H2Odyssey INTRIGUE WS User manual
http://www.h2odyssey.com
H2Odysey
USER / OWNER
BUOYANCY COMPENSATOR
DEVICE MANUAL
INTRIGUE WS SPORTPAK
INDEX
DESCRIPTION PAGE
INTRODUCTION #1
CAUTION #1 / #2 / #15
BCD USE and FUNCTION #3
FEATURES #4
CONSTRUCTION and MATERIALS #5
SCUBA CYLINDER MOUNTING #5 / #6
TANK POSITIONING STRAP #7 / #8
DONNING and ADJUSTMENT #9 / #10
DOFFING and DRAINING BCD #11 / #12
WEIGHT DROP SYSTEM #13 / #16
WARNING #13
REAR WEIGHT POUCHES #15 / #16
PRE-DIVE PROCEDURE #17
OPERATIONAL INSPECTION #17 / #18
DIVE BCD EXAM. / PRODEDURES #19
POST-DIVE EXAM. / PROCEDURE #20
NOTES #21
WARRANTY #22
BUOYANCY COMPENSATOR LIMITED WARRANTY
WHAT IS COVERED
This warranty covers to the original owner, all defects in material or workmanship in any Buoyancy
Compensator sold by H2Odyssey.
WHAT IS NOT COVERED
This warranty does got cover damage, failure or loss caused by wear or tear, failure to per-
form normal maintenance on H2Odyssey items. Cosmetic damage such as scratches,
tears, punctures, discoloration or any damage failure or loss caused by:
1: Accident misuse neglect, abuse, or improper maintenance.
2: Failure to follow instructions in the USERS GUIDE.
3: Rental, Training Class, Military, or Commercial usage.
4: Use by uncertified (ie. PADI, NAUI, SSI, etc.) persons.
FOR HOW LONG
The warranty coverage is limited lifetime on the Buoyancy Compensator Air Cell Radio
Frequency (RF) seams and airway assembly (inflator, corrugated hose and dump valve mech-
anism). The warranty coverage on low pressure hose assembly, sewn seams and non aircell
materials have a one (1) year limited warranty on H2Odyssey BCD’S to the original pur-
chaser, under the terms and conditions defined below.
Within the warranty period, H2Odyssey will at its option, either repair or replace (with
same or equivalent product) the defective in warranty product, part or accessory. Cost of labor
for warranty is not covered by warranty. The product must be accompanied by a dated proof
of purchase for warranty service. As a matter of warranty policy, H2Odyssey will not
refund the consumers purchase price.
NO LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
Repair or replacement of defective products, parts or accessories specified above are Your
sole Remedy under this warranty and IN NO EVENT SHALL H2Odyssey BE LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the exclu-
sion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you.
HOW YOU CAN GET SERVICE
Contact your authorized H2Odyssey Service Center or write to H2Odyssey,
975 Park Center Dr, Vista CA 92083 for the name and address of your nearest
authorized H2Odyssey Service Center.
YOUR RIGHTS UNDER THE LAW
This warranty gives you specific legal rights and you may also have other rights which may vary
from state to state.
IMPORTANT NOTE
The above warranty applies to product sold and serviced in North America and Caribbean.
Consult your local dealer or importer for details of warranty coverage in your country. Product
purchased in the United States, Canada, or Caribbean but serviced in other counties will be
subject to the warranty conditions in effect in the country of use and service.
http://www.h2odyssey.com
PAGE 1 PAGE 18
IMPORTANT INFORMATION
Avoid prolonged exposure to direct sunlight or excessive heat.
The ultraviolet rays of the sun will shorten the life span of the
BCD materials.
Keep sharp objects from coming into contact with the BCD.
Do not rest heavy objects on the BCD. Do not drag your equip-
ment over rough surfaces.
Periodically lubricate the quick connect coupling with silicone
lubricant.
Chlorine can be especially harmful to the BCD materials. Rinse
the BCD thoroughly after pool use.
Use only fresh water and mild soap to clean the BCD. Chemical,
strong detergents or solvents could damage the BCD.
It is recommended that the BCD be inspected yearly by an
authorized SCUBA repair facility.
NAME:....................................................................................
ADDRESS:.............................................................................
CITY:.............................................STATE:...........ZIP:............
MODEL NUMBER:.................................................................
MODEL NAME:......................................................................
DATE PURCHASED:.............................................................
SERVICE DATES:.................................................................
INTRODUCTION
Congratulations on the purchase of your
H2Odyssey
Buoyancy Compensating Device (BCD). Your BCD is one of the
key elements of buoyancy control, and has been designed and
manufactured to combine design features and technology to pro-
vide you with fit and comfort in a high performance package that
will enhance your time spent in the underwater world.
This manual contains information about your BCD as well as infor-
mation which may affect your safety and the longevity of your
equipment. Please take the time to thoroughly read this manual
and become familiar with all of your SCUBA equipment before you
enter the water.
This information has been put together for your safety. Please
read and understand this manual completely before using your
new BCD.
