Grundig GEC-D2201AR User manual

GEC-D2201AR.25.1.04.10.2011
Owner´s Manual
© ASP AG
Transmission
GEC-D2201AR 1 channel video encoder

Content:
1. Introduction 1
2. Important Safety Instructions 1
3. Package Contents 2
4. Installation 2
1. Connections 3
2. System Requirements 4
3. Ceiling/Wall Mounting 5
5. Deleting the Existing GRUNDIG Viewer 7
6. Accessing the Video Server 8
7. Browser-based Viewer Introduction 14
8. Home Page 15
9. System Related Settings 17
1. Host Name & System Time Setting 17
2. Security 18
3. Network 25
4. DDNS 32
5. Mail 33
6. FTP 34
7. HTTP 35
8. Application (Alarm Settings) 35
9. Motion Detection 40
10. Tampering 43
11. Storage Management 45
12. Recording 47
13. File Location 48
14. Camera Control 49
15. View Log File 50
16. View User Information 51
17. View Parameters 53
18. Factory Default 53
19. Software Version 54
20. Software Upgrade 55
21. Maintenance 56
10. Streaming Settings 57
1. Video Format 57
2. Video Compression 58
3. Video OCX Protocol 60
4. Video Frame Rate 61
5. Audio 62
11. PTZ Settings 63
12. Logout 65
13. CMS Software Introduction 65
14. Internet Security Settings 66
15. GRUNDIG Viewer Download Procedure 69
16. Install UPnP Components 71
1. Introduction
This Video Server provides a stable platform for transmission from traditional analogue CCTV cameras to an IP-
based system.
With the ability to select H.264 or MJPEG video compression, the Video Server offers scalability and efficient use
of network bandwidth. By combining the Video Server with a NVR that can receive IP signals from the internet,
users can upgrade analogue cameras to become an IP-based surveillance system that reduces the wiring costs
and maximises the convenience of distant surveillance applications.
2. Important Safety Instructions
Be sure to use only the standard adapter that is specified in the specification sheet. Using any other adapter
could cause fire, electrical shock, or damage to the product. Incorrectly connecting the power supply or replacing
battery may cause explosion, fire, electric shock, or damage to the product. Do not connect multiple products to
one single adapter. Exceeding the capacity may cause abnormal heat generation or fire.
Do not place conductive objects (e.g. screwdrivers, coins or any metal items) or containers filled with water on top
of the product. Doing so may cause personal injury due to fire, electric shock, or falling objects.
1
English

If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately disconnect
the power source and contact the service center. Continued use in such a condition may cause fire or electric
shock.
If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this
product in any way. (GRUNDIG is not liable for problems caused by unauthorised modifications or attempted
repair.)
To prevent fire or electric shock, do not expose the inside of this device to rain or moisture.
3. Package Contents
These parts are included:
4. Installation
Do not install this product in a location subject to high temperature (over 50°C), low temperature (below -10°C),
or high humidity. Doing so may cause fire or electric shock. Keep out of direct sunlight and heat radiation
sources. It may cause fire.
Do not install the unit in humid, dusty or sooty locations. Doing so may cause fire or electric shock. Install it in a
place with good ventilation.
When installing the unit, fasten it securely and firmly. A falling unit may cause personal injury.
If you want to relocate the already installed product, be sure to turn off the power and then move or reinstall it.
2
English

4.1. Connections
The definition for each connector on the Video Server will be given as follows.
The connectors on the front panel are as shown below.
The connectors on the rear panel are as shown below.
3
English

