Half Off Ponds AQF3000 User manual

Aqua Marine Floating Fountains
866-831-6558info@halfoponds.com www.halfoponds.com
AQF3000 -AQF15000

7 arching streams with a middle upward stream
9 arching streams with a
middle upward stream
Nozzles and Spray Patterns
Spray Patterns for all Aqua Marine Fountains
Additional Nozzles for
10,000-15,000 GPH Fountains
Additional Nozzle for
15,000 GPH Fountain
ATTACH ADAPTERS TO YOUR AQUA PULSE WATER PUMP
How to Insert Plug into Arch Nozzles
1.
1. Insert plug into center nozzle
2. Seat plug into center nozzle
2.
Plug Plug seated in
center nozzle

Fittings and Assembly
1. Slide the 2 Flange halves around the hub
2. Lift Float and attach it to the hub using the
4 M8 1" Screws provided
AQF3000: Connect all 4 of the
the pictured ttings to your pump.
AQF5200-8000: Connect 3" Male
x 4" Female to 2" Female by 3"
Female ttings to your pump.
AQF10000-12500: Connect
3" Male x 4" Female tting to
your pump.
AQF15000: Connect Fountain
Nozzle Hub and oat directly to
the pump.
ATTACH ADAPTERS TO YOUR AQUA PULSE WATER PUMP
1. Center Hub Adapter in Fountain Nozzle Hub
2. Attach Nozzle Quick-Release over the Hub Adapter and twist to lock
3. Install the Plastic Locking Screw to the Quick-Release to Float Flange
FIG 1 FOUNTAIN ASSEMBLY
Connect Assembled
Float to Monsoon
Pump, turn clock-wise
until snug (careful not
to cross thread)
Scan QR
code for
assembly
instructions.
3” Male x 4” Female
3” Male x 4” Female
3” Male x 4” Female
2” Female x 3” Female
2” Female x 3” Female
2” Male x 1.5” Male
1.5” Female x 1.5” Female
*Float appearance/
size may vary
REVIEW COMPONENTS
FOUNTAIN PUMP AND FLOAT ASSEMBLY KIT:
1. Float Size and Shape May Vary
2. Nozzle Quick-Release
3. Fountain Nozzles
4. Hub Adapter
5. 2 Pieces Float Flange
6. Fountain Nozzle Hub
7. 25' Mooring Rope x2
8. Operation Manual
9. Aqua Pulse Pump
10. 4 Pieces M8 1" Machine Screws
11. 1 Plastic Locking Screw
12. 1.5" x 1.5" Female Adapter
13. 1.5" x 2" Male Adapter x2
6. Fountain Nozzle Hub
7. Mooring Rope x2
5. Float Flange x2
2. Nozzle Quick Release
1. Float
4. Hub Adapter
3. Fountain Nozzles
9. Aqua Pulse Pump
11. Plastic Locking Screw
8. Operation Manual
13. 1.5" x 2" Male Adapter
12. 1.5" x 1.5" Female Adapter
10. M8 1" Machine Screws x4
COLOR CHANGING LIGHTS WITH CONTROLLER
Our RGB LED Light kits come in 3 or 9
watts. They are available in standard
white or remote color-changing, with a
100' or 200' power cord option. Lighting
kits include a remote which allows you
to select solid colors or color patterns,
a photo cell which turns the unit on
automatically at night and off during
daylight hours.

INSTALLING OPTIONAL IGNITE FOUNTAIN LIGHTING KIT
INSTALLING OPTIONAL IGNITE FOUNTAIN LIGHTING KIT
1. Attach the light clips to the
oat. Do not overtighten as
this can crack the oat.
2. Attach the LED lights to the
light clips. Aim the lights
toward the fountain display
3. Read and follow the
instructions included with
the fountain light kit.
WARNING: Water can cause electrical
hazard if caps are not tightly secured!
The T-Connector on the power cord is for connecting
multiple lights in a row. Do not overload your transformer.
RGB Controller not included with white light kits.
Wi-Fi Conroller (sold seperately) will work with color changing lights.
Photocell switch automatically turns lights on and off.
Transformer available in several watt sizes.
RBG RF Controller
T-Connector
Photocell Transformer
Lights
Attaching Lights

