GRUNDFOS ALLDOS Conex DIA-1 User manual

Conex®DIA-1
Instrument amplifier and controller
GRUNDFOS ALLDOS INSTRUCTIONS
Installation and operating instructions
43XOVH,G90

Declaration of Conformity
We Grundfos Alldos declare under our sole responsibility that the product
Conex®DIA-1, to which this declaration relates, is in conformity with the Council
Directives on the approximation of the laws of the EC Member States relating to
– Electromagnetic compatibility (89/336/EEC).
Standards used:
EN 61000-3-2: 1995 + A1 + A2: 1998,
EN 61000-3-3: 1995,
EN 61326: 1997 + A1: 1998 + A2: 2001 Class B,
EN 61326: 1997 / A1: 1998 + A2: 2001.
– Electrical equipment designed for use within certain voltage limits
(73/23/EEC) [95].
Standard used: EN 61010-1: 2002.
Pfinztal, 15th April 2008
W. Schwald
Managing Director Ulrich Stemick Technical Director
2
43XOVH,G90

3
CONTENTS Page
1. Symbols used in this document 3
2. A few words in advance 4
3. Installation data 4
4. Installation sketch 5
5. Instrument settings 6
6. General information 8
6.1 Warranty 8
7. Applications 8
8. Safety 8
8.1 Obligations of the owner/
operations manager 8
8.2 Avoidance of danger 8
9. Identification 9
9.1 Nameplate 9
9.2 Type key, Conex®DIA-1 controllers 10
9.3 Type key, Conex®DIA-1 preassembled
systems 10
10. Technical data 12
10.1 Design / enclosure class 12
10.2 General data 12
10.3 Electronic data and functions 12
10.4 Measuring ranges 13
10.5 Dimensions 14
11. Installation 15
11.1 Transport and storage 15
11.2 Unpacking 15
11.3 Installation requirements 15
11.4 Installation in control panel 15
11.5 Installation of wall-mounted enclosure 16
12. Commissioning /
electrical connections 17
12.1 Terminals 18
12.2 Power supply connection 20
12.3 Relay outputs 20
12.4 Current output 21
12.5 Connections of controller stop,
sample-water sensor and temperature
sensor 21
12.6 Connection of measuring cells 22
13. Operation 24
13.1 Control and display elements 24
13.2 Display elements during initial
commissioning 25
13.3 Software overview 26
13.4 Main menu 27
13.5 Setup 28
13.6 Selection, configuration and
parameterisation of the controller 34
13.7 "Alarm" menu 39
13.8 Checking the settings in the
"service" menu 41
13.9 Calibration 43
13.10 Manual operation 49
14. Fault finding 53
15. Maintenance 53
16. Disposal 53
1. Symbols used in this document
Warning
These complete installation and
operating instructions are also
available on www.Grundfosalldos.com.
Prior to installation, read these
installation and operating instructions.
Installation and operation must comply
with local regulations and accepted
codes of good practice.
Warning
If these safety instructions are not
observed, it may result in personal
injury!
Caution
If these safety instructions are not
observed, it may result in malfunction
or damage to the equipment!
Note
Notes or instructions that make the job
easier and ensure safe operation.
43XOVH,G90