Before using this product in open water, familiarize yourself with
its function and use in a controlled environment such as a pool.
Use all equipment you would normally use for an open water dive.
A BCD's function is to make diving more comfortable by allowing
a diver to maintain neutral buoyancy. It is NOT a substitute for
proper swimming and diving skills.
A BCD works in combination with your weight belt. It is very impor-
tant for you to be properly weighted. If you over-weight, you
reduce the BCD's capacity to provide positive buoyancy.
Use of this product requires training in buoyancy compensation
from an internationally recognized SCUBA certifying agency
(PADI, NAUI, SSI etc). Read the owner's manual and all warnings
and instructions that accompany this product. Misuse of this prod-
uct, or the use of improperly functioning equipment can result in
uncontrolled ascents, uncontrolled descents, or loss of buoyancy
control.
PAGE 17 PAGE 2
CAUTION
This is NOT a Coast Guard approved surface flotation device and
will not provide face-up flotation for all users in all conditions.
Inflate the BCD slowly. Rapid inflation can cause an uncontrolled
ascent that could result in air embolism, serious injury, or death.
Practice is required to maintain a safe rate of ascent. The
Overpressure Valve (OPV) does not control or prevent uncon-
trolled ascents.
Adding weights in the pockets or attaching them to the BCD may
prevent you from easily releasing the weights in case of an emer-
gency. Excess weight may impair or prevent proper operation of
the BCD and may reduce the buoyancy of the BCD.
Always perform a pre-dive, dive, and post dive inspection of the
BCD and have your dive buddy perform the inspections of your
equipment as well. See the inspection procedures detailed in this
manual for further information.
Adjust the cummerbund and attachment straps for a comfortable
fit. A properly fitted BCD should not restrict your breathing when
fully inflated. Before each use, check all of the bands, straps,
quick- disconnect clips, and the cummerbund for wear. Have an
authorized scuba equipment repair facility replace worn or dam-
aged items before use.
Use of after-market accessories or changes to the BCD can pre-
vent the BCD's proper functioning and result in product damage.
Always soak the air cylinder band in water before each use to
allow the band to stretch. Failure to soak the band may allow the
cylinder to loosen during use resulting in loss of air supply, buoy-
ancy control, or equipment damage. Before each use check all
scuba tank buckles and bands for wear. Have an authorized
scuba equipment repair facility replace worn or damaged items
before use.
POST DIVE
BCD EXAMINATION and PROCEDURES
With proper care your BCD should provide many years of use.
Maintenance procedures are as follows:
AFTER DIVING:
Rinse the BCD thoroughly inside and out with fresh water after
every use. Use the following procedure:
A) Fill the BCD inner bladder approximately one fourth full of
fresh water.
B) Orally inflate the BCD and shake to distribute the water
throughout the inside of the BCD.
C) Hold the BCD upside down. Depress the oral inflator button
and allow the water to drain from the oral inflator mouthpiece.
D) Repeat this rinsing procedure one or two times more.
E) Rinse the exterior of the BCD by dipping it into a tub of fresh
water.
F) Rinse all valving to make sure that sand or other debris is
removed.
G) Hang the BCD out of the sun and allow to dry completely.
H) Partially inflate the BCD and store in a dark and dry location.
PLAN
YOUR
DIVE
DIVE
YOUR
PLAN
PAGE 3 PAGE 16
DIVE
BCD EXAMINATION and PROCEDURES
This is the final BCD check before you begin your actual dive. The
examination can be performed on the beach, on the boat, or on
the water's surface next to the boat.
OPERATIONAL INSPECTION
After your gear is assembled and you have put your BCD and
scuba cylinder on, perform the following operational check.
Check the PIV (3) and the OPV (7). Inflate the BCD using the PIV
(3) until the OPV (7) opens to exhaust the excess air. Use short
bursts of air instead of one long flow to better control the inflation
of the BCD.
Leave the BCD inflated for 60 seconds and check for any leaks. If
you are at the water's surface, you may not hear any leaks but you
may see a steady stream of air bubbles which could indicate a
leak. Use your dive buddy to help with this check.
Check the EDV (2): Deflate the BCD using the EDV (2). You
should hear the air exhausting out of the EDV from the mouth-
piece(1).
Check the OIDV (2): Orally inflate the BCD using the OIDV (2).
Leave the BCD inflated for 60 seconds and check for any leaks.
Deflate the BCD using the OIDV (2).
Have your dive buddy check the tank band for proper assembly
and tightness. (See instructions on page 6).
Check that all connections are secure.
If the BCD fails to pass any of these tests or there is any doubt
about any of the components, DO NOT DIVE WITH THE BCD.
Have the BCD inspected by an authorized repair facility.
CAUTION
Do not attach a high pressure hose to the Pneumatic Inflation Valve
(PIV). The Pneumatic Inflation Valve (PIV) handles only low pres-
sure air (150 psi or less). Read the inflator manufacturer's instruc-
tions concerning proper connection locations and procedures.
