Harman HD730 User manual

ENGLISH
HD730 Engelsk 12/01/98, 15:301
All manuals and user guides at all-guides.com

ENGLISH
AB
PROGRAM INTRO A SPACE AUTO EDIT
TRACK INDEX IOM
DELETE RANDOM REPEAT ALL
11 12 1
16 17 1
6 7
8
21
Power Sensor Stop/Clear
HD 730 harman/kardon
COMPACT
DIGITAL AUDIO
harman/kardon
1111-HD730 Printed in Korea
230 Volt
9007018041
Service and Parts Office:
80 Crossways Park West, Woodbury, New York 11797 [phone]
8500 Balboa Blvd., Northridge CA 91329
A Harman International Company
HD730 Engelsk 12/01/98, 15:312
All manuals and user guides at all-guides.com

ENGLISH
AB
PROGRAM INTRO A SPACE AUTO EDIT
TRACK INDEX IOM
DELETE RANDOM REPEAT ALL
11 12 13 14 15
16 17 18 19
6 7 8 9 10
2 3 4 51
Power Sensor Stop/Clear
Tape Size Time Program Random Repeat 1/All
Edit Peak
Search Check Delete A-B
Level Headphones
Open/Close
HD 730 harman/kardon
COMPACT
DIGITAL AUDIO
HD730
harman/kardon
Compact Disc Player OWNER’S MANUAL
CD-Spieler BEDIENUNGSANLEITUNG
Lecteur de compact-disques MODE D’EMPLOI
Reproductor de CD MANUAL DEL USUARIO
CD-speler GEBRUIKSAANWIJZING
Lettore di Compact Disc ISTRUZIONI PER L’USO
Compact Disc Player Bruksanvisning
Compact Disc Player KÄYTTÖOPAS
CD Player GREEK
HD730 Engelsk 12/01/98, 15:313
All manuals and user guides at all-guides.com

ENGLISH
1
Thank you for choosing a
Harman Kardon compact disc
player. This is a superb piece of
high fidelity equipment that has
been meticulously designed to
provide you with thousands of
hours of enjoyment.
To appreciate the full perfor-
mance of this sophisticated unit,
please be sure to read this
owner’s manual and use your
CD player only in accordance
with its instructions. Keep the
manual in a safe place for future
reference.
Harman Kardon HD730
Date of purchase ___________________________________
Purchased from ____________________________________
Address of business purchased from____________________
_____________________________________________________
Installed by________________________________________
Date of installation__________________________________
Serial No._________________________________________
CLASS 1 LASER PRODUCT
Product complies with DHHS rules
CFR subchapter J part 1040:10 at
date of manufacture.
DANGER: Invisible laser radiation
when opened and interlock failed or
defeated. Avoid direct exposure to
the beam.
CAUTION: USE OF ALL CON-
TROLS, ADJUSTMENTS OR
PERFORMANCE OF PROCE-
DURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION
EXPOSURE.
TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
This digital apparatus does not exceed the
Class B limits for radio noise emissions from
digital apparatus as set out in the Radio
Interference Regulations of the Canadian
Department of Communications.
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated "dangerous voltage" within
the product's enclosure that may be of
sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
HD730 Engelsk 12/01/98, 15:314
All manuals and user guides at all-guides.com

