gwm ORA FUNKY CAT 2023 User manual

OWER’S NL
01-11.2022-000-en
OR FN T
OWER’S NL
--.indd 1--.indd 1 03.01.2023 15:12:2303.01.2023 15:12:23

Thank you for choosing GWM - ORA.
The more familiar you become with your vehicle,
the more you will like it and the better you will be
able to use its features. Therefore, we ask you the
following:
Please read this manual carefully before driving
your vehicle. There are important tips about using
your vehicle in this booklet that will help you make
the best use of your vehicle’s technology. Addition-
ally, you will learn very practical information about
driving safety, road safety and maintaining the val-
ue of your vehicle.
May you enjoy safe and happy travels!
1

Overview
Contains a statement about the use of the manual and the meaning of the symbols.
Vehicle equipment
Please note that this manual describes
all standard equipment, country-specic
equipment and special equipment for
this series. Therefore, some equipment
or functions described in this manual
may not be installed in your vehicle or
only available in certain markets. To
learn more about specic congura-
tions, please refer to sales documents or
consult the dealer where you purchased
the vehicle.
On right-hand drive vehicles, the actual
positions of some operating elements
may be dierent from those shown in
the illustrations.
Validity of this manual
This manual has the latest information
available at the time it was released.
However, as our products continue to
improve, the topics in this manual will
have updated information. Use the vehi-
cle’s multimedia display to nd the latest
digital owner's manual.
Depending on the vehicle specications,
the vehicle equipment shown in pictures
may be dierent from your vehicle.
The screen display information (such as
pictures, icons and text) shown in this
manual is for illustrative purposes only.
Depending on the vehicle conguration,
software version, theme and settings,
the information displayed may be dier-
ent. Please refer to the actual model for
specic information.
Accessories, replacement parts
and modications
Both genuine parts and various other
spare parts and accessories suitable for
this vehicle are available for purchase.
We recommend using genuine parts or
other parts that comply with quality
standards for all replacements.
We are unable to provide any guarantee
and assume no responsibility and obli-
gation for non-genuine parts and acces-
sories or for using non-genuine spare
parts and accessories for replacement
or installation. Moreover, any damage to
the vehicle or performance issue caused
by the use of a non-genuine part or ac-
cessory is not covered by the warranty.
Symbols
WARNING
This represents a warning.
Ignoring these warnings may result in
serious injury or death. These warnings
inform you what you must or must not
do to reduce the risk of serious injury
and death to yourself and others.
CAUTION
This represents a precaution.
2

Ignoring these precautions may result
in damage to the vehicle or equipment.
These precautions inform you what
you must or must not do to avoid or
reduce the risk of damage to the vehi-
cle or equipment.
NOTICE
This represents a notice.
This type of supplementary informa-
tion may be helpful to you.
Safety notice
WARNING
General precautions for driving
〉Sober driving: Alcohol, drugs, anaes-
thetics and some medicines slow
down the body’s reactions and aect
judgement and coordination, which
can easily result in loss of control
over the vehicle and a serious acci-
dent.
〉Drive carefully: Always pay attention
to mistakes that other drivers or pe-
destrians on the road may make, so
you can promptly appraise the situa-
tion and prevent an accident.
〉Pay attention while driving: Anything
that distracts the driver, including ad-
justing vehicle controls, making or re-
ceiving telephone calls and reading
can cause a collision that results in
serious injury or death to you, pas-
sengers in the vehicle or others.
WARNING
Never leave a child, a person needing
assistance or a pet alone in the vehicle.
〉Children, people needing assistance
and pets cannot leave the vehicle or
rescue themselves. The temperature
inside the vehicle may become very
high or very low in certain weather
conditions, which can easily lead to
injury or even death.
〉If a child or pet touches the key, this
may start the vehicle, release the
parking brake, switch the gear posi-
tion, operate the doors or windows
or cause the vehicle to move on its
own, endangering the vehicle and
surrounding trac and pedestrians.
3