Product damage or personal injury can result from improper con-
nection.
These instructions do not necessarily incorporate all steps required
under all conditions for oral inflation of the BCD underwater. Oral
inflation of the BCD underwater requires special training and prac-
tice. This should first be attempted under controlled conditions with
the supervision of a certified instructor.
Never breathe from the BCD Oral Inflation/Deflation Valve (OIDV)
Mouthpiece. Your BCD may contain contamination that may be
hazardous if inhaled.
Use of the Oral Inflation/Deflation Valve (OIDV) or the
Overpressure Valve (OPV) for deflation may allow water to enter
the BCD bladder. Repeated use may allow enough water in to
reduce the amount of buoyancy provided by the BCD. Drain the
BCD of any accumulated water after each dive.
BCD's USE and FUNCTION
Your new BCD:
Provides surface flotation:
The BCD adds to your surface buoyancy and allows you to put
more effort into swimming instead of flotation. The BCD alone,
however, will not necessarily provide adequate surface flotation.
Provides neutral buoyancy at various depths:
When you have reached your desired diving depth, adding or
releasing the correct amount of air will assist in achieving neutral
buoyancy.
Allows adjustment of Buoyancy:
The BCD provides the diver with the ability to adjust their
buoyancy by releasing and adding air to the BCD.
PAGE 15 PAGE 4
FEATURES
PAGE 5
H2Odyssey
BUOYANCY COMPENSATOR
OPERATIONAL INSPECTION (cont.)
Your
H2Odyssey
BCD is equipped with TWO (2) OPV’s.
One (1) is located on the LOWER RIGHT SIDE of your BCD.
The other on the INFLATOR HOSE. To check the LOWER
RIGHT SIDE OPV, inflate BCD until FIRM and pull on cord light-
ly coming out of OPV. If air is released, OPV is functioning.
Check OPV (7) operation by slowly over inflating the BCD. Fill
the BCD until it is firm, then continue to add air in small amounts.
Do this cautiously in case the valve is malfunctioning and does
not release. Once the maximum internal pressure for the BCD
is reached, the OPV (7) will open. You will hear air escaping
through the valve. If the OPV (7) fails to open or if there is any
question about its operation, have the BCD checked by an
authorized scuba repair facility. If the OPV (7) has a Pull Dump
Assembly, make sure it operates by pulling on the cord.
PAGE 14
PRE-DIVE
BCD EXAMINATION
The pre-dive, dive, and post-dive BCD examinations help identify
equipment problems before unsafe conditions exist. Equipment-
related diving accidents can be prevented by following these sim-
ple steps and having all equipment regularly inspected by an
authorized scuba equipment repair facility.
VISUAL INSPECTION
Examine the entire BCD for cuts, punctures, frayed seams.
Excessive abrasion or other damage. If there is any doubt of the
condition of the BCD, do not dive.
Inspect the OIDV/PIV Assembly for any cracks or damage. Check
the OIDV Button and OIDV mouthpiece for sand or other debris.
Check the EDV (2) EXHAUST DUMP VALVE and the OPIV (7)
housings to make sure they are free from damage, sand and or
other debris.
OPERATIONAL INSPECTION
After the visual examination, it is recommended to test the BCD's
operating systems.
Test the oral inflator by inflating the BCD through the oral inflator
mouthpiece(1). Check the inflation system and the BCD for leaks.
Let the BCD stand inflated for 30 minutes or more. Check the
BCD for any loss of air.
Test the power inflator by attaching the male quick connect (4) to
the pressurized L.P. hose (6) and depressing the power inflator
button (3). Check the inflation system and the BCD for leaks. Let
the BCD stand inflated for 30 minutes or more. Check the BCD
for loss of air. Allow the BCD to remain connected to the pressur-
ized L.P. hose. Deflate the BCD using the deflator button (2) and
allow to stand uninflated for 30 minutes or more. Leakage through
the power inflator (3) will be evident if the BCD self inflates.
Test the dump valve by pulling on the inflator assembly. The
internal cable will activate the upper dump valve (7). The valve
should close properly upon release.
PAGE 13
CONSTRUCTION and MATERIALS
Your BCD may employ either a single bag or double bag construc-
tion. The double bag BCD is constructed of a strong nylon fabric
outer shell and a durable polyurethane inner bladder. The urethane
bladder is radio frequency (RF) welded to provide a durable air
chamber. The single bag BCD is constructed of a single chamber
made from a 420 denier nylon fabric backed by a polyurethane
coating. This high strength fabric composite provides exceptional
resistance to tears, abrasions, and punctures. The single bag is
also RF welded to provide an exceptionally strong seal. All hard-
ware and related items on your BCD such as buckles, D-rings, and
webbing have been chosen for their superior strength and resist-
ance to the harsh conditions the diving environment places upon
them. With proper care, your BCD will provide years of service.
SCUBA CYLINDER MOUNTING PROCEDURE
Refer to the following diagrams to properly assemble the tank
strap.
