Haier LE49B7000 User manual

49B7000EL

Contents
-1-
1 Safety and warnings........................................................................................................ ..2-3
2Introduction............................................................................................................... ......4
3Installation............................................................................................................... ....... 5-9
4Remote Controller......................................................................................................... .. 10
5TV Operation.................................................................................................................. 11-14
6Trouble shooting.............................................................................................................1 5

If you are going to clean the product,Unplug the TV,use
soft fabric,no water,never chemicals.

74W
PAL: BG
2 x 8W
00810 x291
123 cm
199
TV 48.25 MHz – 863.25 MHzFrequency
VGA x 1
1xoiduACP
Quick Set up Guide
Note:This product uses a panel consisting of sub pixels which require sophisticated technology to
produce. However, there may be a few bright or dark pixels on the screen. These pixels will have
no impact on the performance of the product.

INSTALLATION NOTES
Locate the TV in a room where light does not strike the screen directly. Total darkness or a reflection
on the screen can cause eyestrain. Soft and indirect lighting is recommended for comfortable viewing.
Allow enough space between the TV and the wall to permit ventilation.
Please do not attempt to rotate the TV on the stand.
Avoid excessively warm locations to prevent possible damage to the cabinet or premature component
failure.
Use the four screws to fix the TV onto a wall mounting bracket (not included) via the four VESA standard
holes on the back of the television.
Wall Mounting Installation Guidelines
Stand Assemble Instruction
INSTALLATION
Finished.Attach the stand base set to the bottom
of the TV by firmly tightening the
supplied 4pcs screws.
M6
M6
M6
M6
400.0
200.0

POWER
POWER
HDMI1, HDMI2, VGA, PC AUDIO, RF.
YPb/Pr, VIDEO/L/R, USB1, USB2, HEADPHONE.
Note: VIDEO and YPbPr share one audio channel.

RF.

The actual power wire is subject to goods.

Y Yellow (Video)

（These models do not support）

11
Installation Guide
The First Time Setup screen will appear when the
TV is first switched on or reset to the factory
setting.
Press the ▼▲ buttons to navigate the menu and
buttons to change the settings. Select your
desired language, Home/Shop Mode to be
displayed on the menu.
▲
▲
Home or Shop modes
When the unit is turn on for the very first time, it
will show Initialization set-up menu. After the
OSD language is set, the user can choose between
"shop mode" and "home mode".
When the screen shows the following setting menu
and the cursor stays on the "home mode" choice,
press to adjust, and "OK" to enter the menu.
Choose "OK" to enter the next prompt Auto
Tuning.
ATV

12
Fav
FAV
You can adjust the OSD Language, Aspect Ratio,
Blue Screen, Reset, Software Update(USB), Shop Mode,
CEC.
Standard
The second item of the MENU is PICTURE MENU.
You can adjust picture effect and ECO mode here,
such as contrast,brightness,etc.
Press▼▲ to move,press toadjust.
▲
▲
Note
1).There are three colors temperature modes
can be selected normal, warm, cool.
2) PC Setting is available in PC mode only
which can adjust Horizontal position, vertical
position, size and phase.

13
Shop Mode Off
CEC

14
ATTENTION:
1. USBHDD compatibility is not assured.
2. Some format video is notplayed for some file reason.
3. Haier will notbear any responsibility for saving
facility quality problem or date missing.
Source Lock:Lock the input source which you want.
Default Source:Set the default input source when
tuning on your TV.
Max Volume:Set max volume limited,this option
allows you to set the max volume level.
Default Volume:Power on default volume,press the
button to select the default volume.
Default Prog: Set the default input prog when tuning on
Key Lock:Lock the key button with TV.
Please press “MENU” button first,and press number
button “1001” to enter into Hotel mode, then press
select “On” or “Off”.“ ” button to
your TV.
Clear Lock:Recall the default settings in Hotel mode.
Export Settings:Export hotel settings to USB device.
Import Settings:Import hotel settings from USB device.

Picture Audio
Snow Noise antenna position, direction
or connection
Inspection
Interfere Noise electronic equipment,car/
motorcycle,fluorescent light
Normal Picture Mute
Volume(inspect wether the
mute function on the remote
control are started , or audio
system are correct or not)
No picture Mute
Power cord is not inserted
Power switch is not opened
Contrast and brightness/volume
setup
Press standby key on the remote
control for inspecting
No color Normal audio color control
Scramble Normal audio
or weak
retune channel
No color Noise Audio system
Special Explanation：The accessories such as remote control is not belongs to the guarantee。
Normal audio
antenna position, direction
or connection
Trouble phenomenon
Ghost
TROUBLE SHOOTING
-14-
