disconnects or unplugging equipment.
6-3 Regularly scheduled inspection, testing, and maintenance of all safety devices shall
be performed. (See Section 7 - Maintenance and Appendix B - Minimum Periodic
Maintenance Report)
6-4 Safety devices shall not be removed or rendered ineffective by bypassing them
electrically or mechanically.
6-5 All units are equipped with an excess temperature limit interlock. Operating at
temperatures above the setting of this device will result in opening the circuit to the
heating elements. These devices must be replaced or reset before power will be
restored to the heating elements. These devices are installed to protect the oven
from a runaway condition. It is the users responsibility to monitor any product in the
oven if over-heating can cause damage to the product or cause a fire. The cause of
over-heating should be determined and corrected before processing is continued.
Do not remove or bypass excess temperature limit interlock.
6-5.1 One-time excess temperature limit interlock (standard on Models LO-201C and
LW-201C) is installed in series with the oven thermostat. If the oven runs over
maximum temperature, the excess temperature limit interlock will open the circuit
to the heating elements. The excess temperature limit interlock and lead wire must
be replaced after this happens. The excess temperature limit interlock cannot be
reset.
6-5.2 Non-adjustable manual reset excess temperature limit interlock (standard on Model
LR-271C) will trip at approximately 50EF above the maximum operating
temperature of the oven. This device is reset by depressing the red button located
on the rear of the oven.
6-6 No matter how much safety equipment is provided on the oven, it cannot protect the
operator, other personnel or property from unsafe conditions caused by poor
judgement or misapplication. Common sense must be used for safe operation. If in
doubt, contact the factory. Check the process periodically to ensure oven is being
used as originally intended.

LABOVENS.INS.7-18.wpd 14 of 23 07/18
7 MAINTENANCE
7-1 For safe oven operation, a preventative maintenance program must be developed
and followed for each individual oven application. The user should review
recommendations from their insurance underwriters. We suggest the review of
Factory Mutual (FM) Specification 6-9 on Industrial Ovens and Dryers and the
National Fire Protection Association (NFPA) Specification 86 on Ovens and
Furnaces. W e also recommend a Maintenance Report be developed which lists
tests and inspections performed. A copy of this report should be kept on file for
future review. At a minimum, the unit should be fully inspected annually.
A Minimum Periodic Maintenance Report is provided in Appendix B as an example
for developing your own periodic maintenance schedule and report.
7-2 Disconnect electric power and any other energy source before servicing equipment.
Ovens operate under high voltage and electrical shock is possible. Proper OSHA
required lockout procedures should be followed.
7-3 Removing the heat chamber guard at the bottom of the work space will expose high
voltage connections. Do not operate with this guard, or any other mechanical or
electrical components that have guards, removed. Operating with guards removed
could result in bodily injury.
7-4 RECOMMENDED MAINTENANCE ITEMS:
It shall be the sole responsibility of the user to establish, schedule and enforce the
frequency of and the extent of the inspection/maintenance program (as well as the
corrective action to be taken) because only the user can know what the actual
operating conditions are. The tests should be made by personnel who are familiar
with the equipment. It is usually better that maintenance personnel from mechanical
and electrical departments check the equipment rather than regular oven operators.
These additional hands and eyes may catch things that may be otherwise
overlooked.
The following are minimum maintenance items we recommend be covered. Your list
will vary depending upon the specific oven and operating conditions.
7-4.1 Application
7-4.1.1 The user is responsible to insure that the oven process has not changed from
the conditions for which it was originally purchased and that the oven is not
modified. It is the user=s responsibility to ensure that flammable solvents are
not placed in the oven and the operating temperature does not exceed the
maximum design temperature.
7-4.2 Electrical
7-4.2.1 Inspect power cord and plug for damage; repair or replace as necessary.
7-4.2.2 Periodically inspect contacts in open thermostats for foreign matter, signs of
wear, or sticking; clean or replace as necessary.