1. Soak the mounting bands in water. Nylon expands as it
absorbs water. Soaking will permit the natural stretch of the
nylon webbing.
2. Place the SCUBA tank against the mounting plate on the back
of the BCD. Pull the end of the tankband around the tank.
3. Make sure that the buckle is in the "open" position.
4. Thread the end of the band between the metal ring and the
plastic body of the buckle.
5. Feed the end of the band through the center slot on the top side
of the buckle.
PAGE 6
6. Feed the webbing end through the lower slot and then back
through the metal ring.
7. Remove excess slack from the tankband by pulling on the
webbing end.
8. Thread the end of the webbing through the top slot on the
buckle. Grasp the end of the webbing and pull the buckle
closed. Press the end firmly onto the hook and loop fastener
on the webbing.
9. Check the entire assembly for tightness. If the assembly is not
secure, retighten the webbing by unweaving the webbing end
through the last slot in the buckle. Pull firmly while "rocking"
the buckle to tighten. Always wet strap assembly before
attaching to Scuba Cylinder.
SCUBA CYLINDER
BUCKLE ASSEMBLY
PAGE 7
DOFFING (REMOVAL)
of your
H2Odyssey
BCD
TO REMOVE YOUR BCD
A: Inflate your BCD slightly.
B: Open Cummerbund Buckle (3) completely.
C: Grasp LEFT Side of Cummerbund Flap and pull from VELCRO.
D: Open one Shoulder Strap Buckle (1).
E: You may now slide out of your BCD.
DRAINING YOUR BCD
A: Slowly INFLATE BCD until firm.
B: Remove Scuba Cylinder.
C: After removal of your Scuba Cylinder it is important that you
drain all of the water from inside of your BCD.
D: Turn BCD upside down and point Inflator DOWNWARD and
DEPRESS ORAL INFLATOR Button to release all of the air
and remaining water in BCD
E: Repeat if necessary to purge all water from inside of BCD.
F: Rinse inside (using fresh water) of BCD to remove any salt
water if present.
PAGE 12
BCD ADJUSTMENTS
SHOULDER and CUMMERBUND
H2Odyssey
PAGE 11
Figure 1
TANK POSITIONING STRAP
Description and Use
Your
H2Odyssey
BCD is equipped with a TANK POSITIONING
STRAP.
This strap will permit you to consistently replace the Scuba Cylinder
on to your BCD in the SAME location (relative to height)
each and every time you mount a Scuba Cylinder to your BCD.
To properly use the TANK POSITIONING STRAP:
A: Loosen the strap to its full open position.
B: Slide the BCD. on to a Scuba Cylinder at the required height
of the Scuba Cylinder Valve.
C: Verify the height of the Scuba Cylinder Valve is correct.
D: Draw up the slack on the TANK POSITIONING STRAP.
E: Lock the Scuba Cylinder Retaining Strap into position.
F: Verify desired height of Scuba Cylinder Valve.
G: If this position is correct, you may remove Scuba Cylinder.
H: Your
H2Odyssey
BCD will now REPEAT the location
of the Scuba Cylinder each time you put a different Scuba
Cylinder, of the same dimension, on your BCD.
NOTE:
If the location of the Scuba Cylinder Valve is incorrect, repeat steps
A through G until desired height is achieved.
PAGE 8
H2Odyssey
PAGE 9
BCD TANK POSITIONING STRAP DONNING and ADJUSTMENT
of your
H2Odyssey
BCD
Your
H2Odyssey
B.C.D. has been designed to make
adjustments to the waistband and shoulder straps a “one
time” adjustment. Your B.C.D. may be used either with a Wet
Suit or Dry Suit with only a “one time” adjustment. Upon com-
pletion of adjustment, you may either doff or don the BCD
without further adjustment.
TO ENSURE A PROPER AND COMFORTABLE FIT
PLEASE FOLLOW INFORMATION ON PAGE 9/10.
A: Release Cummerbund Buckle Assembly (3).
B: Open Cummerbund completely (4).
C: Retract the Shoulder Straps completely to put the
“D-Rings”(2), closest to the Buckle (1).
D: Put the BCD on (no scuba tank) and pull on the “D-Rings”(2)
to bring the shoulder straps close to your body but not tight.
the straps should feel a little snug, but not tight. In the final
position the straps will feel snug, but comfortable to wear.
E: First, fold the RIGHT side of the Cummerbund flap (4) flat
across your stomach and then fold over the LEFT side of the
Cummerbund flap (4).
F: Press the VELCRO flap to connect the VELCRO to the other
flap. The Cummerbund (4) should feel snug, but not uncom-
fortable or too tight in any way.
G: When Cummerbund is adjusted completely, open adjustment
(webbing) on the Cummerbund Buckle (3) completely.
H: Snap Cummerbund Buckle and check adjustment. If adjust-
ment is to loose, open Cummerbund Buckle (3) and take-up
some slack in webbing and try again.
I: Continue until the Cummerbund Buckle feels snug, but not
tight.
