Halogen Purify User manual

EPA Est. No. 97973-CHN-1

QUICK START GUIDE:
Voltage: 110 VAC
Capacity: 4 L
Model: HALOGEN Purify
Power: 35 W
Operating Time: 1, 2 and 4 hours
TO FILL & RUN A NEW BATCH:
1. Add some purified or distilled water to a mixing container.
2. Stir in 8 tsp. salt (non-iodized) to the mixing container and stir
to dissolve.
3. Remove the lid and pour the salt solution into the HALOGEN
Purify.
4. Top up HALOGEN Purify with fresh water to the 4L level and
place the lid back on.
5. Plug the HALOGEN Purify into an outlet. You will hear one
beep indicating that the unit has power.
6. Press the On/Off button 3 times to start the 1 hour brew time.
The unit will turn off when complete.
TO START PURIFYING THE AIR:
1. Using an HOCL test strip, verify that the solution is at the
desired strength. (~200ppm).
2. Press the On/Off button 2 times (The unit will begin fogging).
3. Press the Fogmeter button to switch the unit between 3,2,1 &
0 (High, Med, Low & Off).
TO TURN OFF THE HALOGEN PURIFY:
1. Press the On/Off button 2 times.
Technical Specifications:

Instructions:
Please see Quick Start Guide for step by step instructions.
Prior to brewing your HOCl, measure the pH of your water using
Halogen pH test strips. If pH is 7 or higher, add 2 teaspoons of distilled
white vinegar to adjust the pH between 5-6.5.
Button Sequence for operation below:
Test the hypochlorous acid concentration with the Halogen test strips
to confirm desired concentration. Now your Hypochlorous Acid is
ready to use. Just turn on the fogger and start disinfecting.
•Hypochlorous acid (HOCl) is a form of active chlorine at a
pH range between 4-6. Adding vinegar lowers the pH
increasing yield and potency of disinfectant solution.
•Filtered water is recommended to extend product life.
•Low concentration solution is safe for use on foods. Rinse
food thoroughly after application.
•Store in dark, cool place in a glass or plastic container. Do
not store solution in the Halogen Purify. Use Halogen test
strips before each use to ensure the solution is ready for
application.
See website for a complete list of uses and additional
information:
www.halogenclean.com
HOCl & pH:
Notes on HOCl (Hypochlorous Acid):
Note: If your electrolyzed solution is between a 4-7 pH
then Hypochlorous Acid has been produced. If it is above
that parameter, you will have Bleach.

Halogen Purify Operation Notes:
Follow all instructions and safety precautions to ensure safe operation.
Product Maintenance:
How To Make Hypochlorous Acid (HOCl):
Hypochlorous Acid (HOCl) Concentration and Wait Times
Concentration Salt
Distilled
White
Vinegar
Power Time
200 ppm 1-2 tsp Medium 1 hour
200 ppm Medium 2 hours
200 ppm
~8 tsp (60g)
~4 tsp (30g)
~1Tbsp (26g)
1-2 tsp
1-2 tsp Medium 4 hours
Above salt & vinegar measurements are for making a full tank(4L) of disinfectant.
Adjust as necessary.
1. Please read the manual carefully when using the machine for the first
time.
2. Please use clean water with temperature below 104F (40C).
3. Place on a flat and firm surface to avoid tilting.
4. Do not add any substances in the water other than those described in this
manual.
5. Keep away from heat sources and avoid direct sunlight.
6. Keep 6 feet away from furniture and appliances to avoid them becoming
damp.
7. Do not place books, towels and other articles under the unit or over the fog outlet.
8. Please use your Halogen Purify at normal room temperature (between
41F-100F and below 80% RH).
9. Do not move the appliance when there is water in the reservoir.
10. When cleaning, avoid getting water into the base of the machine.
1. The water tank, transducer and other parts of the appliance should be
cleaned every week after unplugging the unit from the power source.
2. Please use a soft cloth for routine cleaning of all parts.
3. When cleaning the tank, first remove the square float by turning it
counterclockwise (as shown in figure 3 below).
4. When the appliance is not used for a long time, clean and dry all the
parts and place them in a dry place.
5. Do not use hard objects when cleaning to avoid scratching the
transducer.
6. Do not use chemical solvents or other harsh cleaners to clean the
machine.
7. Change the old water in the tank to keep the product clean.
NOTE: When pouring water out of the machine, pour from one of the front
corners to avoid water entering the air tube in back. (See Figure 1 & 2).
Safety Guidelines:
1. Please use this device with the recommended household
voltage and frequency of 110v AC 60Hz.
2. Please do not dismantle, repair, modify or change this
appliance.
3. If the power supply cord is damaged, do not use the machine.
4. Turn off the power and pull the plug before cleaning or moving
the unit.
5. Do not turn the electrical appliance over when it is powered on
to avoid burning out the internal electronic components.
6. Please keep this machine out of reach of children.
7. Do not touch the water or any of the parts in the water tank while
the machine is plugged in and in operation.
8. Do not pull the power cord to pull the power plug or touch the
power plug with wet hands.
9. This machine can only be used indoors.
10.Please unplug the unit during thunderstorms or when not in use.
11.Keep out of reach of children.
12.Never drink the water or electrolyte produced by this machine.
