Groov-e GV-TT03 User manual

1
GV-TT03
MUSIC CENTRE
CD/MP3 PLAYER WITH TURNTABLE
STEREO RADIO AND USB ENCODING
INSTRUCTION MANUAL

2
IMPORTANT SAFETY INSTRUCTIONS:
1.Read the instructions. All uses guidelines must be read before start device.
2. Keep the instructions for future use.
3.Attention, use and security guidelines must be respected.
4. The device must not be used near water or be put in contact with moisture.
5. Make sure has no liquid is spilled on device and device openings.
6. Move device carefully, avoid shocks.
7. Do not block the breakdown of the device outputs.
8. Do not place the device near from a heat source (e.g. radiator). Do not expose it to the Sun.
9. Plug the device as indicate on this information form.
10. This device has a connection with overload protection (security device) decision-making. If the
replacement of decision-making is required, please you send has an experienced or the device
manufacturer technician.
11. For cleaning the device, please follow the recommendations of the notice.
12. The sector cord should be unplugged a long period of use.
13. Device shall be repaired by a qualified person when:
a. the taken or the power cord is damaged,
b. objects have falleninto the apparatus or a liquid has been spilled into device,
c. device was exposes to the rain,
d. device does not work correctly without notable exterior change,
e. device fell and the subwoofer is broken.
14. The user shall not try to maintain device beyond that which is described in this information
form. The guarantee would negate.

3
BATTERY INSTALLATION
The battery compartment is located on the back of the remote control.
1. Remove the battery compartment door by pressing in on the tab and lifting it off.
2. Insert two (2) AAA size batteries (not included) into the battery compartment following the
polarity markings inside the battery compartment.
3. Replace the battery compartment door.
Battery Precautions
Replacement of batteries must be done by an adult.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium) batteries.
The supply terminals are not to be short-circuited.
Non-rechargeable batteries are not to be recharged.
Exhausted batteries are to be removed.
Only batteries of the equivalent type are to be used.
Batteries are to be inserted with the correct polarity.
Dispose of batteries properly. Do not dispose of batteries in fire. The
batteries may explode or leak.

4
LOCATION OF CONTROLS
1) DUST COVER
2) DIAL POINTER
3) LEFT SPEAKER
4) LCD DISPLAY
5) FM STEREO LED INDICATOR
6) REMOTE SENSOR
7) CD DOOR
8) USB SOCKET
9) VOLUME KNOB
10) X-BASS CONTROL BUTTON
11) RECORD BUTTON
12) REPEAT/INTRO/RANDOM BUTTON
13) RIGHT SPEAKER
14) TUNING KNOB
15) CD DOOR OPEN BUTTON
16) SOURCE BUTTON
17) FM MODE SELECTOR
18) POWER OFF/FUNCTIONS SELECTOR
19) 3.5 MM HEADPHONE JACK
20) CD PLAY/PAUSE/STOP BUTTON
21) CD SKIP UP /DOWN BUTTON
22) MP3 FOLDER UP BUTTON
23) SPINDLE ADAPTOR
24) TURNTABLE SPEED SELECTOR
25) AUTO STOP SWITCH
26) PICK-UP HOLDER
27) LINE OUT SOCKET
28) FM ANTENNA
29) AC CORD
CAUTION:
USAGE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULTE IN HAZARDOUS RADIATION EXPOSURE.
THIS UNIT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT QUALIFIED SERVICE
PERSONNEL.
PRECAUTIONS FOR USE
INSTALLATION
UNPACK ALL PARTS AND REMOVE PROTECTIVE MATERIAL.
DO NOT CONNECT THE UNIT TO THE MAINS BEFORE CHECKING THE MAINS VOLTAGE AND BEFORE
ALL OTHER CONNECTIONS HAVE BEEN MADE.
DO NOT COVER ANY VENTS AND MAKE SURE THAT THERE IS A SPACE OF SEVERAL CENTIMETERS
AROUND THE UNIT FOR VENTILATION.
CONNECTION
1. CONNECT THE POWER CORD (29) TO AC OUTLET
2. SWITCH THE FUNCTION SELECTOR (18) TO “TUNER “ FUNCTION. IF THE BACKGROUND OF DIAL SCALE
LIGHT UP WITH AMBER LIGHT, IT’S MEAN THE POWER SUPPLY IS NORMAL. NOW YOUR SYSTEM IS
READY TO PLAY THE MUSIC.
