Harmonic 7014E User manual

HOA 7000 Series
Optical Amplifier
Product Manual
Part No: 700-0005044
Revision F March 2001

Copyright © 2001 Harmonic Inc. ii
Safety
When you work with this equipment, take the following precautions:
•Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
•Never look at an optical fiber using a direct magnification fiber scope without verifying that
all lightwave sources on the fiber are turned off.
•Never look directly into an optical connector.
•Install protective covers or caps over connectors when they are not being used.
•Always assume that exposed optical connectors and cables are energized.
•Always make an optical power measurement of the fiber or connector before cleaning or
before visual inspection, to ensure that the fiber is not energized.
Lorsque vous travaillez avec ce matériel, prenez les précautions suivantes:
•L’utilisation de commandes ou de réglages ou l’utilisation de procédures autres que celles
décrites dans ce manuel d’utilisation peut générer une exposition á des radiations dan-
geureuses.
•Ne jamais regarder une fibre optique directement avec un outil d’inspection de fibres sans
verifier que toutes les sources lumineuses dans la fibres sont éteintes.
•Ne jamais regarder directement á un connecteur de fibre optique.
•Installer les bouchons protecteurs sur les connecteurs qui ne sont pas utilisés.
•Toujours supposer qu’un connecteur éxposé ou une fibre optique émettent de l’énergie
lumineuse.
•Toujours mesurer la puissance optique d’une fibre optique ou d’un connecteur avant de le net-
toyer une inspection visuelle pour s’assurer que la fibre n’émet pas d’énergie lumineuse.
Beim Arbeiten mit diesem Gerät, beachten Sie die folgenden Vorsichtsmaßnahmen:
HOA 7020 H Only

Copyright © 2001 Harmonic Inc. iii
Safety
•Die Verwendung von Reglern oder Einstellungen sowie die Durchführung von Verfahren die
hier nicht beschrieben sind kann dazu führen das Sie gefährlicher Strahlung ausgesetzt
werden.
•Blicken Sie nie mit einem Lichtwellenleiter Microscope in einen Lichtwellenleiter, ohne zu
prüfen, dass alle Laserquellen auf dem Lichtwellenleiter deaktiviert sind.
•Blicken Sie nie direkt in einen optischen Anschluss.
•Installieren Sie Schutzabdeckungen oder Kappen über Lichtwellenleiteranschlüssen, wenn
sie nicht verwendet werden.
•Gehen Sie immer davon aus, dass optische Anschlüsse und Kabel aktiv sind.
•Fuehren Sie immer eine optische Messung am Lichtwellenleiter oder Stecker durch bevor Sie
einen optischen Anschluss reinigen oder inspizieren, um sicherzustellen, dass er nicht aktiv
ist.

Copyright © 2001 Harmonic Inc. iv
Safety
Complies with 21 CFR 1040.10 and 1040 except for deviations pursuant to Laser Notice No. 50, dated June 24,
2007.
Laser Warning (Class 1M)
WARNING: CLASS 1M LASER PRODUCT; INVISIBLE LASER RADIATION;
DO NOT VIEW DIRECTLY WITH MAGNIFIER.
Viewing the laser output with optical instruments (e.g. magnifier, microcscopes) within a distance of 100mm
may pose an eye hazard.
ATTENTION: PRODUIT LASER CLASSE 1M; RADIATION LASER INVISIBLE;
NE PAS OBSERVER A LA LOUPE DIRECTEMENT.
L’observation des effets laser a l’aide d’un appareil optique (comme loupe, microscope...) a une distance jusqu’a
100mm peut poser un danger a l’oeil.
WARNUNG: KLASSE 1M LASER PRODUKT; UNSICHTBARE LASERSTRAHLUNG; NICHT
DIREKT MIT LUPE BETRACHTEN.
Das betrachten des Laser Ausgangs mit optischen Instrumenten (z.B. Vergroeßerunsglas, Mikroscope) innerhalb
eines Abstandes von 100mm kann eine Augenverletungs-Gefahr darstellen.
All Other HOA Covered By This Manual

