Grimmen GR-MO251 User manual

GR-MO251
HARMONY WITH FUTURE
Full Smart
Microwave SolarDom
Full Smart Microwave SolarDom

SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Turntable Installation
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If
glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
Grill Rack( Only be used in grill function
and be placed on the glass tray )
10
Remove the oven and all
materials from the carton
and oven cavity.
Your oven comes with the
following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Grill Rack
( Only be used in grill functionand
be placed on the glass tray )
a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring as-
sembly must always be used during cook-
ing.
c. All food and containers of food are al-
ways placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest au-
thorized service
center
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
Grill Rack( Only be used in grill function
and be placed on the glass tray )
10

(a) Do not attempt to operate this oven with the door open since this can result in
harmful exposure to microwave energy. It is important not to break or tamper with the
safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not be operated
until it has been repaired by a competent person.
Addendum
If the apparatus is not maintained in a good state of cleanliness, its surface could be
degraded and affect the lifespan of the apparatus and lead to a dangerous situation.
Important Safety Instructions Warning
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive
microwave oven energy when using your appliance, follow basic precautions, including
the following:
1. Warning: Liquids and other foods must not be heated in sealed containers since
they are liable to explode.
2. Warning: It is hazardous for anyone other than a competent person to carry out any
service or repair operation that involves the removal of a cover which gives protection
against exposure to microwave energy.
3. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and knowl-
edge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children unless they
are older than 8 and supervised.
4. Keep the appliance and its cord out of reach of children less than 8 years.
5. Only use utensils that are suitable for use in microwave
6. The oven should be cleaned regularly and any food deposits should be removed.
7. Read and follow the specific:”PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY”.
8. When heating food in plastic or paper containers, keep an eye on the oven due to
the the possibility of ignition.
9. If smoke is emitted, switch off or unplug the appliance and keep the door closed in
order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage purposes. Do not store items, such as
Precautions To Avoid Possible Exposure To
Excessive Microwave Energy

bread, cookies, etc. inside the oven.
12. Remove wire twist-ties and metal handles from paper or plastic containers/bags
before placing them in the oven.
13. Install or locate this oven only in accordance with the installation instructions pro-
vided.
14. Eggs in the shell and whole hard-boiled eggs should not be heated in microwave
ovens since they may explode, even after microwave heating has ended.
15.This appliance is intended to be used in household and similar applications such as:
-staff kitchen areas in shops, offices and other working environments;
-by clients in hotels, motels and other residential type environments;
-farm houses;
-bed and breakfast type environments.
16. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
17. Do not store or use this appliance outdoors.
18. Do not use this oven near water, in a wet basement or near a swimming pool.
19. The temperature of accessible surfaces may be high when the appliance is operat-
ing. The surfaces are liable to get hot during use. Keep cord away from heated surface,
and do not cover any vents on the oven.
20. Do not let cord hang over edge of table or counter.
21. Failure to maintain the oven in a clean condition could lead to deterioration of the
surface that could adversely affect the life of the appliance and possibly result in a haz-
ardous situation.
22.The contents of feeding bottles and baby food jars shall be stirred or shaken and the
temperature checked before consumption, in order to avoid burns.
23. Microwave heating of beverages can result in delayed eruptive boiling, therefore
care must be taken when handling the container.
24.The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
25.Children should be supervised to ensure that they do not play with the appliance.
26.The appliances are not intended to be operated by means of an external timer or
separate remote-control system.
27.Accessible parts may become hot during use. Young children should be kept away.
28.Steam cleaner is not to be used.
29.During use the appliance becomes hot. Care should be taken to avoid touching
heating elements inside the oven.
30.Only use the temperature probe recommended for this oven.(for ovens provided
with a facility to use a temperature-sensing probe.)
31. WARNING: The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less than 8 years of age
shall be kept away unless continuously supervised.
32.The microwave oven must be operated with the decorative door open. (for ovens
with a decorative door.)
33.The rear surface of appliance shall be placed against a wall.

