Hartman Sorrento User manual

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Sorrento/Bari 115cm Square Gas Firepit with Ceramic Top
( 67009068 / 64513007 )
ATTENTION:
1. Please read these instructions carefully before assembly
2. Aluminium is a soft metal and over tightening may strip the thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the table over and into position when
fully assembled
ASSEMBLY STEPS:
1. Turn table top over and put onto a soft clean surface, be careful of the glass fixed on table top and no need to take out of the glass
2. LOOSELY attach Side panel 1 (B) and Side panel 2 (C) to table top (A) with bolts (K) and big flat washers (M) using Spanner (N) DO
NOT TIGHTEN THE BOLTS AT THIS STAGE
3. LOOSELY attach rear panel (D) to Side panel 1 & 2 with bolts (K) and big flat washers (M) using Spanner (N)
4. LOOSELY attach bottom frame (E) to connecting bar (F) with bolts (K) and big flat washers (M) using Spanner (N)
5. LOOSELY attached assembled bottom frame to Side panel with bolts (L) and big flat washers (M) using Spanner (N)
6. Tighten all bolts one by one using spanner, being careful not to over tighten any as this will cause the thread to become damaged
7. Turn table top over and place in desired position, be careful of the glass fixed on table top while turning over the table
8. Open the door, connect the gas pipe then put the gas tank on the fixed bottom frame and close the door
9. Pour the bag of glass beads (H) into fire pit
10. Put the centre glass (G) on top of the fire pit
11. Fire guard: fix 4pc glass (I) onto the glass clips (J). Note: When installing the glass clips, the direction of the clip on the same piece of
glass must be in reverse.
12. Put the assembled fire guard on the correct position on table top, the table is assembled completely.
For more information regarding maintenance of your furniture please visit
https://www.hartmanuk.com/home
Component’s
Fixings
Parts List
Parts Picture
Description
Q’ty
Part no
Parts list
Parts Picture
Description
Q’
ty
Part no.
A
Table Top
with Glass
1
67009068A
64513007A
H
Glass
beads
1
67009068H
64513007H
B
Side panel
1 with door
1
67009068B
64513007B
I
Fire Guard
Glass
4
67009068I
64513007I
C
Side panel
2
1
67009068C
64513007C
J
Glass clip
8
21000042
D
Rear panel
1
67009068D
64513007D
K
M6*25mm
bolts
12
1231162
E
Bottom
frame
1
67009068E
64513007E
L
M6*35mm
bolts
4
2100040
F
Connecting
bar
2
67009068F
64513007F
M
Flat
washers
16
1061162
G
Centre
glass
1
67009068G
64513007G
N
Spanner
1
2100041

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Sorrento/Bari 115cm Square Gas Firepit with Ceramic Top
( 67009068 / 64513007 )
1
2
3
4

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
5
6
7
8
9

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Sorrento Square Corner Casual Dining Set - Left and Right 2 Seaters plus Corner & Sorrento Middle Sofa
( 67006068 / 67008068 )
ATTENTION:
1. Please read these instructions carefully before assembly
2. Aluminium is a soft metal and over tightening may strip the thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the sofa over and into position when
fully assembled
RH SOFA ASSEMBLY STEPS:
1. Position part (A), part (B) and part (C) ready for assembly
2. LOOSELY attach RH arm with leg frame (A) and LH leg frame (B) to seating section (C) using bolts (G) and flat washers (I) with the
spanner (J) DO NOT TIGHTEN BOLTS AT THIS STAGE.
3. LOOSELY attach backrest (D) to assembled leg frames using bolts (H) and flat washers (I) with spanner (J) DO NOT TIGHTEN
BOLTS AT THIS STAGE.
4. Tighten all bolts using the spanner (J)
5. Turn it over and place in desired position, then put all seat cushions (E) and back cushions (F) on the sofa
For more information regarding maintenance of your furniture please visit
https://www.hartmanuk.com/home
Component’s
Fixings
Parts List
Parts Picture
Description
Q’ty
Parts list
Parts Picture
Description
Q’ty
A
RH arm
with leg
frame
1
67006068A
F
Back
cushion
2
67006068
F
B
LH leg
frame
1
67006068B
G
M6*35 bolts
7
2100040
C
Seating
section
1
67006068C
H
M6*25 bolts
2
1231162
D
Backrest
1
67006068D
I
Flat
washers
9
1061162
E
Seat
cushion
2
67006068E
J
Spanner
1
2100041

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Sorrento Square Corner Casual Dining Set Right Hand 2 Seaters Sofa
( 67006068 / 67008068 )
1
2
3