Copyright © 2001 Harmonic Inc. ii
Safety
ATTENTION
AVERTISSEMENT
ACHTUNG
Pursuant to the pertinent sections of Title 21, (United States) Code of Federal Regulations
(CFR), Chapter I, Subchapter J, and administered by the Center for Devices and Radiological
Health (CDRH), operation under the Food and Drug Administration (FDA), this product,
which produces or receives an optical signal, composed of Laser Radiation, complies with 21
CFR Chapter I, Subchapter J, as applicable to Class I Laser Products with a Class 3B Hazard.
Copyright 2000 Harmonic Inc.
Harmonic continues to improve and enhance all product designs. Specifications are subject to change without notice. Harmonic and logo design, eXchange,
MAXLink, METROLink, NETWatch, PWRBlazer, TRANsend, and “Redefining the Network” are trademarks of Harmonic Inc. YAGLink and PWRLink are
registered trademarks of Harmonic Inc. All other names are trademarks or registered trademarks of their respective owners.
INTENDED MEANING
SIGIFICATION
BEDEUTUNG
INTERNATIONAL SYMBOL
SYMBOLE INTERNATIONAL
INTERNATIONALES SYMBOL
DANGER: Invisible Laser Radiation, when open or when operating with fiber
disconnected. AVOID DIRECT EXPOSURE TO THE BEAM. Never oper-
ate unit with a broken fiber or with a fiber connector disconnected.
DANGER: Les rayons laser sont invisibles à l´oeil. NE PAS S´EXPOSER
DIRECTEMENT AU FAISCEAU. Ne jamais utiliser l´appareil lorsque la fibre
est interrompue ou un connecteur endommagé ou déconnecté.
VORSICHT: Unsichtbare Laserstrahlung, wenn Abdeckung geöffnet oder
Glasfaserkabel entfernt. DIREKTEN KONTAKT MIT DEM STRAGL VER-
MEDIDEN. Das Gerät nicht einschalten, wenn das Glasfaserkabel beschädigt
oder nicht angelchlossen ist.
CAUTION: There are no user serviceable parts inside. Refer all servicing to
qualified service personnel. Other than those specific measurements, adjust-
ments and tests specified in the manual, make NO attempt to modify or alter
any circuit or assembly in any manner.
ATTENTION: Toute intervention sur cet équipement est formellement décon-
seillée par le fabricant. En dehors de réglages décrits dans le manuel,
l´utilisateur doit contacter une personne qualifiée par le fabricant pour toute
modification ou réparation.
VORSICHT: Es sind keine zu wartenden Teile im Gerät, alle Wartungsarbe-
iten nur von qualifiziertem Personal ausführen lassen. Ex dürfen nur die im
Handbuch spezifisch aufgeführten Messungen, Justierungen und Tests vom
Benutzer vorgenommen werden.Unter keinen Umständen, dürfen Modifika-
tionen oder Änderungen jeglicher Art am Gerät unternommen werden.
Note
This laser warning is included in all Harmonic manuals. The intended use of all
Harmonic products, including those products that do not contain lasers, are in systems
that contain lasers. Therefore this warning is important for the safety of all persons
operating or maintaining the equipment.
!

Copyright © 2001 Harmonic Inc. iii
Table of Contents
Table of Contents
Safety.................................................................................................................................................ii
Chapter 1 Overview
1.1 About this Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
1.2 Product Manual Applicability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
1.3 Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
1.4 Product Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Chapter 2 Installation of the HOA 7000 Series
2.1 Receiving and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Installing the HOA 7000 Series into the HLP 4200 Platform. . . . . . . . . . . . . . . . . . . . . . .2-2
2.3 Connecting the Fiber Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
2.3.1 Cleaning Fiber Optic Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
2.4 NETWatch Site Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
Chapter 3 Power Up
3.1 Power Up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Chapter 4 Setting Up the HOA 7000 Series
4.1 Setup with the HOA 7000 Front Panel Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
4.1.1 Switch Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
4.1.2 Switch Power Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
4.2 Setup with the HLP 4200 WD Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
4.2.1 Original Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
4.2.2 Resetting To Factory Optimized Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
4.3 NETWatch Element Management System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Chapter 5 Maintenance
5.1 Cleaning the Fiber Optic Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
5.2 Fan Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
5.3 In Case of Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
5.4 Warranty Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
5.5 Limitations of Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
5.6 Exclusive Remedies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4