4
2. A few words in advance
The Conex®DIA-1 (Dosing Instrumentation
Advanced with 1 input) multipurpose measuring
amplifier and controller you have just purchased
uses the company’s leading-edge measuring
technology.
The Conex®DIA-1 is a multipurpose device
designed to carry out high-precision measurements
and controls of pH value, redox potential, chlorine,
chlorine dioxide, ozone, hydrogen peroxide, fluoride
or peracetic acid.
The integrated controller, the high-resolution
graphics display and the multilingual plain-text user
interface make complicated measuring and control
tasks in water chemistry much easier.
Just a few button inputs lead you to your goal. The
potentiostat helps save even more time, being
automatically matched to the various input variables.
The safety standard of the dosing process is raised
by the automatic open-circuit monitoring of the
current outputs.
The Conex®DIA-1 combines the functions of exact
chlorine measuring and automatic pH value
compensation in one single device. For this purpose,
the Conex®DIA-1 features a pH sensor interface
and an interface for external instrument amplifiers.
Properties of the Conex®DIA-1 measuring amplifier
and controller include the following:
• all control functions including PID and
continuous-action controls
• manual or automatic temperature compensation
• logbook function: chronological recording of
calibration values with date and time
• user coding function as a means of protection
against access by unauthorised persons and for
system administration
• error message function for indication of non-
functioning sensors.
3. Installation data
Owner:
Grundfos Alldos customer number:
Order number:
Product number:
Product serial number:
Put into service on:
Location of product:
Used for:
Note
Please fill in the data below after
commissioning. It will help you and
your Grundfos Alldos service partner
make subsequent adjustments to the
installation.
43XOVH,G90

5
4. Installation sketch
43XOVH,G90

6
5. Instrument settings
General settings
Control of cleaning motor
(with measuring cell type AQC-D1) Dosing time monitoring
Yes:_ No:_ Yes:_ No:_
Sample-water deficiency sensor Maximum dosing time at constant load of 100 % of
dosing capacity
On:_ Off:_ sec.
Parameter settings
Chlorine Chlorine
dioxide Ozone Peroxide Peracetic
acid
Temperature measurement Yes:_ No:_ Yes:_ No:_ Yes:_ No:_ Yes:_ No:_ Yes:_ No:_
Compensation of temperature Yes:_ No:_ Yes:_ No:_ Yes:_ No:_ Yes:_ No:_ Yes:_ No:_
pH measurement Yes:_ No:_
Compensation of pH value Yes:_ No:_
Measuring cell type
Measuring range mg/l(ppm)–––––
Sensor slope A/ppm
Current output mA–––––
pH Redox Fluoride
Temperature measurement Yes:_ No:_ Yes:_ No:_ Yes:_ No:_
Temperature compensation Yes:_ No:_ Yes:_ No:_
Measuring cell type
Measuring range pH – – mg/l –
Slope mV/pH mV/dec
Current output mA – – –
43XOVH,G90

7
Controllers
Controller settings Controller parameters
Switching
controller
Relay 1 Relay 2 Proportional band Min. pulse width
(3-pos. crtl.)
On:_
Off:_ On:_ Off:_ %sec.
Limit contact
Switching direction
Downward/upward violation Reset time TN
(PI/PID-control) Constant load (two-pos.-/cont. controller)
Downwd.
Upwd. Downwd. Upwd. sec. %
Two-position
controller
interpulse period (PP) or pulse
frequency (PF) controller Deriv. action TV
(PI-control) Max. dosing rate (two-pos.-/cont. controller)
PP:_
PF:_ PP:_ PF:_ sec. %
Control direction
Downward or upward Pulse-interp. interval
(interpulse period controller) Motor runtime (3-pos. crtl.)
Downwd.:_
Upwd.:_ Downwd.:_ Upwd.:_ sec. sec.
Type of control Min. operation time
(interpulse period controller) Hysteresis (limit contact)
P:_
PI:_
PID:_
P:_
PI:_
PID:_ sec.
Setpoint Max. frequency
(interpulse period controller)
Internal:_
External:_ Internal:_ External:_ Hz
3-pos. crtl.
Type of control
Downward or upward
Down:_ Up:_
Setpoint
Internal:_ External:_
Continuous
controller
Control direction
Downward or upward
Down:_ Up:_
Type of control
P:_ PI:_ PID:_
Setpoint
Internal:_ External:_
43XOVH,G90