ENGLISH
2
TABLE OF CONTENTS
Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Rear Panel Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
HD730 Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
PLACEMENT
The HD730 is fully shielded and may be
placed on top of or under other stereo
components as long as the “feet” provide
sufficient clearance for cooling of the compo-
nent below. Please make sure that the HD730
receives adequate ventilation. It should
always be located away from heat sources
such as radiators, fireplaces, stoves, and other
appliances that produce heat. Avoid placing
the unit in locations that receive prolonged
direct sunlight or extremely low temperatures.
While your compact disc player is designed to
be vibration-resistant, excessive shocks or
placement too close to large speakers can
cause “stuttering” or skipping. When choosing
a place for your new CD player, take the same
precautions you would with a turntable.
GENERAL CONNECTION HINTS
As you connect your compact disc player,
carefully connect the plugs to the output jacks,
being sure to push the plugs in all the way.
Loose connection of a plug can cause hum or
other intermittent noise. Take care to match
the left and right plugs on the CD player with
the left and right input jacks on the back of the
receiver/preamplifier/integrated amplifier.
Common practice is to use the red plug as
right, and the white, gray, or black plug as left.
Do not wind the cables with the power cord;
doing so may degrade the sound quality.
When you have finished connecting your
HD730 to your receiver/preamplifier/integrated
amplifier, plug the power cord of the CD player
either into a power outlet on the back of
another component, or into the power outlet in
the wall.
CARE OF THE LASER PICKUP
The laser pickup that detects the music
recorded on a CD is located under the
compact disc drawer. The laser pickup,
especially its precision lens, is particularly
sensitive to dust. Keep the disc drawer closed
when the unit is not in use, and do not put your
hand inside the unit.
INTERFERENCE
This compact disc player uses high-frequency
signals that can sometimes interfere with
reception in tuners and televisions. If you start
to experience reception problems after
connecting and turning on your CD player,
move the CD player farther away from your
tuner or television set or turn the CD player off
when it is not in use.
POWER CORD PROTECTION
The power cord should be routed in such a
way that it is not likely to be walked on or
pinched by items laying on or against it. Any
power cord is susceptible to stress at the point
where it joins the plug and the point where it
exits from the back of the unit, so take care not
to fold or bend it excessively at those points.
Never pull or stretch the cord. The CD
player’s power cord should be unplugged from
the outlet when the unit is left unused for a
long period of time.
CARE OF THE LASER PICKUP
The laser pickup that detects the music
recorded on a CD is located under the
compact disc drawer. The laser pickup,
especially its precision lens, is particularly
sensitive to dust. Keep the disc drawer closed
when the unit is not in use, and do not put your
hand inside the unit.
CLEANING
Use only a clean dry cloth to clean your
compact disc player. Do not use solvents
such as alcohol, benzine, gasoline, etc. Take
care that excessive dust does not accumulate
on your unit, and that objects are not dropped
inside or liquids spilled into the unit.
WATER AND MOISTURE
Do not operate this compact disc player
around water (e.g., near a swimming pool,
sink, or in a wet basement).
ABNORMAL SMELLS
If you detect an abnormal smell or smoke,
immediately turn the compact disc player off
and pull out the power cord. Contact your
dealer or nearest Harman Kardon service
center.
SERVICE
Please contact your local distributor for
service.
PACKING MATERIAL
Your box and packing material are custom
designed to provide optimum protection for
your compact disc player. Be sure to save the
box and packing material in case you need to
transport or ship the unit at some future time
(e.g., service or moving).
HD730 Engelsk 12/01/98, 15:315
All manuals and user guides at all-guides.com

ENGLISH
AB
PROGRAM INTRO A SPACE AUTO EDIT
TRACK INDEX IOM
DELETE RANDOM REPEAT ALL
11 12 13 14 15
16 17 18 19
678910
23451
Power Standby Stop/Clear
Tape Size Time Program Random Repeat 1/All
Edit Peak
Search Check Delete A-B
Level Headphones
Open/Close
HD 730 harman/kardon
COMPACT
DIGITAL AUDIO
Front Panel Controls
3
22 16 10
15
13 24 23
18
2120197
8
12
9
17
3 14 11
5
2
1 4 6
HD730
Sensor
HD730 Engelsk 12/01/98, 15:316
All manuals and user guides at all-guides.com

ENGLISH
19. BACKWARD SEARCH
BUTTON ( )
This button is used for searching for a
particular passage in fast reverse.
20. FORWARD SEARCH
BUTTON ( )
This button is used for searching for a
particular passage in fast forward.
21. BACKWARD SKIP
BUTTON ( )
This button is used for replaying from the
beginning of the current track or returning
to a previous track.
22. FORWARD SKIP
BUTTON ( )
This button is used for moving onto the
next track.
23. HEADPHONE JACK
This JACK is used for listening with the
headphone.
24. HEADPHONE VOLUME
This is used for the adjustment of the
headphone and variable audio output
level.
4
Front Panel Controls
5. MULTI-FUNCTION
DISPLAY
This display shows the corresponding
information according to each mode.
6. PLAY BUTTON ( )
This button is used for starting play.
7. PAUSE BUTTON ( )
This button is used for holding play at the
start of a track or interrupting play.
8. STOP/CLEAR
BUTTON ( )
This button is used for stopping play,
clearing programmed tracks or recovering
the deleted tracks.
9. PROGRAM BUTTON
This button is used for storing the tracks
in the Program mode or in the Edit mode.
10. PROGRAM/CHECK
BUTTON
This button is used for checking the
stored tracks.
11. RANDOM PLAY BUTTON
This button is used for playing a disc
randomly.
12. REPEAT 1/ALL BUTTON
This button is used for repeating one
track or all tracks.
13. REPEAT A B BUTTON
This button is used for repeating a
particular passage.
14. TIME BUTTON
This button is used for checking the
elapsed playing time from the beginning
of current track or remaining playing time
of current track or remaining playing time
of disc.
15. PEAK SEARCH BUTTON
This button is used for searching for a
peak level passage on a CD to adjust
record level.
16. EDIT BUTTON
This button is used for editing the tracks
to be recorded onto the cassette tape.
17. TAPE SIZE BUTTON
This button is used for selecting the tape
length.
18. DELETE BUTTON
This button is used for deleting the
undesired tracks.
1. POWER SWITCH
The POWER switch turns the unit on and
off.
2. COMPACT DISC
DRAWER
Load a disc (full-size or 3-inch/8 cm) into
your compact disc player by placing it in
this drawer with the label side up. Open
and close the drawer using the OPEN/
CLOSE button (3).
3. OPEN/CLOSE
BUTTON ( )
Press this button to open or close the
compact disc drawer. The drawer will
also close if you press the play button or
push the drawer gently toward the
chassis of the player; however, we
recommend that you do not push the
drawer.
4. REMOTE SENSOR
This area receives the signal from the
remote control unit. Make sure this area
of the front panel is kept free from dirt or
other obstructions that might prevent
proper reception of the infrared signal
from the remote control.
HD730 Engelsk 12/01/98, 15:317
All manuals and user guides at all-guides.com