LABOVENS.INS.7-18.wpd 15 of 23 07/18
7-4.3 Oven Body
7-4.3.1 Do not allow accumulation of combustible material or other foreign matter in
the work space, heat chamber (including heating elements) ductwork, air
inlets, vent outlets, control enclosures, door latches, and door hinges. Care
must be taken in cleaning any combustible build-up to avoid creating a
source of ignition (spark). Scraping with non-sparking tools is suggested.
Lint and dust should be removed by vacuum cleaning. Blowing with
compressed air or steam should be avoided if there is a possibility of
explosion from a combustible dust cloud.
7-4.3.2 Do not allow accumulation of combustible material on work holders, drip
pans or on floor of oven.
7-4.3.3 Temperature control and excess temperature control sensing bulb or bi-
metal must be inspected periodically for damage. Location of these cannot
be changed.
7-4.4 Duct Work
7-4.4.1 It is important ovens be kept clean. If they are subjected to a build-up of
combustible deposits of dust or other combustible debris they must be
periodically cleaned. The build-up of condensed vapors or combustible
debris is a major cause of fires.
7-4.5 Doors/Gaskets
7-4.5.1 The oven doors should be inspected regularly to see that latches are
holding the door firmly and uniformly against the oven providing a maximum
sealing force.
7-4.5.2 The door should be inspected for damage which would allow excessive
leakage of hot air. The gasket (applicable to LR-271C only) should be
replaced when damaged or when an adequate seal cannot be maintained.
7-4.5.3 The door and associated spring loaded latches should be checked
periodically.
7-4.6 Temperature Control
7-4.6.1 Run oven at predetermined setting and compare temperature at
thermometer to previous tests. Significantly higher temperatures could
indicate temperature controller is failing.
7-4.7 Location
7-4.7.1 The user is responsible to determine that facility changes in the vicinity of
the oven have not created a hazardous condition. Specifically, the oven
should be protected from external heat, vibration, mechanical hazards and
corrosive environment.

LABOVENS.INS.7-18.wpd 16 of 23 07/18
7-4.7.2 Processes involving flammable liquids or creating explosive vapor or
combustible dust clouds must not be located near the oven.
7-4.7.3 Portable fire extinguishers located in the vicinity of the oven must be
inspected periodically.
7-4.7.4 Fire suppression system installed in the oven should be periodically tested.
All sprinkler heads in oven or located in work area should be periodically
inspected and cleaned.

LABOVENS.INS.7-18.wpd 17 of 23 07/18
8 TROUBLE SHOOTING
8-1 NO HEAT
8-1.1 Oven Has Run Over-temperature.
For Model LO-201C and LW -201C, check continuity of heat limiter (one time
thermal fuse) and replace it if there is no continuity through the heat limiter.
Heat limiter is located in one of the wires leading to the thermostat. This wire is
covered with a radiant shield that must cover the heat limiter for correct
operation.
For Model LR-271C, reset excess temperature limit interlock (after oven has
cooled) by pressing red reset button located on rear of oven. If excess
temperature limit interlock will not reset, it needs to be replaced.
8-1.2 On/Off Switch
Check for defective switch.
8-1.3 Fuse Burned Out or Circuit Breaker Tripped
Make sure there is power at the oven.
8-1.4 Burned Out Heating Element
Check that there is power to each heating element and that elements are not
open.
8-2 REDUCED OVEN TEMPERATURE
8-2.1 Excessive Exhaust
The amount of heated air removed from the oven may be excessive and result
in a reduced operating temperature. In this case, the oven heat will be running
continuously. This can be corrected by reducing the exhaust until the
maximum operating temperature is achieved.
8-2.2 Door Leakage
Poorly adjusted door or damaged door gaskets (Model LR-271C only) could
result in excessive heat loss around the doorway. Adjust door and/or repair
gasket.
8-2.3 Improper Line Voltage
Voltage at the oven should be measured to determine if an excessive line drop
is causing reduced power input to the heating elements on an electrically
heated oven. This could be caused by too many devices connected to the
same circuit or by undersized wiring between the oven and the power source.
Measure the voltage with the oven heating elements on and all other
equipment on the same circuit operating.

