Guild CDT212G User manual

GUILD
10.8V Lithium-Ion Drill Driver
Instruction Manual
Important - Please read these instructions fully before operating or maintaining your Guild cordless drill driver
These instructions contain important information that will help you get the best from your Guild
cordless drill driver, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989
After Sales Support
CDT212G
UK/Ireland 0333 3201989
[e-mail]

Customer Helpline 0333 3201989
2
Contents
Safety Information.....................................................................................................3
In The Box..................................................................................................................9
Accessories................................................................................................................9
OperatingInstructions..............................................................................................10
Trouble Shooting......................................................................................................14
Maintenance.............................................................................................................14
Technical Data..........................................................................................................15
Environmental Protection........................................................................................16
Guarantee................................................................................................................17

Customer Helpline 0333 3201989
3
Safety Information
Important - Please read these instructions fully before starting assembly
Warning Symbols
The following warning symbols appear throughout this assembly manual and
indicate the appropriate safety measures you should take when assembling and
operating the cordless drill driver.
To reduce the risk of injury, Please read the instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Double insulation
Indoor use only
Do not expose to rain or water
Do not burn
Li-ion battery. This product has been marked with a symbol relating to ‘separate
collection’ for all battery packs and battery pack. It will then be recycled or
dismantled in order to reduce the impact on the environment. Battery packs can be
hazardous for the environment and for human health since they contain hazardous
substances.
Fuse
T 0.2 A time lag fuse with rated current of 0.2 A
Positive terminal
Negative terminal
Li-I on Li-Ion

Customer Helpline 0333 3201989
4
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of electric
shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
Safety Information
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
Original Instructions

Customer Helpline 0333 3201989
5
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce
dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together
may cause burns or a fire.
Safety Information
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings

Customer Helpline 0333 3201989
6
Safety Information
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
Drill Safety Warnings
Safety Warnings For Battery Pack
1. Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal
injury.
2. Hold power tool by insulated gripping surfaces, when performing an operation
where the cutting accessory may contact hidden wiring. Cutting accessory contacting
a “live” wire may make exposed metal parts of the power tool “live” and could give the
operator an electric shock.
a) Do not dismantle, open or shred cells or battery pack.
b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in a
box or drawer where they may short-circuit each other or be short-circuited by
conductive materials. When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small metal objects, that
can make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
c) Do not expose battery pack to heat or fire. Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical shock.
e) In the event of battery leaking, do not allow the liquid to come into contact with the
skin or eyes. If contact has been made, wash the affected area with copious amounts
of water and seek medical advice.
f) Seek medical advice immediately if a cell or battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean dry cloth if they become dirty.
i) Battery pack needs to be charged before use. Always refer to this instruction and use
the correct charging procedure.
j) Do not maintain battery pack on charge when not in use.
k) After extended periods of storage, it may be necessary to charge and discharge the
battery pack several times to obtain maximum performance.
l) Battery pack gives its best performance when it is operated at normal room
temperature (20 °C ± 5 °C).
m) When disposing of battery packs, keep battery packs of different electrochemical
systems separate from each other.
n) Recharge only with the charger specified by POSITEC . Do not use any charger other
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
6) Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.

Customer Helpline 0333 3201989
7
Safety Information
WARNING Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
Additional safety instructions for your Battery Charger
1. Before charging, read the instructions.
2. After charging, disconnect the battery charger from the supply mains. Then remove
the chassis connection and then the battery connection.
3. Do not charge a leaking battery.
4. Do not use chargers for works other than those for which they are designed.
5. Before charging, ensure your charger is matching the local AC supply.
6. For indoor use, or do not expose to rain.
7. The charging device must be protected from moisture.
8. Do not use the charging device in the open.
9. Do not short out the contacts of battery or charger.
10.Respect the polarity “+/-“ when charging.
11.Do not open the unit and keep out of the reach of children.
12.Do not charge the batteries of other manufactures or ill-suited models.
13.Ensure that the connection between the battery charger and battery is correctly
positioned and is not obstructed by foreign bodies.
14.Keep battery charger’s slots are free of foreign objects and protect against dirt and
humidity. Store in a dry and frost-free place.
15.When charging batteries, ensure that the battery charger is in a well-ventilated area
and away from inflammable materials. Batteries can get hot during charging. Do not
overcharge any batteries. Ensure that batteries and chargers are not left unsupervised
during charging.
16. Do not recharge non-rechargeable batteries, as they can overheat and break.
General Safety Warnings for Battery Charger
Safety Warnings For Battery Pack
Important - Please read these instructions fully before starting assembly
than that specifically provided for use with the equipment. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery
pack.
o) Do not use any battery pack which is not designed for use with the equipment.
p) Keep battery pack out of the reach of children.
q) Retain the original product literature for future reference.
r) Remove the battery from the equipment when not in use.
s) Dispose of properly.