ENGLISH
DIGITAL
OUTPUT
REMOTE
MODEL NO.: HD730
HARMON/KARDON
NORTHRIDGE
CALIFORNIA U.S.A.
SER. NO.
INPUT
TO INPUT JACKS OF POWER AMP
TO REMOTE OUT OF HARMAN/KARDON
REMOTE CONTROL AMPLIFIER,
RECEIVER OR TAPE DECK
AC INPUT
230V- 50 Hz
CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOTE
REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
IN
OUT
LEFT
RIGHT
5
Rear Panel Connections
Before you begin to connect this unit
to your system, be sure that all
components are turned off and
unplugged from the electrical outlet.
See the connection diagram in the
operating instruction manual of a
Harman/Kardon compatible amplifier
or receiver.
Note: NEVER connect your CD player
to the PHONO inputs.
2. OPTIONAL DIGITAL
CONNECTION
The HD730 also has a digital output jack
— a single electrical RCA-type connector.
If your preamplifier has a digital-to-analog
decoder and can accept a digital signal
from a compact disc player, you can
connect your CD player to your preampli-
fier using this digital jack.
1. CONNECTION CORDS
On the back of your HD730 are output
jacks that connect your CD player to your
receiver, integrated amplifier, or preampli-
fier. Using the supplied shielded cords,
connect the left and right output jacks on
the back of the CD player to the left and
right input jacks marked CD or AUX on the
back of your receiver/preamplifier/
integrated amplifier. Alternatively, you can
also use the TAPE INPUT or TAPE PLAY
jacks on your receiver/preamplifier/
integrated amplifier.
Please note that using the digital output
will bypass the internal D/A conversion
circuitry and therefore miss one of the
major benefits of this machine. The best
use of this output is for direct connection
to a digital recorder, a very high perfor-
mance external D/A Converter, or a true
Digital Signal Processing (DSP) Preampli-
fier.
3. AC INPUT CORD
Plug this cord into the AC outlet of
amplifier or receiver or a household AC
outlet.
•
•
2
1 3
MODEL NO.: HD730
HARMAN/KARDON
NORTHRIDGE
CALIFORNIA U.S.A.
HD730 Engelsk 12/01/98, 15:318
All manuals and user guides at all-guides.com