LISTENING TO RADIO
MANUAL TUNING
1. SWITCH THE FUNCTION SELECTOR (18) TO “ TUNER “ FUNCTION.
2. TUNE TO THE REQUIRED STATION BY TURNING THE TUNING KNOB (14).
3. ADJUST VOLUME KNOB(9) TO THE DESIRE VOLUME LEVEL.

5
FM & FM-STEREO RECEPTION
SET THE FM MODE SELECTOR (17) AT “ FM ” POSITION. PROGRAMS ARE RECEIVED IN MONO MODE. IN
PARTICULAR WHEN STEREO SIGNAL ARE WEAK. IT IS PREFERABLE TO RECEIVE THE PROGRAM IN
MONO.
SET THE FM MODE SELECTOR (17) AT “FM-ST” POSITION FOR RECEIVING STEREO PROGRAMS. THE
FM-STEREO LED INDICATOR (5) WILL LIGHT UP TO SHOW FM STEREO PROGRAM IS RECEIVING.
HINTS FOR BEST RECEPTION:-
- FM : THE RECEIVER HAS A BUILT-IN FM WIRE ANTENNA HANGING AT THE REAR CABINET. THIS WIRE
SHOULD BE TOTALLY UNRAVELED AND EXTENDED FOR BEST RECEPTION.
PLAYING COMPACT DISC
GETTING START
1. TURN FUNCTION SELECTOR(18) TO SELECT “ CD/USB ” MODE.
2. PRESS “OPEN/CLOSE” BUTTON (15) TO OPEN THE CD DOOR (7).
3. PLACE A CD WITH THE PRINTED SIDE FACING UP INSIDE THE TRAY & THEN CLOSE THE CO DOOR.
4. FOCUS SEARCH IS PERFORMING, THE LCD DISPLAY (4) WILL SHOW THE TOTAL NUMBER OF TRACKS &
TOTAL PLAYING TIME.
PLAY / PAUSE / STOP MODE
1. PRESS THE “PLAY/PAUSE/STOP” BUTTON (20) TO START PLAYBACK, THE FIRST TRACK WILL START
PLAYBACK.
2. TO INTERRUPT, PRESS THE “PLAY/PAUSE/STOP” BUTTON (20) ONCE, THE PLAYING TIME WILL BE
FREEZE & FLASHING ON THE LCD DISPLAY (4). PRESS AGAIN TO RESUME NORMAL PLAYBACK.
3. IF PRESS AND HOLD THE “ PLAY / PAUSE STOP “ BUTTON (20) FOR OVER 2 SECONDS DURIGN
PLAYBACK MODE. THESYSTEM WILL GO TO STOP MODE.
SKIP/SEARCH MODE (SKIP/SEARCH UP / SKIP/SEARCH DOWN )
1. DURING PLAY OR PAUSE MODE, IF “SKIP UP” BUTTON (3) IS PRESSED. IT WILL GO TO NEXT TRACK AND
DISPLAY THE TRACK NO. AND THEN REMAIN THE PLAY OR PAUSE MODE.
2. DURING PLAY OR PAUSE MODE, IF “SKIP DOWN” BUTTON (3) IS PRESSED. IT WILL GO BACK TO THE
BEGINNING OF THE TRACK, ORIGINAL TRACK NO. IS DISPLAY AND REMAIN THE PLAY OR PAUSE MODE.
3. AFTER STEP 2, PRESS “SKIP DOWN” BUTTON (3) AGAIN WILL GO TO THE PREVIOUS TRACK AND
REMAIN THE PLAY OR PAUSE MODE.
4. IF PRESS AND HOLD THE “ SKIP UP/DOWN BUTTON “ (3) DURING CD/MP3 PLAYABCK, THE PLAYING
TRACK WILL GO FAST FORWARD OR BACKWARD UNTIL THE BUTTON BEING RELEASED.