Customer Helpline 0333 3201989
8
Safety Information
Important - Please read these instructions fully before starting assembly
General Safety Warnings for Battery Charger
17. Longer life and better performance can be obtained if the battery pack is charged when
the air temperature is between 18°C and 24°C. Do not charge the battery pack in air
temperatures below 4°C, or above 40°C. This is important as it can prevent serious
damage to the battery pack.
18. Charge only battery pack of the same model provided by GUILD and of models
recommended by GUILD

Customer Helpline 0333 3201989
9
In The Box
Parts
1
5
6
2
9
8
7
3
4
Battery pack release button
Battery pack
On/off switch
LED light
Keyless chuck
Torque adjustment ring
Two-speed gear control
Forward/Reverse rotation control
Soft grip handle
Accessories
Double Ended Bit (SL5.5/PH2) 1pc
Battery Pack (1.3 Ah Li-ion) 1pc
Charger (3-5 hr) 1pc
123
4
5
6
9
8
7

Customer Helpline 0333 3201989
10
NOTE: Before using the tool, read the instruction book carefully.
INTENDED USE
This tool is intended for driving in and loosening screws as well as for drilling in wood,
metal and plastic.
BEFORE PUTTING INTO OPERATION
1. RECHARGING BATTERIES
A) CHARGING THE BATTERY
The battery charger supplied is matched to the Li-ion battery installed in the tool. Do not
use another battery charger.
The Li-ion battery is protected against deep discharging. When the battery is empty, the
tool is switched off by means of a protective circuit: The tool holder no longer rotates.
In a warm environment or after heavy use, the battery pack may become too hot. Allow
time for the battery to cool down before recharging.
WARNING!
Do not continue to press the On/Off switch after the tool has been automatically
switched off. The battery can be damaged.
B) IMPORTANT NOTES FOR CHARGING THE BATTERY
The battery in your new tool is not charged when it leaves the plant. Therefore it must be
full charged before using the first time
NOTE: If the battery pack is very hot you must remove your battery pack from the charger and
allow your battery pack to cool first to ambient temperature and then recharging can be started.
To prevent damage to the Battery Pack, when charge runs out, please charge the battery
to reach full or no less than half charge before storage.
If the tool will not be used for long periods of time, charge the battery every 3-6 months.
C) CHARGING (SEE FIG A)
1) Plug the charger into an appropriate outlet. The light (a) will be green.
2) Insert the Battery Pack (7) into the charger, the light (b) will be red to indicate the
charging process has started.
3) On completion of charge, the light (a) is green, and light (b) will be off. The pack is now
fully charged, unplug the charger and remove the battery pack.
WARNING:
When battery charge runs out after continuously use or exposure to direct sunlight
or heat, allow time for the tool to cool down before re-charging to achieve the full charge.
Operating Instructions
A B
a
b