34.The microwave oven must not be placed in a cabinet.
35.The microwave oven is intended for heating food and beverages.Drying of food or
clothing and heating of warming pads,slippers,sponges,damp cloth and similar may
lead to risk of injury,ignition or fire.
36. Metallic containers for food and beverages are not allowed during microwave cook-
ing.
To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard Touching some of the internal components can cause serious
personal injury or death. Do not disassemble this appliance.
WARNING
Electric Shock Hazard Improper use of the gro unding can result in electric shock. Do
not plug into an outlet until appliance is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit,grounding
reduces the risk of electric shock by providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is properly installed and grounded Consult
a qualified electrician or serviceman if the grounding instructions are not completely
understood or if doubt exists as to whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a 3-wire 1. A short power-supply
cord is provided to reduce the risks resulting from becoming entangled in or tripping
over a longer cord.
2. If a long cord set or extension cord is used:
1)The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance.
2)The extension cord must be a grounding-type 3-wire cord.
3)The long cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally.

Cleaning
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a
damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door
glass since they can scratch the surface, which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the food cooked can touch:
Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on 100% microwave
power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
Utensils
Caution
Personal Injury Hazard It is hazardous for anyone other than a compentent person to
carry out any service or repair operation that involves the removal of a cover which gives
protection against exposure to microwave energy.
See the instructions on “Materials you can use in microwave oven or to be avoided in
microwave oven.”
There may be certain non-metallic utensils that are not safe to use for microwaving. If in
doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil
in question.
2. Cook on maximum power for 1 minute. 3. Carefully feel the utensil. If the empty uten-
sil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.

Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking. Arcing can occur if foil is too
close to oven walls. The foil should be at least 1 inch (2.5cm) away from
oven walls.
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
9

Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such
as dents or broken door. Do not install if oven is damaged.
Installation
1.Select a level surface that provide enough
open space for the intake and/or outlet
vents.
(1) The minimum installation height is 85cm.
(2) The rear surface of appliance shall be
placed against a wall.
Leave a minimum clearance of 30cm
above the oven, a minimum clearance of
20cm
is required between the oven and any ad-
jacent walls.
(3) Do not remove the legs from the bottom of the oven.
(4) Blocking the intake and/ or outlet openings can damage the oven.
(5) Place the oven as far away from radios and TV as possible. Operation of microwave
oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the fre-
quency is the same as the voltage and the frequency on the rating label.
WARNING:
Do not install oven over a range cooktop or other heat-producing appliance. If installed
near or over a heat source, the oven could be damaged and the
warranty would bevoid.
The accessible surface may be hot during operation.
Operation Instruction
This microwave oven uses modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
1.Select a level surface that
provide enough open space
for the intake and/or outlet
vents.
(1) The minimum installation
height is 85cm.
(2) The rear surface of
appliance shall be placed
against a wall.
Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm
is required between the oven
and any adjacent walls.
(3) Do not remove the legs
from the bottom of the oven.
(4) Blocking the intake and/
or outlet openings can
damage the oven.
(5) Place the oven as far
away from radios and TV
as possible. Operation of
microwave oven may
cause interference to your
radio or TV reception.
2. Plug your oven into a
standard household outlet.
Be sure the voltage and
the frequency is the same
as the voltage and the
frequency on the rating
label.
WARNING: Do not install
oven over a range cooktop
or other heat-producing
appliance. If installed near
or over a heat source, the
oven could be damaged
and the warranty would be
void.
20cm
30cm
20cm
min85cm
0cm
The accessible
surface may be
hot during operation.
11
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
1.Select a level surface that
provide enough open space
for the intake and/or outlet
vents.
(1) The minimum installation
height is 85cm.
(2) The rear surface of
appliance shall be placed
against a wall.
Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm
is required between the oven
and any adjacent walls.
(3) Do not remove the legs
from the bottom of the oven.
(4) Blocking the intake and/
or outlet openings can
damage the oven.
(5) Place the oven as far
away from radios and TV
as possible. Operation of
microwave oven may
cause interference to your
radio or TV reception.
2. Plug your oven into a
standard household outlet.
Be sure the voltage and
the frequency is the same
as the voltage and the
frequency on the rating
label.
WARNING: Do not install
oven over a range cooktop
or other heat-producing
appliance. If installed near
or over a heat source, the
oven could be damaged
and the warranty would be
void.
20cm
30cm
20cm
min85cm
0cm
The accessible
surface may be
hot during operation.
11