LABOVENS.INS.7-18.wpd 18 of 23 07/18
8-3 WIRING DIAGRAMS:
Do not operate oven without a functioning heat limiter or manual reset excess
temperature interlock. Do not bypass or otherwise defeat the heat limiter or manual
reset excess temperature interlock.

LABOVENS.INS.7-18.wpd 19 of 23 07/18
9 APPENDIX A - REFERENCES
The following sources of additional information are referenced in these instructions. This is
not presented as a complete list of all possible reference sources.
9.1 Factory Mutual Engineering Corporation
1151 Boston-Providence Turnpike
P.O. Box 9102
Norwood, Massachusetts 02062
Attn: Publications Order Processing
Specifications 6-9, Industrial Ovens and Dryers
9.2 National Fire Protection Association
One Batterymarch Park
Quincy, Massachusetts 02209-9101
Most current issue of:
NFPA 86 - Ovens and Furnaces
NFPA 70 - National Electric Code
NFPA 10 - Standard for Portable Fire Extinguishers
NFPA 11 - Standard for Low-Expansion Foam
NFPA 12 - Standard on Carbon Dioxide Extinguishing Systems
NFPA 13 - Standard for the Installation of Sprinkler Systems
NFPA 14 - Standard for the Installation of Standpipe and Hose Systems
NFPA 15 - Standard for Water Spray Fixed Systems for Fire Protection
NFPA 17 - Standard for Dry Chemical Extinguishing Systems
NFPA 17A-Standard for Wet Chemical Extinguishing Systems
NFPA 25 - Standard for the Inspection, Testing and Maintenance of W ater-
Based Fire Protection Systems
NFPA 30 - Flammable and Combustible Liquids Code

LABOVENS.INS.7-18.wpd 20 of 23 07/18
10 APPENDIX B - MINIMUM PERIODIC LABORATORY OVEN INSPECTION REPORT
Model: _________________________________________________ Serial No.: _________________
Inspected By: ___________________________________________ Date: _________________
BEFORE APPLYING POWER CHECK THAT:
1. ____ No changes in process have been made including types of materials processed and
temperature:
-Oven originally purchased for (reference previous Inspection Report): ______________
______________________________________________________________________
______________________________________________________________________
-Oven being used for: ____________________________________________________
______________________________________________________________________
______________________________________________________________________
2. ____ No flammable solvents are involved in process.
3. ____ All thermostats with open contacts have been inspected for foreign matter, wear or
sticking.
4. ____ Oven interior inspected, cleaned, and all foreign matter removed from:
________ Floor
________ Heat chamber (including heating elements)
________ Control enclosure and components
________ Door hinges
5. ____ Remove and clean all drip pans. Inspect and clean all work racks, trays, holders or
spacers.
6. ____ Locate temperature controller sensors and inspect for damage. Make sure sensor is in
free air and not touching anything.
7. ____ On Models LO and LW : Locate heat limiter in lead to thermostat to make sure it is
present. This lead is covered with a radiant shield that must be present for correct
operation.
On Model LR: Locate manual reset excess temperature limit interlock sensor, inspect for
damage and make sure located in free air.
8. ____ Inspect heating elements for contamination, distortion and adequate support.
9. ____ Doors are free to move and not obstructed.
10. ____ Exhaust ductwork from oven (if applicable) has been inspected and cleaned; all foreign
matter removed.
11. ____ Inspect door latches and check for freedom of movement.
APPLY POWER AND CHECK:
12. ____ Supply voltage agrees with oven nameplate - measure and record: ____________.
13. ____ Set oven at number _____, temperature on thermometer fluctuates from _____ to
_____. Compare to previous test report.