Customer Helpline 0333 3201989
11
Operating Instructions
2. REMOVE OR INSERT BATTERY PACK (SEE FIG B)
Press the battery pack release button and remove the battery pack from the tool.
After recharge slide the battery pack into tool’s battery port. A simple push and slight
pressure will be sufficient.
OPERATION
1. ON / OFF SWITCH (SEE FIG C)
Depress the On/Off switch to start and release it to stop your drill. The on/off switch
is fitted with a brake function which stops your chuck immediately when you quickly
release the switch.
It is also a variable speed switch that delivers higher speed and torque with increased
trigger pressure. Speed is controlled by the amount of switch trigger depression.
WARNING: Do not operate for long periods at low speed because excess heat
will be produced internally.
2. SWITCH LOCK
The switch trigger can be locked in the OFF position. This helps to reduce the
possibility of accidental starting when not in use. To lock the switch trigger, place the
rotation control in the center position.
3. REVERSIBLE (SEE FIG C)
For drilling and screw driving use forward rotation marked “ ” (lever is moved
to the left). Only use reverse rotation marked “ ” (lever is moved to the right) to
remove screws or release a jammed drill bit.
WARNING: Never change the direction of rotation when the chuck is rotating,
wait until it has stopped!
4. TWO-SPEED GEAR CONTROL (SEE FIG D)
The drill has a two-speed gear control designed for drilling or driving at LO (mark is
1) or HI (mark is 2) speeds. A slide switch is located on top of the drill to select either
LO or HI speed. When using the drill in the LO speed range, the speed will decrease
and the drill will have greater power and torque. When using the drill in the HI speed
range, the speed will increase and the drill will have less power and torque.
C D

Customer Helpline 0333 3201989
12
Operating Instructions
Gear I
Low speed range: for screwdriving or working with large drilling diameter
Gear II
High speed range: for working with small drilling diameter
WARNING: To prevent gear damage, always allow the chuck to come to a complete
stop before changing the direction of rotation or the two-speed gear control.
5. CHUCK ADJUSTMENT (SEE FIG E)
To open the chuck jaws rotate the front section of the chuck. Insert the drill bit between
the chuck jaws and rotate the front section in the opposite direction. Ensure the drill
bit is in the center of the chuck jaws. Finally, firmly rotate the front chuck section in the
opposite directions. Your drill bit is now clamped in the chuck.
6. TORQUE ADJUSTMENT (SEE FIG F)
(Screw driving force of your drill driver)
The torque is adjusted by rotating the torque adjustment ring. The torque is greater
when the torque adjustment ring is set on a higher setting. The torque is less when the
torque adjustment ring is set on a lower setting.
Make the setting as follows:
1 - 4 for driving small screws
5 - 9 for driving screws into soft material
10 - 18 for driving screws into soft and hard material
for heavy drilling
E F

Customer Helpline 0333 3201989
13
Operating Instructions
7. USING THE LED LIGHT
The sight light allows you to keep a clear view under less illuminated circumstances. To
turn on the light simply press the on/off switch. When you release the on/off switch, the
light will be off.
8. DRILLING
When drilling into a hard smooth surface, use a center punch to mark the desired hole
location. This will prevent the drill bit from slipping off center as the hole is started. Hold
the tool firmly and place the tip of the bit at the point to be drilled. Depress the switch
trigger to start the tool. Move the drill bit into the workpiece, applying only enough
pressure to keep the bit cutting. Do not force or apply side pressure to elongate a hole.
Tungsten carbide drill bits should always be used for concrete and masonry.
When drilling in metal, only use HSS drill bits in good condition. Always use a
magnetic bit holder (not included) when using short screwdriver bits. When screw-
driving, apply a small quantity of liquid soap or similar to the screw threads to ease
insertion.
9. DISPOSAL OF AN EXHAUSTED BATTERY PACK
To preserve natural resources, please recycle or dispose of the battery pack properly.
This battery pack contains Lithium batteries. Consult your local waste authority for
information regarding available recycling and/or disposal options. Discharge your
battery pack by operating your drill, then remove the battery pack from the drill housing
and cover the battery pack connections with heavy-duty adhesive tape to prevent short
circuit and energy discharge. Do not attempt to open or remove any of the components.
10. OVERLOAD PROTECTION
When overloaded, the motor comes to a stop. Relieve the load on the tool immediately
and allow cooling for approx. 30 seconds at the highest no-load speed.
11. TEMPERATURE DEPENDENT OVERLOAD PROTECTION
When using as intended for the power tool cannot be subject to overload. When the load
is too high or the allowable battery temperature of 75°C is exceeded, the electronic
control switches off the power tool until the temperature is in the
optimum temperature range again.
12. PROTECTION AGAINST DEEP DISCHARGING
The Li-ion battery is protected against deep discharging by the “Discharging Protection
System”. When the battery is
empty, the tool is switched off by means of a protective circuit: The inserted tool no
longer rotates.

