Haier L32K3 User manual

Please READ this manual carefully before
operating your TV, and retain it for future
reference.
OWNER’S MANUAL
TFT-LCD TELEVISION
L32K3

Contents
2 TFT -LCD television Owner’s Manual
Contents
Warning 3
Important Safety Instructions 4
Panel Control and Rear Terminals
Control 6
Panel Control ....................................................... 6
Rear Terminals Control........................................ 6
Remote Control 7
Battery loading.................................................... 7
Precautions ..........................................................7
Remote Control Function 8
Function introduction.........................................8
External Equipment Connections 9
Antenna Connection ...........................................9
Choose Your Connection ...................................10
VCR Connection.................................................................. 10
DVD Setup ............................................................................ 10
HDMI or DVI Setup............................................................. 10
PC Setup ................................................................................ 11
Monitor Out Setup............................................................. 12
Connecting Headphones ..................................12
Power source......................................................12
Basic Receiving and Playing
Operations 12
Switching ON/OFF the TV set ...........................12
Switching ON/OFF the TV set ........................................ 13
Choose the Menu Language.......................................... 13
Choose the Input source ................................................. 13
Searching Channel ............................................13
Channel Edit......................................................................... 13
Auto search........................................................................... 14
Exchange............................................................................... 15
Watching TV Program .......................................15
How to select the desired program............................. 15
How to select the desired sound.................................. 15
Mute Setting ........................................................................ 15
Quick program view.......................................................... 15
Picture Control Functions .................................15
How to select the picture mode ................................... 16
How to customize your own picture status.............. 16
Sound Control Functions ..................................16
How to choose audio mode.................................................... 16
How to customize your own audio status.......................... 17
Timer Functions .................................................17
Setting of Current Time.................................................... 17
Setting of ON/OFF Time................................................... 18
Setting of On Channel...................................................... 18
Setting of Remind Time and Remind Channel ........ 18
Function Menu...................................................19
Function Menu Set ............................................................ 19
Adjust Menu.......................................................19
Lock Setup..........................................................20
How to use the password function.............................. 20
Streaming Media Playing System ....................21
Start/Exit Streaming Media Playing System............. 21
Operating Method of Streaming Media Menu........ 22
Playing a Picture ................................................................. 22
Playing a Movie................................................................... 22
Playing Music ......................................................................... 23
Text .......................................................................................... 23
Settings ................................................................................... 23
Maintenance 24
Troubleshooting 24
Specification 25
Format 25

Warning
TFT -LCD television Owner’s Manual 3
WARNING
!
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
*
To avoid electric hazards, it is strongly suggested that the back cover not be opened, as there is no any
accessory inside the casing.
*
lf necessary, please contact authorized after-sales services.
*
A lighting ash mark in a triangle: A potentially hazardous situation, which, if not avoided, could result in
serious injury by high voltage.
*
An exclamation mark in a triangle: Major part or accessory of which technical specications must be followed if
it is to be replaced.
RISK ELECTRIC SHOCK
DO NOT OPEN
WARNING: To avoid fire or electric hazards, never place your television receiver in an area with heavy
moisture. Attention should be paid to avoid accidental scratches or impacts onto the screen.
CAUTION: ▲Please read this manual carefully before using your television and keep this manual in a
good place for future reference.
▲ To achieve the best performance of your television, read this User’s Manual carefully and
properly store it for future reference.
▲ Information of screen displays and figures in the User’s Manual may vary due to technical
innovations.
CAUTION: ▲ Unauthorized disassembly of this product is prohibited.
Warning

Important Safety Instructions
4 TFT -LCD television Owner’s Manual
Important Safety Instructions

Important Safety Instructions
TFT -LCD television Owner’s Manual 5

Panel Control and Rear Terminals Control
6 TFT -LCD television Owner’s Manual
Panel Control and Rear Terminals Control
- This is a simplified representation of front panel.
- Here shown may be somewhat dierent from your TV.
Panel Control
32”/42”
 2   

 






2


Rear Terminals Control
COMPONENT IN
32”/42”
AV
OUT
5
ANT IN
VIDEO AUDIO
VGA/AUDIO
VIDEO L AUDIO R VIDEO L AUDIO R
HDMI 3
VGA IN
Y Pb Pr L R
1COMPONENT In Connect a componentVideo/Audio device to
these jacks
2VGA/DVI AUDIO Connect a VGA/DVI Audio device to these jacks.
3VGA IN
Connect the monitor output connector from a PC
to the jack.
4AV IN Connect Video/Audio out from anVideo/
Audio device to these jacks
5AV OUT
Video/Audio output terminal
6ANT IN Connect cable antenna signal to theTV, either
directly or through your cable box
7HDMI Connect a signal to HDMI

Remote Control
TFT -LCD television Owner’s Manual 7
Remote Control
Battery loading
1. Slide open the cover of the battery compartment on
the back of the remote controller.
2. Load two 7# (AAA) alkaline batteries in the
compartment, (plus and minus poles to respective mark)
3. Replace the cover of the battery compartment.
Precautions
As strong light may interfere the signals, change your
position to operate the remote controller if the television
cannot be turned on or o as you expect.
Keep the remote controller away from heat source or
humid area to ensure eective performance of the
remote controller.
Make sure that two AAA alkaline batteries are loaded.
The batteries must be of the same type. The batteries
must be located properly. The batteries are not
rechargeable.
Make sure that there is no obstacle between the remote
controller and television set.