J: Adjustment is now complete.
PAGE 10
H2Odyssey
PAGE 9
BCD TANK POSITIONING STRAP DONNING and ADJUSTMENT
of your
H2Odyssey
BCD
Your
H2Odyssey
B.C.D. has been designed to make
adjustments to the waistband and shoulder straps a “one
time” adjustment. Your B.C.D. may be used either with a Wet
Suit or Dry Suit with only a “one time” adjustment. Upon com-
pletion of adjustment, you may either doff or don the BCD
without further adjustment.
TO ENSURE A PROPER AND COMFORTABLE FIT
PLEASE FOLLOW INFORMATION ON PAGE 9/10.
A: Release Cummerbund Buckle Assembly (3).
B: Open Cummerbund completely (4).
C: Retract the Shoulder Straps completely to put the
“D-Rings”(2), closest to the Buckle (1).
D: Put the BCD on (no scuba tank) and pull on the “D-Rings”(2)
to bring the shoulder straps close to your body but not tight.
the straps should feel a little snug, but not tight. In the final
position the straps will feel snug, but comfortable to wear.
E: First, fold the RIGHT side of the Cummerbund flap (4) flat
across your stomach and then fold over the LEFT side of the
Cummerbund flap (4).
F: Press the VELCRO flap to connect the VELCRO to the other
flap. The Cummerbund (4) should feel snug, but not uncom-
fortable or too tight in any way.
G: When Cummerbund is adjusted completely, open adjustment
(webbing) on the Cummerbund Buckle (3) completely.
H: Snap Cummerbund Buckle and check adjustment. If adjust-
ment is to loose, open Cummerbund Buckle (3) and take-up
some slack in webbing and try again.
I: Continue until the Cummerbund Buckle feels snug, but not
tight.
J: Adjustment is now complete.
PAGE 10
BCD ADJUSTMENTS
SHOULDER and CUMMERBUND
H2Odyssey
PAGE 11
Figure 1
TANK POSITIONING STRAP
Description and Use
Your
H2Odyssey
BCD is equipped with a TANK POSITIONING
STRAP.
This strap will permit you to consistently replace the Scuba Cylinder
on to your BCD in the SAME location (relative to height)
each and every time you mount a Scuba Cylinder to your BCD.
To properly use the TANK POSITIONING STRAP:
A: Loosen the strap to its full open position.
B: Slide the BCD. on to a Scuba Cylinder at the required height
of the Scuba Cylinder Valve.
C: Verify the height of the Scuba Cylinder Valve is correct.
D: Draw up the slack on the TANK POSITIONING STRAP.
E: Lock the Scuba Cylinder Retaining Strap into position.
F: Verify desired height of Scuba Cylinder Valve.
G: If this position is correct, you may remove Scuba Cylinder.
H: Your
H2Odyssey
BCD will now REPEAT the location
of the Scuba Cylinder each time you put a different Scuba
Cylinder, of the same dimension, on your BCD.
NOTE:
If the location of the Scuba Cylinder Valve is incorrect, repeat steps
A through G until desired height is achieved.
PAGE 8
6. Feed the webbing end through the lower slot and then back
through the metal ring.
7. Remove excess slack from the tankband by pulling on the
webbing end.
8. Thread the end of the webbing through the top slot on the
buckle. Grasp the end of the webbing and pull the buckle
closed. Press the end firmly onto the hook and loop fastener
on the webbing.
9. Check the entire assembly for tightness. If the assembly is not
secure, retighten the webbing by unweaving the webbing end
through the last slot in the buckle. Pull firmly while "rocking"
the buckle to tighten. Always wet strap assembly before
attaching to Scuba Cylinder.
SCUBA CYLINDER
BUCKLE ASSEMBLY
PAGE 7
DOFFING (REMOVAL)
of your
H2Odyssey
BCD
TO REMOVE YOUR BCD
A: Inflate your BCD slightly.
B: Open Cummerbund Buckle (3) completely.
C: Grasp LEFT Side of Cummerbund Flap and pull from VELCRO.
D: Open one Shoulder Strap Buckle (1).
E: You may now slide out of your BCD.
DRAINING YOUR BCD
A: Slowly INFLATE BCD until firm.
B: Remove Scuba Cylinder.
C: After removal of your Scuba Cylinder it is important that you
drain all of the water from inside of your BCD.
D: Turn BCD upside down and point Inflator DOWNWARD and
DEPRESS ORAL INFLATOR Button to release all of the air
and remaining water in BCD
E: Repeat if necessary to purge all water from inside of BCD.
F: Rinse inside (using fresh water) of BCD to remove any salt
water if present.
PAGE 12
PRE-DIVE
BCD EXAMINATION
The pre-dive, dive, and post-dive BCD examinations help identify
equipment problems before unsafe conditions exist. Equipment-
related diving accidents can be prevented by following these sim-
ple steps and having all equipment regularly inspected by an
authorized scuba equipment repair facility.