Exterior (Type I)
79B86D2AFCB3
ⒶCamera, for:
Panoramic view 113
ⒷHigh position brake light
ⒸRear lights assembly
ⒹAutomatic front wipers 63
ⒺDepending on the model congura-
tion, the camera may be used for:
Lane assist system 134
Forward assist system 129
Trac sign information 138
ⒻRear fog lamp 58
ⒼAnti-collision radar 114
ⒽCamera, for:
Panoramic view 113
ⒾAnti-collision radar 114
ⒿFront lights assembly
ⓀCharging port cover 40
ⓁSide mirrors 53
4

Exterior (type II)
57B924118940
ⒶCamera, for:
Panoramic view 113
ⒷHigh position brake light
ⒸRear lights assembly
ⒹAutomatic front wipers 63
ⒺDepending on the model congura-
tion, the camera may be used for:
Lane assist system 134
Forward assist system 129
Trac sign information 138
ⒻRear fog lamp 58
ⒼAnti-collision radar 114
ⒽCamera, for:
Panoramic view 113
ⒾAnti-collision radar 114
ⒿFront lights assembly
ⓀCharging port cover 40
ⓁSide mirrors 53
5

Interior - left-hand drive
F843E817A78C
ⒶCamera used for
intelligent monitoring system 121
ⒷLighting control combination
switch 58
ⒸSteering wheel 56
ⒹDisplay screen, for:
Virtual instruments panel 144
Instruments panel lights 148
Multimedia 164
ⒺWiper control combination
switch 63
ⒻA/C control switch 66
ⒼHazard warning light switch 60
ⒽLuggage hook
ⒾA/C outlet vent 71
ⒿDriving mode switch 106
ⓀHeadlamp levelling switch 61
ⓁBoot lid control switch 24
ⓂVehicle power supply o button 97
ⓃBrake pedal
ⓄAccelerator pedal
ⓅUSB port 161
ⓆGear change twist knob 102
ⓇBackup power supply 76
ⓈGlove box 74
6

Interior - right-hand drive
B65B38A7777B
ⒶA/C outlet vent 71
ⒷA/C control switch 66
ⒸHazard warning light switch 60
ⒹLighting control combination
switch 58
ⒺDisplay screen, for:
Virtual instruments panel 144
Instruments panel lights 148
Multimedia 164
ⒻSteering wheel 56
ⒼWiper control combination
switch 63
ⒽCamera used for
intelligent monitoring system 121
ⒾGlove box 74
ⒿUSB port 161
ⓀGear change twist knob 102
ⓁBackup power supply 76
ⓂDriving mode switch 106
ⓃHeadlamp levelling switch 61
ⓄBoot lid control switch 24
ⓅVehicle power supply o button 97
7

Contents
1 Operation Explains the basic functions of interior equipment such as
the key, doors, windows and seats.
2 Driving Provides information about starting the vehicle, changing
gear, the instrument panel and other driving-related items.
3 Audio-visual sys-
tem
Explains the functions of the audio-visual system such as
making calls using Bluetooth and system settings.
4 Safety & Security Describes vehicle safety devices such as the anti-theft system
and seat belts.
5 Emergency Explains how to deal with a vehicle failure such as a burst
tyre or at battery.
6 Maintenance Explains daily inspections and regular maintenance.
7 Technical data Describes information such as vehicle specications and the
vehicle identication number.
8 Index List of the alphabetical index in this manual.
9

Operation
Key .........................................................18
Information about the key..............18
Button introduction.........................18
Battery replacement........................19
Door locks.............................................21
Intelligent entry system locking and
unlocking...........................................21
Key button locking and unlocking
............................................................22
Central locking and unlocking........22
Mechanical key locking and unlock-
ing.......................................................22
Internal release unlocking ..............23
Super lock .........................................23
Emergency locking...........................23
Boot lid ..............................................24
Child lock...........................................29
Parking unlocking ............................29
Auto lock ...........................................29
Automatic relock..............................30
Collision auto-unlock.......................30
Windows ...............................................31
Window switch .................................31
Heat protection function ................32
Anti-trapping function.....................32
Delay function ..................................32
Easy close..........................................32
Initialisation ......................................33
Sunroof..................................................34
Sunroof operation ...........................34
Closing and opening the sunshade
............................................................35
Linked function ................................35
Anti-trapping function.....................35
Delay function .................................36
Easy close..........................................36
Automatic closing function.............36
Initialisation ......................................36
Bonnet...................................................38
Opening.............................................38
Closing ...............................................38
Vehicle charging...................................40
Charging mode.................................40
Charging cable..................................41
Normal charging ..............................42
Emergency release ..........................45
Fast charging ....................................45
Seats ......................................................46
Headrests..........................................46
Front row manual seats..................46
Front row electric seats...................48
Rear row seat adjustment ..............48
Easy entry function..........................49
Driver's seat memory......................49
Seat settings .....................................51
Mirrors...................................................53
Rear view mirror ..............................53
Side mirror adjustment...................53
Side mirror settings .........................54
10