Remote Control Function
8 TFT -LCD television Owner’s Manual
- The remote control cannot be operated unless the batteries are properly loaded.
- When using the remote control, aim it at the remote control sensor on the TV.
Function introduction
1POWER Press this key to startTV from standby mode, press it again to return to standby
mode.
2SCAN It is only available in TV mode.
3Picture Mode Press this key continuously to select the picture mode.
4FREEZE Press once to display a frozen image of the current program, but audio
continues. Press again to return to the program.
5HDMI Press to select a device connrcted to the HDMI input.
6Sound Mode
Press this key continuously to select the sound mode.
7ARC
Press this key to select the screen display proportion.
8SLEEP Displaying the sleep time.
9H. LOCK Refer to the Functional Description on Page 20
0I/II No available
AFAVORITE Press to open the favorite channel list inTV.
B0-9 These keys are used to select a channel.
CSOURCE Press this key to open/close signal source options menu.
DDISPLAY Press to display the TV status information on the top of the TV screen.
EMUTE Press this key to mute the sound, press it again to activate the sound.The sound
may be activated by turning theTV on again or increasing the volume .
FRECALL Press this key to display the Special Function Menu (it functions when special
modules are inserted).
GVOL+ /- Used to adjust the volume when the screen menu is closed.
HCH+/- Used to select a TV channel when the screen options menu is closed, specifically,
press CH- to decrease the channel and press CH+ to increase the channel.
IMENU Press this key to display or exit the main menu.
JEXIT
Clears all on-screen displays and returns to TV viewing from any menu.
K
THUMBSTICK (Up/
Down/Left/Right/
OK)
PAllows you to navigate the on-screen menus and adjust the system setting to
your preference. Press OK buuton to confirm the selection.
LOK Press this key to conrm the selection
MUSB Press this key for quick switching of streaming media.
NBACK Back button(only for USB).
OREC No available.
P
TIMESHIFT No available.
QHELP Fast Reverse (only for USB)
RPLAY/PAUSE Fast Reverse (only for USB)
SREV Fast Reverse(only for USB).
TFWD Fast Forward(only for USB).
UNEXT
Next(only for USB).
VPREV
Previous(only for USB)
WTEXT No available.
.
XMIX No available.
YHOLD No available.
ZSUBCODE No available.
[PIP No available.
\SWAP No available.
]ZOOM
Fast Reverse(only for USB).
`MOVE No available.
SCAN
H.LOCK
SLEEP
MUTE RECALL
USB
REC
TEXT
PIPSWAP MOVE ZOOM
MIX HOLD
SUBCODE
TIMESHIFTPLAY/PAUSE
HELP
BACK
HDMI
FREEZE
P.MODE
S.MODE
ARC
FAVORITE
SOURCEDISPLAY
VOL CH
MENU EXIT
INDEX
REVFWD PREV NEXT
12
14
16
18
19 20
21
23
22
25
24
26
27
29
28
30
31
32
33
34
37
35
36
38
39
40
Ⅰ/Ⅱ
OK
Remote Control Function

External Equipment Connections
TFT -LCD television Owner’s Manual 9
Antenna Connection
- Antenna or Cable Service without a Cable Box Connections.
- For optimum picture quality, adjust antenna direction if needed.
Note:
* It is recommended that you'd better use 75Ωcoaxial cable to remove
the disturbance caused by airwave.
* Don't bind antenna cable and electric wire together.
To improve picture quality in a poor signal area,
purchase and install a signal amplifier.
If the antenna needs to be split for two Tv’s, install a
"2-WaySignal Splitter" in the connections.
If the antenna is not installed properly, contact your
dealer for assistance.
Note
All cables shown are not included with the TV.R
ANT.
External Equipment Connections

External Equipment Connections
10 TFT -LCD television Owner’s Manual
Choose Your Connection
There are several ways to connect your television,
depending on the components you want to connect and
the quality of the signal you want to achieve.
The following are examples of someways to connect
your TV. Choose the connection which is best for you.
VCR Connection
To avoid picture noise (interference), leave an adequate
distance between the VCR and TV.
on the remote control, and then press
5
/
6
button to
select the source, press the

button to confirm.
DVD Setup
How to connect
Connect the DVD video outputs (Y, Pb/Cb, Pr/Cr)A
to the COMPONENT (Y, Pb/Cb, Pr/Cr) input jacks on
the TV and connect the DVD audio outputs to the
AUDIO jacks on the TV’ as shown in the gure.
If your DVD only has an S-Video output jack,
A
cconnect this to the S-Video input on the TV and
Connect the DVD audio outputs to the AV IN jacks
on the TV, as shown in the gue.
COMPONENT IN
AV1
OUT
Note
If your DVD player dose not have component
video output,use S-Video.
How to use
Turn on the DVD player, insert a DVD.A
Use theB SOURCE button on the remote control, and
then press
5
/
6
button to to select COMPONENT
mode
, press the

button to confirm.
PressC Play button on external equipment for
program play.
Refer to the DVD player’s manual for operating
D
instructions.
HDMI or DVI Setup
COMPONENT IN
AV1
OUT
Connection Option 1
Set VCR output switch to channel 3 or 4 and then tune
the TV to the same channel number.
Connection Option 2
Connect the audio and video cables from the VCR’sA
output jacks to the TV input jacks, as shown in the
figure. When connecting the TV to VCR, match the
jack colors (Video = yellow, Audio Left = white, and
Audio Right = red). If you connect a S-VIDEO output
from VCR to the S-VIDEO input, the picture quality is
improved; compared to connecting a regular VCR to
the Video input.
Insert a video tape into the VCR and press
B PLAY on
the VCR. (Refer to the VCR owner’s manual.)
Select the input source with using theC SOURCE button