This microwave oven uses modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
OPERATION INSTRUCTION
Cooking
Turn " " to adjust the cooking time. (The maximum cooking time is 95 minutes.)
Pressthe " key to start cooking.
1) In standby state, press the "
" to select the microwabe power.
Note: The
Turn "
CONFIRM/+30S/START " to confirm the power.
Microwave
microwave power can be chosen from P10 to P1.
MICROWAVE" once, the screen will display "P10"
2)
"
CONFIRM/+30S/START
2) Turn " " to adjust the hour figures, the input time should be within 0--23(24-hour).
3) Press " CLOCK/KITCHEN TIMER ", the minute figures will flash.
5) Press " CLOCK/KITCHEN TIMER
1) Press " CLOCK/KITCHEN TIMER " once. "00 00" displays, and the hour figures will
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
1.Clock Setting
flash.
" to finish clock setting.
2. Kitchen Timer
CLOCK/KITCHEN TIMER "twice, the screen will display 00 00.
" to confirm setting.
Note: The kitchen Time is differ from 24-hour system,Kitchen Timer is a timer.
CONFIRM/+30S/START
3.
1) Press "
2) Turn " " to enter the correct timer.(The maximum cooking time is 95 minutes.)
3) Press "
3) Press the "
4)
5)
12
Convection Cooking (With preheating function)
The convection cooking can let you to cook the food as a traditional oven. Microwave is not
used. It is recommended that you should preheat the oven to the appropriate temperature
before placing the food in the oven.
1) In standby state, press the "
" to select the convection temperature.
Note: The temperature can be chosen from 140 to 230 .
4) Press the " " to start preheating. When the preheating
temperature arrives, the buzzer will sound to remind you to put the food into the
And the preheated temperature is displayed and flashes.oven.
5) Put the food into the oven and close the door.
Turn " " to adjust the cooking time.
6) Pressthe " key to startcooking.
Turn "
"
C
o
C
oC
o
CONVECTION/COMBI."once, the screen will display " "
140
" to confirm the temperature.
CONFIRM/+30S/START
CONFIRM/+30S/START
CONFIRM/+30S/START
Level
Power
Display
10
100%
P10
8
80%
P8
5
50%
P5
3
30%
P3
1
10%
P1
Note:If half the grill time passes, the oven sounds twice to tell you to turn the food over.
You can just leave continue working. But in order to have a better effect of grilling
food, you should turn the food over, close the door, and then press
work
Cooking
Grill
1) In standby state, press the "GRILL" button once, the screen will display "G".
Turn " " to adjust the cooking time. (The maximum cooking time is 95 minutes.)
Pressthe " key to startcooking.
"
CONFIRM/+30S/START
2)
3)
" " continue cooking. If no operation, the oven will
CONFIRM/+30S/START
automatically.
4.
5.
2)
3) Press the "
13