FOR MP3 DISC
1. PRESS “ FOLDER “ BUTTON (22), THE FOLDER NO. WILL GOES UP
2. PRESS “ SKIP UP “ OR SKIP DOWN (21) BUTTON, THE TRACK NO. CHANGE.
3. WHEN THE DESIRED TRACK IS BEING SELECTED, PRESS THE CD “PLAY/PAUSE/STOP ” BUTTON (20) TO
START PLAYBACK.
ID3 (TRACK/ALBUM TITLE) FUNCTION (BY REMOTE HANDSET)
1. PRESS THE “ INFO“ BUTTON DURING PLAYBACK OF MP3/WMA DISC, THE SONG TITLE IS BEING
DISPLAYED. PRESS THE “ INFO ” BUTTON AGAIN TO DISABLE THE FUNCTION.
MP3 TRACK FORMAT REQUIREMENT:-
- MP3 BIT RATE : 32 KBPS~256 KBPS.
- THE PERFORMANCE OF PLAYING MP3 DISC IS VARIOUS FROM THE QUALITY OF RECORDING DISC AND
THE METHOD OF RECORDING. FURTHERMORE, THE SEARCHING LEAD-TIME FOR MP3-CD IS LONGER
THAN NORMAL CD DUE TO DIFFERENCE FORMAT.

6
REPEAT/INTRO/RANDOM MODE
PRESS THE REPEAT/INTRO/RANDOM BUTTON BEFORE OR DURING PLAYBACK, A SINGLE TRACK, SINGLE
FOLDER (MP3 ONLY) OR ALL THE TRACKS CAN BE PLAYED IN DIFFERENCE MODE AS FOLLOW:-
FOR CD
(1) REPEAT 1 (2) REPEAT ALL TRACK (3) INTRO (4) RANDOM (5) OFF MODE
INDICATOR
PLAY MODE ON LCD DISPLAY
REPEAT TRACK
REPEAT ALL ALL
INTRO INTRO
RANDOM RANDOM
OFF MODE --------------
FOR MP3 DISC
(1) REPEAT 1 (2) REPEAT ALLTRACKS (3) REPEAT 1 FOLDER
(6)OFFMODE (5)RANDOM (4) INTRO PLAY
INDICATOR
PLAY MODE ON LCD DISPLAY
REPEAT SINGLE TRACK
REPEAT ALL TRACKS ALL
REPEAT SINGLEFOLDER
INTRO PLAY MODE INTRO
RANDOM MODE RANDOM
OFF MODE -----------------
REPEAT PLAY
YOU CAN LISTEN TO THE DESIRED TRACKS OR FOLDER REPEATEDLY BY THIS FUNCTION.
INTRO PLAY (BY REMOTE CONTROL)
YOU CAN LISTEN THE BEGINNING (10 SECONDS) OF EACH TRACK IN A CD BY THIS FUNCTION & SAVING
YOUR TIME TO SEARCH THE DESIRE SONG
RANDOM PLAY
YOU CAN LISTEN ALL THE TRACKS OR FOLDER IN A RANDOM ORDER BY THIS FUNCTION
CD DISC PROGRAMMING (BY REMOTE CONTROL)
UP TO 32 TRACKS CAN BE PROGRAMMED FOR CD FILE AND PLAY IN ANY ORDER. BEFORE USE, BE SURE
THE SYSTEM IS AT STOP MODE BEFORE PROGRAMMING:-
1. SET IN CD/USB MODE & STOP THE CD PLAYBACK.
2. PRESS THE “PROGRAM” BUTTON, “ PROG“ WILL APPEAR ON LCD DISPLAY (4).MOREOVER, IT WILL
INDICATE PROGRAM NO. AND DIGITS FOR TRACK NO. TO BE PROGRAMMED.
3. SELECT A DESIRED TRACK BY PRESSING SKIP OR BUTTONS (21).
4. PRESS THE“ PROGRAM ” BUTTON TO STORE THE TRACE INTO MEMORY.
5. REPEAT STEPS 3 AND 4 TO ENTER ADDITIONAL TRACKS INTO THE MEMORY IF NECESSARY.
6. WHEN ALL THE DESIRED TRACKS HAVE BEEN PROGRAMMED, PRESS CD “ PLAY/PAUSE/STOP ”
BUTTON (20) TO PLAY THE DISC IN ASSIGNED ORDER.