ENGLISH
Press the PLAY button. Then the
play starts and the first track number
and elapsed playing time from
beginning of the first track and ,
etc., appear on the display.
After the last track has been played
the unit switches to the stop mode.
Press the FORWARD SKIP button
( ) to advance to the beginning of
the next track.
During normal or deleted play, etc., if
the FORWARD SKIP button is pressed
when playing the last track, the last
track is skipped to the first track.
During random or programmed play,
etc., if the FORWARD SKIP button is
pressed when playing the last track,
the “End” sign appears on the display
and the last track continues to be
played.
Operations
6
LOADING AND UNLOADING
Do not leave the disc tray open to
prevent dirt and dust from entering
the mechanism, when not in use.
NORMAL PLAY
Press the POWER switch.
Open the disc tray, load a disc and
close it.
The display shows the total number of
the tracks and the total playing time of
the disc. And music calendar displays
each number of tracks. When the
total number of tracks is more than
19, ⇒will appear next to 19 as
indicated below.
TRACK MIN
11 12 13 14 15
16 17 18 19
678910
23451
SWC
TRACK INDEX MIN
11 12 13 14 15
16 17 18 19
67 8910
23 45
SEC
PLAY MODE
BEGINNING AT A SPECIFIC TRACK IN
STOP MODE
1. Repeatedly press the FORWARD or
BACKWARD SKIP button ( / )
until the desired track number appears on
the display.
TRACK
11 12 13 14 15
16 17 18 19
678910
23451
TRACK INDEX MIN
11 12 13 14 15
16 17 18 19
78910
SEC
PLAYING A DISC
•
•
•
•
•
•
INTERRUPTING PLAY (PAUSE MODE)
Press the PAUSE button to tempo-
rarily interrupt play. The disc contin-
ues to spin but the sound stops, and
appears on the display. To replay,
press the PLAY or PAUSE button
again.
Press the STOP/CLEAR button to
stop play before the end of the disc is
reached.
STOPPING PLAY (STOP MODE)
TRACK INDEX MIN
11 12 13 14 15
16 17 18 19
678910
5
SEC
PAUSE MODE
•
•
•
•
•
SELECTING A PREVIOUS TRACK IN
PLAY MODE
If a track is playing, press the BACK-
WARD SKIP BUTTON ( ) to
return to the beginning of the track.
Press the BACKWARD SKIP button
before a track begins playing to move
to the beginning of the previous track.
During normal or deleted play, etc., if
the BACKWARD SKIP button is
pressed at the beginning of the first
track, the first track is skipped to the
last track.
During random or programmed play,
etc., the BACKWARD SKIP button can
be pressed only to return to the
beginning of the first track.
2. Press the PLAY button
•
•
•
•
•Do not insert any objects into the tray
as it can damage the mechanism.
MUSIC SEARCH
OPERATION
SKIP PLAY
SELECTING A NEXT TRACK IN PLAY
MODE
STOP MODE
Press the OPEN/CLOSE button. The
disc tray slides out automatically.
Take care that the tray is not ob-
structed. If it is obstructed in opening,
it will be closed after about five
seconds. If it is obstructed in closing,
it will be opened automatically after
about five seconds.
Load a disc with the labelled side up
after the disc tray is opened com-
pletely.
•
•
•
LABELLED
SURFACE
Do not tilt the unit while the disc tray is
opening or closing because the disc
could fall off.
If you want to take a disc out of the
tray, press the OPEN/CLOSE button.
Hold a disc out of the tray in the same
way as loading to avoid leaving
fingerprints on the disc surface.
After putting a disc into its storage
case, close the disc tray by pressing
the OPEN/CLOSE button or pushing
the tray.
•
•
•
•
CAUTION IN LOADING AND
UNLOADING
HD730 Engelsk 12/01/98, 15:319
All manuals and user guides at all-guides.com

ENGLISH
1. In the stop mode, press the PRO-
GRAM button.
2. Select the desired track with the SKIP
or NUMERIC buttons.
3. Press the PROGRAM button. (Only
when you use one of the SKIP butttons.)
Example: When you wish to program
the tracks 4, 17 and 8, the program-
ming procedure is as follows.
7
Press and hold down the FORWARD
or BACKWARD SEARCH button
( / ) and release the button
when the desired point has been
reached.
If the CD player reaches the end of
the last track during forward search,
the unit switches to the stop mode.
If the CD player reaches the begin-
ning of a CD during backward search
in normal or deleted play mode, etc.,
play restarts at this point.
If the CD player reaches the begin-
ning of a track during backward
search in random or programmed play
mode, etc., play restarts at this point.
You can program up to 20 tracks to play
in any sequence you choose.
If you exceed 20 tracks, the “Full” sign
appears to remind you that the memory is
full and cannot accept any more tracks.
PROGRAMMED PLAY
PROGRAM TRACK MIN SEC
After the last programmed track has
been played, the last programmed
track number and the total playing
time of the programmed tracks are
shown on the display.
During program play, if you want
normal play, select the desired track
with the NUMERIC buttons, then
normal play will start that track.
If you want program play again, press
the PROGRAM button in the stop
mode, then the unit switches to the
program mode.
PROGRAM TRACK INDEX MIN
17
8
4
SEC
PROGRAM INTRO
TRACK
17
8
4
PROGRAM TRACK MIN
17
8
4
SEC
AFTER ABOUT
1 SECOND
4. Repeat steps 2 and 3 to complete
programming.
•
•
•
5. Press the PLAY button.
PROGRAMMING
PROGRAM
TRACK
4
PROGRAM
TRACK MIN
4
AFTER ABOUT
1 SECOND
SEC
SEARCH PLAY
SEARCHING A SPECIFIC PASSAGE IN
PLAY MODE
•
•
•
•
PROGRAM TRACK
4
REPEAT PLAY
REPEAT ALL TRACKS
Press the REPEAT button before or
during play.
REPEAT ALL appears on the display
and all tracks of the CD will be
repeated.
If the CD player reaches the end of
the last track during forward search,
the unit goes back to the beginning of
the first track and continues to search
forward.
•
•
•
After selecting a desired track with the
FORWARD or BACKWARD SKIP
button, press the REPEAT button
twice before or during play.
REPEAT 1 appears on the display and
the selected track will be repeated.
If the REPEAT button is pressed once
again in this mode, repeat play mode
is canceled.
During play, press the REPEAT
A B button at the beginning of the
passage you want, then REPEAT
appears on the display and A ↔
blinks.
Press this button at the end of the
passage again, then A ↔B ap-
pears on the display and the specific
passage is being played repeatedly.
If you want to cancel repeat A B
play, press the REPEAT A B or
STOP/CLEAR button.
REPEAT ONE TRACK
REPEAT A B
•
•
•
•
•
•
HD730 Engelsk 12/01/98, 15:3110
All manuals and user guides at all-guides.com

