GSD WKCT2FM2501 User manual

Hui Zhou Gaoshengda Technology Co., LTD WKCT2FM2501
PAGE 1 OF 6
Version 1.0
WIFI+BT Module
IEEE 802.11 a/b/g/n/ac 2T/2R
Model Number: WKCT2FM2501
Product Descrition
The WKCT2FM2501 is a complete dual-band(2.4GHz and 5GHz)WIFI 2×2 MIMO module. This module provides a
high level of integration with a dual-stream IEEE 802.11ac MAC/ base band /radio and Bluetooth 5.2.The WLAN
operation supports 20MHz,40MHz and 80MHz channels for data rates up to 866.7Mbps. It fully complies with IEEE
802.11 a/b/g/n/ac feature rich wireless connectivity at high standards,delivers reliable,cost-effective, throughput
from an extended distance.
Product Features
Product Specification
Model
WIFI+BT Module
Product Name
WKCT2FM2501
Standard
802.11 a/b/g/n/ac
Interface
USB
Data Transfer Rate
Up to 866.7Mbps
Modulation Method
GFSK,π/4-DQPSK,8DPSK(bluetooth)
DQPSK,DBPSK,CCK(802.11b)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11g)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11n)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11a)
QPSK,BPSK,16QAM,64QAM,256QAM with OFDM (802.11ac)
Frequency Band
BLUETOOTH
2402~2480 MHz
WIFI
2.4G: 2412~2462 MHz
5G: 5180~5240MHz,5260~5320MHz,5500~5720MHz,5745~5825MHz
Operation Mode
Infrastructure
Security
WEP, TKIP, AES, WPA, WPA2
Operating Voltage
3.3V±10%
Current Consumption
＜1000mA
Antenna Type
PIFA
Operating
Temperature
0 ~ 70°C ambient temperature
Storage Temperature
-40 ~ 80°C ambient temperature
Humidity
5 to 95 % maximum (non-condensing)
◆Complies with IEEE 802.11b/g/n for 2.4GHz and IEEE 802.11a/n/ac 5GHz Wireless LAN.
◆Bluetooth v5.2
◆Two transmit and Two receive path(2T2R)
◆Works with all existing network nfrastructure.
◆Capable of up to 128-Bit WEP Encryption.
◆Freedom to roam while staying connected.
◆UP to 866.7 Mbps High-Speed Transfer Rate in 802.11ac mode of operation.
◆Operating Systems：Linux,Windows
◆Low power consumption.
◆Easy to install and configure.
◆High speed USB 2.0 interface
◆ROHS compliant

Hui Zhou Gaoshengda Technology Co., LTD WKCT2FM2501
PAGE 2 OF 6
Version 1.0
NOTICE:
◆please keep this product and accessories attached to the places which children can't touch;
◆do not splash water or other liquid onto this product, otherwise it may cause damage;
◆do not put this product near the heat source or direct sunlight, otherwise it may cause
deformation or malfunction;
◆please keep this product away from flammable or naked flame;
◆please do not repair this product by yourself. Only qualified personnel can be repaired.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
2.2
This module has been assessed against the following FCC rule parts: CFR 47 FCC Part 15 C (15.247, DTS
and DSS) and CFR 47 FCC Part 15 E (NII). It is applicable to the modular transmitter
2.3
This radio transmitter 2AC23-WKCT2F has been approved by Federal Communications Commission to operate
with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in
this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for
use with this device.
The concrete contents to check are the following three points.
１)Antenna type is a PIFA with no more than 0.3 dBi gain at BT/BLE, 2.04 dBi for 2.4 G WIFI ,4.01 dBi gain for
5G WIFI .
２)Should be installed so that the end user cannot modify the antenna
３)Feed line should be designed in 50ohm
Fine-tuning of return loss etc. can be performed using a matching network.
The antenna shall not be accessible for modification or change by the end user.
2.4
The module complies with FCC Part 15.247 / Part 15.407 and apply for Single module approval.
2.5
Trace antenna designs: Not applicable, the antennas for this module are integrated into the module. Use of external
antennas or antennas integrated into the host circuit board are not an option.

Hui Zhou Gaoshengda Technology Co., LTD WKCT2FM2501
PAGE 3 OF 6
Version 1.0
2.6
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2.7
The following antennas have been certified for use with this module.
Only antennas of the same type with equal or lower gain may also be used with this module.
Other types of antennas and/or higher gain antennas may require the additional authorization for operation. The
installer should use unique antenna connector and Antenna types not included in this list that have a gain
greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device. The
manufacturer of module will inform installer to meet with the FCC part 15.203 in the warning part.
Antenna Specification list below:
BLE/BT:
Antenna
Frequency (MHz)
Antenna Type
MAX Antenna Gain (dBi)
1
2402-2480
PIFA
0.3
2.4 G wifi:
Antenna
Frequency (MHz)
Antenna Type
MAX Antenna Gain (dBi)
1
2412-2462
PIFA
2.04
2
2412-2462
PIFA
-0.26
5G wifi:
Antenna No.
Frequency Band
Antenna Type
Max Antenna Gain (dBi)
1
5150-5850
PIFA antenna
4.01
2
5150-5850
PIFA antenna
3.13
2.8
Please notice that if the FCC identification number is not visible when the module is installed inside another
device, then the outside of the device into which the module is installed must also display a label referring to the
enclosed module. This exterior label can use wording such as “Contains FCC ID: 2AC23-WKCT2F”; any similar
wording that expresses the same meaning may be used.
2.9
In accordance with FCC guidance it is recommended that the host product manufacturer perform investigative
measurements to confirm that the system does not exceed the spurious emissions limits or band edge limits
once the module is installed in the host system.
If the host system contains other transmitters additional testing is required to check for emissions that may occur
due to the intermixing of emissions with the other transmitters, digital circuitry, or due to the physical properties
of the host product (enclosure). RF exposure assessments to account for transmissions across all transmitters
that can operate simultaneously is also required.
For additional information refer to FCC KDB 996369 D04 Module Integration Guide.
2.10
The host product manufacturer is responsible for compliance with any other FCC rules that apply to the host not
covered by the modular transmitter grant of certification.

