Haussmann RL User manual
Reach-in Merchandisers
Medium and Low Temperature
Installation &
Operation Manual
Shipped With Case Data Sheets
P/N 0387183_V
February 2017
Spanish P/N 0517045
French P/N 0527085
IMPORTANT
Keep in store for
future reference!
®
Æ
MANUAL- I/O REACH-IN
Use this manual along with door manual P/N 0425683
for cases with Innovator Doors
Use this manual along with door manual P/N 3008521
for cases with EcoVision II Doors (RMTD)
Permit Number:
20-05195
Permit Number:
20-05195
P/N 0387183_V
IMPORTANT
KEEP IN STORE FOR FUTURE REFERENCE
Quality that sets industry standards!
This merchandiser is NSF®certified.
12999 St. Charles Rock Road • Bridgeton, MO 63044-2483
U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900
www.hussmann.com
© 2017 Hussmann Corporation
Table of Contents
ANSI Z535.5 DEFINITIONS ..................iv
INSTALLATION TOOL LIST ...............iv
INSTALLATION
UL Listing..................................................... 1-1
Federal / State Regulations. ............................. 1-1
Location ....................................................... 1-1
Shipping Damage ........................................... 1-1
Exterior Loading ........................................... 1-2
Merchandisers Shipped With End Installed......... 1-2
Shipping Braces ............................................. 1-2
Moving Merchandiser Through Narrow
Store Entrances .............................................. 1-3
Final Location ............................................... 1-5
Leveling ........................................................ 1-5
Door Adjustment............................................ 1-7
Joining.......................................................... 1-7
Joining Instructions ....................................... 1-8
Installing Splashguard Brackets ..................... 1-23
Installing Bumpers........................................ 1-24
REFRIGERATION / ELECTRICAL
Refrigerant .................................................... 2-1
Refrigerant Piping.......................................... 2-1
Insulation ...................................................... 2-3
Branch Line Piping ........................................ 2-4
Expansion Valve Adjustment ........................... 2-5
Refrigeration Thermostat ................................ 2-6
Defrost Termination Thermostat ...................... 2-7
Control Settings Medium Temperature ............. 2-7
Control Settings Low Temperature ................... 2-7
Merchandiser Electrical Data ........................... 2-9
Field Wiring ................................................. 2-9
Electrical Connections .................................... 2-9
Identification of Wiring .................................. 2-9
Wiring Color Code ....................................... 2-10
DRIP PIPING AND SPLASHGUARDS
Waste Outlet and Water Seal ............................ 3-1
Installing Drip Piping ..................................... 3-1
Drip Piping Lineup Arrangements ................... 3-4
Installing Splashguards ................................... 3-5
Sealing Splashguard to Floor ........................... 3-6
START UP / OPERATION
Start Up ......................................................... 4-1
Stocking ........................................................ 4-1
Load Limits .................................................... 4-1
Load Limit Profiles.......................................... 4-2
Installing FDA/NSF Required Thermometer ...... 4-3
MAINTENANCE
Care and Cleaning............................................ 5-1
Cleaning Honeycomb Assemblies........................ 5-2
Cleaning Stainless Steel Surfaces .........................5-3
Cleaning Coils ..................................................5-3
Cleaning Under Merchandisers ......................... 5-3
Removing Scratches from Bumper...................... 5-3
SERVICE
Replacing Fan Motors and Blades ...................... 6-1
Replacing Electric Defrost Heaters .................... 6-3
Replacing Drain Pan Heater ............................. 6-5
Servicing Vertical Lighting .............................. 6-6
Servicing Doors and Frames ............................. 6-6
Replacing Door or Door Frame Parts ................ 6-6
Replacing Damaged Drain Fitting ..................... 6-6
Repairing Aluminum Coils ............................... 6-7
WARRANTY
Permit Number:
20-05195
P/N 0387183_V
iv Contents
U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
INSTALLATION
TOOL LIST
Unloading From Trailer:
Lever Bar (also known as a Mule,
Johnson Bar, J-bar, Lever Dolly,
and pry lever)
Moving Dolly
Setting Case Line-Up:
Level, 4 ft suggested
Ratchet
¼in. Socket
5/16 in. Socket
½in. Socket
Battery Drill/Screw Gun
Caulking Gun
10 in. Adjustable Crescent Wrench
ANSI Z535.5 DEFINITIONS
• DANGER – Indicate[s] a hazardous
situation which, if not avoided, will
result in death or serious injury.