ENGLISH
Example: When the desired tape
length is 46 minutes.
Each time the TAPE SIZE button is
pressed, the tape length display
changes as follows.
You can edit up to 20 tracks to be
recorded according to the tape length.
AUTO EDIT
1. In the stop mode, press the EDIT
button.
Each time the CHECK button is
pressed, the programmed track
will appear in the programmed
sequence.
Each time the STOP/CLEAR button is
pressed during programming or after
completion of programming, the
programmed tracks are cleared one
by one in the opposite sequence.
If you wish to clear a specific track,
find that track with the PROGRAM/
CHECK button and clear with the
STOP/CLEAR button.
By pressing the OPEN/CLOSE or
STOP/CLEAR button over 4 seconds
in the stop mode, all programmed
tracks will be cleared.
b. Select the desired tape length at
your option with the NUMERIC
buttons.
Example: When the desired tape
length of each side is 23 minutes,
press, 2, 3, 0 and 0 to enter
“23:00”.
8
EDIT FOR RECORDING
A SPACE AUTO EDIT
11 12 13 14 15
16 17 18 19
67 8910
2 3451
A SPACE AUTO EDIT
MIN
11 12 13 14 15
16 17 18 19
67 8910
2 3451
SEC
AUTO EDIT IS COMPLETED
AFTER 2
SECONDS
A SPACE AUTO EDIT
11 12 13 14 15
16 17 18 19
67 8910
2 3451
A SPACE AUTO EDIT
MIN
11 12 13 14 15
16 17 18 19
67 8910
2 3451
SEC
3. Press the EDIT button to automatically
edit the tracks to be recorded.
AB
A SPACE AUTO EDIT
TRACK IOM
69
2 3451
AFTER ABOUT 2 SECONDS
AFTER ABOUT 2 SECONDS
AB
A SPACE AUTO EDIT
TRACK MIN
11 12 13 14
18
78 10
A
B
A SPACE AUTO EDIT
TRACK MIN
11 12 13 14
18
678910
23451
SEC
SEC
THE TRACKS AND
REMAINING TIME OF
THE SIDE A APPEAR
THE TRACKS AND
REMAINING TIME OF
THE SIDE B APPEAR
AUTO EDIT IS COMPLETED
2. a. Select the desired tape length with
the TAPE SIZE button.
•
CHECKING THE CONTENTS OF THE
PROGRAM
You can check the contents of the
program during programming or after
completion of programming.
CLEARING THE PROGRAMMED
TRACKS
•
•
•
•
RECTIFYING ANY WRONG PRO-
GRAMMED TRACK
PROGRAM TRACK MIN
17
8
4
SEC
PROGRAM TRACK
17
810
4
PROGRAM TRACK MIN
810
4
SEC
When you made a mistake and
programmed any wrong track, you
can rectify as follows.
Example: When you made a mistake
and stored track 17 instead of track
10.
•
1. Find track 17 with the PROGRAM
button.
2. Select track 10 with the SKIP or
NUMERIC buttons.
3. Press the PROGRAM button. (Only
when you use one of the SKIP buttons.)
C-46 C-54 C-60 C-74 C-90 C-120
HD730 Engelsk 12/01/98, 15:3111
All manuals and user guides at all-guides.com