iv Copyright © 2001 Harmonic Inc.
Table of Contents
Appendix A
A.1 Link Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.2 Optical Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.3 User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
A.4 RF Monitor Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
A.5 Harmonic NETWatch Element Management System. . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
A.6 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
A.7 Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Appendix B
B.1 Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.2 Sales Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
List of Figures
Figure 1-1 Typical Deployments of the Optical Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Figure 1-2 HOA 7000GF Optical Amplifier Signal Flow Diagram. . . . . . . . . . . . . . . . . . . . 1-4
Figure 1-3 HOA 7000E Optical Amplifier Signal Flow Diagram . . . . . . . . . . . . . . . . . . . . . 1-4
Figure 1-4 HOA 7000 Optical Amplifier Front Panel Feature. . . . . . . . . . . . . . . . . . . . . . . . 1-5
Figure 1-5 HOA 7000 Optical Amplifier Rear Panel Feature . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Figure 2-1 Safety Shutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Figure 2-2 Typical Fiber Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Figure 3-1 HLP 4200 Platform Main Menu Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Figure 3-2 Optical Power Output Measurement HOA 7000 Series . . . . . . . . . . . . . . . . . . . . 3-3
Figure 4-1 HOA 700xE Display User Interface Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Figure 4-2 HOA 7000-GF Display User Interface Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Figure 5-1 Optical Connector Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Figure 5-2 HOA 7000 Optical Amplifier Rear Panel Features . . . . . . . . . . . . . . . . . . . . . . . 5-3
List of Tables
Table A-1 Noise Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Table A-2 Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Copyright © 2001 Harmonic Inc. 1 - 1
Overview
Chapter 1
Overview
1.1 About this Manual
This instruction manual is a complete guide to installing and operating the single
width HOA 7000 Optical Amplifier single width module. Please read the entire man-
ual before beginning
installation.
•Chapter 1 gives General Information about the HOA 7000 Series Optical
Amplifiers.
•Chapter 2 describes the Installation of the HOA 7000 Series Optical Amplifiers.
•Chapter 3 follows through the Power up of the HOA 7000 Series.
•Chapter 4 describes the Setup of the HOA 7000 Series.
•Chapter 5 describes Maintenance.
•Appendix A gives Technical Specifications.
•Appendix B covers Assistance and Sales Offices.
1.2 Product Manual Applicability
This manual applies to all HOA7000 Series Optical Amplifiers with an optical output
of +20dBm. Models currently included in this manual are the 7014E,7017E,7014I-
GF,7017I-GF,7019IL-GF,7020I-GF,7017H-GF,7020H-GF. Appendix A, Table A-2,
includes specific output power information for each of these models. Separate manu-
als are provided for the HOA 7000 series Optical Amplifiers with output power
greater than +20 dBm.
1.3 Product Description
The HOA 7000 Series Optical Amplifiers are erbium-doped fiber amplifier (EDFA)
modules. They include:
•The HOA 7000E series for high-performance supertrunking applications.
•The HOA 7000-GF series for DWDM applications.
•The capability of producing over 100 mW of optical power in the 1535 to
1565 nm range.
•Microprocessor controlled.
•Local control of operating parameters and display of the HLP 4200
Platform.