8
6. General information
These installation and operating instructions
contain all information important for users of the
Conex® DIA-1:
• technical data
• instructions on commissioning, use and
maintenance
• safety information.
Should you require further information or should you
encounter problems that are not handled in sufficient
depth in this manual, please contact Grundfos
Alldos.
We shall be pleased to support you with our
comprehensive know-how in the fields of measuring
and control technology as well as water treatment.
We always welcome suggestions on how to optimise
our installation and operating instructions to satisfy
our customers.
6.1 Warranty
A warranty claim in accordance with our general
terms of sale and delivery is only valid if these
requirements are complied with:
• The device has been used in accordance with the
information in this manual.
• The device has not been dismantled or handled
incorrectly.
7. Applications
The Conex®DIA-1 instrument amplifier and
controller is suitable for measuring chlorine (Cl2),
chlorine dioxide (ClO2), ozone (O3), hydrogen
peroxide (H2O2), peracetic acid, fluoride, pH or
redox potential and for controlling these variables
using appropriate actuators within the applications
described in this manual.
8. Safety
8.1 Obligations of the owner/operations
manager
The owner/operations manager must ensure that
persons working with the Conex®DIA-1 instrument
amplifier and controller fulfil these requirements:
• They are acquainted with the regulations
concerning working safety and accident
prevention.
• They have been trained in use of the device.
• They have read and understood the warning
information and handling symbols.
The owner/operations manager is also responsible
for ensuring that this manual is kept in the immediate
vicinity of the device and is always available for the
operating personnel.
8.2 Avoidance of danger
Warning
Other applications are not approved
and not permitted. Grundfos Alldos
cannot be held liable for any damage
resulting from incorrect use.
Warning
Installation and connection of the
device and the associated
supplementary components must only
be carried out by authorised personnel!
The local safety regulations must be
observed!
Warning
Switch off the power supply before
connecting the power supply cable and
relay contacts!
Do not dismantle the device!
Maintenance and repair must only be
carried out by authorised personnel!
Caution
The mounting location must be
selected so that the housing is not
subjected to mechanical loading.
Check that all settings are correct
before starting up the device!
43XOVH,G90

9
9. Identification
9.1 Nameplate
Fig. 1 Nameplate, Conex®DIA-1
TM04 0332 0408
Pos. Description
1 Type designation
2 Model
3 Product name
4 Voltage [V]
5 Frequency [Hz]
6 Product number
7 Country of origin
8 Year and week of production
9 Marks of approval, CE mark, etc.
10 Power consumption [VA]
11 Enclosure class
12 Serial number
DIA-1, 1-P/R/D/HP/PA/F, W-G
350-2200-10001
S/N: 08/12345
Conex DIA-1
230/240V 50/60Hz, 15 VA,
IP 65
96622359P1108120808565
1
2
3
4
5
789
10
11
12
6
43XOVH,G90

10
9.2 Type key, Conex®DIA-1 controllers
Type key example: DIA-1, 1-P/R/D/HP/PA/F, W-G
9.3 Type key, Conex®DIA-1 preassembled systems
Type key example: DIA-1-A, D1-X-AU-X-QS-T, W-G
Example: DIA -1 1-P/R/D/HP/PA/F -W -G
Measuring amplifier and controller
DIA-1 Dosing Instrumentation Advanced with 1 input
Input parameter 1
PpH
R Redox (ORP)
D Chlorine (Cl2), chlorine dioxide (ClO2) or ozone (O3)
HP Hydrogen peroxide (H2O2)
PA Peracetic acid (PAA)
F Fluoride (F–)
Mounting
W Wall-mounted
P Panel-mounted
Voltage
G 1 x 230 V, 50/60 Hz
H 1 x 120 V, 50/60 Hz
I 24 VDC
Example: DIA -1 -A D1 -P -PT -PCB -QS -T W -G
Units for measurement and control
DIA-1 Dosing Instrumentation Advanced, with 1 input
Assembly
A Preassembled
Cell type
D1 Pressure-proof, with cleaning motor
D2 Pressure-proof, with hydro-mechanical cleaning
D3 Pressureless, with hydro-mechanical cleaning
D4 For total chlorine measurement
D5 For free chlorine measurement with buffer dosing
P/R pH or redox (ORP) only
F Fluoride only
PA/HP Peracetic acid or hydrogen peroxide only
P With pressure retention valve
X Without pressure retention valve (to be continued)
43XOVH,G90