ENGLISH
6. Select and program the tracks to be
edited like programming for the Side B. 2. In the edit mode, repeat and
random play, etc., are not operative.
3. When checking, clearing or
rectifying the tracks, do like program-
ming.
4. During manual edit, if the “–” sign
on the time display disappears and
the repeats on and off, it means
that the total time of the edited tracks
is greater than the selected tape
length. So edit the tracks again lest
the total time of the edited tracks
should exceed the tape length.
9
MANUAL EDIT
1. In the stop mode, press the EDIT
button twice.
2. Select the desired tape length like the
auto edit.
3. Press the PROGRAM button to
manually edit the tracks to be recorded.
4. Select and program the tracks to be
edited like programming for the side A.
5. After editing the tracks of the side A,
press the EDIT button.
A SPACE EDIT
11 12 13 14 15
16 17 18 19
678910
234 51
DELETED PLAY
When there are undesired tracks on a
CD, you can delete up to 20 tracks like
programming.
Example: When you wish to delete
the tracks 4, 8 and 17, the deleting
procedure is as follows.
TRACK
DELETE
11 12 13 14 15
16 17 18 19
678910
234 51
DELETING
1. In the stop mode, press the DELETE
button.
DELETE
11 12 13 14 15
16 17 18 19
678910
234 51
2. Select the undesired track with the
SKIP or NUMERIC buttons.
3. Press the DELETE button. (Only
when you use one of the skip buttons.)
AFTER A FEW
SECONDS
TRACK
DELETE
11 12 13 14 15
16 17 18 19
678910
23 51
TRACK MIN
DELETE
11 12 13 14 15
16 17 18 19
678910
23 51
SEC
Example: When the tracks 7, 8, 10,
11, 12, 13, 14 and 18 are edited for
the side B.
AFTER A FEW
SECONDS
AB
A SPACE EDIT
TRACK
11 12 13 14
18
78 10
A
B
A SPACE EDIT
TRACK
11 12 13 14
18
678910
234 51
MIN SEC
If the PLAY button is pressed after
editing the tracks, play starts from the
first track of the side A for recording.
If all tracks of the side A have been
played, the unit switches to the pause
mode.
If the PLAY button is pressed, play
starts from the first track of the side B
for recording.
NOTE:
1. In the edit mode, the auto space
function, leaving the spaces of 4
seconds between the tracks, is
automatically activated.
•
•
•
A
PROGRAM A SPACE EDIT
TRACK MIN SEC
Example: When the tracks 1, 2, 3, 4,
5, 6 and 9 are edited for the side A.
A
PROGRAM A SPACE EDIT
TRACK MIN 69
234 51
SEC
AB
PROGRAM A SPACE EDIT
TRACK MIN SEC
⇒
•
If the PEAK SEARCH button is
pressed in the stop mode, repeats
on and off and the unit automatically
searches all tracks for peak level.
After searching, a peak level passage
is played repeatedly for 5 seconds.
If you want to cancel the peak search
play, press the STOP/CLEAR button.
Though you repeat peak search play
on the same CD, the peak level
passage can be changed.
•
•
•
PEAK SEARCH PLAY
When adjusting record level for recording,
Peak Search Play is very convenient.
HD730 Engelsk 12/01/98, 15:3112
All manuals and user guides at all-guides.com

