GWC HE3130 User manual

1
USB 3.0 3-port Hub
With Gigabit Ethernet Adapter
User’s Manual

2
ABOUT THIS MANUAL
This manual is designed for use with the USB 3.0 3 Port Hub with Gigabit Ethernet Adapter.
Information in this document has been carefully checked for accuracy; however, no guarantee is
given to the correctness of the contents. The information in this document is subject to change
without notice. The manufacturer does not make any representations or warranties (implied or
otherwise) regarding the accuracy and completeness of this document and shall in no event be
liable for any loss of profit or any commercial damage, including but not limited to special,
incidental, consequential, or other damage.
SAFETY INSTRUCTIONS
Always read the safety instructions carefully:
Keep this User’s Manual for future reference
Keep this equipment away from humidity
If any of the following situation arises, get the equipment checked by a service technician:
• The equipment has been exposed to moisture.
• The equipment has been dropped and damaged.
• The equipment has obvious sign of breakage.
• The equipment has not been working well or you cannot get it to work according to the
User’s Manual.
COPYRIGHT
This document contains proprietary information protected by copyright. All right are reserved. No
part of this manual may be reproduced by any mechanical, electronic or other means, in any
form, without prior written permission of the manufacturer.
TRADEMARKS
All trademarks and registered trademarks are the property of their respective owners or
companies.

3
Table of Contents
1. Introduction........................................................................................4
Features...................................................................................................... 5
Package Contents....................................................................................... 5
System Requirements................................................................................. 6
2. Installation..........................................................................................7
Hardware Connection ................................................................................ 7
Driver Installation...................................................................................... 8
On Windows
®
XP/ Windows
®
Vista/ Windows
®
7 / Windows
®
8.......... 8
On Mac OS

X v10.6-10.8........................................................................ 9
Verifying the Driver Installation.............................................................. 13
On Windows
®
XP/ Windows
®
Vista/ Windows
®
7 / Windows
®
8........... 13
On Mac OS

X v10.6-10.8...................................................................... 14
3. Specifications...................................................................................16
4. Regulatory Compliance...................................................................17
FCC Conditions........................................................................................ 17
CE............................................................................................................. 17
WEEE Information .................................................................................. 17

4
1. Introduction
USB 3.0 3-Port hub with Gigabit Ethernet adapter is compliant with USB2.0
specification. It is two applications in the product. You can be through USB
interface to access USB 3.0 Hub and Giga Ethernet at the same time. Stylish
design and slim type make you easy hand carry.

5
Features
USB3.0 Giga Lan with 3 ports USB 3.0 HUB
Small design make users easy hand carry.
Support wake-on-lan function
Support Green Ethernet
Support IEEE 802.3az(Energy Efficient Ethernet)
Support IPV4/IPV6 pack Checksum Offload Engine(COE) to reduce CPU
loading
Support USB 3 ports hub with BC1.2 compatible.
It works with Window
®
XP, Windows
®
Vista, Windows
®
7, Windows
®
8,
Mac
®
Bus power or self power with power adapter 5V/2.5A
Package Contents
USB 3.0 3-port Hub with Gigabit Ethernet
Adapter
x1
Power adapter (option)
CD (Driver & User’s Manual)
x1
x1
Quick Installation Guide x1

6
System Requirements
PC with RJ-45 and USB port.
Laptop with RJ-45 and USB port.
One of the following operation systems: Windows

XP, Windows

Vista,
Windows

7, Windows
®
8 & Mac OS

10.6-10.8

7
2. Installation
Hardware Connection
General instructions for installing the USB 3.0 3-port Hub with Gigabit Ethernet adapter
are provided below. Since the design of system may vary, refer to your system’s
reference manual for further information, if needed.