11
Example: DIA -1 -A D1 -P -PT -PCB -QS -T W -G
Disinfection electrodes
AU Gold
PT Platinum
X No disinfection measuring
Other electrodes
PCB pH, ceramic diaphragm, incl. buffer solution
PTB pH, PTFE diaphragm, incl. buffer solution
PKB pH, KCl filling, incl. buffer solution
PGB pH, gel filling incl. buffer solution
PCX pH, ceramic diaphragm, excl. buffer solution
PTX pH, PTFE diaphragm, excl. buffer solution
PKX pH, KCL filling, excl. buffer solution
PGX pH, gel filling, excl. buffer solution
RCB Redox (ORP), ceramic diaphragm, incl. buffer solution
RTB Redox (ORP), PTFE diaphragm, incl. buffer solution
RCX Redox (ORP), ceramic diaphragm, excl. buffer solution
RTX Redox (ORP), PTFE diaphragm, excl. buffer solution
F Fluoride
PA Peracetic acid
HP Hydrogen peroxide
X No electrode
Flow sensor
QS Flow sensor integrated
X No flow sensor
Temperature sensor
T With Pt100
X No temperature sensor
Mounting of controller
W Wall-mounted
P Panel-mounted
Voltage
G 1 x 230 V, 50/60 Hz
H 1 x 120 V, 50/60 Hz
I24VDC
43XOVH,G90

12
10. Technical data
10.1 Design / enclosure class
10.2 General data
10.3 Electronic data and functions
10.3.1 Electronics
10.3.2 Functions of the instrument amplifier
Wall-mounted
enclosure
including built-in
potentiostat
IP65
Control panel
enclosure
including separate
potentiostat
IP54 (front) /
IP65 (sensor interface)
Input power Approximately 15 VA
Permissible
ambient
temperature 0 °C to +50 °C
Permissible
storage
temperature –20 °C to +65 °C
Maximum relative
humidity 90 % (non-condensing)
Weight 2 kg
Enclosure Plastic (control panel enclosure: noryl, wall-
mounted enclosure: ABS)
Power supply
versions
• 230/240 V (50/60 Hz)
(standard model)
• 115/120 V (50/60 Hz)
• 24 V DC
Electronics 16-bit microprocessor
Display High-resolution graphics LCD
with background light
Potential-freerelay
outputs
1 alarm relay, 2 controller
relays (250 V/6 A, maximum
550 VA)
Signal inputs
Controller stop; external
setpoint / external pH value
0/4 to 20 mA; sample-water
deficiency sensor
Signal outputs 4 analog outputs 0/4 to 20 mA, freely adjustable,
maximum load 500 :
Freely adjustable
analog outputs for
measured values
• Chlorine, chlorine dioxide,
ozone, peroxide, peracetic
acid
• pH, redox (ORP) or fluoride
• Temperature
• Continuous control
(0/4 to 20 mA)
Display mode
Measured-value display:
measured value with its unit,
temperature display:
in °C or °F
Temperature
compensation Manual or automatic with Pt100 (–5 °C to +120 °C)
Calibration Manual or with automatic
recognition of buffer solution
43XOVH,G90