ENGLISH
RANDOM PLAY
In this mode, CD player plays the tracks
on the CD in random sequence.
10
Press the RANDOM PLAY button.
The unit automatically selects and
plays tracks at random.
If the RANDOM PLAY button is
pressed during random play, random
play is canceled and normal play
starts at the present track.
TRACK MIN
78 9
78 9
SEC
MIN SEC
TRACK INDEX
789
THE TRACK NUMBER AND REMAINING PLAYING TIME OF
THE CURRENT TRACK APPEAR
AFTER A FEW
SECONDS
RANDOM
12 13 14 15
16 17 18 19
68910
2451
TRACK INDEX MIN
RANDOM
12 13 14 15
16 17 18 19
68910
2451
SEC
Each time the TIME button is
pressed, the time display changes as
follows.
THE REMAINING PLAYING TIME OF THE DISC APPEARS
THE TRACK NUMBER AND ELAPSED PLAYING TIME FROM
BEGINNING OF THE CURRENT TRACK APPEAR
•
•
•
You can check the deleted tracks during
deleting or after completion of deleting.
CHECKING THE DELETED TRACKS
Each time the DELETE button is
pressed, the deleted tracks will appear
in the deleted sequence.
•
RECOVERING THE DELETED TRACKS
•
By pressing the OPEN/CLOSE or
STOP/CLEAR button over 4 seconds
in the stop mode, all deleted tracks
will be recovered.
•
•
Each time the STOP/CLEAR button is
pressed during deleting or within 4
seconds after completion of deleting,
the deleted tracks are recovered one
by one in the opposite sequence.
If you wish to recover a specific track,
find that track with the DELETE
button and recover with the STOP/
CLEAR button.
TRACK MIN
DELETE
11 12 13 14 15
16 18 19
67 910
23 51
SEC
TRACK INDEX
DELETE
11 12 13 14 15
16 18 19
67 910
23 51
MIN SEC
4. Repeat steps 2 and 3 to complete
deleting.
5. Press the PLAY button.
TIME DISPLAY SELECTION
This unit has three different time display
modes.
Example: When a disc of 53 minutes
47 seconds is playing at the point of
3 minutes 15 seconds after the
beginning of track 7.
TRACK 1 TRACK 2 TRACK 7 TRACK 8 TRACK 9
6 MIN. 4 MIN. 23 MIN. 47 SEC. 5 MIN. 7 MIN. 8 MIN.
9 TRACKS, 53 MIN. 47 SEC.
• • • • • •
3 MIN. 15 SEC., POINT OF TRACK 7
NOTE:
1. When a track of which number is
greater than 30 is programmed, edited,
deleted or being played, the time display
may show “– –:– –”.
2. During random play or when the total
playing time is more than 99 minutes, the
time display may show “– –:– –”.
HD730 Engelsk 12/01/98, 15:3113
All manuals and user guides at all-guides.com

ENGLISH
HD730 REMOTE CONTROL
OPERATION
The remote control operates wtihin a 30°
angle of the remote sensor on the front
panel of the unit. Make sure that the
remote's front projection “lens” as well as
the REMOTE SENSOR area on the front
panel of the unit are kept free from dirt to
ensure proper transmission and reception
of the infrared beam. Also make sure
that no objects (e.g., stereo cabinet
doors, end tables) block the path from the
remote control to the REMOTE SENSOR
area.
Avoid using the remote control near
fluorescent lamps, as they may shorten
its operating range.
If your remote control will sit unused for a
long period of time, remove the batteries
to prevent damage from corrosion.
REAR PANEL REMOTE
JACKS
The remote control input jack allows
remote control of this unit via a cable.
This cable can be connected to the
remote control output jack of another
Harman Kardon product. Alternatively, it
can be connected to an accessory device
that converts infrared remote control
signals into detected pulses. While all
Harman Kardon products with remote
control jacks are compatible with one
another, not all accessory devices or
other manufacturer’s products are.
However, it is safe to experiment.
Remote Control
11
The remote control for the HD730
provides the same functions found on the
front panel of the compact disc player
itself. In addition, the remote control
provides some functions that are not
found on the front panel.
The functions found on the remote
control that are not found on the front
panel are INTRO, INDEX, DISPLAY, and
the 1-10 keys. These four functions are
described below (for other functions, see
the descriptions on page 4.)
1. INTRO BUTTON
This button puts your compact disc player
in and out of INTRO SCAN mode. When
INTRO SCAN is on and you press PLAY,
the unit plays only the first 15 seconds of
each track before moving on to the next.
Press the button once to turn on INTRO
SCAN mode; press again to turn it off
and stop the scanning. When the unit is
in INTRO SCAN mode, the FUNCTION
indicator (5) will display the word INTRO.
2. NUMERIC BUTTONS (0 - 9)
If you press the number that corre-
sponds to your desired track with the
NUMERIC buttons, the unit plays that
track immediately without the PLAY
button.
To select two digit track number, the
second digit must be pressed within
about 2 seconds after the first digit
has been pressed.
During programming or deleting, etc.,
if you select the desired or undesired
track with the NUMERIC buttons, that
track is programmed or deleted
without the PROGRAM or DELETE
button.
•
•
•
Each time the DISPLAY button is
pressed, the brightness of the display
changes as follows.
In the display OFF mode, if any button
is pressed, the unit switches to the
display ON mode.
3. DISPLAY BUTTON
ON DIM OFF
•
•
Display Time
1/All A B Random Delete
Intro Prog/Rev Tape Size Edit
9 10
5 6 7 8
1 2 3 4
harmon/kardon
Compact Disc Player
Repeat
3
1
2
harman/kardon
HD730 Engelsk 12/01/98, 15:3114
All manuals and user guides at all-guides.com

