Shelf lighting uses parallel
wiring. Please follow these
instructions to ensure
good contact between male
and female connectors.
1SHUT OFF POWER TO ASE. REMOVE
ALL SHELVES.
2Engage each power socket cap and ensure
that each cap is fully seated before cleaning.
Ensure the proper seating of the cap at all
times when the plug is not engaged.
3Clean the merchandiser as described in the
Care and Cleaning paragraphs of Section 5 –
Maintenance in the Installation and Operation
Manual (P/ 378414 or P/ 428668) provid-
ed with the case. Keep liquid out of sockets.
4Verify that power is at the case and turned on.
Verify that the case light switch is turned
“OFF.” Switch is located in the canopy, on
the left, behind first row of lamps.
5See the illustration below. It is typical of D5,
C5, and D6 models. ote that other models
will have fewer rows of shelves.
Starting from the left-hand bottom section,
choose the location for the first shelf, X-1.
Secure the shelf in the slotted upright. Make
certain that the shelf is level and that ends are
in the same slot on the left and right upright.
It is important that shelf brackets be proper-
ly seated in the slotted upright.
6Remove the cap from
the rear wall socket and
insert the shelf plug in
the socket. Secure cord
under clip.
7Working from left to right, install the next
shelf, X-2, to the right of the first shelf you
installed.
Always work from left to right and from the
bottom up in each 8 ft (2438 mm) and 12 ft
(3685 mm) case. After each shelf on the
bottom row is in position, be sure to remove
the cap and insert the shelf plug. Push firmly.
8Turn “O ” the case light switch after the
entire bottom row has been installed in either
8 or 12 ft (2438 or 3658 mm) cases. The shelf
lights should light.
If a shelf lights do not operate,
A. Turn off light switch.
B. Make certain the shelf lamps are properly
engaged in the shelf lamp holders.
C. Remove and firmly re-insert each shelf
plug.
D. Turn on light switch.
If lights do not operate after checking the
items listed above, contact the installation
contractor.
9Using the row of shelves just installed as
support, set the next shelf, X-4, in the desired
location. Remove the cap and insert the shelf
plug. Continue working left to right installing
shelves X-5 and X-6.
ote: Since the location for the remaining
shelves, X-4 to X-15, may be directly over
the rear wall receptacle, the shelf should be
plugged in before engaging brackets in the
uprights. The lower shelf will support the
weight of the next shelf until it is plugged
in. After installing each shelf, verify that its
plug is properly connected to its rear wall
receptacle. Continue working row by row,
bottom up, left to right.
Important
If a shelf is plugged in and the lamp does
not work, verify:
A. the case light switch is “O ” and
B. that the shelf lamp is properly engaged
in the shelf lamp holders.
P/N 0432812
June, 2001
Socket with Cap Installed
10 Sockets in
8-ft Case
15 Sockets in
12-ft Case
Always work Left to Right,
and Bottom to Top
X-1
X-4
X-7
X-10
X-13
X-2
X-5
X-8
X-11
X-14
X-3
X-6
X-9
X-12
X-15
Light Switch Location
R
I
G
H
T
W
R
N
G
Procedure for Installing Lighted Shelves with Single-Prong Connector
Push in clip