7. TO CANCEL THE PROGRAMMED FILE, PRESS “STOP” BUTTON ON REMOTE HANDSET UNTIL “ PROG “ IS
DISAPPEAR ON LCD DISPLAY (4)

7
PLAYBACK OF MP3 SONG VIA USB STORAGE MEDIA
CONNECTING
THE SYSTEM IS ABLE TO DECODE AND PLAYBACK ALL MP3FILE WHICH STORED IN THE MEMORY MEDIA
WITH USB CONNECTING PORT.
1. SET FUNCTION SELECTOR (18) AT CD/USB MODE AND THEN PRESS
SOURCE BUTTON (16) TO SELECT “ USB ” MODE.
2. PLUG-IN THE USB PLUG WITH THE FACE UP & MAKE SURE IT GOING
INTO COMPLETELY. INSERT STRAIGHT WITHOUT BENDING.
CONNECTING THE USB UPSIDE DOWN OR BACKWARDS COULD
DAMAGE THE AUDIO SYSTEM OR THE STORAGE MEDIA. CHECK TO BE
SURE THE DIRECTION IS CORRECT BEFORE CONNECTION.
3. THE SYSTEM WILL START READING THE STORAGE MEDIA
AUTOMATICALLY AFTER CONNECTING, AND LCD DISPLAY (4) WILL
SHOW THE TOTAL NUMBER OF MP3 FILES AND TOTAL NUMBER OF
FOLDER BEING DETECTED.
4. REPEAT THE SAME PLAYBACK PROCEDURE AS PLAYING CD/MP3 DISC
AS ABOVE
REMARK
- THE SYSTEM CAN DETECT AND READ THE FILE UNDER MP3FORMAT
ONLY THOUGH THE USBPORT.
- IF CONNECT THE SYSTEM TO MP3 PLAYER VIA THE USB SOCKET, DUE TO VARIANCES IN MP3
ENCODING FORMAT, SOME MP3 PLAYER MAY NOT BE ABLE TO PLAY VIA THE USB SOCKET. THIS IS
NOT A MALFUNCTION OF THE SYSTEM.
ENCODING OF CD/PHONO INTO MP3 FILE
THE SYSTEM IS ABLE TO ENCODE NORMAL CD OR TURNTABLE TO MP3 FORMAT AND RECORDING AT
MEMORY MEDIA WITH USB CONNECTING PORT.
A) CD ENCODING
I) ECNODING 1 TRACK
1. PERFORM NORMAL PLAYBACK OF THE CD TRACK YOU WANT TO ENCODE & RECORD,
2. PRESS “ REC “ BUTTON (11) DURING THE PLAYBACK OF THE DESIRE TRACK, UNIT WILL DISPLAY “
“&“ “ AND FLASHING. ENCODING IS PERFORMING NOW.
3. AFTER COMPLETING OF ENCODING, UNIT WILL STOP PLAYBACK AUTOMATICALLY.
II) ENCODING 1 DISC – TO RECORD A WHOLE CD
1. PLACE A CD WITH THE PRINTED SIDE FACING UP INSIDE THE TRAY & THEN CLOSE THE CD DOOR
2. STOP THE PLAYBACK BY PRESSING THE ONCE AND THEN AGAIN TO STOP CD
COMPLETELY. THE NUMBER OF TRACKS ON THE CD WILL DISPLAY.
3. PRESS THE “ REC “ BUTTON (11) AFTER FOCUS SEARCH COMPLETED.UNIT WILL DISPLAY “
“&“ “ AND FLASHING. ENCODING IS PERFORMING NOW.
4. AFTER COMPLETING OF ENCODING, UNIT WILL STOP PLAYBACK AUTOMATICALLY.
III) ENCODING BY PROGRAM
1. PLACE A CD WITH THE PRINTED SIDE FACING UP INSIDE THE TRAY & THEN CLOSE THE CD DOOR
2. SELECT THE DESIRE TRACKS BY FOLLOWING “CD DISC PROGRAMMING“ PROCEDURES. THEN
PRESS “ CD PLAY/PAUSE/STOP “ BUTTON (20) TO START PLAYBACK.
3. DURING CD PLAYBACK, PRESS AND HOLD THE “ CD PLAY/PAUSE/STOP “ BUTTON (20) FOR 2
SECONDS TO ENTER THE STOP MODE.