13
10.3.3 Controller functions
10.4 Measuring ranges
Control functions
Limit contact, two-position
controller (P, PI, PID), three-
position step controller (PI),
continuous controller
(P, PI, PID)
Limiting value
0 to 100 % of full-scale value
(only with limit contact),
adjustable in the unit of the
measured value
Setpoints 0 to 100 % of the measuring range, adjustable in the unit
of the measured value
Proportional band 0.1 to 3000 %
Reset time 1 to 3000 seconds, resolution
1 second
Derivative action
time 1 to 1000 seconds, resolution 1 second
Minimum pulse
length
0.1 to 10.0 seconds,
resolution 0.1 second (only
with three-position step
controller)
Minimumoperating
time 0.1 to 10 seconds (only with interpulse period controller)
Interpulse period 1 to 100 seconds (only with
interpulse period controller)
Maximum pulse
frequency
1 to 180 pulses per minute
(only with pulse frequency
controller)
Hysteresis 0 to half of the measuring range, adjustable in the unit
of the measured value
Constant load
0 to 50 % (only with interpulse
period controller, pulse
frequency controller or
continuous controller)
Maximum dosing
flow
Base load dosing up to 100 %
of full-scale value (only with
interpulse period controller or
pulse frequency controller)
Motor runtime 10 to 240 seconds, resolution 1 second (only with three-
position step controller)
Effective direction Can be set to upward or
downward
Control relays Can be set to pulse-interpulse
or pulse frequency control
CI2CIO2O3H2O2Peracetic
acid pH Redox
(ORP) Fluoride
mg/l mg/l mg/l mg/l mg/l pH mV mg/l
0.00 - 0.50 0.00 - 0.50 0.00 - 0.50 0-100 0-100 0.00 - 14.00 –1500 to +1500 0.00 - 2.00
0.00 - 1.00 0.00 - 1.00 0.00 - 1.00 0-500 0-500 2.00 - 12.00 0-1000 0.00 - 5.00
0.00 - 2.00 0.00 - 2.00 0.00 - 2.00 0-1000 0-1000 5.00 - 9.00
0.00 - 5.00 0.00 - 5.00 0.00 - 5.00 0-2000 0-2000
0.00 - 10.00 0.00 - 10.00
0.00 - 20.00
Note
With the additional menu option "others", the measuring range can be set to any range within
the limits listed above. In the case of chlorine and chlorine dioxide, the measuring range can
be extended up to 50.0 mg/l.
43XOVH,G90

14
10.5 Dimensions
Fig. 2 Wall-mounted enclosure Conex®DIA-1
Fig. 3 Control panel enclosure Conex®DIA-1
TM03 6687 4506
59
125
84
59.5
184.5
212
198
10
145 27
110
180
Ø 4.5
TM03 6688 4506
90
96
96
166
90
158
90
18
43XOVH,G90

15
11. Installation
11.1 Transport and storage
• Transport the device carefully, do not drop!
• Store at dry and cool location.
11.2 Unpacking
1. Check the device for damage.
Install as soon as possible after unpacking.
2. Do not install or connect damaged devices!
11.3 Installation requirements
• Dry room
• Room temperature: 0 °C to 50 °C
• Vibration-free location.
11.4 Installation in control panel
Fig. 4 Control panel enclosure Conex®DIA-1
Fig. 5 Sensor interface
1. Make an opening of 92 + 0.8 mm x 92 + 0.8 mm in
the control panel.
2. Slip on the supplied gasket.
3. Insert the Conex®DIA-1 into the opening from
the front.
1. Hook the clamps into the tightening cones on the
sides at the top and bottom.
2. Secure the device from the rear using a
screwdriver.
3. Install a separate sensor interface near the
sensors.
Note
Retain the packing material or dispose
of it according to local regulations.
Caution
If you do not observe the installation
requirements, the device may be
damaged!
The measurements may not be correct!
TM03 6689 4506TM03 6690 4506
Caution
Do not damage the gasket!
The gasket must be fitted exactly!
92+0.8
92+0.8
> 20
> 20
43XOVH,G90

16
11.5 Installation of wall-mounted enclosure
Fig. 6 Wall-mounted enclosure Conex®DIA-1
1. Drill three holes (8 mm) as shown in the
diagram, and insert the supplied dowels.
2. Screw the screw (A) into the top centre dowel
until it projects by approximately 1 cm. See fig. 7.
3. Loosen the fastening screws of the front panel,
and remove the front panel.
4. Hang the instrument onto the screw (A).
5. Tighten the instrument with the two screws (B).
6. Mount the front panel of the enclosure.
Fig. 7 Mounting drawing
Warning
Switch off the power supply before
installing!
Enclosure class IP65 is only
guaranteed if the terminal cover is
correctly sealed, if the front panel of
the terminal enclosure is closed and
the appropriate cable glands or dummy
caps fitted.
Caution
Do not damage the terminal cover
gasket! The terminal cover gasket must
fit exactly!
TM03 6691 4506
198
145 27
10.5
TM03 6692 4506
B
B
A
43XOVH,G90