ENGLISH
Two batteries are provided with your
remote control. To load batteries:
1. Locate the cover over the battery
compartment on the back of the
remote control. Remove the cover by
sliding it in the direction of the
embossed arrow.
2. Insert the two AA (1.5V/R6/UM3)
batteries. Make sure you insert the
batteries according to the + and –
polarity symbols at the bottom of the
battery compartment.
3. Replace the cover of the battery
compartment.
12
NOTE:
1. When you replace weak batteries,
replace both at the same time.
2. Remove the batteries if it is not to
be used for an extended period of time.
3. Do not use rechargeable batteries
(Ni-Cd type).
CONCERNING USE OF
BATTERIES
23 FEET
7 M
30°30°
REMOTE CONTROL UNIT
HD730 Engelsk 12/01/98, 15:3115
All manuals and user guides at all-guides.com

ENGLISH
13
Troubleshooting Guide
If your HD730 does not operate as
expected, first check the items in the
following list. If you cannot deter-
mine the source of the problem,
contact your dealer or authorized
Harman Kardon service representa-
tive.
NO LIGHTS ON THE FRONT
PANEL
Power cord is not plugged into
power outlet.
Wall outlet or extension cord is
faulty. Check for poor connec-
tions.
Breaker on plug strip has tripped.
Reset breaker.
FRONT PANEL LIGHTS ARE ON,
BUT THE CD DOES NOT PLAY
The disc may have been inserted
upside down. Make sure the label
side is facing up.
Moisture may have formed on the
laser/receptor inside the unit.
This sometimes occurs in damp
climates or when the unit is
moved from a cold to a warm
area. Leave the unit turned on at
room temperature for 30 minutes
to allow the moisture to evapo-
rate, then play your disc.
THE PLAY INDICATOR LIGHTS,
BUT NO SOUND IS HEARD
The wrong SOURCE has been
selected on your integrated
amplifier/receiver/preamplifier.
Make sure you have selected the
SOURCE where your CD player is
connected.
THE SOUND SKIPS OR STUTTERS
DURING PLAYBACK
The disc may be dirty or damaged.
The unit may have been placed on
an unstable surface. Isolate the
unit from excessive vibration by
placing it on a firmer surface or
farther away from your speakers.
THE SOUND IS CONTINUOUSLY
DISTORTED
The cables from the HD730 have
been plugged into the wrong input
jacks on your integrated amplifier/
receiver/preamplifier. Make sure
you have not plugged the unit into
the PHONO jacks.
•
•
••
•
•
•
•
•
NOTHING HAPPENS WHEN
FUNCTION KEYS ARE PRESSED
THE DISPLAY SHOWS BROKEN
CHARACTERS
THE REMOTE CONTROL DOES
NOT FUNCTION CORRECTLY
Turn the power to the unit off, then
back on again.
Turn the power to the unit off, then
back on again.
Make sure you are using the
remote control within the 30°
angle described in this manual.
Make sure the remote transmitter
lens and the front panel REMOTE
SENSOR window are clean and
that no objects are blocking the
path from the remote control to
the REMOTE SENSOR area on
the front panel.
Make sure that no strong fluores-
cent lights are being used in the
listening room.
Check that the batteries inside the
remote control are fresh.
•
•
•
•
•
•
HD730 Engelsk 12/01/98, 15:3216
All manuals and user guides at all-guides.com

ENGLISH
SIGNAL FORMAT
Sampling Frequency
D/A Conversion
Oversampling
Error Correction
Frequency Response
Total Harmonic Distortion (THD)
Dynamic Range
Signal to Noise Ratio
Channel Separation
Line Output Level
Power Consumption
Dimensions (W x H x D)
Weight
14
Discrete Dual Differential Analog
Output Section
44.1 kHz
1 bit (Bit Stream Conversion)
8 times
Note: Specifications and features are subject to change without notice.
•
•
Specifications
CIRC System
10 Hz to 20 kHz ±0.5 dB
0.008%
96 dB
100 dB
95 dB
2.2 V @ RMS
12 Watts
440 mm x 95 mm x 300 mm
10.6 lbs (4.8 kg)
Kongevejen 194B
DK-3460 Birkerød
Danemark
We, Harman Marketing Europe a/s
Steen Michaelsen
harman marketing europe a/s
DECLARATION OF CONFORMITY
declare that the product described in
this owner's manual is in compliance
with technical standards:
Accredited test laboratory:
MIKES PRODUCT SERVICE GmbH
Ohmstrasse 2-4
D-94342 Strasskirchen
Germany
The appliance conforms with EEC directive
87/308/EEC regarding interference suppression
EN 55013/6.1990. EN 55022/4.1987
EN 60555/4. 1987
HD730 Engelsk 12/01/98, 15:3217
All manuals and user guides at all-guides.com