4. PRESS THE “ REC “ BUTTON (11) AND THE UNIT WILL DISPLAY “ “&“ “& FLASHING. ENCODING
IS PERFORMING NOW.
5. AFTER COMPLETING OF ENCODING, UNIT WILL STOP PLAYBACK AUTOMATICALLY.
REMARK:-
- THE RECORDING SPEED IS 1:1 AND ACCORDING TO THE ACTUAL PLYING TIME OF THE CD TRACK
- THE SYSTEM WILL CREAT A “ AUDIO “ FOLDER AND THEN STORE THE ENCODING TRACK IN IT.
- THE RECORDING FORMAT IS PRESET AT – MP3 BIT RATE : 128 KBPS, SAMPLING RATE : 44.1KHZ
- NO SONG TITLE WILL BE RECORDED DURING ENCODING MODE
- TO INTERRUPT THE RECRODING, PRESS THE “RECORD“ BUTTON AGAIN DURING RECORD MODE
- RECORDING WILL BE COMPLETED ONLY ENTIRE SONG BEING ENCODED, IF TERMINATED THE
ENCODING PROCESS INTERMEDIATELY, THERE IS NO TRACK BEING RECORDED NOR STORED TO
THE USB.

8
IV) COPYING OF MP3 FILE
IF PUTTING A MP3 DISC INSTEAD OF A CD-DISC, THE SYSTEM WILL COPY THE FILES TO THE USB IF PRESS
THE “ REC “ BUTTON. THE OPERATION PROCEDURES IS SAME AS CD ENCODING AS STIPULATE ON ABOVE,
AND THE SYSTEM WILL SWITCH TO COPYING MODE ONLY IF MP3 FILE BEING READ.
B) PHONO ENCODING
1) SET THE FUNCTION BUTTON TO “ PHONO “ MODE AND THEN PRESS THE “ REC “ BUTTON DIRECTLY.
2) THE LCD DISPLAY WITH SHOW THE WORD “ USB “ AND THEN FLASHING, AND THEN DISPLAY “
“ & “ “ AND FLASHING AFTER FEW SECONDS. NOW THE SYSTEM IS STARTING THE ENCODING
MODE.
3) START PLAYBACK AT PHONO FOR THE TRACK WHICH YOU WANT TO RECORD TO USB.
4) AFTER FINISH OF RECODING, PRESS AND HOLD THE “REC“ BUTTON (11) UNTIL THE LCD STOP
FLASHING AND RETURN TO “ PHONO “ MODE.
C) ENCODING BITRATE (BY REMOTE HANDSET)
YOU CAN SELECT THE DESIRED BITRATE DURING ENCODING FROM CD OR PHONO TO USB, THE
SELECTABLE RANGE FROM 32 / 64 /96 /128 / 192 / 256 KBPS.
1) SET IN “PHONO “FUNCTION(18)&REMAIN STOP MODE.
2) PRESS THE “ INFO “ FUNCTION AND THE LCD DISPLA WILL SHOW THE DEFAULT BITRATE (128 KBPS)
3) PRESS SKIP OR BUTTONS (21) TO SELECT THE DESIRED BITRATE FOR ENCODING.
4) PRESS AGAIN THE “ INFO “ TO CONFIRM THE SETTING AND THE LCD DISPLAY (4) RESUME TO “ PHONO
“ MODE
D)TRACK SEPARATION (BY REMOTE HANDSET)
YOU CAN DIVIDE THE RECORDING MUSIC FROM PHONO TO USB/SD TRACK BY TRACE DURING ENCODING.
EVERY TIME WHEN PRESS THE “ “ (TRACK SEPARATION) BUTTON ONCE AT REMOTE HANDSET DURING
ENCODING FROM PHONO TO USB/SD, THE SYSTEM WILL GENERATE A NEW TRACK AND CONTINUOUS THE
RECRODING. THE TEXT “ PHONO “ AT LCD DISPLAY WILL FLASHING ONE TIME, IT MEAN THE UNIT IS
CREATING A NEW TRACK SUCCESSFULLY.