Side mirror defrosting function .....55
Steering wheel......................................56
Adjustment method ........................56
Horn...................................................56
Heating function ..............................57
Lighting controls ..................................58
Lighting control combination switch
............................................................58
Hazard warning lights .....................60
Daytime running lights....................61
Follow me home headlights ...........61
Emergency braking warning...........61
Levelling the headlamps.................61
Lighting settings...............................61
Interior lights ....................................62
Wiper controls......................................63
Front wipers......................................63
Optical rain sensor ..........................64
Windscreen washer nozzle heating
function .............................................65
Front wiper interval .........................65
A/C system............................................66
A/C control screen ...........................66
A/C settings screen ..........................67
A/C controller ...................................70
Cabin air refresh ..............................71
Air vents ............................................71
Mobile phone wireless charging........72
Usage.................................................72
Interior ttings .....................................74
Sun visors..........................................74
Vanity mirror.....................................74
Storage ..............................................74
Power supply socket........................76
Driving
Driving procedures..............................80
Before driving...................................80
While driving.....................................81
Precautions for passengers............83
Parking the vehicle ..........................83
Economical driving...........................84
Driving in adverse weather conditions
................................................................85
Driving in fog ....................................85
Driving in the rain ............................85
Driving through water.....................85
Driving in hot weather.....................86
Driving in cold weather ...................87
Running-in ............................................90
Tyres ..................................................90
Brake pads ........................................90
Pure electric vehicles...........................91
Power battery recycling ..................91
About pure electric vehicles...........92
Charger temperature regulation
function .............................................94
Energy recovery ...............................94
Battery safety switch .......................95
High-voltage warning labels ...........95
Vehicle power supply ..........................97
11

Vehicle power supply ......................97
Parking brake .......................................99
Safety notice .....................................99
Electric parking brake......................99
Gearbox.............................................. 102
Gears .............................................. 102
Changing gear ............................... 102
Creep function............................... 103
Driving o....................................... 103
Park................................................. 104
Driving mode..................................... 106
Switching modes........................... 106
Acoustic vehicle alert system.......... 109
Usage.............................................. 109
Power assisted steering mode........ 110
Switching modes........................... 110
Parking assist system....................... 111
Safety notice .................................. 111
Parking settings............................. 112
Panoramic view............................. 113
Anti-collision radar........................ 114
Intelligent integrated parking sys-
tem ................................................. 115
Track-back reverse........................ 117
Tyre pressure monitoring system .. 119
System overview ........................... 119
Monitoring function...................... 119
Warnings ........................................ 119
Intelligent monitoring system......... 121
Intelligent monitoring system..... 121
Cruise control assist system ........... 123
System overview ........................... 123
Usage.............................................. 124
Trac jam assist ........................... 126
Cornering assist ............................ 126
Lane centring assist while cruising
......................................................... 126
Function limits............................... 127
Sensors........................................... 128
Intelligent driving assistance system
............................................................. 129
Usage.............................................. 129
Forward assist system.................. 129
Side and rear assist system......... 132
Lane assist system........................ 134
Smart cruise................................... 137
Trac sign information................ 138
Driving assistance systems.............. 141
Safety notice .................................. 141
Anti-lock braking system.............. 141
Electronic brake force distribution
system ............................................ 142
Emergency brake assist ............... 142
Traction control system ............... 142
Secondary collision mitigation sys-
tem.................................................. 142
Hill hold control............................. 142
Electric power steering................. 142
Electronic stablity control ............ 142
Virtual instruments........................... 144
12