Convection Cooking (With preheating function)
The convection cooking can let you to cook the food as a traditional oven. Microwave is not
used. It is recommended that you should preheat the oven to the appropriate temperature
before placing the food in the oven.
1) In standby state, press the "
" to select the convection temperature.
Note: The temperature can be chosen from 140 to 230 .
4) Press the " " to start preheating. When the preheating
temperature arrives, the buzzer will sound to remind you to put the food into the
And the preheated temperature is displayed and flashes.oven.
5) Put the food into the oven and close the door.
Turn " " to adjust the cooking time.
6) Pressthe " key to startcooking.
Turn "
"
C
o
C
oC
o
CONVECTION/COMBI."once, the screen will display " "
140
" to confirm the temperature.
CONFIRM/+30S/START
CONFIRM/+30S/START
CONFIRM/+30S/START
Level
Power
Display
10
100%
P10
8
80%
P8
5
50%
P5
3
30%
P3
1
10%
P1
Note:If half the grill time passes, the oven sounds twice to tell you to turn the food over.
You can just leave continue working. But in order to have a better effect of grilling
food, you should turn the food over, close the door, and then press
work
Cooking
Grill
1) In standby state, press the "GRILL" button once, the screen will display "G".
Turn " " to adjust the cooking time. (The maximum cooking time is 95 minutes.)
Pressthe " key to startcooking.
"
CONFIRM/+30S/START
2)
3)
" " continue cooking. If no operation, the oven will
CONFIRM/+30S/START
automatically.
4.
5.
2)
3) Press the "
13
Convection Cooking (With preheating function)
The convection cooking can let you to cook the food as a traditional oven. Microwave is not
used. It is recommended that you should preheat the oven to the appropriate temperature
before placing the food in the oven.
1) In standby state, press the "
" to select the convection temperature.
Note: The temperature can be chosen from 140 to 230 .
4) Press the " " to start preheating. When the preheating
temperature arrives, the buzzer will sound to remind you to put the food into the
And the preheated temperature is displayed and flashes.oven.
5) Put the food into the oven and close the door.
Turn " " to adjust the cooking time.
6) Pressthe " key to startcooking.
Turn "
"
C
o
C
oC
o
CONVECTION/COMBI."once, the screen will display " "
140
" to confirm the temperature.
CONFIRM/+30S/START
CONFIRM/+30S/START
CONFIRM/+30S/START
Level
Power
Display
10
100%
P10
8
80%
P8
5
50%
P5
3
30%
P3
1
10%
P1
Note:If half the grill time passes, the oven sounds twice to tell you to turn the food over.
You can just leave continue working. But in order to have a better effect of grilling
food, you should turn the food over, close the door, and then press
work
Cooking
Grill
1) In standby state, press the "GRILL" button once, the screen will display "G".
Turn " " to adjust the cooking time. (The maximum cooking time is 95 minutes.)
Pressthe " key to startcooking.
"
CONFIRM/+30S/START
2)
3)
" " continue cooking. If no operation, the oven will
CONFIRM/+30S/START
automatically.
4.
5.
2)
3) Press the "
13
Note:
a. Cooking time cannot be input until the preheating temperature arrives. If the tempera-
ture arrives, door must be opened to input the cooking time.
b. If the time not input in 5 minutes, the oven will stop preheating. The buzzer sounds
4 times and turn back to standby state.
Note:
If half the grill time passes, the oven sounds twice to tell you to turn the food over.
You can just leave continue working. But in order to have a better effect of grilling food,
you should turn the food over, close the door, and t h e n press “ C O N F I R M / + 3 0
S / S T A R T “ continue cooking. If no operation, the oven will work automatically.

Cooking
Turn " " to adjust the cooking time. (The maximum cooking time is 95 minutes.)
Pressthe " key to startcooking.
1) In standby state, press the "
" to select the combi. cooking mode from C-1 to C-4.
Turn "
CONFIRM/+30S/START " to confirm the selection.
2)
"
CONFIRM/+30S/START
Combi.
CONVECTION/COMBI." twice, the screen will display "C-1"
Instructions Microwave Grill
Display Convection
1
2
3
4
C-1
C-2
C-3
C-4
Note: Combination instructions
n Cooking ( Without pre-heating function)
1) In standby state, press the "
" to select the convection temperature.
Note: The temperature can be chosen from 140 to 230 .
urn " "" to adjust the cooking time.
Pressthe " key to startcooking.
Turn "
"
C
o
C
oC
o
CONVECTION/COMBI."once, the screen will display " "
140
" to confirm the temperature.
CONFIRM/+30S/START
CONFIRM/+30S/START
4)T
2)
3) Press the "
5)
Note: a. Cooking time cannot be input until the preheating temperature arrives.
If the temperature arrives, door must be opened to input the cooking time.
The buzzer soundsb. If the time not input in 5 minutes, the oven will stop preheating.
4 times and turn back to standby state.
6.Convectio
7.
3) Press the "
4)
5)
14
10. Auto Menu
Note: When you choose A
The oven needs to be preheated to 160 degree first. After sevarel minutes, the buzzer
sounds twice to remind you to put the cake into the oven. After putting the cake in the oven,
please press" "again. The timer will count down, and the cake will
1) In waiting state, press " AUTO MENU" once, the screen will display "A1"
and "A1","A2","A3"...."A10" will be
" to confirm the menu you need.
" to start cooking.
If half the 2/3 grill time pass in roast chicken, the oven sounds twice to tell you
to turn the food over.
displayed.
CONFIRM/+30S/START
CONFIRM/+30S/START
1) Press " " key twice, the oven will display "d
2) Turn " " to select the cooking time. The maximum setting time is 95 minutes.
3) Press " " key to start defrosting.
1) Press " " pad once,the oven will display "d
3) Press " " key to start defrosting.
2) Turn " " to select the weight of food.At the same time.
The weight should be 100g-2kg.
1",.
2"
DEFROST
DEFROST
CONFIRM/+30S/START
CONFIRM/+30S/START
8. Defrost by W.T.
9. Defrost by Time
8 cake, please do not put the cake into the oven at the begining.
2) Turn " " to choose the menu you want,
3) Press "
4) Turn " " to choose the weight of menu,and "g" indicator will light.
5) Press "
15
CONFIRM/+30S/START
be cooked perfectly.

