WASHING MACHINE
USER‘S MANUAL
GWM 9901 S
2820524851_EN/25-02-16.(16:18)
Document number

Please read this user manual first!
Dear Customer,
Thank you for preferring a Grundig product. We hope that you get the best results
from your product which has been manufactured with high quality and state-of-
the-art technology. Therefore, please read this entire user manual and all other
accompanying documents carefully before using the product and keep it as a
reference for future use. If you handover the product to someone else, give the
user manual as well. Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints
about usage.
AWarning for hazardous situations with
regard to life and property.
BWarning for electric shock.
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated by the
local authorities.
2

Important instructions for safety
and environment 4
General safety . . . . . . . . . . . . . . . . . .4
Electrical safety . . . . . . . . . . . . . . . . . .4
Product safety . . . . . . . . . . . . . . . . . . . .5
Intended use . . . . . . . . . . . . . . . . . . .6
Children's safety . . . . . . . . . . . . . . . .6
Compliance with the WEEE
Directive . . . . . . . . . . . . . . . . . . . . . . .7
Package information. . . . . . . . . . . . .7
Your washing machine 8
Overview. . . . . . . . . . . . . . . . . . . . . . .8
Package Contents . . . . . . . . . . . . . . .9
Technical specifications . . . . . . . . .10
Installation 11
Appropriate installation location . .11
Removing packaging
reinforcement . . . . . . . . . . . . . . . . .11
Removing the transportation locks12
Connecting water supply . . . . . . . .12
Connecting to the drain . . . . . . . . .13
Adjusting the feet . . . . . . . . . . . . . .14
Electrical connection . . . . . . . . . . .14
Preparation 15
Sorting the laundry . . . . . . . . . . . . .15
Preparing laundry for washing . . .16
Things to be done for energy saving16
Initial use . . . . . . . . . . . . . . . . . . . . .16
Correct load capacity . . . . . . . . . . .17
Loading the laundry . . . . . . . . . . . .17
Using detergent and softener . . . .17
Tips for efficient washing . . . . . . . .20
Operating the product 21
Programme and consumption
table . . . . . . . . . . . . . . . . . . . . . . . . .22
Programme selection . . . . . . . . . . .23
Programmes . . . . . . . . . . . . . . . . . .23
Quick User Guide 28
Preparing the machine. . . . . . . . . .28
Programme selection . . . . . . . . . . .28
Auxiliary function selection . . . . . .28
Starting the programme. . . . . . . . .28
End of programme . . . . . . . . . . . . .28
Cancelling the programme . . . . . .28
Child Lock . . . . . . . . . . . . . . . . . . . .28
Maintenance and cleaning 29
Cleaning the detergent drawer . . .29
Cleaning the loading door and the
drum . . . . . . . . . . . . . . . . . . . . . . . . .29
Cleaning the body and control
panel. . . . . . . . . . . . . . . . . . . . . . . . .30
Cleaning the water intake filters . .30
Draining remaining water and
cleaning the pump filter . . . . . . . . .30
In order to clean the dirty filter and
discharge the water: . . . . . . . . . . . .30
The product has an emergency
water draining hose, in order to
drain the water:. . . . . . . . . . . . . . . .31
Troubleshooting 32
TABLE OF CONTENTS
3
EN

Important instructions for safety and environment
This section contains safety instructions that will
help protect from risk of personal injury or property
damage. Failure to follow these instructions shall
void any warranty.
General safety
••This product can be used by children at and
above 8years old and by persons whose physi-
cal, sensory or mental capabilities are not fully
developed or who lack experience and knowl-
edge provided that they are supervised or trained
on the safe usage of the product and the risks it
brings out. Children must not play with the prod-
uct. Cleaning and maintenance works should not
be performed by children unless they are super-
vised by someone. Children of less than 3 years
should be kept away unless continuously super-
vised.
••Never place the product on a carpet-covered
floor. Otherwise, lack of airflow beneath the ma-
chine will cause electrical parts to overheat. This
will cause problems with your product.
••Always have the installation and repairing pro-
cedures carried out by the Authorised Service
Agent. Manufacturer shall not be held liable for
damages that may arise from procedures carried
out by unauthorised persons.
Electrical safety
••If the product has a failure, it should not be op-
erated unless it is repaired by the Authorised
Service Agent. There is the risk of electric shock!
••This product is designed to resume operating in
the event of powering on after a power interrup-
tion. If you wish to cancel the programme, see
"Cancelling the programme" section.
4

