Hach DRB 200 User manual

DOC022.97.80188
DRB 200
04/2013, Edition 2
User Manual
Manuel d'utilisation
Manual del usuario
Manual do Usuário
用户手册
取扱説明書
사용 설명서
คูมือผูใช

English...................................................................................................................................................................................................3
Français..............................................................................................................................................................................................11
Español...............................................................................................................................................................................................19
Português..........................................................................................................................................................................................28
中文.......................................................................................................................................................................................................37
日本語..................................................................................................................................................................................................45
한글.......................................................................................................................................................................................................53
ไทย..........................................................................................................................................................................................................61
2

Specifications
Specifications are subject to change without notice.
Specification Details
Dimensions 25 x 14.5 x 31 cm (9.8 x 5.7 x 12.2 in.)
Weight Single heating block: 2 kg (4.4 lb)
Dual heating block: 2.8 kg (6.17 lb)
Power requirements 100–240 V, +5%/–15%, 50/60 Hz, Protection Class I
Power input Single heating block: 115 V: 300 VA; 230 V: 450 VA
Dual heating block: 115 V: 600 VA; 230 V: 900 VA
Storage temperature –40 to +60 °C (–40 to +140 °F)
Operating temperature 10 to 45 °C (50 to 113 °F)
Operating humidity 90% (non-condensing)
Instrument range Temperature: 37 to 165 °C (98.6 to 329 °F)
Timer: 0 to 480 minutes
Temperature stability ± 2 °C (± 3.5 °F)
Heating rate From 20 to 150 °C (68 to 302 °F) in 10 minutes
Certification CE, GS and cTUVus
General information
Revised editions are found on the manufacturer’s website.
Safety information
Please read this entire manual before unpacking, setting up or operating
this equipment. Pay attention to all danger and caution statements.
Failure to do so could result in serious injury to the operator or damage
to the equipment.
Make sure that the protection provided by this equipment is not impaired,
do not use or install this equipment in any manner other than that
specified in this manual.
Use of hazard information
DANGER
Indicates a potentially or imminently hazardous situation which, if not avoided, will
result in death or serious injury.
W A R N I N G
Indicates a potentially or imminently hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation that may result in minor or moderate
injury.
NOTICE
Indicates a situation which, if not avoided, may cause damage to the instrument.
Information that requires special emphasis.
Precautionary labels
Read all labels and tags attached to the instrument. Personal injury or
damage to the instrument could occur if not observed. A symbol, if noted
on the instrument, will be included with a danger or caution statement in
the manual.
English 3

This symbol, if noted on the instrument, references the instruction
manual for operation and/or safety information.
Note: For return for recycling, please contact the equipment producer or supplier
for instructions on how to return end-of-life equipment, producer-supplied
electrical accessories, and all auxillary items for proper disposal.
Electrical equipment marked with this symbol may not be disposed of
in European public disposal systems after 12 August of 2005. In
conformity with European local and national regulations (EU Directive
2002/98/EC), European electrical equipment users must now return
old or end-of-life equipment to the Producer for disposal at no charge
to the user.
This symbol indicates that the marked item can be hot and should not
be touched without care.
This symbol indicates that the marked item requires a protective earth
connection. If not provided with a plug on a cord, connect positive
earth to this terminal (U.S. cord set provides ground).
Product overview
This instrument has one or two heating blocks that increase the
temperature of solutions in round sample cells to a specified temperature
for a specified time period (Figure 1). There are six stored temperature
programs and three temperature programs that are configured by the
user and saved.
Figure 1 Front view
1 Protective cover 3 Display 5 Left heating block
2 Right heating block 4 Keys
Installation
Install the protective covers
W A R N I N G
Shock and Burn Hazard. The protective cover must be installed to prevent
personal injury. The protective cover prevents burns and power cord contact with
the heating block.
Refer to the illustrated steps on page 0 .
4 English

1 2
English 5

User interface and navigation
User interface
The instrument is operated using three keys that are located below the
display (Figure 2). The function of each key is shown on the display. If
no function is shown for a key, that key is not currently active.
Figure 2 Keypad description
1 Display 3 Middle key
2 Right key 4 Left key
Display description
Figure 3 Screen display when a program is active on the left
heating block only
1 Thermometer symbol 5 Left heating block
2 Temperature of heating block 6 Remaining time
3 Right heating block 7 Timer symbol
4 Down arrow key (use to select
program)
6 English

