HAMOKI VRX Glass Operation instructions

0
VRX Glass Assemble Instruction
1 、VRX Glass Accessory List
2.Assemble Steps
Glass clamp
glass
clamp
Countersunk
head screw
Countersunk
head screw
Silicone
protective cover
foot
frame
Knurled
screw
Glass locking
set screw
3.Insert the Silicone
protective cover into
the glass hole.
1.Use countersunk head
screws to lock glass clamp on
the VRX show case body .
glass locking set
screw
glass clamp
2.Place the two side glass and back glass
into the glass clamps separately.
Silicone
protective cover
Glass hole
Knurled screw
foot frame
4.Assemble the foot frame on the inside of
glass panel and fix it with knurled screws.
5.Secure the top glass with knurled
screws fixed on the installed foot
frame.
glass

1
Instructions for Installing VRX on PZ Marble Series Products
1.Assemble Accessory List：
2.Assemble Steps
↓
VRX fixed buckle
cross fixed
screws
1.Fasten the fixed buckle with a cross fixed
screw on the two sides（left&right） and back
of the bottom of show case.
2.Clip the fixed buckles on three
sides onto the marble.
cross fixed screws
VRX fixed buckle
VRX show case
bottom
VRX
fixed buckle
marble
VRX show
case bottom
6.Structural Diagram after Assemble
3.Display after finished Assemble