VISUAL INSPECTION
Examine the entire BCD for cuts, punctures, frayed seams.
Excessive abrasion or other damage. If there is any doubt of the
condition of the BCD, do not dive.
Inspect the OIDV/PIV Assembly for any cracks or damage. Check
the OIDV Button and OIDV mouthpiece for sand or other debris.
Check the EDV (2) EXHAUST DUMP VALVE and the OPIV (7)
housings to make sure they are free from damage, sand and or
other debris.
OPERATIONAL INSPECTION
After the visual examination, it is recommended to test the BCD's
operating systems.
Test the oral inflator by inflating the BCD through the oral inflator
mouthpiece(1). Check the inflation system and the BCD for leaks.
Let the BCD stand inflated for 30 minutes or more. Check the
BCD for any loss of air.
Test the power inflator by attaching the male quick connect (4) to
the pressurized L.P. hose (6) and depressing the power inflator
button (3). Check the inflation system and the BCD for leaks. Let
the BCD stand inflated for 30 minutes or more. Check the BCD
for loss of air. Allow the BCD to remain connected to the pressur-
ized L.P. hose. Deflate the BCD using the deflator button (2) and
allow to stand uninflated for 30 minutes or more. Leakage through
the power inflator (3) will be evident if the BCD self inflates.
Test the dump valve by pulling on the inflator assembly. The
internal cable will activate the upper dump valve (7). The valve
should close properly upon release.
PAGE 13
CONSTRUCTION and MATERIALS
Your BCD may employ either a single bag or double bag construc-
tion. The double bag BCD is constructed of a strong nylon fabric
outer shell and a durable polyurethane inner bladder. The urethane
bladder is radio frequency (RF) welded to provide a durable air
chamber. The single bag BCD is constructed of a single chamber
made from a 420 denier nylon fabric backed by a polyurethane
coating. This high strength fabric composite provides exceptional
resistance to tears, abrasions, and punctures. The single bag is
also RF welded to provide an exceptionally strong seal. All hard-
ware and related items on your BCD such as buckles, D-rings, and
webbing have been chosen for their superior strength and resist-
ance to the harsh conditions the diving environment places upon
them. With proper care, your BCD will provide years of service.
SCUBA CYLINDER MOUNTING PROCEDURE
Refer to the following diagrams to properly assemble the tank
strap.
1. Soak the mounting bands in water. Nylon expands as it
absorbs water. Soaking will permit the natural stretch of the
nylon webbing.
2. Place the SCUBA tank against the mounting plate on the back
of the BCD. Pull the end of the tankband around the tank.
3. Make sure that the buckle is in the "open" position.
4. Thread the end of the band between the metal ring and the
plastic body of the buckle.
5. Feed the end of the band through the center slot on the top side
of the buckle.
PAGE 6
FEATURES
PAGE 5
H2Odyssey
BUOYANCY COMPENSATOR
OPERATIONAL INSPECTION (cont.)
Your
H2Odyssey
BCD is equipped with TWO (2) OPV’s.
One (1) is located on the LOWER RIGHT SIDE of your BCD.
The other on the INFLATOR HOSE. To check the LOWER
RIGHT SIDE OPV, inflate BCD until FIRM and pull on cord light-
ly coming out of OPV. If air is released, OPV is functioning.
Check OPV (7) operation by slowly over inflating the BCD. Fill
the BCD until it is firm, then continue to add air in small amounts.
Do this cautiously in case the valve is malfunctioning and does
not release. Once the maximum internal pressure for the BCD
is reached, the OPV (7) will open. You will hear air escaping
through the valve. If the OPV (7) fails to open or if there is any
question about its operation, have the BCD checked by an
authorized scuba repair facility. If the OPV (7) has a Pull Dump
Assembly, make sure it operates by pulling on the cord.
PAGE 14
DIVE
BCD EXAMINATION and PROCEDURES
This is the final BCD check before you begin your actual dive. The
examination can be performed on the beach, on the boat, or on
the water's surface next to the boat.
OPERATIONAL INSPECTION
After your gear is assembled and you have put your BCD and
scuba cylinder on, perform the following operational check.
Check the PIV (3) and the OPV (7). Inflate the BCD using the PIV
(3) until the OPV (7) opens to exhaust the excess air. Use short
bursts of air instead of one long flow to better control the inflation
of the BCD.
Leave the BCD inflated for 60 seconds and check for any leaks. If
you are at the water's surface, you may not hear any leaks but you
may see a steady stream of air bubbles which could indicate a
leak. Use your dive buddy to help with this check.
Check the EDV (2): Deflate the BCD using the EDV (2). You
should hear the air exhausting out of the EDV from the mouth-
piece(1).
Check the OIDV (2): Orally inflate the BCD using the OIDV (2).
Leave the BCD inflated for 60 seconds and check for any leaks.
Deflate the BCD using the OIDV (2).
Have your dive buddy check the tank band for proper assembly
and tightness. (See instructions on page 6).
Check that all connections are secure.