Table 1 Thermometer symbols
Symbol Description
The heating block is increasing in
temperature.
The heating block is at the selected
temperature.
The heating block is decreasing in
temperature.
Start-up
Turn the instrument on
NOTICE
Do not turn the instrument off and on quickly as this can damage the instrument.
Always wait about 20 seconds before turning the instrument on again.
1. Put the instrument on a stable, level, heat-resistant surface.
2. Connect the power cord to the power plug on the back of the
instrument.
3. Connect the power cord to a power socket with earthing contact.
4. Push the power switch on the back of the instrument to turn the
instrument on.
Select the language
To change the default language setting (English):
1. Hold down the left key and turn the instrument on.
2. Push the right arrow key to scroll through the menu. The display
goes back to the start of the menu at the end of the menu.
3. When the correct language is shown, push the key for the language.
Refer to Table 2.
Table 2 Language settings
Setting Language Setting Language
GB English NL Dutch
D German S Swedish
F French PL Polish
I Italian DK Danish
E Spanish
Set the display contrast
1. Hold down the middle key and turn the instrument on.
2. Push or hold down the up and down arrow keys to change the
contrast value.
3. Push OK to save the change.
Operation
W A R N I N G
Chemical exposure hazard. Obey laboratory safety procedures and wear all of
the personal protective equipment appropriate to the chemicals that are handled.
Refer to the current material safety data sheets (MSDS) for safety protocols.
Routine operation
CAUTION
Burn Hazard. Do not put a finger in an opening in the heating block. Close the
protective cover before increasing the temperature of the heating block, and
always keep the protective cover closed during operation.
English 7

CAUTION
Burn Hazard. Sample cells are hot. Wear thermal insulating material (e.g., gloves
or finger cots). Do not remove a sample cell that is greater than 80 °C. Do not put
a sample cell that is greater than 80 °C in a colorimeter.
CAUTION
Chemical Hazard. If a sample cell breaks, do not let the liquid touch skin. Use a
fume hood as necessary to remove chemical fumes.
NOTICE
To prevent sample cell and instrument damage, keep the openings in the heating
block dry. Dry the outside of sample cells fully.
NOTICE
To prevent instrument damage, immediately disconnect power if an accidental
spill occurs or a sample cell breaks, then clean the instrument. Refer to Clean the
instrument on page 9.
NOTICE
Do not cover the ventilation slits in the protective cover. The instrument and
sample cells may become too hot and decrease the accuracy of measurement.
1. Prepare the test sample cells as specified in the analysis procedure.
2. Close the sample cells with the cap.
3. Dry the outside of the sample cells fully.
4. Turn the instrument on and open the protective cover. The last
temperature program(s) selected is shown on the display.
5. If using 16 mm tubes with a heating block with 20 mm openings, put
reducing adapters in the openings.
6. Select the correct temperature program (and digestion period if
applicable) using the keys, then push OK. Refer to Stored programs
on page 8. The temperature program is selected independently
for each heating block when there are two heating blocks.
Note: To stop a program, push the key below the program two times.
7. When the heating block is at the selected temperature (two beeps
are heard), put the test sample cells in the correct heating block and
close the protective cover.
8. Push Start to start the program.
The time counts down to zero (0). Three beeps are heard and the
heater turns off when the program is completed.
Stored programs
Table 3 gives descriptions of the stored temperature programs.
Table 3 Stored programs
Program Description
COD Increases the temperature of the sample cells to 150 °C for
120 minutes. In the cooling phase, four beeps are heard when the
sample cells are at 120 °C. Remove and carefully invert the sample
cells several times, before letting them decrease in temperature in a
rack.
TOC Increases the temperature of the sample cells to 105 °C for
120 minutes. The TOC temperature program can be used for all Hach
TOC sample cell tests.
100 °C Increases the temperature of the sample cells to 100 °C for 30, 60 or
120 minutes. For example, the “100 °C, 60 minutes” temperature
program is used to:
• Digest samples using the Metals Prep Set
• Identify phosphate and chromium
• Digest heavy metals
105 °C Increases the temperature of the sample cells to 105 °C for 30, 60 or
120 minutes.
150 °C Increases the temperature of the sample cells to 150 °C for 30, 60 or
120 minutes.
165 °C Increases the temperature of the sample cells to 165 °C for 30, 60 or
120 minutes.
User programs
The instrument has three temperature programs that are configured by
the user (PRG1–PRG3).
8 English