Overview ........................................ 144
Instruments panel controls......... 146
Instruments panel lights.................. 148
Instruments panel lights.............. 148
Power management system ........... 155
System overview ........................... 155
Things you should know .............. 155
Audio-visual system
Safety notice...................................... 158
Vehicle equipment........................ 158
Safety.............................................. 158
Use .................................................. 158
Radio............................................... 158
USB storage devices ..................... 158
Bluetooth ....................................... 158
Introduction to the panel ................ 160
Vehicle equipment........................ 160
Steering wheel buttons................ 160
External devices ............................ 161
Introduction to the display screen. 164
Multimedia display ....................... 164
Using the display screen.............. 164
Central display status bar............ 164
Function introduction ...................... 166
Vehicle equipment........................ 166
Screen overview............................ 166
Shortcut screen............................. 167
Launcher screen ........................... 167
Communication............................. 168
System settings ............................. 169
My account .................................... 172
Power assistant............................. 172
Voice assistant............................... 172
Entertainment scenario ............... 173
Driving scenario ............................ 174
Skill tree.......................................... 177
E-manual ........................................ 177
Safety & Security
Seat belts ........................................... 180
Safety notice .................................. 180
Correctly wearing your seat belt. 181
Pre-tensioner seat belts............... 181
How to use the three-point seat belt
......................................................... 182
Airbags ............................................... 184
Vehicle equipment........................ 184
Safety notice .................................. 184
Airbags............................................ 185
Front airbags ................................. 186
Side airbags ................................... 188
Curtain airbags.............................. 189
Seat-mounted side airbags ......... 190
Front passenger airbag switch.... 190
Child restraint system...................... 192
Recommended child seat types.. 192
Child seat safety instructions...... 193
Child seat xing points................. 194
Child seat installation................... 195
13

Complete vehicle anti-theft system 199
System description ....................... 199
Usage.............................................. 199
Ultrasonic theft protection system 201
Usage.............................................. 201
Vital signs monitoring ...................... 202
Function overview......................... 202
Alarm types.................................... 202
Switching o the alarm ................ 203
Emergency shut-o system............. 204
Emergency shut-o system......... 204
Event data recorder.......................... 205
System description ....................... 205
Data access.................................... 205
Data disclosure.............................. 205
Information security......................... 207
Data privacy and protection........ 207
Emergency
Toolkit................................................. 212
Toolkit location.............................. 212
Punctures or low tyre pressure ...... 213
Air pump and tyre repair uid .... 213
Emergency tyre repair.................. 213
Tyre ination.................................. 215
In case of an accident....................... 216
In case of a trac accident.......... 216
In case of re ................................. 216
Jump lead connection ...................... 218
Signs of a drained battery ........... 218
Starting with jump leads.............. 218
Towing................................................ 220
Using a specialised vehicle for trans-
port ................................................. 220
If the vehicle gets stuck or high-cen-
tred.................................................. 220
Tow rope ........................................ 221
Towing hook .................................. 222
Services and recovery ...................... 224
Function introduction................... 224
Maintenance
The importance of vehicle care ...... 228
Engine compartment ....................... 229
Safety notice .................................. 229
Location of oil and uids.............. 229
Brake uid...................................... 230
Coolant ........................................... 230
Windscreen washer uid ............. 231
Active intake grille......................... 231
Battery............................................ 231
Safety stickers and labels ................ 232
Engine compartment warning stick-
er ..................................................... 232
Warm air system overow tank
warning label ................................. 232
Powertrain system overow tank
warning label ................................. 232
Battery warning symbol............... 233
Replacing components .................... 234
Fuses............................................... 234
14

Wiper blades.................................. 235
Bulbs............................................... 237
Vehicle care ....................................... 238
Tyre care......................................... 238
Sunroof care .................................. 240
Exterior maintenance................... 241
Interior care................................... 242
Anti-corrosion measures ............. 243
Long term vehicle storage ........... 244
Environmental information............. 246
Disposal of batteries and electronic
equipment ..................................... 246
Vehicle recycling and scrapping.. 246
Technical data
Vehicle identication........................ 248
Vehicle identication number..... 248
Drive motor serial no. .................. 249
Vehicle parameters .......................... 250
Basic parameters .......................... 250
Powertrain parameters................ 250
Tyre specication .......................... 251
Wheel parameters ........................ 251
Brake parameters......................... 251
Oil and uid parameters.............. 252
Seat parameters............................ 252
Index
Alphabetical index ............................ 254
15