If the BCD fails to pass any of these tests or there is any doubt
about any of the components, DO NOT DIVE WITH THE BCD.
Have the BCD inspected by an authorized repair facility.
CAUTION
Do not attach a high pressure hose to the Pneumatic Inflation Valve
(PIV). The Pneumatic Inflation Valve (PIV) handles only low pres-
sure air (150 psi or less). Read the inflator manufacturer's instruc-
tions concerning proper connection locations and procedures.
Product damage or personal injury can result from improper con-
nection.
These instructions do not necessarily incorporate all steps required
under all conditions for oral inflation of the BCD underwater. Oral
inflation of the BCD underwater requires special training and prac-
tice. This should first be attempted under controlled conditions with
the supervision of a certified instructor.
Never breathe from the BCD Oral Inflation/Deflation Valve (OIDV)
Mouthpiece. Your BCD may contain contamination that may be
hazardous if inhaled.
Use of the Oral Inflation/Deflation Valve (OIDV) or the
Overpressure Valve (OPV) for deflation may allow water to enter
the BCD bladder. Repeated use may allow enough water in to
reduce the amount of buoyancy provided by the BCD. Drain the
BCD of any accumulated water after each dive.
BCD's USE and FUNCTION
Your new BCD:
Provides surface flotation:
The BCD adds to your surface buoyancy and allows you to put
more effort into swimming instead of flotation. The BCD alone,
however, will not necessarily provide adequate surface flotation.
Provides neutral buoyancy at various depths:
When you have reached your desired diving depth, adding or
releasing the correct amount of air will assist in achieving neutral
buoyancy.
Allows adjustment of Buoyancy:
The BCD provides the diver with the ability to adjust their
buoyancy by releasing and adding air to the BCD.
PAGE 15 PAGE 4
CAUTION
This is NOT a Coast Guard approved surface flotation device and
will not provide face-up flotation for all users in all conditions.
Inflate the BCD slowly. Rapid inflation can cause an uncontrolled
ascent that could result in air embolism, serious injury, or death.
Practice is required to maintain a safe rate of ascent. The
Overpressure Valve (OPV) does not control or prevent uncon-
trolled ascents.
Adding weights in the pockets or attaching them to the BCD may
prevent you from easily releasing the weights in case of an emer-
gency. Excess weight may impair or prevent proper operation of
the BCD and may reduce the buoyancy of the BCD.
Always perform a pre-dive, dive, and post dive inspection of the
BCD and have your dive buddy perform the inspections of your
equipment as well. See the inspection procedures detailed in this
manual for further information.
Adjust the cummerbund and attachment straps for a comfortable
fit. A properly fitted BCD should not restrict your breathing when
fully inflated. Before each use, check all of the bands, straps,
quick- disconnect clips, and the cummerbund for wear. Have an
authorized scuba equipment repair facility replace worn or dam-
aged items before use.
Use of after-market accessories or changes to the BCD can pre-
vent the BCD's proper functioning and result in product damage.
Always soak the air cylinder band in water before each use to
allow the band to stretch. Failure to soak the band may allow the
cylinder to loosen during use resulting in loss of air supply, buoy-
ancy control, or equipment damage. Before each use check all
scuba tank buckles and bands for wear. Have an authorized
scuba equipment repair facility replace worn or damaged items
before use.
POST DIVE
BCD EXAMINATION and PROCEDURES
With proper care your BCD should provide many years of use.
Maintenance procedures are as follows:
AFTER DIVING:
Rinse the BCD thoroughly inside and out with fresh water after
every use. Use the following procedure:
A) Fill the BCD inner bladder approximately one fourth full of
fresh water.
B) Orally inflate the BCD and shake to distribute the water
throughout the inside of the BCD.
C) Hold the BCD upside down. Depress the oral inflator button
and allow the water to drain from the oral inflator mouthpiece.
D) Repeat this rinsing procedure one or two times more.
E) Rinse the exterior of the BCD by dipping it into a tub of fresh
water.
F) Rinse all valving to make sure that sand or other debris is
removed.
G) Hang the BCD out of the sun and allow to dry completely.
H) Partially inflate the BCD and store in a dark and dry location.
PLAN
YOUR
DIVE
DIVE
YOUR
PLAN
PAGE 3 PAGE 16
IMPORTANT INFORMATION
Avoid prolonged exposure to direct sunlight or excessive heat.
The ultraviolet rays of the sun will shorten the life span of the
BCD materials.
Keep sharp objects from coming into contact with the BCD.
Do not rest heavy objects on the BCD. Do not drag your equip-
ment over rough surfaces.
Periodically lubricate the quick connect coupling with silicone
lubricant.
Chlorine can be especially harmful to the BCD materials. Rinse
the BCD thoroughly after pool use.
Use only fresh water and mild soap to clean the BCD. Chemical,
strong detergents or solvents could damage the BCD.
It is recommended that the BCD be inspected yearly by an
authorized SCUBA repair facility.
NAME:....................................................................................