10. Auto Menu
Note: When you choose A
The oven needs to be preheated to 160 degree first. After sevarel minutes, the buzzer
sounds twice to remind you to put the cake into the oven. After putting the cake in the oven,
please press" "again. The timer will count down, and the cake will
1) In waiting state, press " AUTO MENU" once, the screen will display "A1"
and "A1","A2","A3"...."A10" will be
" to confirm the menu you need.
" to start cooking.
If half the 2/3 grill time pass in roast chicken, the oven sounds twice to tell you
to turn the food over.
displayed.
CONFIRM/+30S/START
CONFIRM/+30S/START
1) Press " " key twice, the oven will display "d
2) Turn " " to select the cooking time. The maximum setting time is 95 minutes.
3) Press " " key to start defrosting.
1) Press " " pad once,the oven will display "d
3) Press " " key to start defrosting.
2) Turn " " to select the weight of food.At the same time.
The weight should be 100g-2kg.
1",.
2"
DEFROST
DEFROST
CONFIRM/+30S/START
CONFIRM/+30S/START
8. Defrost by W.T.
9. Defrost by Time
8 cake, please do not put the cake into the oven at the begining.
2) Turn " " to choose the menu you want,
3) Press "
4) Turn " " to choose the weight of menu,and "g" indicator will light.
5) Press "
15
CONFIRM/+30S/START
be cooked perfectly.
10. Auto Menu
Note: When you choose A
The oven needs to be preheated to 160 degree first. After sevarel minutes, the buzzer
sounds twice to remind you to put the cake into the oven. After putting the cake in the oven,
please press" "again. The timer will count down, and the cake will
1) In waiting state, press " AUTO MENU" once, the screen will display "A1"
and "A1","A2","A3"...."A10" will be
" to confirm the menu you need.
" to start cooking.
If half the 2/3 grill time pass in roast chicken, the oven sounds twice to tell you
to turn the food over.
displayed.
CONFIRM/+30S/START
CONFIRM/+30S/START
1) Press " " key twice, the oven will display "d
2) Turn " " to select the cooking time. The maximum setting time is 95 minutes.
3) Press " " key to start defrosting.
1) Press " " pad once,the oven will display "d
3) Press " " key to start defrosting.
2) Turn " " to select the weight of food.At the same time.
The weight should be 100g-2kg.
1",.
2"
DEFROST
DEFROST
CONFIRM/+30S/START
CONFIRM/+30S/START
8. Defrost by W.T.
9. Defrost by Time
8 cake, please do not put the cake into the oven at the begining.
2) Turn " " to choose the menu you want,
3) Press "
4) Turn " " to choose the weight of menu,and "g" indicator will light.
5) Press "
15
CONFIRM/+30S/START
be cooked perfectly.
Note:
When you choose A8 cake, please do not put the cake into the oven at the begining.
The oven needs to be preheated to 160 degree first. After sevarel minutes, the buzzer
sounds twice to remind you to put the cake into the oven. After putting the cake in the
oven, please press” CONFIRM/+30S/START “again. The timer will count down, and the
cake will be cooked perfectly.
If half the 2/3 grill time pass in roast chicken, the oven sounds twice to tell you to
turn the food over.