Please follow the procedure below for power, video and Ethernet connections of the Video Server.
Step 1:
Connect an analogue camera to the Video Server’s BNC connector. To do this, please refer to section 4.1.
Connections (Front Panel).
Step 2:
Connect the power adaptor to the Video Server’s DC Jack. To do this, please refer to section 4.1. Connections
(Rear Panel).
Step 3:
Use of Category 5 Ethernet cable is recommended for network connection; to have best transmission quality,
cable length shall not exceed 100 meters. Connect one end of an Ethernet cable to the RJ-45 connector in the
Video Server, and the other end of the cable to the network switch or PC.
NOTE: In some cases, you may need to use an Ethernet crossover cable when connecting the Video Server
directly to the PC.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.
4.2. System Requirements
Personal Computer :
1.) Intel Pentium M, 2.16 GHz or Intel Core 2 Duo, 2.0 GHz
2.) 2 GB RAM or more
4
English

Operating System :
Windows XP / Windows VISTA / Windows 7
Web Browser :
Microsoft Internet Explorer 6.0 or later
Firefox
Chrome
Safari
Network Card :
10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer :
ActiveX control plug-in for Microsoft IE
4.3. Ceiling/Wall Mounting
Installation Tools:
STEP 1:
Use a power drill to drill two holes in the ceiling or wall for the
two M4 plastic anchors.
5
English

STEP 2:
Use a hammer to install two M4 plastic anchors.
STEP 3:
Install the video server on the ceiling by using a screwdriver to
tighten the two M4 pan head self-tapping screws in the plastic
anchors.
6
English

5. Deleting the Existing GRUNDIG Viewer
Users who have installed the GRUNDIG Viewer for 1.3 Megapixel Series IP Cameras on the PC need to delete the
existing GRUNDIG Viewer first from the PC before accessing the Video Server.
Deleting the GRUNDIG Viewer :
Click on “Control Panel”, and then click on “Add or Remove Programs”. In the “Currently installed programs” list,
select “GRUNDIG Viewer” and click the button “Remove” to uninstall the existing GRUNDIG Viewer as shown in
the figure below.
Deleting Temporary Internet Files :
To improve the browser performance, it is suggested to clean up all the files in the Temporary Internet Files. The
procedure is as follows (for other web browsers please read the corresponding manuals):
STEP 1: Click on the “Tools” tab and select the option “Internet Options”.
7
English

STEP 2: Click on “Delete” in the first pop-up window. Then tap “Delete Files” in the “Temporary Internet files”
section in the next pop-up window.
6. Accessing the Video Server
For initial access to the Video Server, users can search through the installer program: GRUNDIG Finder.exe, that
can be found on the supplied CD.
GRUNDIG Finder Software Setup :
Step 1: Double-click on the program GRUNDIG Finder.exe (see the desktop icon below); its window will appear
as shown below. Then click on the “Find Device” button.
8
English

Step 2: The security alert window will pop up. Click “Unblock” to continue.
Device Search:
Step 3:
Click on “Find Device” again, afterwards all found IP devices will be listed in the page, as shown in the figure
below. The Video Server’s default IP address is: 192.168.1.1.
9
English

Step 4:
Double-click or right-click and select “Browse” to access the Video Server directly via the web browser.
Step 5:
Then the dialogue box for entering the default user name and password (as shown below) will appear for logging
in to the Video Server.
The default login ID and password for the Administrator are:
Login ID: admin
Password: 1234
NOTE: ID and password are case sensitive.
It is strongly advised to alter the administrator’s password due to security concerns. Please refer to section 9.2.
Security for further details.
Additionally, users can change the Video Server’s network property, either to DHCP or to Static IP, directly in the
device finding list. Please refer to the following section for changing the Video Server’s network property.
Example of Changing the Video Server’s Network Property :
Users can directly change a Video Server’s network property, e.g. from static IP to DHCP, in the finding device list.
The prosedure to change the Video Server’s network property is explained below:
10
English

Step 1:
In the finding device list, click on the Video Server of which you would like to change the network property. Right-
click on the selected item and select “Network Setup.” Meanwhile, record the Video Server’s MAC address for
future identification.
Step 2:
The “Network Setup” page will come out. Select “DHCP,” and press the “Apply” button down the page.
Step 3:
Click on “OK” in the Note of setting the change. Wait for one minute to re-search the Video Server.
11
English