17
12. Commissioning / electrical
connections 1. Remove the terminal cover on the front of the
device.
2. Use the appropriate cable feedthroughs and
tighten the screws carefully.
3. Connect the cables used to the terminals
according to the Conex®DIA-1 terminal
assignment.
4. Close the terminal cover again with correctly
positioned gasket.
Warning
Switch off the power supply before
installing!
Enclosure class IP65 is only
guaranteed with the front panel of the
terminals enclosure closed and with
appropriate cable glands or dummy
caps.
Warning
Switch off the power supply before
connecting the power supply cable and
the relay contacts! For safety reasons,
the protective conductor must be
connected correctly!
Observe the local safety regulations!
Protect the cable connections and
plugs against corrosion and moisture.
Caution
Before connecting the power supply
cable, check that the supply voltage
specified on the nameplate
corresponds to the local conditions!
An incorrect supply voltage may
destroy the device!
To guarantee electromagnetic
compatibility (EMC), the input and
current output cables must be
screened.
Connect the screening to the screen
ground on one side.
Refer to the wiring diagram! Route the
input, current output and power supply
cables in separate cable channels.
Caution
Enclosure class IP65 is only
guaranteed if the terminal cover is
correctly sealed! Do not damage the
gasket on the terminal cover!
The gasket on the terminal cover must
be positioned precisely!
Do not damage the gasket!
Note
Unused terminals must remain open.
43XOVH,G90

18
12.1 Terminals
12.1.1 Wall-mounted enclosure Conex®DIA-1
Fig. 8 Terminals of wall-mounted enclosure
TM03 6693 4506
15 17 19 21 23 25 27 29 31 33 35
3634323028262422201816
15 17 19 21 23 25 27 29 31 33 35
3634323028
262422201816
37 38 39 40 41 42
37 = 38 =M
15 17 19 21 23 25 27 29 31 33 35
3634323028262422201816
PAA H
2
O
2
15 (wh)
16 (br)
17 - 22 23 - 30 32,34,36
810
79
12 N.C.
N.O .
11 13
12 14
21/22 =Pt 100
19 =+H
2O,20 =–H
2O
17/18 =
1
2
3
4
Cl2,ClO2,O
3,
H2O2,PAA
T/
+–
mA
pH, mV, F –mA
mA
mA
33/35
mA
mA
39 =B/R
40 =G/C
mA
+–
+–
+–
+–
41/42 = +/– mV
–
pH
F
14
14
P1
P2
P2
P1
135
24 6
135
24 6
+-
+-
115/120 V
230/240 V
24 V/DC
NLPE
NLPE
Cells / electrodes
External input
Outputs
Sensors
cells
Alarm
Relays
Sensors
(water)
Controller stop
Outputs
External input
24 V/DC
115/120 V
230/240 V
15 (white) 16 (brown)
43XOVH,G90