• WARNING – Indicate[s] a hazardous
situation which, if not avoided, could
result in death or serious injury.
• CAUTION – Indicate[s] a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
• NOTICE – Not related to personal injury –
Indicates[s] situations, which if not avoided,
could result in damage to equipment.
REVISION HISTORY
REVISION V — FEBRUARY 2017
1. Page 1-1, Added Additional Statement to Fed.
/ State Regulations; Ambient Conditions note,
Page 4-1
REVISION U — DECEMBER 2016
1. Page 1-24, Added Splashguard Brackets for
RMT
REVISION T — AUGUST 2016
1. Page 1-6 new diagram and note: “Bottom front
supports must be shimmed if not in full contact
with the floor.”
REVISION S — APRIL 2016
1. PAGE 1-1 Revised UL, PAGE 2-5 Valve
Adjustment
2. Updated text and drawings to add RMTM
nomenclatures, revised size of joining gasket
REVISION R — JULY 2015
1. Replaced RLT drawings in Section 1;
New Drawing Page 2-6, 2-7, 4-2, wording
on 6-2 and 6-4, removed drawing 6-4.
Updated heater replacement, 6-5
REVISION Q — MAY 2015
1. Redesigned manual to 1/2 letter size
REVISION P — OCTOBER 2014
1. California Warning Statement, Page 1-2;
changed to 2 in. partition kit, Page 1-7;
Shim location, Page 1-6; End Caps, Page 1-8;
Removed screws, Page 2-2; Time Termination,
Page 2-8, 2-9; No thread sealer, Page 3-2, 3-3;
RLT load limit drawing, Page 4-2; Ammonia
cleaners, Page 5-3; Number 11, Page 6-1, 6-2;
Heater drawings, Page 6-4, 6-5; Removed
number 2 teflon tape, Page 6-7.
!
!
!
Permit Number:
20-05195
P/N 0387183_V
REVISION N — APRIL 2013
1. Inserted Joining Instructions,
Pages 1-8 - 1-22
REVISION M — MARCH 2013
1. Revised caution note on page 1-1; added to
Page 4-1.
REVISION L — AUGUST 2012
1. Updated instructions for moving case through
small doors, Section 1.
REVISION K — JULY 2012
1. Included instructions for clearing smaller store
entrances, Section 1. Ice cream note added to
Page 4-1.
REVISION J — APRIL 2012
1. Corrected Table of Contents, page iii.
REVISION I — NOT ISSUED
REVISION H — MARCH 2012
1. Amended Installing Drip Piping procedure,
Page 3-2.
REVISION G — MARCH 2010
1. Revised Installing Drip Piping procedure,
Pages 3-1 through 3-6.
REVISION F — DECEMBER 2009
1. Changed shimming drawing, Page 1-3.
2. Updated drip piping pitch, Page 3-1.
3. Added page division lines for thermometer,
Page4-3.
4. Added cleaning stainless steel rails,
Page5-2.
5. Added heater front and rear drawing,
Page6-3.
6. Updated warnings and cautions throughout
7. Added new back cover
REVISION E — JANUARY 2009
1. Added page division lines for thermometer,
Page 4-3.
2. Added heater front and rear drawing,
Page6-3.
3. Changed shimming drawing, Page 1-3.
REVISION D — SEPTEMBER 2007
1. Added front panel text and illustration, Page
1-2.
2. Clarified shimming directions, Page 1-3.
3. Added RLT information throughout.
4. Added note to remove bumper protective film,
Page 1-6.
5. Added information on Always*Clear™ glass,
page 5-1.
6. Removed reference to Anthony doors, Page
6-5.