••Connect the product to a grounded outlet pro-
tected by a 16 A fuse. Have the grounding instal-
lation made by a qualified electrician. Our com-
pany shall not be liable for any damages that will
arise when the product is used without ground-
ing in accordance with the local regulations.
•Unplug the product when not in use.
••Never wash the product by spreading or pouring
water onto it! There is the risk of electric shock!
••Never touch the plug with wet hands! Never un-
plug by pulling on the cable, always pull out by
grabbing the plug.
••Unplug the product during installation, mainte-
nance, cleaning and repairing procedures.
••If the power cable is damaged, it must be re-
placed by the manufacturer, after sales service
or a similarly qualified person (preferably an
electrician) or someone designated by the im-
porter in order to avoid possible risks.
Product safety
••The water supply and draining hoses must be
securely fastened and remain undamaged.
Otherwise, there is the risk of water leakage.
••Never open the loading door or remove the filter
while there is still water in the drum. Otherwise,
risk of flooding and injury from hot water will oc-
cur.
••Do not force open the locked loading door. The
loading door will be ready to open just a few min-
utes after the washing cycle comes to an end. In
case of forcing the loading door to open, the door
and the lock mechanism may get damaged.
••Use detergents, softeners and supplements suit-
able for automatic washing machines only.
••Follow the instructions on the textile tags and on 5
EN

the detergent package.
••Place the product on a rigid, flat and level sur-
face.
••Do not place it on a long-pile rug or similar sur-
faces.
••Do not place the product on a high platform or
near the edge on a cascaded surface.
••Do not place the product on the power cable.
••Never use sponge or scrub materials. These will
damage the painted, chrome plated and plastic
surfaces.
Intended use
••This product has been designed for domestic
use. It is not suitable for commercial use and it
must not be used for anything other than its in-
tended use.
••Use the product only for washing and rinsing of
textile products that are marked accordingly.
••The manufacturer waives any responsibility aris-
en from incorrect usage or transportation.
Children's safety
••Packaging materials are dangerous to children.
Keep packaging materials in a safe place away
from reach of the children.
••Electrical products are dangerous to children.
Keep children away from the product when it is
in use. Do not let them to tamper with the prod-
uct. Use child lock to prevent children from in-
tervening with the product.
••Do not forget to close the loading door when
leaving the room where the product is located.
••Store all detergents and additives in a safe place
away from the reach of the children by closing
the cover of the detergent container or sealing
the detergent package.
6

While washing the laundry at high
temperatures, the loading door glass
becomes hot. Therefore, keep child-
ren away from the loading door of the
machine while the washing operation
is in progress.
Compliance with the WEEE Directive
This product complies with EU WEEE
Directive (2012/19/EU). This product bears
a classification symbol for waste electrical
and electronic equipment (WEEE).
This product has been manufactured with
high quality parts and materials which can
be reused and are suitable for recycling.
Do not dispose of the waste product with normal do-
mestic and other wastes at the end of its service life.
Take it to the collection center for the recycling of
electrical and electronic equipment. Please consult
your local authorities to learn about these collection
centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
Package information
••Packaging materials of the product are manu-
factured from recyclable materials in accordance
with our National Environment Regulations. Do
not dispose of the packaging materials together
with the domestic or other wastes. Take them to
the packaging material collection points desig-
nated by the local authorities.
7
EN

Your washing machine
Overview
7
3
4
6
5
2
1
8
1- Power cable
2- Top panel
3- Control panel
4- Filter cap
5- Adjustable feet
6- Loading door
7- Detergent drawer
8- Drain hose
8

Package Contents
1
2
3 4
a b c
5
6
7
8
1- Power cable
2- Drain hose
3- Transportation safety bolts *
4- Mains water inlet hose (One of the following filter types is used for the mains
hose connection.)
a- Electronic water shut-off
b- Mechanical water shut-off
c- Standard
5- Liquid detergent container**
6- User Manual
7- Blind plug***
8- Plastic plug group
* Number of transportation safety bolts may change depending on the model of
your machine.
** This may be supplied with the machine depending on the model of your
machine.
*** This is supplied if your machine is equipped with double water inlet. 9
EN

Technical specifications
Complying Commission Delegated Regulation (EU) No 1061/2010
Supplier name or trademark GRUNDIG
Model name GWM 9901 S
Rated capacity (kg) 9
Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++
Annual Energy Consumption (kWh) (1) 211
Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.100
Energy consumption of the standard 60°C cotton programme at partial load (kWh) 0.830
Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0.820
Power consumption in ‘off-mode’ (W) 0.500
Power consumption in ‘left-on mode’ (W) 0.500
Annual Water Consumption (l) (2) 10780
Spin-drying efficiency class / Scale from A (Highest Efficiency) to G (Lowest Efficiency) C
Maximum spin speed (rpm) 1000
Remaining moisture Content (%) 62
Standard cotton programme (3) Cotton Eco 60°C and 40°C
Programme time of the standard 60°C cotton programme at full load (min) 240
Programme time of the standard 60°C cotton programme at partial load (min) 205
Programme time of the standard 40°C cotton programme at partial load (min) 205
Duration of the left-on mode (min) N/A
Airborne acoustical noise emissions washing/spinning (dB) 54/74
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 60
Net weight (±4 kg.) 74
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 220-240 V / 50Hz
Total current (A) 10
Total power (W) 2000-2350
Main model code 108
(1) Energy Consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load, and the
consumption of the low-power modes. Actual energy consumption will depend on how the appliance is used.
(2) Water consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load. Actual water
consumption will depend on how the appliance is used.
(3) „Standard 60°C cotton programme“ and the „standard 40°C cotton programme“ are the standard washing programmes to which the information
in the label and the fiche relates and these programmes are suitable to clean normally soiled cotton laundry and that they are the most efficient
programmes in terms of combined energy and water consumption.
Technical specifications may be changed without prior notice to improve the quality of the product.
10