Overview
1-2 Copyright © 2001 Harmonic Inc.
•Remote control and monitoring by means of the NETWatch Element
Management System.
1.4 Product Application
The HOA7000 Series Optical Amplifiers are part of Harmonic's MAXLink and
METROLink Product Lines. These product lines are designed to meet the economic
and technical requirements of Broadband service providers. The HOA 7000 series
optical amplifiers are plug-in modules intended for use in Harmonic's HLP4200
equipment
platforms.
Typical applications include:
•Medium and long haul applications beyond the reach of 1310 nm
transmitters.
•Fiber dense architectures.
•Redundant rings.
•Broadcast layer transmission.
•Hub interconnects.
•DWDM architectures.
The modular design of the MAXLink and METROLink product lines offer the user a
number of advantages:
•The flexibility to add other plug-in modules as industry requirements change
without the need to replace equipment shelves, power supplies or status monitor-
ing equipment.
•The economic advantage of sparing plug-in modules rather than entire
subsystems.
•The ability to decrease the life-cycle cost of the equipment by means of an
increased numerical count of spare plug-in modules.
•Reduced service outages based on the ease of plug-in module replace-
ments in contrast to “all in one” type systems.
Typical deployments of the Optical Transmitter are shown in Figure1- 1.
The HOA 7000-GF Optical Amplifier Signal Flow Diagram is shown in Figure1- 2.
The HOA 7000-E Optical Amplifier Signal Flow Diagram is shown in Figure1- 3.
The front and rear panel features of the HOA 7000 Optical Amplifier are shown in
Figure1- 4 and Figure1- 5.

Copyright © 2001 Harmonic Inc. 1 - 3
Overview
Figure 1-1 Typical Deployment of the Optical Amplifier
MAXLink
HLT 77xx MAXLink
HOA 70xx
MAXLink
HOA 70xx HRM 3810
HRM 3810
PW L 49xx
MAXLink
HLT 77xx MAXLink
HOA 70xx HRM 3810
Primary Path
Secondary Path
HOS 7010
MAXLink
HLT 77xx MAXLink
HOA 70xx
MAXLink
HOA 70xx HRM 3810
Σ
HLE 3700
Point-to-Point Interconnect (Long Haul)
Redundant Ring
Repeater Solution with HLE 3000 Link Extender

Overview
1-4 Copyright © 2001 Harmonic Inc.
Figure 1-2 HOA 7000-GF Optical Amplifier Signal Flow Diagram
Figure 1-3 HOA 7000E Optical Amplifier Signal Flow Diagram
Changes with different
Connectors
1) 2)
1) Not included in the H7000H-GF modles. 2)only when the output power >19dBm
2)
Isolator

Copyright © 2001 Harmonic Inc. 1 - 5
Overview
Figure 1-4 HOA 7000 Optical Amplifier Front Panel Features
HLP 4200 WD buttons/
HLP 4200 WD.

Overview
1-6 Copyright © 2001 Harmonic Inc.
Some models may have more than 1 output
Figure 1-5 HOA 7000 Optical Amplifier Rear Panel Features
1,2
Optical Input
1
1)Optical input and output shown here with SC/APC connectors
2)Some models may have more than one output

Copyright © 2001 Harmonic Inc. 2-1
Installing the HOA 7000 Series
Chapter 2
Installation of the HOA 7000 Series
This chapter describes how to:
•Receiving and Inspection.
•Installing the Unit in the HLP 4200 Platform.
•Connecting the fiber cable.
2.1 Receiving and Inspection
When unpacking the unit, inspect the shipping container and equipment for damage. Save the
shipping material for future use.
If the container or the equipment is damaged, notify both the freight carrier and Harmonic Inc.
To protect the operator from potential injury and to protect the equipment from future damage,
do not perform any operational tests.
The HOA 7000 series is provided with the following accessories:
1. Product Manual.
2. Male GSK to Female F-Adapter.
3. Fiber cleaning kit.
4. Extra safety labels supplied for user cable(s).
Warning
Do not perform any operation test if the equipment appears to be damaged.