7. Added repairing aluminum coil, Page 6-12.
8. Changed warranty page.
9. Added Installation Tool List, Page iv.
10. Added revision history, Page iv.
REVISION C — JUNE 2002
1. Added NSF information, Pages 1-1,4-2
through 4-4.
2. Sections 2 through 6 are completely
rewritten.
3. Changed warranty to March 15,2002.
Reach-In
HUSSMANN CORPORATION, BRIDGETON, MO 63044-2483 U.S.A.
Permit Number:
20-05195
Permit Number:
20-05195
Reach-In
P/N 0387183_V 1-1
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
UL LISTING
These merchandisers are manufactured to meet ANSI/
UL 471 standard requirements for safety. Proper
installation is required to maintain the listing.
FEDERAL / STATE REGULATION
These merchandisers at the time they are manufac-
tured, meet all federal and state/ provincial regula-
tions. Proper installation is required to ensure these
standards are maintained. Near the serial plate, each
merchandiser carries a label identifying the environ-
ment for which the merchandiser was designed for use.
In compliance with DOE 2017, standard low temp
Reach In cases with Innovator I Doors are equipped
with an anti-sweat controller that maintains the door
heat at a level that meets DOE energy limits.Any factory
or eld-installed anti-sweat controller applied to a low
temp Reach In case with Innovator I Doors must be
programmed to cycle the heaters at no more than 50%
run time at design conditions of 75 degrees, 55% RH
for frozen food operating condition.
ANSI/NSF-7 Type I – Display Refrigerator / Freezer
Intended for 75°F (24°C) / 55%RH Ambient Application
ANSI/NSF-7 Type II – Display Refrigerator / Freezer
Intended for 80°F / 55%RH Ambient Application
ANSI/NSF-7 – Display Refrigerator
Intended for Bulk Produce
LOCATION
These merchandisers are designed for displaying prod-
ucts in air conditioned stores where temperature is
maintained at or below the ANSI/NSF-7 specified level
and relative humidity is maintained at or below 55%.
Placing refrigerated merchandisers in direct sunlight,
near hot tables or near other heat sources could
impair their efficiency.
Like other merchandisers, these are sensitive to air dis-
turbances. Air currents passing around merchandisers
will seriously impair their operation. Do NOT allow
air conditioning, electric fans, open doors or windows,
etc. to create air currents around the merchandisers.
To prevent sweating on the exterior surfaces of
merchandisers, there must be aminimum clearance
of 4 inches (102 mm)between the merchandisers
and other fixtures or walls. Product should always
be maintained at proper temperature. This means that
from the time the product is received, through storage,
preparation and display, the temperature of the product
must be controlled to maximize the life of the product.
SHIPPING DAMAGE
All equipment should be thoroughly examined for
shipping damage before and during unloading. This
equipment has been carefully inspected at our factory.
Any claim for loss or damage must be made to the car-
rier. The carrier will provide any necessary inspection
reports and/or claim forms.
Apparent Loss or Damage
If there is an obvious loss or damage, it must be noted
on the freight bill or express receipt and signed by the
carrier’s agent; otherwise, carrier may refuse claim.
The carrier will supply necessary forms.
Concealed Loss or Damage
When loss or damage is not apparent until after
equipment is uncrated, a claim for concealed damage
is made. Upon discovering damage, make request in
writing to carrier for inspection within 15 days and
retain all packing. The carrier will supply inspection
report and required claim forms.
INSTALLATION
Do not store items or ammable
materials atop the unit.
Do not walk on case.
Permit Number:
20-05195
1-2 InstallatIon
P/N 0387183_V U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
EXTERIOR LOADING
Do NOT walk on top of merchandisers or damage to
the merchandisers and serious personal injury could
occur. They are noT sTrucTurally designed To supporT
excessive exTernal loading such as the weight of
a person. Do not store items or flammable materials
atop the unit.
MERCHANDISERS SHIPPED WITH
END INSTALLED
If the case was shipped with the end installed, two
long bolts were used to hold the shipping brace to the
end. If the shipping bolts are reinserted after remov-
ing the brace, they will extend into the product area
and may damage the coil. Therefore, be sure To
replace These bolTs wiTh The shorTer bolTs
provided.