ADDRESS:.............................................................................
CITY:.............................................STATE:...........ZIP:............
MODEL NUMBER:.................................................................
MODEL NAME:......................................................................
DATE PURCHASED:.............................................................
SERVICE DATES:.................................................................
INTRODUCTION
Congratulations on the purchase of your
H2Odyssey
Buoyancy Compensating Device (BCD). Your BCD is one of the
key elements of buoyancy control, and has been designed and
manufactured to combine design features and technology to pro-
vide you with fit and comfort in a high performance package that
will enhance your time spent in the underwater world.
This manual contains information about your BCD as well as infor-
mation which may affect your safety and the longevity of your
equipment. Please take the time to thoroughly read this manual
and become familiar with all of your SCUBA equipment before you
enter the water.
This information has been put together for your safety. Please
read and understand this manual completely before using your
new BCD.
Before using this product in open water, familiarize yourself with
its function and use in a controlled environment such as a pool.
Use all equipment you would normally use for an open water dive.
A BCD's function is to make diving more comfortable by allowing
a diver to maintain neutral buoyancy. It is NOT a substitute for
proper swimming and diving skills.
A BCD works in combination with your weight belt. It is very impor-
tant for you to be properly weighted. If you over-weight, you
reduce the BCD's capacity to provide positive buoyancy.
Use of this product requires training in buoyancy compensation
from an internationally recognized SCUBA certifying agency
(PADI, NAUI, SSI etc). Read the owner's manual and all warnings
and instructions that accompany this product. Misuse of this prod-
uct, or the use of improperly functioning equipment can result in
uncontrolled ascents, uncontrolled descents, or loss of buoyancy
control.
PAGE 17 PAGE 2
INDEX
DESCRIPTION PAGE
INTRODUCTION #1
CAUTION #1 / #2 / #15
BCD USE and FUNCTION #3
FEATURES #4
CONSTRUCTION and MATERIALS #5
SCUBA CYLINDER MOUNTING #5 / #6
TANK POSITIONING STRAP #7 / #8
DONNING and ADJUSTMENT #9 / #10
DOFFING and DRAINING BCD #11 / #12
WEIGHT DROP SYSTEM #13 / #16
WARNING #13
REAR WEIGHT POUCHES #15 / #16
PRE-DIVE PROCEDURE #17
OPERATIONAL INSPECTION #17 / #18
DIVE BCD EXAM. / PRODEDURES #19
POST-DIVE EXAM. / PROCEDURE #20
NOTES #21
WARRANTY #22
BUOYANCY COMPENSATOR LIMITED WARRANTY
WHAT IS COVERED
This warranty covers to the original owner, all defects in material or workmanship in any Buoyancy
Compensator sold by H2Odyssey.
WHAT IS NOT COVERED
This warranty does got cover damage, failure or loss caused by wear or tear, failure to per-
form normal maintenance on H2Odyssey items. Cosmetic damage such as scratches,
tears, punctures, discoloration or any damage failure or loss caused by:
1: Accident misuse neglect, abuse, or improper maintenance.
2: Failure to follow instructions in the USERS GUIDE.
3: Rental, Training Class, Military, or Commercial usage.
4: Use by uncertified (ie. PADI, NAUI, SSI, etc.) persons.
FOR HOW LONG
The warranty coverage is limited lifetime on the Buoyancy Compensator Air Cell Radio
Frequency (RF) seams and airway assembly (inflator, corrugated hose and dump valve mech-
anism). The warranty coverage on low pressure hose assembly, sewn seams and non aircell
materials have a one (1) year limited warranty on H2Odyssey BCD’S to the original pur-
chaser, under the terms and conditions defined below.
Within the warranty period, H2Odyssey will at its option, either repair or replace (with
same or equivalent product) the defective in warranty product, part or accessory. Cost of labor
for warranty is not covered by warranty. The product must be accompanied by a dated proof
of purchase for warranty service. As a matter of warranty policy, H2Odyssey will not
refund the consumers purchase price.
NO LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
Repair or replacement of defective products, parts or accessories specified above are Your
sole Remedy under this warranty and IN NO EVENT SHALL H2Odyssey BE LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the exclu-
sion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you.
HOW YOU CAN GET SERVICE
Contact your authorized H2Odyssey Service Center or write to H2Odyssey,
975 Park Center Dr, Vista CA 92083 for the name and address of your nearest
authorized H2Odyssey Service Center.
YOUR RIGHTS UNDER THE LAW
This warranty gives you specific legal rights and you may also have other rights which may vary
from state to state.
IMPORTANT NOTE
The above warranty applies to product sold and serviced in North America and Caribbean.
Consult your local dealer or importer for details of warranty coverage in your country. Product
purchased in the United States, Canada, or Caribbean but serviced in other counties will be
subject to the warranty conditions in effect in the country of use and service.
http://www.h2odyssey.com
PAGE 1 PAGE 18
This manual suits for next models
1
Table of contents
Other H2Odyssey Diving Instrument manuals