Installing the HOA 7000 Series
2-2 Copyright © 2001 Harmonic Inc.
2.2 Installing the HOA 7000 Series into the HLP 4200
Platform
The HOA7000 Series Optical Amplifiers are designed for use in the HLP4200 Platform and
can be inserted into any available HLP4200 slot. The HLP4200 Platform is available in two
configurations, with a display (HLP4200 WD) or without the display (HLP4200 ND). If the
unit is to be installed in a HLP4200 WD Platform, the display/control panel must be lowered
prior to inserting the unit. If a HLP4200 ND Platform is being used, there is no display/control
panel to be lowered. Once the unit is seated in the platform, lock the unit into position by
tightening the knurled lock screw, as shown in Figure 1-4.
2.3 Connecting the Fiber Cable
•Direct viewing of the beam may cause serious eye damage and possible vision loss.
•Never operate system with fiber disconnected, an aperture open or a broken fiber.
•Do not view fiber ends or apertures directly with optical instruments (such as a magnify-
ing glass or an eye loupe).
•This Product is a Class I Laser with a Level 3B Hazard. The product is rated to 200 mW at
1550 nm ± 15nm.
2.3.1 Cleaning Fiber Optic Connectors
Dirty optical connectors are the leading source of poor performance in a broadband optical
fiber network. Dirty optical connectors lead to optical signal loss and reflections, that in turn
can result in serious carrier-to-noise (CNR) performance degradation and in some cases distor-
tion performance degradation.
Danger!
Invisible Laser Radiation when open or fiber disconnected. AVOID DIRECT EXPOSURE
TO THE LASER BEAM. Direct viewing of the beam can cause serious eye damage and
possible loss of vision.
Note!
Never operate unit with a broken fiber or with a fiber connector
disconnected.
!
Danger!
The fiber cable carries invisible laser radiation. AVOID EXPOSURE TO BEAM.
Never operate a unit that has a broken fiber or a disconnected fiber connector.

Copyright © 2001 Harmonic Inc. 2 - 3
Installing the HOA 7000 Series
Harmonic recommends that all mating fiber connections be cleaned before making a
connection to an optical transmitter. If it is suspected that the optical connector of a
HOA module may have been exposed to contamination then properly clean the HOA
optical connectors before connecting optical fiber.
Each Optical Amplifier is supplied with an accessory kit that includes an SC/APC
fiber jumper. For optical installation, follow the steps below:
1. Make sure the laser disable switch is in the off/down position. The laser emission
indicator (Amber LED) is OFF.
2. Remove the plastic dust cover from the SC/APC connectors and store them in a
clean plastic bag for future use. Remove protectors from connectors.
3. Loosen the lock screw and move the safety shutter. See Figure 2- 1.
Figure 2-1 Safety Shutter
4. Carefully insert the plug into the optical connector at the rear panel of the
Optical Amplifier. Push the plug until you hear a click.
Caution!
Improper cleaning of an optical connector can do more harm than good. Never use a
clean air product to spray air onto the surface of an optical connector. Spraying air
onto an optical connector can cause condensation on the connector surface, leaving
water spots and trapping dust.
Caution!
Failing to wipe a connector with a dry lens paper immediately after wiping with
paper wet with Isopropyl alcohol can also lead to condensation on the connector.
Using low grade cleaning paper or other cloth to wipe an optical connector can
leave microscopic fibers on the optical connector surface.
Changes with different
Connectors
7000 Series