Auto menu Chart
Menu
Weight
Display
Power
A1
AUTO REHEAT
150g
150
100%
250g
250
350g
350
450g
450
600g
600
A2 POTATO
1 (about 230g)
1
100%
2 (about 460g)
2
3 (about 690g)
3
A3
MEAT
150g
150
100%
300g
300
450g
450
600g
600
A4 VEGETABLE
150g
150
100%
350g
350
500g
500
A5
FISH
150g
150
80%
250g
250
350g
350
450g
450
650g
650
A6
PASTA
50g(with 450g cold water)
50
80%
100g(with 800g coldwater)
100
150g(with 1200g cold water)
150
A7
SOUP
200ml
200
100%
400ml
400
600ml
600
A8
CAKE
475g
475
Preheat to
160℃
A9
PIZZA
200g
200
C-4
300g
300
400g
400
A10
CHICKEN
500g
500
C-4
750g
750
1000g
1000
1200g
1200
16
Auto Menu Chart

11. Healthy Fry
1) In waiting state, press " HEALTHY FRY" once, the screen will display "H1"
and "H1","H2","H3"...."H9" will be
" to start cooking.
displayed.
CONFIRM/+30S/START
ChartHealthy Fry menu
1) In standby state, press " " to start cooking with 100%
each added press will increase 30 seconds cooking time up
2) In microwave, grill, combination combi. cooking state , each
" " can increase 30 seconds of cooking time.
12. Quick start
CONFIRM/+30S/START
power for 30 seconds,
to minutes94 and 59 seconds. Then press " " to start cooking
CONFIRM/+30S/START
CONFIRM/+30S/START
"" key to cook with 100% microwave power.
3) In waiting state, turn " " left to choose cooking time directly then press
CONFIRM/+30S/START
2) Turn " " to choose the menu you want,
3) Press "
Note: this fun ction canno t work und er w ei g ht defrost auto menu cookin g.
, and time defrost
press of
or
17
Note: When you choose Healthy Fry function
The oven needs to be preheated first. After sevarel minutes, the buzzer sounds
twice to please
press" "
, please do not put the food into the oven at
remind you to put the into the oven. After putting the in the oven,food food
again. The timer will count down, and the will be cooked
perfectly.
food
the begining.
CONFIRM/+30S/START
NO Menu Temp.( )
H1
H2
H3
H4
H5
H6
H7
H8
H9
Frozen French fries
Frozen Potato croquettes
Frozen Squid
Frozen Onion rings
Frozen Chicken nuggets
Escalope
Shrimps
Vegetable
Spring rolls
210
230
230
200
230
200
200
230
230
Weight(g)
50-150
100-300
100-300
100-200
100-300
100-300
100-300
100-300
100-300
℃
1
Lock: In standby state, press "STOP for 3 seconds, there will be a long "beep"
denoting entering into the children-lock state and the lock indicator will light. The screen
Lock quitting: In locked state, press "STOP for 3 seconds, there will be a long "beep"
denoting that the lock is released, and indicator will disapear.
/CANCEL"
will enter to initial state.
/CANCEL"
1 . Special Specifications
programmer has been set , " pressed in " is not
the lock
CONFIRM/+30S/START
5 minutes. The screen will enter to
Once the cooking
4. Lock-out Function for Children
5
standby state.
18
In standby state, press" ECO "once , the screen goes off. Press any button to thelight
screen again.
13. ECO Function
11. Healthy Fry
1) In waiting state, press " HEALTHY FRY" once, the screen will display "H1"
and "H1","H2","H3"...."H9" will be
" to start cooking.
displayed.
CONFIRM/+30S/START
ChartHealthy Fry menu
1) In standby state, press " " to start cooking with 100%
each added press will increase 30 seconds cooking time up
2) In microwave, grill, combination combi. cooking state , each
" " can increase 30 seconds of cooking time.
12. Quick start
CONFIRM/+30S/START
power for 30 seconds,
to minutes94 and 59 seconds. Then press " " to start cooking
CONFIRM/+30S/START
CONFIRM/+30S/START
"" key to cook with 100% microwave power.
3) In waiting state, turn " " left to choose cooking time directly then press
CONFIRM/+30S/START
2) Turn " " to choose the menu you want,
3) Press "
Note: this fun ction canno t work und er w ei g ht defrost auto menu cookin g.
, and time defrost
press of
or
17
Note: When you choose Healthy Fry function
The oven needs to be preheated first. After sevarel minutes, the buzzer sounds
twice to please
press" "
, please do not put the food into the oven at
remind you to put the into the oven. After putting the in the oven,food food
again. The timer will count down, and the will be cooked
perfectly.
food
the begining.
CONFIRM/+30S/START
NO Menu Temp.( )
H1
H2
H3
H4
H5
H6
H7
H8
H9
Frozen French fries
Frozen Potato croquettes
Frozen Squid
Frozen Onion rings
Frozen Chicken nuggets
Escalope
Shrimps
Vegetable
Spring rolls
210
230
230
200
230
200
200
230
230
Weight(g)
50-150
100-300
100-300
100-200
100-300
100-300
100-300
100-300
100-300
℃
11. Healthy Fry
1) In waiting state, press " HEALTHY FRY" once, the screen will display "H1"
and "H1","H2","H3"...."H9" will be
" to start cooking.
displayed.
CONFIRM/+30S/START
ChartHealthy Fry menu
1) In standby state, press " " to start cooking with 100%
each added press will increase 30 seconds cooking time up
2) In microwave, grill, combination combi. cooking state , each
" " can increase 30 seconds of cooking time.
12. Quick start
CONFIRM/+30S/START
power for 30 seconds,
to minutes94 and 59 seconds. Then press " " to start cooking
CONFIRM/+30S/START
CONFIRM/+30S/START
"" key to cook with 100% microwave power.
3) In waiting state, turn " " left to choose cooking time directly then press
CONFIRM/+30S/START
2) Turn " " to choose the menu you want,
3) Press "
Note: this fun ction canno t work und er w ei g ht defrost auto menu cookin g.
, and time defrost
press of
or
17
Note: When you choose Healthy Fry function
The oven needs to be preheated first. After sevarel minutes, the buzzer sounds
twice to please
press" "
, please do not put the food into the oven at
remind you to put the into the oven. After putting the in the oven,food food
again. The timer will count down, and the will be cooked
perfectly.
food
the begining.
CONFIRM/+30S/START
NO Menu Temp.( )
H1
H2
H3
H4
H5
H6
H7
H8
H9
Frozen French fries
Frozen Potato croquettes
Frozen Squid
Frozen Onion rings
Frozen Chicken nuggets
Escalope
Shrimps
Vegetable
Spring rolls
210
230
230
200
230
200
200
230
230
Weight(g)
50-150
100-300
100-300
100-200
100-300
100-300
100-300
100-300
100-300
℃
Note:
When you choose Healthy Fry function , please do not put the food into the oven at
the begining. The oven needs to be preheated first. After sevarel minutes, the buzzer
sounds twice to remind you to put the food into the oven. After putting the food in the
oven, please press “ CONFIRM/+30S/START “ again. The timer will count down, and
the food will be cooked perfectly.
Note:
this function cannot work under weight defrost or auto menu cooking.