Step 4:
Click on the “Find Device” button to search all the devices. Then select the Video Server with the correct MAC
address. After double-clicking on the Video Server, the login window will appear.
Step 5:
Enter User name and Password to access the Video Server.
Installing the GRUNDIG Viewer Software Online:
For the initial access to the Video Server, a client program, GRUNDIG Viewer, will be automatically installed to
your PC when connected to the Video Server.
If the Web browser does not allow the GRUNDIG Viewer installation, please check the Internet security settings or
ActiveX controls and plug-ins settings (see 14. Internet Security Settings) to continue the process.
The Information Bar (just below the URL bar) may come out and ask for permission to install the ActiveX Control
for displaying video in browser (see the picture below). Right-click on the Information Bar and select “Install
ActiveX Control…” to allow the installation.
Then the security warning window will pop up. Click “Install” to carry on with the software installation.
Click on “Finish” to close the GRUNDIG Viewer window when download is finished. For detailed software
download procedure, please refer to chapter 15. GRUNDIG Viewer Download Procedure.
12
English

Once logged in to the Video Server, users will see the Home page as shown below:
Administrator/User Privileges :
“Administrator” represents the person who can configure the Video Server and who authorises users to have
access to the Video Server; “User” refers to someone who has access to the Video Server with limited authority,
i.e. to enter the Home and Video Server setting pages.
Image and Focus Adjustment :
The image appears on the Home page when the Video Server was successfully accessed. Adjust zoom and focus
as necessary to produce a clear image.
13
English

7. Browser-based Viewer Introduction
The picture below shows the main page of the Video Server’s user interface.
There are four tabs on the left (System, Streaming, PTZ/Cam and Logout) and one tab on the right (Languages).
System setting :
The administrator can set host name, system time, admin password, network related settings, etc. Further
details will be interpreted in chapter 9. System Related Settings.
Streaming setting :
The Administrator can configure a specific video resolution, video compression mode, video protocol, audio
transmission mode, etc. in this page.
PTZ/Cam setting :
Users can access the Camera’s OSD menu via the OSD Menu Control in the "PTZ/Cam" page.
Logout :
Click on this tab to re-login to the Video Server with another user name and password.
14
English

8. Home Page
In the Home page, there are several function buttons that are specified below.
Please note that all the function buttons will be visible after you selected "PTZ Camera" under System > Camera
Control.
Display Mode (Screen Size Adjustment) :
The display size of the image can be adjusted to x1/2 and full screen.
Talk button (on/off) :
Talk function allows the local site to talk to the remote site. Click on this button to switch it on/off. Please refer to
section 9.2. Security: User >> Add user >> Talk/Listen for further details. This function is only open to the “User”
who has been granted this privilege by the Administrator.
Please note that additional equipment will be necessary.
Speaker button (on/off) :
Click on the Speaker button to mute/activate the audio.
Snapshot button :
After clicking this button, the JPEG snapshots will be automatically saved in the appointed place. The default
place of saving snapshots is: C:\. For changing the storage location, please refer to section 9.13. File Location for
further details.
NOTE: Users with the Windows 7 operating system on their PC need to follow the following procedure to be able
to use the Snapshot function. First you need to log on to your computer as an Administrator. Then please go to
Windows Start menu, click with the right mouse button on your Internet Browser and select in the appearing pop-
up window “Run as Administrator”. Afterwards you can log in to your Video Server as usual (as an administrator
or user).
Video Streaming Pause/Restart button (pause/restart) :
If you click on the stop button to disable video streaming, the live video will be displayed as black. click on the
restart button to show the live video again.
15
English