FILE DELETE AT USB/SD CARD (BY REMOTE CONTROL)
THE SYSTEM IS ABLE TO ERASE THE FILE STORED INSIDE THE USB PEN DRIVE OR SD CARD BY
FOLLOWING:-
A) SINGLE FILE DELETE
1．PRESET AT “ USB “ OR “ SD “ MODE.
2．PRESS AND HOLD THE “ INFO “ BUTTON FOR 3 SECONDS AND THE LCD DISPLAY (4) WILL SHOW (DEL
---001)
3．PRESS SKIP FORWARD OR SKIP BACKWARD BUTTON TO SELECT THE FILE GOING TO DELETE
4．PRESS THE “ REC “ BUTTON TO ENTER “ YES / NO “ MODE AND THEN PRESS SKIP FORWARD OR
SKIP BACKWARD TO SELECT “ YES “ OR “ NO “.
5．PRESS THE “ REC “ BUTTON AGAIN TO CONFIRM THE SETTING.
B) ALL FILES DELETE
1. PRESET AT “ USB “ OR “ SD “ MODE.
2. PRESS AND HOLD THE “ INFO “ BUTTON FOR 3 SECONDS AND THE LCD DISPLAY (4) WILL SHOW (DEL
---001)
3. PRESS AND HOLD THE “ INFO “ BUTTON TO ENTER “ YES / NO “ MODE AND THEN PRESS SKIP
FORWARD OR SKIP BACKWARD TO SELECT “ YES “ OR “ NO “.
4. PRESS THE “ REC “ BUTTON AGAIN TO CONFIRM THE SETTING.
REMOVING OF USB / MEMORY CARD
TO REMOVE THE USB, TURN OFF THE POWER OR SWITCH THE FUNCTION MODE TO EITHER CD OR TUNER
FIRST. FOR USBPORT – UN-PLUG IT BY PULLING OUT THE USB SOCKET DIRECTLY.
PHONO
NOTED:
-REMOVE THE STYLUS PROTECTOR.
-BE SURE THAT THE TONE ARM IS BEING DETACHED FROM THE TONE ARM
REST BEFORE OPERATING AND RE-SECURED AGAIN AFTERWARDS.
1. SELECT TO “ PHONO ” FUNCTION FROM FUNCTION SELECTOR (18)
2. SET THE SPEED SELECTOR TO THE PROPER POSITION DEPENDING ON THE RECORD TO BE PLAYED.
3. PLACE THE RECORD ON THE PLATTER (USE THE SPINDLE ADAPTOR IF REQUIRED).

9
4. LIFT THE TONE ARM FROM THE REST AND SLOWLY MOVE IT TO THE RECORD
SIDE. THE PLATTER WILL START TO ROTATE.
5. PLACE THE TONE ARM TO THE DESIRED POSITION OF THE RECORD.
6. ADJUST THE VOLUME TO THE DESIRED LEVEL.
7. AT THE END OF RECORD, THE PLATTER WILL AUTOMATICALLY STOP ROTATING.
LIFT THE TONE ARM FROM THE RECORD AND RETURN IT TO THE REST.
8. TO STOP MANUALLY, LIFT THE TONE ARM FROM THE RECORD AND RETURN IT TO
THE REST.
REMARK : AS SOME KIND OF RECORD THE AUTO-STOP AREA WAS OUT OF THE UNIT SETTING, SO IT WILL
STOP BEFORE THE LAST RACK FINISH. IN THIS CASE, SELECT THE AUTO-STOP SWITCH (26) TO “ OFF
“ POSITION, THEN IT WILL RUN TO THE END OF THE RECORD BUT WILL NOT STOP AUTOMATICALLY (TURN
OFF THE UNIT BY POWER BUTTON OR SWITCH BACK THE AUTO-STOP SWITCH TO “ ON “ POSITION TO
STOP THE PLATTER ROTATE). THEN PUT BACK THE TONE ARM TO THE REST POSITION.
LINE OUT CONNECTION
YOU CAN CONNECT THE SYSTEM TO YOUR WHOLE HI-FI SYSTEM BY CONNECTING THE LINE OUT SOCKET
(27) TO THE AUXILIARY INPUT SOCKET WITH A RCA CABLE (NOT INCLUDED).