1
Lock: In standby state, press "STOP for 3 seconds, there will be a long "beep"
denoting entering into the children-lock state and the lock indicator will light. The screen
Lock quitting: In locked state, press "STOP for 3 seconds, there will be a long "beep"
denoting that the lock is released, and indicator will disapear.
/CANCEL"
will enter to initial state.
/CANCEL"
1 . Special Specifications
programmer has been set , " pressed in " is not
the lock
CONFIRM/+30S/START
5 minutes. The screen will enter to
Once the cooking
4. Lock-out Function for Children
5
standby state.
18
In standby state, press" ECO "once , the screen goes off. Press any button to thelight
screen again.
13. ECO Function
1
Lock: In standby state, press "STOP for 3 seconds, there will be a long "beep"
denoting entering into the children-lock state and the lock indicator will light. The screen
Lock quitting: In locked state, press "STOP for 3 seconds, there will be a long "beep"
denoting that the lock is released, and indicator will disapear.
/CANCEL"
will enter to initial state.
/CANCEL"
1 . Special Specifications
programmer has been set , " pressed in
" is not
the lock
CONFIRM/+30S/START
5 minutes. The screen will enter to
Once the cooking
4. Lock-out Function for Children
5
standby state.
18
In standby state, press" ECO "once , the screen goes off. Press any button to thelight
screen again.
13. ECO Function
According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be
separately collected and treated. If at any time in future you need to dispose of this product
please do NOT dispose of this product with household waste. Please send this product to
WEEE collecting points where available.
Trouble shooting
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
It is forbidden to run the unit without any food inside.
It is very dangerous.
19
Trouble shooting
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
It is forbidden to run the unit without any food inside.
It is very dangerous.
19

www.grimmenhome.com
