HANSS ACOUSTICS PA-30 User manual

PA-30
PHONO AMPLIFIER
USER MANUAL

Page 1
HOW TO AVOID DAMAGES
1. When unpacking the unit place it on a clean dry stable surface
before removing the unit from the box.
2. It is suggested that the unit be shut off and the mains/power
cable be disconnected before changing cables or moving
the unit. This will add to the life of the unit as well as prevent
your other equipment from being damaged.
3. If the unit is not going to be used for an extended period of
time, it is suggested that the unit to be unplugged.
4. The unit should not be placed in a moist area or directly under
an air-conditioner or heater.
PACKAGE CONTENTS
1 PC HANSS ACOUSTICS PA-30 Phono Amplifier
1 PC Mains/Power Cable

Page 2
CONNECTION
Connecting the PA-30
1. Place the unit on a clean dry stable surface.
2. On the back of the unit switch off the power button located beside the
IEC power socket.
3. Plug in the supplied power/mains cable ad switch on the power button
besides the IEC power socket. The unit will now be in Standby mode
until you press the power button located on the front panel.
AC-MAINS
MC INPUT MM INPUT
LEFT
RIGHT
OUTPUT
LEFT
RIGHT
S/N
RISK OF ELECTRICAL SHOCK DO NOT OPEN
RISQ UE DE CHOC ELECTRIQUE NE PAS OUV RIR
NO USER-SERVICEABLE PARTS

Page 3
MM INPUT(pF)MC INPUT( )
CAPACITANCE RESISTANCE
MM
MC
400
300
200
100
47
220
1K
47K
PHONO AMPLIFIER PS-310
POW ER
MM/MC
MM Input Capacitance
MC Input
MC GND
MM GND
Output
MM Input
MC Input Resistance
AC-MAINS
MC INPUT MM INPUT
LEFT
RIGHT
OUTPUT
LEFT
RIGHT
S/N
RISK OF ELECTRICAL SHOCK DO NOT OPEN
RISQ UE DE CHO C ELECTRIQUE NE PAS OUV RIR
NO USER-SERVICEABLE PARTS
OPERATION
FRONT PANEL
REAR PANEL

Page4
MC input
Sensitivity : 0.35mV for 350mV output at 1KHz
Input impedance : 47\100\1K\47K Ω
S/N ratio : >75dB unwweighted
MM input
Sensitivity : 0.35mV for 350mV output at 1KHz
Input impedance : 100\200\300\400(pf)
S/N ratio : >91dB unwweighted
General
RIAA accuracy : ±0.5dB 20Hz to 20KHz
Power : AC 220V~ 50/60Hz
Output AC : 8Vrms
Dimensions : 430*354*100 mm
Weight : 14 kg
LIMITED WARRANTY
HANSS ACOUTSICS warrants the product designated herein to be free from manufacturing
defects provided proper operation for a period of two years from the original dat of purchase.
Each HANSS ACOUSTICS distributor is responsible to honour the warranty during this time.
Any unauthorized servicing or modification of the equipment shall immediately voids the 2
years service warranty. For questions regarding the service or operation please contact your
dealer where the unit was originally purchased or please do not hesitate to contact us at
for further [e-mail]
TECHNICAL SPECIFICATION
HANSS ACOUSTICS
E-mail:
Website: http://www.hanss-acoustics.com
[e-mail]