Be careful not to damage the factory-installed end
while moving the merchandiser. Make sure that tools
are positioned past the end and beneath the merchan-
diser’s support bar.
SHIPPING BRACES
Move the merchandiser as close as possible to its per-
manent location and then remove all packaging. Check
for damage before discarding packaging. Remove all
separately packed accessories such as kits and shelves.
Locate the shipping block in the center of the heat
exchanger (see illustration), and remove it before
piping the merchandiser. This block was installed to
minimize shipping vibration.
This product may contain chemicals
known to the State of California to
cause cancer, birth defects, or other
reproductive harm.
This warning is the result of the California State law
known as the California Safe Drinking Water and Toxic
Enforcement Act of 1986, which is commonly referred
to as“Proposition 65.”
This warning does not mean that Hussmann prod-
ucts will cause cancer or reproductive harm, or is in
violation of any product-safety standards or require-
ments.As claried by the California State government,
Proposition 65 can be considered more of a‘right to
know’law than a pure product safety law. When used
as designed, Hussmann believes that our products are
not harmful. We provide the Proposition 65 warning
to stay in compliance with California State law. It is
your responsibility to provide accurate Proposition 65
warning labels to your customers when necessary. For
more information on Proposition 65, please visit the
California State government website.
For California Businesses:
Permit Number:
20-05195
Reach-In
P/N 0387183_V 1-3
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
MOVING MERCHANDISER THROUGH
NARROW STORE ENTRANCES
Some exterior merchandiser parts may be disassembled
for transit access through small doors or passage ways.
This procedure takes approximately 30 minutes to
disassemble and reassemble one case. Contact your
Hussmann representative to see if store merchandisers
have this kit option. The case height without these
components installed on top is 82.75 in. (2102 mm).
Case depth is 35.5 in. with handles, wireway pan and
external frames removed.
Follow the steps below to decrease the
merchandiser profile for narrow access:
1. Remove the door handles.
2. Remove the front bumper. Pull from the
bottom and set aside.
3. Remove the lower front panel to access the
wireway.
Remove
Screws from
Door Handle
Edge Fits over
Wireway
Tabs t in
Retainer Slots
Front Panel
Remove Screws
Permit Number:
20-05195
1-4 InstallatIon
P/N 0387183_V U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
4. Remove the screws that attach the wireway pan to
the bottom assembly.
5. Detach the rubber and plastic gromets from the
wireway pan.
6. Remove the screws that attach the grounding lug to
the wireway pan.
7. Slide the wireway pan out, and remove it from the
case. Bumper brackets and supports are attached to
wireway pan. Removing the pan will remove the entire
assembly.
8. Remove the back, external braces from the rear of
the case as shown below. Braces will slide straight
back away from the case when nuts and screws are
removed.
6 nuts and 1
bottom screw per
external brace
Bottom screw is located approximately
10 inches inboard from the rear of the
case. Bottom screw location on removed
rear brace.
Permit Number:
20-05195
Reach-In
P/N 0387183_V 1-5
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Check the following before the rear of the case is posi-
tioned at its final location according to the store plan:
1. The external braces must be reinstalled
with (6) nuts per brace, torqued to 24 foot
pounds.
FINAL LOCATION
Once the case reaches its final location, reassemble the
wireway and door handles as follows:
1. Reinstall wireway pan in reverse order of removal.
2. The ground lug must be reinstalled using the
screws provided.
3. Replace the conduit connectors and plastic gromets
to the wireway pan.
4. Replace wireway cover, bumper and door handles.
LEVELING
Merchandisers must be installed level to ensure proper
operation of the refrigeration system and to ensure
proper drainage of defrost water. When leveling mer-
chandisers, use a carpenter’s level as shown.
Metal leveling shims or wedges are provided with each
merchandiser for use if needed.
Rear external frames must be
reinstalled securely before setting
or unloading shelves.
Donot walk on top of the merchandIser.
donot place heavy objects on case.
Do not walk on top of merchandiser.
Do not store items or
ammable materials atop the unit.”