Attach mooring ropes and secure to anchors or weights. Place the anchors gently into the pond at opposite edges of the oat. Set one
anchor near the edge of the pond to make it easier to retrieve the fountain for servicing. Be sure to not use sharp rocks, as they can
damage your liner. Make sure the ropes are secured to the oat.
Important: Always retrieve the fountain using mooring ropes. Never retrieve with the power cord.
Position the oating fountain in the desired location and set the anchors. To keep fountain stationary, place the anchors 2' – 4' away
from fountain for every foot of pond depth.
Position the oating fountain in the desired location and set the anchors. To keep fountain stationary, place the anchors 2' – 4' away
from fountain for every foot of pond depth.
1. Securely attach mooring ropes to the fountain oat. We
recommend using a carabiner to make fountain-removal
simple. After unhooking fountain, you can clip to a oat so that
you can easily nd the mooring rope for reinstallation.
2. Use mushroom anchors or concrete blocks to hold the foun-
tain in position You can also use stakes to secure lines closer
to the pond edge so that a boat is not needed for fountain
service.
Drip Loop

Visit Us at www.halfoffponds.com
Scan QR code
for assembly
instructions and
more information.
Customer Support
[e-mail]
1-866-831-6558
WARRANTY
These products, distributed by Half Off Ponds are warranted to the original user only to be free of defects in material and workmanship
for a period of 24 months from the date of purchase, but not more than 30 months from the date of manufacture. Half Off Ponds’s liability
under this warranty shall be limited to repairing or replacing, at Half Off Ponds’ discretion, without charge, F.O.B. Half Off Ponds will not be
liable for any cost of removal, installation, transportation, or other charges which may arise related to a warranty claim.
FOUNTAIN MODELS
AQF3000 AQF5200 AQF6100 AQF8000 AQF10000 AQF12500 AQF15000
Reference the pump manual and light manual for warranty details on products.
To obtain service under this warranty, the defective product must be returned to Half Off Ponds together with proof of purchase and
installation date, failure date, and supporting installation data. Any defective product to be returned to Half Off Ponds or a service center
must be sent freight prepaid: documentation supporting the warranty claim and/or an Authorized Warranty Return (AWR) must be included if
instructed. In the absence of suitable proof of purchase date, the effective date of this warranty will be based upon the date of manufacture.
Any replacement product may be either new or like-new, provided it has functionality at least equal to that of the product being replaced.
No requests for service under this warranty will be accepted if received more than 30 days after the term of the warranty. Correction of
defects, in the manner and for the duration of the warranty described in this warranty, shall constitute complete fulllment of all liabilities
and responsibilities of Half Off Ponds to the user with respect to the product, and shall constitute full satisfaction of all claims, whether based
on contract, negligence, strict liability or otherwise. Except for the obligations specically set forth in this warranty, in no event shall Half Off
Ponds be liable for direct, indirect, special, incidental, or consequential damages, whether based on contract, tort, or any other legal theory
and whether advised of the possibility of such damages.
Half Off Ponds reserves the right to change or improve its products or any portions thereof without being obligated to provide such a change
or improvement for units sold and/or shipped prior to such a change or improvement.
THERE ARE NO EXPRESS OR IMPLIED WARRANTIES, INCLUDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WHICH
EXTEND BEYOND THOSE WARRANTIES DESCRIBED OR REFERRED TO ABOVE EXCEPT AS EXPRESSLY HERIN PROVIDED THE GOODS ARE
SOLD “AS IS”, THE ENTIRE RISK AS TO QUALITY AND FITNESS FOR A PARTICULAR PURPOSE, AND PERFORMANCE OF THE GOODS IS WITH
THE BUYER, AND SHOULD THE GOODS PROVE DEFECTIVE FOLLOWING THEIR PURCHASE, THE BUYER AND NOT THE MANUFACTURER,
DISTRIBUTOR, OR RETAILER ASSUMES THE ENTIRE RISK OF ALL NECESSARY SERVICING AND REPAIR.