REMOTE CONTROL TRANSMITTER
CONTROL FUNCTIONS
BATTERY INSTALLATION (BATTERY NOT PROVIDED)
THE INFRA-RED TRANSMITTER REQUIRES 2 PC AAA SIZE BATTERY FOR OPERATION
BUTTON DESCRIPTION
1) OPEN/CLOSE PRESS TO OPEN OR CLOSE THE CD DOOR IN CD
MODE
2) INFO IN CD/PHONO STOP MODE, PRESS TO SELECT
ENCODING BITRATE
3) REC IN CD OR PHONO MODE, PRESS TO ACTIVE
RECRRDING FUNCTION
4) REP/INTRO/RAN IN CD/USB MODE, PRESS TO ACTIVE REPEAT /
INTRO / RANDOM FUNCTION
5) PROGRAM IN CD/USB MODE, PRESS TO ACTIVE
PROGRAMMING FUNCTION
6) PLAY/PAUSE IN CD/USB MODE, PRESS ONCE TO START
PLAYBACK. PRESS AGAIN TO ENTER PAUSE MODE.
7) SKIP/SEARCH FORWARD PRESS ONCE TO SKIP TO NEXT TRACK, PRESS &
HOLD FOR SEARCH FORWARD
SKIP/SEARCH BACKWARD PRESS ONCE TO SKIP TO PREVIOUS TACK.PRESS &
HOLD FOR SEARCH BACKWARD
8) STOP IN CD/USB MODE, PRESS TO STOP PLAYBACK OR CANCEL THE STORED
PROGRAM.
9) FOLDER UP /DOWN IN MP3 MODE, PRESS TO SELECT FOLDER UP OR DOWN
10) SOURCE IN CD/USB MODE, PRESS TO SELECT CD OR USB FUNCTION REPEATLY

10
CARE AND MAINTENANCE
1. Avoid operating your unit under direct sunlight or in hot, humid or dusty places.
2. Keep your unit away from heating appliances and sources of electrical noise such as fluorescent lamps
or motors.
3. Unplug the unit from the electrical power outlet immediately in case of malfunction.
CLEANING THE UNIT
To prevent fire or shock hazard, disconnect your unit from the AC power source when cleaning.
The finish on the unit may be cleaned with a dust cloth and cared for as other furniture, Use caution
when cleaning and wiping the plastic parts.
If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax or polish sprays on
the cabinet.
If the front panel becomes dirty or smudged with fingerprints it may be cleaned with a soft cloth
slightly dampened with a mild soap and water solution. Never use abrasive cloths or polishes as
these will damage the finish of your unit.
CAUTION: Never allow any water or other liquids to get inside the unit while cleaning.
SPECIFICATION
AC POWER AC 230V ~ 50Hz
RADIO FREQUENCY FM 87.5 – 108 MHz
TURNTABLE 33 1/3, 45 RPM
OUTPUT POWER 2 X 1.5W RMS
NOTE: Due to ERP stage two requirements and to protect the environment, the
unit will switch to standby mode automatically if no is music playing after 15
minutes.
INSTRUCTIONS ON ENVIRONMENT PROTECTION
DO NOT DISPOSE OF THIS PRODUCT IN THE USUAL HOUSEHOLD WASTE AT THE END OF ITS LIFECYCLE,
HAND IT OVER AT A COLLECTION POINT FOR THE RECYCLING OF ELECTRICAL AND ELECTRONIC
APPLIANCES. THE SYMBOL ON THE PRODUCT, THE INSTRUCTIONS FOR USE OR THE PACKING WILL
INFORM THEM ABOUT THE METHODS FOR DISPOSAL. THE MATERIALS ARE RECYCLABLE AS INDICATED
BY THE SYMBOL ON THE LEFT.
BY RECYCLING, MATERIAL RECYCLING OR OTHER FORMS OF RE-UTILIZATION OF OLD APPLIANCES, YOU
ARE MAKING AN IMPORTANT CONTRIBUTION TO PROTECT OUR ENVIRONMENT. PLEASE CONTACT YOUR
LOCAL COUNCIL FOR THE AUTHORIZED DISPOSAL LOCATION AND RECYCLING FACILITIES.
Unit J, Braintree Road
Braintree Industrial Estate
Ruislip
Middlesex HA4 0EJ
UK
www.groov-e.co.uk
Ver. 1