1Operation
Key ............................................ 18
Door locks................................ 21
Windows .................................. 31
Sunroof .................................... 34
Bonnet...................................... 38
Vehicle charging...................... 40
Seats......................................... 46
Mirrors ..................................... 53
Steering wheel ........................ 56
Lighting controls ..................... 58
Wiper controls......................... 63
A/C system............................... 66
Mobile phone wireless charging
................................................... 72
Interior ttings ........................ 74
17

Vehicle equipment
Please note that this manual describes
all standard equipment, country-specic
equipment and special equipment for
this series. Therefore, some equipment
or functions described in this manual
may not be installed in your vehicle or
only available in certain markets. To
learn more about specic congura-
tions, please refer to sales documents or
consult the dealer where you purchased
the vehicle.
Information about the key
4357ACCBE65C
ⒶSmart key
ⒷKey number plate
NOTICE
〉Please keep track of the key number
plate. The code on the plate is re-
quired to make a replacement key.
You will need this code to ask an au-
thorised service centre to make a re-
placement key.
〉This number must be given to the
owner when buying or leasing the ve-
hicle.
Button introduction
580544CE25D5
ⒶBoot lid control button
ⒷLock button
ⒸUnlock button
Lock button
Press the lock button to lock all doors.
The indicators will blink once.
NOTICE
If the indicators do not ash when lock-
ing the doors, check that all doors and
the boot lid are fully closed.
Unlock button
Press the unlock button to unlock all
doors. The indicators will blink twice.
〉You can set the unlocking mode in
【Vehicle Settings】→【Body】→
【Door Lock】via the multimedia
screen.
If it is set to【Driver Only】, when the
unlock button is pressed, only the driv-
er’s door will be unlocked. At that
point, if the unlock button is pressed
again, all doors will be unlocked.
If it is set to【Four Doors Unlock】,
Key
18
1
Operation

when you press the unlock button, all
doors will be unlocked.
Boot lid control button
When the power supply mode is OFF,
the boot lid can be unlocked by pressing
and holding the boot lid control button.
After unlocking, press the boot lid micro
switch within 30 seconds to open the
boot lid. For an electric sensor boot lid,
pressing and holding the boot lid control
button will open or close the electric
sensor boot lid.
Car search
When all the doors and the boot lid are
locked and the anti-theft system is on,
press the lock button twice to turn on
car search function to quickly nd your
vehicle in car parks and other places.
Pressing the lock button again will
switch o the search function.
NOTICE
Go to 【Vehicle Settings】→【Light-
ing】→【Parked Car Alert Mode】 on
the multimedia display to set the vehi-
cle alert status when car search is trig-
gered.
CAUTION
〉You must not change the transmit-
ting frequency or increase the trans-
mitting power rating (including by
adding a radio-frequency power am-
plier) and must not connect an ex-
ternal antenna or adapt any other
aerial.
〉Your usage must not interfere with
any legal radio communications op-
eration. If any interference occurs,
usage should be stopped and meas-
ures taken to eliminate the interfer-
ence before usage continues.
〉Usage may be aected by various ra-
dio devices, causing brief interrup-
tions in function.
Battery replacement
WARNING
The vehicle key contains a button bat-
tery.
〉The button battery built into the ve-
hicle key is dangerous. Both new and
old batteries must be kept away from
children at all times.
〉If swallowed or inserted into any part
of the body, the button battery can
cause severe or fatal injury within
two hours or less.
〉If it is suspected that the battery has
been swallowed or that it has been
inserted into any part of the body,
seek immediate medical attention.
〉Dispose of used batteries in accord-
ance with local laws. Incorrect dis-
posal of used batteries may cause
environmental damage.
CAUTION
〉During this operation, be sure to
19
1
Operation