Installing the HOA 7000 Series
2-4 Copyright © 2001 Harmonic Inc.
5. Move the safety shutter back so that the shutter locks the connector in place.
Tighten the lock screw.
6. Whenever a connector is opened, the plastic dust covers must be placed on both
ends. SeeFigure 2- 1. Typical fiber connections are shown in
Figure 2- 2.
Figure 2-2 Typical Fiber Cable Connections HOA 7000 Series
2.4 NETWatch Site Controller
Harmonic’s NETWatch Site Controller element management system can be used to monitor
and control the HOA 7000 series optical amplifiers, either remotely or locally. For information
on configuring and using this system consult the NETWatch Site Controller Instruction
Manual.
(A) Two HOA 7000 Amplifiers used with HLT 7803 Transmitter
LASER ON
DANG ER
INVISIBLE
LASER
RADIATION
(B) HOA 7000 Amplifier used as repeater or inline amplifier in a 1550 nm network
1550 nm
Optical
Output
to Network
1550 nm
Optical Signal
HLW9-019-601
CLASS1 LASER PRODUCT
!
DANGER:
WHENPANELSOR OPTICAL CONNECTIONSARE OPEN :
IEC 825-2 3b 1993
CAUTION:
InvisibleLaserradiation when open.
Avoidexposureto beam.
Lasourcelaser émet une radiation
invisible.EVITERUNE EXPOSITION
DIRECTEAUFAISCEAU.
HAZARDLEVEL IIIb
CLASS1 LASER PRODUCT
!
DANGER:
WHENPANELSOR OPTICAL CONNECTIONSARE OPEN :
IEC 825-2 3b 1993
CAUTION:
InvisibleLaserradiation when open.
Avoidexposureto beam.
Lasourcelaser émet une radiation
invisible.EVITERUNE EXPOSITION
DIRECTEAUFAISCEAU.
HAZARDLEVEL IIIb
U.
CLASS1 LASER PRODUCT
!
DANGER :
WHENPANELSOR OPTICAL CONNECTIONSARE OPEN :
IEC 825-2 3b 1993
CAUTION:
InvisibleLaserradiation when open.
Avoidexposureto beam.
Lasourcelaser émet une radiation
invisible.EVITERUNE EXPOSITION
DIRECTEAUFAISCEAU.
HAZARDLEVEL IIIb
CLASS1 LASER PRODUCT
!
DANGER :
WHENPANELSOR OPTICAL CONNECTIONSARE OPEN :
IEC 825-2 3b 1993
CAUTION:
InvisibleLaserradiation when open.
Avoidexposureto beam.
Lasourcelaser émet une radiation
invisible.EVITERUNE EXPOSITION
DIRECTEAUFAISCEAU.
HAZARDLEVEL IIIb
DANGER:
Invisible laser radiation.
AVOI D DIRECT
EXPOSURE TO BEAM.
LASER ON
EXTERNAL.
FAN
DANGE R:
Invisible laser radiation.
AVOI D DIRECT
EXPOSURE TO BEAM.
LASER ON
EXTERNAL.
FAN
DANGE R:
Invisible laser radiation.
AVOI D DIRECT
EXPOSURE TO BEAM.
LASER ON
EXTERNAL.
FAN
DANGER:
Invisible laser radiation.
AVOI D DIRECT
EXPOSURE TO BEAM.
LASER ON
EXTERNAL.
FAN
RF Input
1550 nm
Optical Output
to Network
HLT 7803
HLP 4200 Platform
HLP 4200 Platform
Fiber Jumpers
Changes with
Different Connectors
Changes with
Different Connectors

Copyright © 2001 Harmonic Inc. 3 - 1
Power Up
Chapter 3
Power Up
This chapter covers:
•Power Up.
•HLP 4200 Platform Main Menu Display.
3.1 Power Up
1. Depress the power button on the power supply. (Normally, this would be a CPS
4000 Series power supply in the HLP 4200 platform).
2. If the unit is operating normally, the status LED on the front panel should
illuminate green.
If your system has an HLP 4200 ND option, all controls and parameters can be
monitored and controlled locally or remotely. See the NETWatch Element Manage-
ment System Manual.
If your system has an HLP 4200 WD option, the display will greet the operator with
<HLP 4200 SYSTEM READY> message as shown in Figure 3- 1. The operator can
then walk through the Optical Amplifier menus by following the steps described
below:
1. Depressing any key on the front panel will show a module selection message on
the front panel, which reads <MODULE SELECTION>.
2. Pressing <ENTER> when the above message is shown leads the operator to a
menu displaying a list of connected modules by using <UP> and <DOWN> keys
from the keyboard. The module messages show the module position as the first
field in the message, the left most being the number 1. The select LED of the
currently selected module is illuminated.
3. Once the Optical Amplifier under installation is the focus of the front panel
display, pressing <ENTER> will lead the operator to the Optical Amplifier
menus. See Figure 3- 1.
4. Refer to Figure 4-2 in Chapter 4, to see how to traverse the Optical Amplifier
menus.
DANGER!
Avoid direct exposure to the Laser Beam. Direct viewing of the beam can cause
serious eye damage and possible loss of vision. Invisible laser radiation present
when fiber is open or fiber disconnected.

Power Up
3-2 Copyright © 2001 Harmonic Inc.
Figure 3-1 HLP 4200 Platform Main Menu Display
HLP 4200