Permit Number:
20-05195
1-6 InstallatIon
P/N 0387183_V U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
NOTE: Begin lineup le ve li ng f ro m th e hi gh -
est point of the s to re f lo or .
Place shims under the rail and make sure that they
are positioned at a base component (crossbar).
This transfers the weight directly from the loaded
case through to the floor.
Placing shims at other locations will cause uneven
distribution of weight leading to piping leaks, as
well as sagging or wracked doors.
Bottom front supports must be shimmed if not in
full contact with the floor.
Front
Back
Base Component
Shim Here Shim Here
Shim Here
Permit Number:
20-05195
Reach-In
P/N 0387183_V 1-7
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
DOOR ADJUSTMENT
After leveling and joining the merchandisers, adjust
and level doors according to manufacturer’s instructions
shipped with each product. Factory settings may be
lost due to vibration during shipment.
JOINING
Sectional construction means that two or more mer-
chandisers may be joined in line yielding one long
continuous display requiring only one pair of ends.
Joining kits and instructions are shipped with each
merchandiser.
To join like fixtures, a joining kit is required. To
join unlike fixtures, or like fixtures operating at dif-
ferent temperatures, a 2inch (51mm) partition kit
is required. To join same temperaturemerchandisers
on different defrost cycles, a plexiglass partition kit is
required.
all joinTs musT be air-TighT To prevenT formaTion
of ice or condensaTion.
Refer to the instructions on the next page.
Permit Number:
20-05195
1-8 InstallatIon
P/N 0387183_V U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
PARTS LIST
Item
Quantity Description
RL/RM RLN RLNIM RMTM
RM/RMF RMN RLNIE RLTM, RMTD
1. 2 2 4 2 Donut Gasket
2. 1 1 2 2 Gasket, .906 x 1/2 x 200 in.
3. 1 1 2 1 Gasket,
1/2 x 1/4 x 600 in.
4. 8 8 14 6 Cap Screw
5/16 -18 x 11/4
5. 8 8 14 6 Split Lock Washers 5/16
6. 1 12 1 Joint Molding
7. 5 5 10 5 Binder Post and Screw
8. 1 12 1 Splice Connector
Remote Reach-Ins
Joining Instructions
Joining Instructions
NOTE: Be sure first merchandiser has been leveled
according to the main installation instruction.
Carefully unpack and inspect the joining parts listed
above to verify completeness and that there is no
damage.
1Prepare cases for joining (both sides of
islands) as shown in Figure 1.
A. Remove bumpers, rails, packing materials,
and splashguards from the both cases.
B. Remove shelves (if installed).
C. Remove display racks and pans from
ends to be joined.
D. Remove plenum covers.
Splashguard brackets must
be installed before piping or
wiring case.
B
A
CD
E
Figure 1. Prepare Cases
Bumper
Bumper
Retainer
Splashguard
SIDE VIEW
A
RLTM
C
RLNS
RMNS
RLTIM
4
4
2
12
12
2
10
2
Permit Number:
20-05195
Reach-In
P/N 0387183_V 1-9
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
PARTS LIST
Item
Quantity Description
RL/RM RLN RLNIM RMTM
RM/RMF RMN RLNIE RLTM, RMTD
1. 2 2 4 2 Donut Gasket
2. 1 1 2 2 Gasket, .906 x 1/2 x 200 in.
3. 1 1 2 1 Gasket,
1/2 x 1/4 x 600 in.
4. 8 8 14 6 Cap Screw
5/16 -18 x 11/4
5. 8 8 14 6 Split Lock Washers 5/16
6. 1 12 1 Joint Molding
7. 5 5 10 5 Binder Post and Screw
8. 1 12 1 Splice Connector
E. Remove back panels from ends to be
joined by lifting up and out near the bot-
tom. No tools are necessary. The RLTM
models have upper and lower back panels
that must be removed.
F. Remove joint molding from any door
frames that will be joined to another case.
G. RLNI Only: Remove screws and inte-
rior top panel on both sides of the island
case end to be joined
(see Figure 1).