19
12.1.2 Control panel enclosure Conex®DIA-1
Fig. 9 Terminals of control panel enclosure
TM03 6979 4506
2/1 2/2 2/3 2/4
2/1, 2/2
=
5/1 - 5/5
2/3 (+), 2/4 (–)
=
H2O
+–
M B/R G/C Pt 100
3/1 - 3/4
pH, mV, F –
Cl2, ClO2,
O3, PAA,
H2O2
pH, mV, F –
3/1 3/2 3/3 3/4 4/1 4/2 4/3 4/4
7/1 7/2 7/3 N.C.
N.O.
1/1 (br), 1/2 (wh)
PAA H
2
O
2
6/1 6/2
6/3
6/4
1
2
A 1/1 (br) B 1/2 (wh)
PAA
H
2
O
2
A2
/3 (+)
B 2 /4 (-)
H2O
1/11 1/13 4/1
1/12 1/14
4/3
4/2 4/4
3/1 3/3
3/2 3/4
B
A
1/11 -1/14 Pt 100
4/1 - 4/4
Conex DIA-1
5/1
5/2
5/3
5/4
5/5
5/1 5/2 5/3 5/4 5/5
1
2
3
4
T
mA
Cl2, ClO
2,
O3,H
2O2,
PAA
pH, mV, F –
mA
+
–
5/1 - 5/5
41
1/1 1/2 1/3 1/4 1/5 1/6 1/7 1/8 1/9 1/10 1/11 1/12 1/13 1/14
8/1 8/2 8/3
PE
N
L
8/1
8/2
8/3
-
+
115/120 V
230/240 V
24 V/DC
Controller stop
(water)
Relays
Alarm
Connection to Conex®DIA-1
Cells
(water)
Cells:
Outputs
External input
Sensor interface
Cells / electrodes
Cells Electrodes
Jumper
DIP
off on
24 V/DC
115/120 V
230/240 V
1/11 (brown), 1/2 (white)
1/1 (brown)
1/2 (white)
43XOVH,G90

20
Legend of terminals
Control panel enclosure Conex®DIA-1
•Conex®DIA-1: for installation in the control
panel.
• Sensor interface: for installation near the sensors.
12.2 Power supply connection
1. Control panel enclosure: Plug the plug strip into
the corresponding terminal strip at the rear side of
the device. Ensure correct orientation.
2. Connect the protective earth conductor (PE) to
terminal 5 (wall-mounted enclosure) or terminal 8/
1 (control panel enclosure).
3. Connect the neutral conductor (N) (or the –
conductor with 24 V version) to terminal 3 (wall-
mounted enclosure) or terminal 8/2 (control panel
enclosure).
4. Connect phase (L1) (or the + conductor with 24 V
version) to terminal 1 (wall-mounted enclosure) or
8/3 (control panel enclosure).
Switch the device on and off by switching the power
supply on and off accordingly. The device itself is not
equipped with a separate on/off switch.
12.3 Relay outputs
With inductive loads (also relays and contactors),
interference suppression is necessary. If this is not
possible, protect the relay contacts using a
suppressor circuit as described below.
• With AC voltage:
• With DC voltage: Connect the free-wheeling
diode in parallel to relay or contactor.
Fig. 10 Suppressor circuit, DC/AC
Pos. Description
Relays Relay 1 + 2
Alarm Alarm relay
– N.O.: normally open
– N.C.: normally closed
Pt100 Temperature sensor
H2O Sample-water deficiency sensor
Stop Controller stop
Outputs Current outputs [mA]
1
Cl2(chlorine), ClO2(chlorine
dioxide), O3(ozone), H2O2
(hydrogen peroxide) or PAA
(peracetic acid)
2 pH, mV (redox), F–(fluoride)
3 T: temperature
4 Continuous controller
Inputs External inputs [mA]
Electrodes Measuring cells, electrodes and
single-rod measuring chains
M Measuring electrode
B/R Reference electrode
G/C Counter electrode
Earth
mV Redox electrode
F–Fluoride electrode
Note
The connection of the relay outputs
depends on the application and the
final control elements used. Therefore
the connections described below
should only be considered as
guidelines.
Current up to Capacitor C Resistor R
60 mA 10 nF, 275 V 390 :, 2 W
70 mA 47 nF, 275 V 22 :, 2 W
150 mA 100 nF, 275 V 47 :, 2 W
1.0 A 220 nF, 275 V 47 :, 2 W
Caution
Provide the relay outputs with a
corresponding backup fuse!
TM03 7209 4506
+
-
R
C
ACDC
43XOVH,G90