To configure a user temperature program:
1. Select a user temperature program using the keys.
2. Push Prog to enter programming mode.
3. Select a 4-character name for the program. Push the left key to
change the character. Push the right arrow key to move the cursor to
the next position. Push OK to save the change.
4. Push or hold down the up and down arrow keys to set the
temperature (37 to 165 °C). Push OK to save the change.
5. Push or hold down the up and down arrow keys to set the time (0 to
480 minutes). Push OK to save the change.
6. Push OK to save the program.
Maintenance
W A R N I N G
Multiple hazards. Do not disassemble the instrument for maintenance or service.
If the internal components must be cleaned or repaired, contact the
manufacturer.
CAUTION
Personal injury hazard. Only qualified personnel should conduct the tasks
described in this section of the manual.
Clean the instrument
Keep the instrument clean to get continuous and accurate operation.
W A R N I N G
Fire Hazard. Do not use flammable agents to clean the instrument.
CAUTION
Burn Hazard. Do not clean the instrument when it is hot.
NOTICE
To prevent instrument damage, do not use cleaning agents such as turpentine,
acetone or similar products to clean the instrument including the display.
1. Turn the instrument off and disconnect the power cord.
2. When the instrument is cool, clean the surface of the instrument with
a soft, moist cloth and a weak soap solution. Make sure that no water
gets into the instrument.
If the liquid in a sample cell spills or a sample cell breaks:
1. Turn the instrument off and disconnect the power cord.
2. Let the temperature of the heating block(s) and sample cells
decrease until cool.
3. Remove the liquid with a pipette. Do not let the liquid touch skin.
4. Move the liquid to the correct disposal.
5. Remove broken glass using tweezers. Remove any remaining liquid
on the instrument. Do not let the liquid touch skin.
Measure the temperature of the heating block
Measure the temperature of the heating block to make sure that the
temperature shown on the display is correct.
The temperature shown on the display is the temperature in a closed
sample cell that is filled with a liquid. While the temperature of the
heating block is increasing, the temperature of the heating block, near
the heater, may be greater than the temperature shown on the display.
Tools needed:
• Sample cell (2275800)
• Glycerol (anhydrous), 5 mL
• Thermometer, stem-type, calibrated for 95 to170 °C (203 to 338 °F)
To measure the temperature of the heating block:
1. Fill a clean, empty sample cell with glycerol that is at room
temperature.
2. Put the thermometer in the sample cell until the thermometer touches
the bottom of the sample cell.
3. Make sure that the level of the glycerol is 56 mm ± 0.5 mm (2.20 in. ±
0.02 in.) from the bottom of the sample cell when the thermometer is
in the sample cell.
English 9

4. Put the sample cell in the center opening of the second row of the
heating block.
5. Select a temperature program of 150 °C for 60 minutes using the
keys, then push OK.
6. When the heating block is at the selected temperature (two beeps
are heard), the thermometer temperature should be the same as the
temperature shown on the display.
Troubleshooting
Refer to Table 4 for error messages, possible causes and corrective
actions.
Table 4 Error messages
Error Solution
BLOCK IS TOO HOT!
PLEASE WAIT
The temperature of the heating block is greater than the
selected temperature. Wait until the temperature of the
heating block decreases.
INIT ERROR The instrument is defective. Contact Customer Service.
Replacement parts and accessories
Note: Product and Article numbers may vary for some selling regions. Contact the
appropriate distributor or refer to the company website for contact information.
Replacement parts
Description Quantity Item no.
Protective cover 1 LZT048
Accessories
Description Quantity Item no.
Reducing adapter, 20 > 16 mm 1 HHA155
Reducing adapter, 16 > 13 mm 1 2895805
Replacement parts and accessories (continued)
Description Quantity Item no.
Tube, 16 x 100 mm 1 2275800
Tube, 16 x 100 mm 6 2275806
Thermometer, 0 to 200 °C 1 4565500
10 English