E
GG
RLNI Only
Alignment Pin
F
E
RL / RM / RMF
RLN / RMN
and RLNI
RLTM
RMTM
RMTD
Permit Number:
20-05195
1-10 InstallatIon
P/N 0387183_V U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
2Locate and remove the shipping block in the
center of the heat exchanger in the interior
bottom of each case, see Figure 2.
Snap a chalk line on the floor to use as a guide
for positioning the front of the cases in the
line-up. The front base frame should be on the
chalk line.
3Once cases are close to final placement, remove
the shipping braces from the ends to be joined,
see Figure 3. Discard bolts and flat washers
used to hold shipping braces. Bolts are too
long to be used for joining.
RMN
Figure 3. Remove Shipping Braces
Donot use shipping bolts to join cases!
Shipping Brace
Figure 2. Remove Shipping Block
(One From Each Side of Island Models)
Shipping
Block
RLNI / RLNI
Permit Number:
20-05195
Reach-In
P/N 0387183_V 1-11
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
4If not already installed make
sure NutRetainers and
Alignment Pins are in place in
the right end frame as shown
in Figure 4A or 4B.
Figure 4A. Verify Nut Retainer Installation
Factory Installed
Nut Retainer
RLT has no
Alignment Pin
RLTM
RMTM
RL / RM / RMF
and
RLN / RMN
Alignment Pin
Permit Number:
20-05195
1-12 InstallatIon
P/N 0387183_V U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
RLNI
Permit Number:
20-05195
Reach-In
P/N 0387183_V 1-13
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
5Apply Donut Gasket– 1 in recess around both
left end as shown in Figure 5A, Part 1; 5B or
5C, Part 1, and right end frames as shown in
Figure 5A, Part 2; 5B or 5C, Part 2.
Apply the wider Foam Tape Gasket — 2
around the right end frame as shown in Figure
5A, Part 2, 5B or 5C, Part 2.
Figure 5A, Part 1. Apply Gasket to Left End of
RL/RM/RMF and RLN/RMN
RL / RM / RMF
and
RLN / RMN
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
Left End Case
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
Left End Case
Right End Case
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
1
Permit Number:
20-05195
1-14 InstallatIon
P/N 0387183_V U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
Figure 5A, Part 2. Apply Gaskets to Right End of RL/RM/RMF and RLN/RMN
RL / RM /
RMF
and
RLN / RMN
Apply gasket pad to right end
first, then apply the narrower
Foam Tape Gasket — 3
around the perimeter of the
right end frame outside of
the donut gasket as shown in
Figure 5A, Part 2, 5B or 5C,
Part 2.
• Lap gaskets at lower
corners.
• Check that there are no
gaps between gasket and case.
• Do not stretch gasket,
especially around corners.
To make sharp corners, paper
backing can be torn without
removing from gasket.
• Do not butt gaskets; always
lap joints.
• Remove paper backing after
gasket is applied to keep gasket
free of debris.
• Gasket has high tack
adhesive and must be properly
placed the first time.
Overlap
Gasket
Gasket Pad
F
R
O
N
T
Right End
Le End
F
R
O
N
T
/ / / / / / /
/////////////////////////////
2
3
/////////////////////////////
Detail D
1
Overlap
Foam Gasket 3
as Shown
/////////////////////////////
1
2
3
/////////////////////////////
Detail A
/ / / / / / / /
/////////////////////////////
1
2
3
Donut Gasket
Foam .906 inch x 1/2 inch x 200 inch
Foam 1/2 inch x 1/4 inch
Right End
Case-to-Case
Joint or End Panel
Apply Donut Gasket,
Foam Gaskets
and Gasket Pad to
Right End Only
Apply Gasket Pad
2
Detail C
Install Donut
Gasket
(seat into groove)
Left End
Only Use
Donut Gasket on
left end of
a Case-to-Case
Joint
If attaching an End
Panel, all 4 Gaskets
must be applied.
1. Butyl is NOT an acceptable
substitute for donut or foam
gasket.
Gasket
Pad
Permit Number:
20-05195
This manual suits for next models
10
Table of contents