Customer Helpline 0333 3201989
14
1. WHY DOES THE DRILL NOT TURN ON WHEN YOU PRESS THE SWITCH?
The forward/reverse rotation control, which is on top of the trigger, is positioned in the lock
function. Unlock the forward/reverse rotation control by putting it into the required rotation
position. Push the trigger and the drill will start to rotate.
2. THE DRILL STOPS BEFORE THE SCREW IS COMPLETELY TIGHTENED. WHY?
Verify the torque position of the torque adjusting ring, you can find the torque-adjusting ring
between the chuck and the drill body. Position 1 is the lowest torque (screw driving force) and
position 18 is the highest torque (screw driving force). Position is for drill operation. Regulate
the torque adjusting ring to a higher position to reach the best result.
3. REASONS FOR DIFFERENT BATTERY PACK WORKING TIMES
Charging time problems, as above, and having not used a battery pack for a prolonged time
will reduce the battery pack working time. This can be corrected after several charge and
discharge operations by charging & working with your drill. Heavy working conditions such as
large screws into hard wood will use up the battery pack energy faster than lighter working
conditions. Do not re-charge your battery pack below 0°C and above 45°C as this will affect
performance.
Maintenance
Trouble Shooting
Your tool requires no additional lubrication or maintenance.
There are no user serviceable parts in your power tool. Never use water or chemical cleaners to
clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place.
Keep the motor ventilation slots clean. Keep all working controls free of dust. Occasionally you
may see sparks through the ventilation slots. This is normal and will not damage your power tool.

Customer Helpline 0333 3201989
15
Technical Data
Voltage 10.8V
No load speed 0-400 / 0-1400 /min
Number of clutch positions 18+1
Max torque 15Nm
Chuck capacity 10mm
Charging time 3-5hr
Charger Input 100-240V~50/60Hz
Charger Output 15V 0.27A
Max. drilling capacity Steel 8mm
Wood 20mm
Machine weight 1.00kg
Technical Data Table
A weighted sound pressure LpA : 70.5dB(A)
A weighted sound power LwA : 81.5dB(A)
KpA & KwA=3.0dB(A)
Wear ear protection when sound pressure is over: 80dB(A)
Noise Information
Vibration Information
Vibration total values (triax vector sum) determined according to EN 60745:
Drilling into metal Vibration emission value ah= 2.878m/s2
Uncertainty K = 1.5 m/s²
Screwdriving without impact Vibration emission value ah =1.560m/s²
Uncertainty K = 1.5 m/s²
The declared vibration total value may be used for comparing one tool with another, and
may also be used in a preliminary assessment of exposure.
WARNING: The vibration emission value during actual use of the power tool can
differ from the declared value depending on the ways in which the tool is used
dependant on the following examples and other variations on how the tool is used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and in good
condition.
The tightness of the grip on the handles and if any anti vibration accessories are used.
And the tool is being used as intended by its design and these instructions.

Customer Helpline 0333 3201989
16
Environmental Protection
Waste electrical products must not be disposed of with household waste. Please
recycle where facilities exist. Check with your local authorities or retailer for
recycling advice.
Vibration Information
Technical Data
This tool may cause hand-arm vibration syndrome if its use is not adequately
managed.
WARNING: To be accurate, an estimation of exposure level in the actual conditions
of use should also take account of all parts of the operating cycle such as the
times when the tool is switched off and when it is running idle but not actually doing the
job. This may significantly reduce the exposure level over the total working period.
Helping to minimize your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti vibration accessories.
Avoid using tools in temperatures of 100C or less.
Plan your work schedule to spread any high vibration tool use across a number of days.

Customer Helpline 0333 3201989
17
This product is selected for DOMESTIC USE ONLY and not for business use.
This product is guaranteed against manufacturing defects for a period of 24 months. This
does not cover the product where the fault is due to misuse, abuse, use in contravention of
the instructions, or where the product has been the subject of unauthorised modifications
or alterations, or has been the subject of commercial use. In the event of a problem with
the product within the guarantee period please return it to your nearest store. If the item is
shown to have an inherent defect present at the time of sale, the store will provide you with
a replacement. Your statutory rights remain unaffected.
Issue1 08/2015
Guarantee