Hui Zhou Gaoshengda Technology Co., LTD WKCT2FM2501
PAGE 4 OF 6
Version 1.0
2.11
The host manufacturer is recommended to use FCC KDB 996369 D04 Module Integration Guide recommending as
"best practice" RF design engineering testing and evaluation in case non-linear interactions generate additional
non-compliant limits due to module placement to host components or properties.
2.12
This module is stand-alone modular. If the end product will involve the Multiple
simultaneously transmitting condition or different operational conditions for a stand-alone
modular transmitter in a host, host manufacturer have to consult with module manufacturer
for the installation method in end system.
Canada Statement
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two
conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
Please notice that if the ISED certification number is not visible when the module is installed inside another
device, then the outside of the device into which the module is installed must also display a label referring to the
enclosed module. This exterior label can use wording such as the following: “Contains IC: 12290A-WKCT2F”
any similar wording that expresses the same meaning may be used.
l'appareil hôte doit porter une étiquette donnant le numéro de certification du module d'Industrie Canada,
précédé des mots « Contient un module d'émission », du mot « IC: 12290A-WKCT2F» ou d'une formulation
similaire exprimant le même sens, comme suit.
1、the device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for
harmful interference to co-channel mobile satellite systems;
1、les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour uneutilisation
à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles
utilisant les mêmes canaux;
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance
with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 etla
conformité à l'exposition de RSS-102 RF, utilisateurs peut obtenir l'information canadienne surl'exposition et la
conformité de rf.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne
ouémetteur. Cet équipement devrait être installé et actionné avec une distance minimum de 20 centimètres

Hui Zhou Gaoshengda Technology Co., LTD WKCT2FM2501
PAGE 5 OF 6
Version 1.0
entre le radiateur et votre corps.
Antenna type and antenna gain:
BLE/BT:
Antenna
Frequency (MHz)
Antenna Type
MAX Antenna Gain (dBi)
1
2402-2480
PIFA
0.3
2.4 G wifi:
Antenna
Frequency (MHz)
Antenna Type
MAX Antenna Gain (dBi)
1
2412-2462
PIFA
2.04
2
2412-2462
PIFA
-0.26
5G wifi:
Antenna No.
Frequency Band
Antenna Type
Max Antenna Gain (dBi)
1
5150-5850
PIFA antenna
4.01
2
5150-5850
PIFA antenna
3.13
Notice to OEM integrator
Must use the device only in host devices that meet the FCC/ISED RF exposure category of mobile, which
means the device is installed and used at distances of at least 20cm from persons.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The end user manual shall include FCC Part 15 /ISED RSS GEN compliance statements related to the
transmitter as show in this manual(FCC/Canada statement).
Host manufacturer is responsible for compliance of the host system with module installed with all other
applicable requirements for the system such as Part 15 B, ICES 003.
Host manufacturer is strongly recommended to confirm compliance with FCC/ISED requirements for the
transmitter when the module is installed in the host.
The use condition limitations extend to professional users, then instructions must state that this information
also extends to the host manufacturer’s instruction manual.
Host manufacturer is strongly recommended to confirm compliance with FCC/ISED
requirements for the transmitter when the module is installed in the host.
Must have on the host device a label showing Contains FCC ID: 2AC23-WKCT2F or IC: 12290A-WKCT2F
Both FCC ID and IC ID are not to be placed on the host at the same time and only hosts going into the US can
use the FCC ID and only hosts going into Canada can use the IC ID.
Installer should put it in the manual：
The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for
harmful interference to co-channel mobile satellite systems.

Hui Zhou Gaoshengda Technology Co., LTD WKCT2FM2501
PAGE 6 OF 6
Version 1.0
l'hôte doit utiliser l'instrument uniquement dans des dispositifs qui répondent à la fcc / (catégorie d'exposition rf
mobile, ce qui signifie le dispositif est installé et utilisé à une distance d'au moins 20 cm de personnes.
le manuel de l'utilisateur final doit inclure la partie 15 / (fac rss gen déclarations de conformité relatives à
l'émetteur que de montrer dans ce manuel.
le fabricant est responsable de la conformité de l'hôte, le système d'accueil avec le module installé avec toutes
les autres exigences applicables du système comme la partie 15 b, ices - 003.
accueillir le fabricant est fortement recommandé de confirmer la conformité avec les exigences de la fcc /
(émetteur lorsque le module est installé dans l'hôte
le dispositif d'accueil doivent avoir une étiquette indiquant contient FCC ID: 2AC23-WKCT2F ，IC:
12290A-WKCT2F
Les personnes chargées de l'installation devraient figurer dans le manuel:
Les dispositifs fonctionnant dans la bande de 5 150 à 5 250 MHz sont réservés uniquement pour une utilisation
à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les
mêmes canaux.
Doit avoir sur l'appareil hôte une étiquette indiquant Contient l'ID FCC 2AC23-WKCT2F ou IC :
12290A-WKCT2F L'ID FCC et l'ID IC ne doivent pas être placés sur l'hôte en même temps et seuls les hôtes se
rendant aux États-Unis peuvent utiliser l'ID FCC et seuls les hôtes se rendant au Canada peuvent utiliser l'ID IC.