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ATTENTION:
1. Please read these instructions carefully before assembly
2. Aluminium is soft metal and over tightening may strip thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the sofa over and into position when
fully assembled
LH SOFA ASSEMBLY STEPS:
1. Position part (A), part (B) and part (C) ready for assembly
2. LOOSELY attach RH leg frame (A) and LH arm with leg frame (B) to seating section (C) using bolts (G) and flat washers (I) with the
spanner (J) DO NOT TIGHTEN
BOLTS AT THIS STAGE.
3. LOOSELY attach backrest (D) to assembled leg frames using bolts (H) and flat washers (I) with spanner (J) DO NOT TIGHTEN
BOLTS AT THIS STAGE.
4. Tighten all bolts using the spanner (J)
5. Turn it over and place in desired position, then put all seat cushions (E) and back cushions (F) on the sofa
For more information regarding maintenance of your furniture please visit
https://www.hartmanuk.com/home
Component’s
Fixings
Parts List
Parts Picture
Description
Q’ty
Part no
Parts list
Parts Picture
Description
Q’ty
Part no.
A
RH leg
frame
1
67006068A1
F
Back
cushion
2
67006068
F
B
LH arm
with leg
frame
1
67006068B1
G
M6*35 bolts
7
2100040
C
Seating
section
1
67006068C
H
M6*25 bolts
2
1231162
D
Backrest
1
67006068D
I
Flat
washers
9
1061162
E
Seat
cushion
2
67006068E
J
Spanner
1
2100041

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Sorrento Square Corner Casual Dining Set Left Hand 2 Seaters Sofa
( 67006068 / 67008068 )
1
2
3

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ATTENTION:
1. Please read these instructions carefully before assembly
2. Aluminium is soft metal and over tightening may strip thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the sofa over and into position when
fully assembled
CORNER SOFA UNIT ASSEMBLY STEPS:
1. Position part (A), part (B) and part (C) ready for assembly
2. LOOSELY attach RH Leg frame (A) and LH arm with leg frame (B) to seating section (C) using bolts (H) and flat washers (J) with
spanner (K) DO NOT TIGHTEN BOLTS AT THIS STAGE.
3. LOOSELY attach backrest (D) to assembled leg frames using bolts (I) and flat washers (J) with spanner (K) DO NOT TIGHTEN
BOLTS AT THIS STAGE.
4. Tighten all bolts using the spanner (K)
5. Turn it over and place in desired position, then put all seat cushion (E), back cushion (F) and side cushion(G) on the sofa
For more information regarding maintenance of your furniture please visit
https://www.hartmanuk.com/home
Component’s
Fixings
Parts List
Parts Picture
Description
Q’ty
Part no
Parts list
Parts Picture
Description
Q’ty
Part no.
A
RH leg
frame
1
67006068A1
G
Side
cushion
1
67006068
G
B
LH arm
with leg
frame
1
67006068B1
H
M6*35 bolts
6
2100040
C
Seating
section
1
67006068C1
I
M6*25 bolts
2
1231162
D
Backrest
1
67008068D1
J
Flat
washers
8
1061162
E
Seat
cushion
1
67006068E
K
Spanner
1
2100041
F
Back
cushion
1
670086068F

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Sorrento Square Corner Casual Dining Set Corner Sofa
( 67006068 / 67008068 )
1
2
3

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ATTENTION:
1. Please read these instructions carefully before assembly
2. Aluminium is soft metal and over tightening may strip thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the sofa over and into position when
fully assembled
ASSEMBLY STEPS:
1. Position part (A), part (B), part (C) and part (D) ready for assembly
2. With brackets (E) and (F) position over the section that adjoin parts (A), (B), (C) and (D).
3. Turn sofas over and place in desired position.
4. Put all cushions on the sofa
For more information regarding maintenance of your furniture please visit
http://www.hartmanuk.co.uk/after_care_videos.html
Component’s
Fixings
Parts List
Parts Picture
Description
Q’ty
Part no
Parts list
Parts Picture
Description
Q’ty
Part no.
A
RH Sofa
1
D
Middle sofa
1
B
LH Sofa
1
E
Bracket
2
2100103
C
Corner sofa
1
F
Bracket
4
2100104

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Sorrento Lounge Chair
( 67005068 / 67001068 )
ATTENTION:
1. Please read these instructions carefully before assembly
2. Aluminium is soft metal and over tightening may strip thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the sofa over and into position when
fully assembled
ASSEMBLY STEPS:
1. Position part (A), part (B) and part (C) ready for assembly
2. LOOSELY attach RH arm with leg frame (A) and LH arm with leg frame (B) to seating section (C) using bolts (G) and flat washers (I)
with the spanner (J) DO NOT TIGHTEN BOLTS AT THIS STAGE.
3. LOOSELY attach backrest (D) to assembled leg frames using bolts (H) and flat washers (I) with the spanner (J) DO NOT TIGHTEN
BOLTS AT THIS STAGE.
4. Tighten all bolts using the spanner (J)
5. Turn it over and place in desired position, then put all seat cushion (E) and back cushion (F) on the sofa
For more information regarding maintenance of your furniture please visit
https://www.hartmanuk.com/home
Component’s
Fixings
Parts List
Parts Picture
Description
Q’ty
Part no
Parts list
Parts Picture
Description
Q’ty
Part no.
A
RH arm
with leg
frame
1
67005068A
G
M6*35 bolts
6
2100040
B
LH arm
with leg
frame
1
67005068B
H
M6*25 bolts
2
1231162
C
Seating
section
1
67005068C
I
Flat
washers
8
1061162
D
Backrest
1
67005068D
J
Spanner
1
2100041
E
Seat
cushion
1
67005068E
F
Back
cushion
1
67005068F

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to http://spares.hartmanuk.co.uk/purchase
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Sorrento Lounge Chair
( 67005068 / 67001068 )
1
2
3
1