8
Driver Installation
On Windows
®
XP/ Windows
®
Vista/ Windows
®
7 /
Windows
®
8
Caution: DO NOT connect the Ethernet adapter to your computer before you install
the provided driver. You will be instructed to do so later.
1. Insert the provided CD into your disc drive. Then locate and double-click the
setup.exe file under x:\Driver\Windows where x is your disc drive letter.
2. When you click setup.exe, you could see the screen as below

9
3. Click Finish to complete Ethernet Driver.
Now the installation is completed. You can connect the adapter to a network
device by an Ethernet cable:
1. Connect an Ethernet cable to the Ethernet port on the adapter.
2. Connect the other end of the Ethernet cable to your network hub, switch or
router.
The Link LED should light up green to indicate a proper physical connection
between the adapter and the network. If the Link LED doesn’t light up, please
verify the cable connections between all the network devices.
On Mac OS



X v10.6-10.8
1. Insert the provided driver CD into your CD-ROM drive. Double-click
<AX88179….pkg> to launch the setup procedure

10
2. When the Install AX88179/178A USB Ethernet Adapter Driver screen
appears, please select Continue.
3. When the screen below appears, please click Install to install

11
4. When the screen below appears, please click Continue Installation
5. Please enter your password as prompted.

12
6. It will take for a while to install the driver.
7. The installation was successful, click Restart to restart your computer

13
Verifying the Driver Installation
On Windows
®
XP/ Windows
®
Vista/ Windows
®
7 /
Windows
®
8
Once you finished the installation, you can open Windows Device Manager to
verify if your Ethernet adapter is properly installed.
To access the Device Manager:
On Windows

7 / Windows
®
8: Right-click Computer on the desktop and
click System Properties>Device Manager
On Windows

Vista: Right-click Computer on the desktop and click
Properties > Device Manager.
On Windows

XP: Right-click My Computer on the desktop and click
Properties > (Hardware) > Device Manager.
In the Network adapters group, an item named ASIX AX88179 USB 3.0 to
Gigabit Ethernet Adapter should be displayed.
If there is a question or exclamation mark next to that item, then the driver is not
properly installed. Please delete the item, select the Delete the driver software
for this device option (if provided), unplug the adapter from your computer and
then repeat the installation steps.

14
On Mac OS



X v10.6-10.8
To verify the driver of the adapter, follow the below steps to open the
About this Mac on Mac
®
1. When the screen below appears and click More Info…
2. When the screen below appears, please click System Report…

15
3. You will find that a new Ethernet network interface is available. It’s usually
named USB 3.0 Hub AX88179.
*Actual strings depend on your operation system. These screen shots are from Mac OS X v10.8
and might vary slightly for each operation system.
Now the installation is completed. You can connect the adapter to a network device
by an Ethernet cable:
1. Connect an Ethernet cable to the Ethernet port on the adapter.
2. Connect the other end of the Ethernet cable to your network hub, switch or
router.
The Link LED should light up green to indicate a proper physical connection
between the adapter and the network. If the Link LED doesn’t light up, please verify
the cable connections between all the network devices.

16
3. Specifications
USB
Upstream port x 1 (USB Type A plug)
Downstream port x 3 (USB Type A receptacles)
Compliance: USB3.0
LAN
RJ-45 x 1 (Ethernet 10/100/1000M Gigabit)
Complies with the Full-duplex with flow control and Half-duplex
with backpressure operation
Power Supply Input : 100~240V, 50Hz-60Hz
Output: 5V/2.5A (option)
LED Green and Yellow LED for Ethernet Connection indication
Housing
Size (Lx W x H) : 210 x 42 x 23.4 mm approx.
Material : plastic
Weight : 60g approx.
Power Mode
Bus-powered : 3.3V/500mA
Self-powered : 5V/2.5A (option)
Adapter：(option)
Input : 100~240V, 50Hz ~60Hz
Output : 5V/2.5A
Working
Environment
Operation temperature : 0 ~ 40 °C
Storage temperature : -20 ~ 70 °C
Certification : FCC, CE
Notice: The hub bus power may not meet higher power need like 2.5” HDD. In this case,
we suggest that you use power adapter for the power need.

17
4. Regulatory Compliance
FCC Conditions
This equipment has been tested and found to comply with Part 15 of
the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received. Including
interference that may cause undesired operation.
Important! Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user’s
authority to operate the equipment. Use an approved phone set.
CE
This equipment is in compliance with the requirements of the following
regulations: EN 55 022: CLASS B
WEEE Information
For EU ( European Union ) m ember users:
According to the WEEE ( Waste electrical and electronic equipment )
Directive, do not dispose of this product as household waste or commercial
waste. Waste electrical and electronic equipment should be
appropriately collected and recycled as required by practices
established for your country. For information on recycling of this product,
please contact your local authorities , your household waste disposal service
or the shop where you purchased the product.