Recording button (on/off) :
When you click on this button, the recordings from the Live View will be saved to the location specified in the “File
Location” (snapshot) page. The default storage location for the recordings is: C:/. See section 9.13. File Location
for further details.
NOTE: Users with the Windows 7 operating system on their PC who want to use the Recording function, need to
follow the procedure in the NOTE below the “Snapshot button” section in this chapter.
Pan/Tilt Control :
Users can implement pan/tilt control by first moving the cursor to the live video pane; then left-click, hold the
click and drag the pointer in any direction.
NOTE: You can access the PTZ Control only after you selected "PTZ Camera" under System > Camera Control.
Optical/Digital Zoom Control :
In Normal View display mode, users can implement zoom in/out by clicking in the zoom setting bar and adjusting
the zoom manually or by clicking on the "Wide" / "Tele" buttons. In Full Screen mode, users can rotate the mouse
wheel to zoom in/out on the image. When the camera reaches the limit of its optical range, it will automatically
switch to digital zoom.
Zoom Adjustment :
Click on the buttons wide/ tele to control zoom in/out.
Zoom Adjustment :
Click on the buttons wide/ tele to control zoom in/out.
Focus Adjustment :
- Auto Focus:
Click on the “auto” button to enable AF mode. In this mode, the camera will keep in focus automatically and
continuously regardless of zoom changes or any view changes.
- Manual Focus:
After clicking on the “Manual” button, users can adjust the focus manually via the “Near” and “Far” buttons.
Multiple Languages Support :
Multiple languages are supported for the viewer window interface.
16
English

9. System Related Settings
The picture below shows all categories under the “System” tab. Each category in the left column will be explained
in the following sections.
NOTE: The “System” configuration page is only accessible by the Administrator.
9.1. Host Name & System Time Setting
Click on the first category <System> in the left column; the page is shown below.
Host Name :
The name is for Video Server identification (max. 30 characters). If the alarm function (see section 9.8.
Application) is enabled and is set to send an alarm message by Mail/FTP, the host name entered here will be
displayed in the alarm message.
Time Zone :
Select the time zone you are in from the drop-down menu.
Enable Daylight Saving Time :
To enable DST, please check the item and then specify the time offset and DST duration. The format for time
offset is [hh:mm:ss]; for instance, if the amount of time offset is one hour, please enter “01:00:00” into the field.
Sync with Computer Time :
After selecting this item, the video date and time display will be synchronised with the PC.
Manual :
The Administrator can set the date, time and day manually. Entry format should be identical with the format
shown next to the enter fields.
Sync with NTP Server :
Network Time Protocol (NTP) is an alternate way to synchronise your Video Server’s clock with a NTP server.
Please specify the server you wish to synchronise the Video Server with in the enter field. Then select an update
interval from the drop-down menu. For further information about NTP, please see the web site: www.ntp.org.
NOTE: Click on < Save > to confirm the new setting.
17
English

9.2. Security
When you click on the category <Security>, there will be a drop-down menu with several tabs including <User>,
<HTTPS>, <IP Filter>, and <IEEE 802.1X>.
<User> :
When you click on the <User> tab under the category <Security>, the <User> page will be shown as in the picture
below.
NOTE: The following characters are valid: A-Z, a-z, 0-9, !#$%&’-.@^_~.
Admin Password :
Change the administrator’s password by putting in the new password in both text boxes. The input
characters/numbers will be displayed as dots for security purposes. After clicking <Save>, the web browser will
ask the Administrator for the new password for access. The maximum length of the password is 14 digits.
Add User :
Type in the new user name and password and click <Add> to add the new user. The user name can have up to 16
characters, the password up to 14 characters. The new user will be displayed in the user name list. A maximum
of 20 user accounts can be set. To each user the privileges “Camera control”, “Talk” and “Listen” can be assigned
.
- I/O access:
This item supports fundamental functions that enable users to view video when accessing the Video Server.
- Camera control:
This item allows the appointed user to change the Video Server’s parameters on the Video Server Setting page.
- Talk/Listen:
Talk and Listen functions allow the appointed user on the local site (PC site) to communicate, for instance, with
the administrator on the remote site.
18
English
