HARTMANN TRESORE HTM T40-02 User manual

General information
INSTALLATION AND OPERATING INSTRUCTIONS
for HTM T40-02 minibar
EN

HARTMANN TRESORE
TABLE OF CONTENTS
1. Notes on putting into operation and safe use
2. Technical specifications
3. Range of use
4. Putting the product into operation
5. Installation notes
6. Changing the door hinge
7. Installation of the sliding door fitting
8. Tips and help
9. Cleaning and care
10. Saving energy
11. Disposal
12. Guarantee
2

HARTMANN TRESORE
Please read the operating instructions first.
This product complies with the requirements of the following EU directives:
• 2006/95/EG (73/23/EEC)
Directive relating to electrical equipment for use within certain voltage limits
• 2004/108/EG (89/336/EEC)
Directive relating to electromagnetic compatibility
• Delegated regulation (EC) Nr. 1060/2010
Directive relating to energy labelling of household refrigerating equipment
• (EG/643/2009)
Directive relating to energy efficiency clauses
Dear Customer,
Please read the operating instructions carefully before you put the product into
operation.
This high-quality product has been manufactured on modern machinery taking environ-
mental aspects into account, and tested by a detailed quality check. Please follow the
safety instructions for long and optimum function.
Keep the operating instructions for later reference. Please also read the other
documents delivered with the product.
IMPORTANT NOTE:
The manufacturing company reserves the right to make changes to the product!
Hartmann Tresore AG is not liable for damage caused by improper use.
3

HARTMANN TRESORE
General notes
• Never set the appliance up near sources of heat (e.g. radiator). Avoid direct sunlight.
• Set the appliance up on a safe level surface. Please note that the appliance has to be
screwed to the substructure for installation of the optional sliding door fitting.
• The ambient temperature should be between 16 and 32 °C to achieve optimum appliance
performance.
• Check the appliance for any defects and make sure all the accessories included are
complete before putting it into operation.
• Allow the appliance to cool for 2 to 3 hours after switch-on before you fill it with food.
• We recommend that you disconnect your appliance from the power supply if you are not
using it for a longer period.
WARNING! Non-observance of the safety instructions below can lead
to danger for life and limb!
• This appliance must not be used by persons (including children) with reduced physical,
sensory or mental capacities or a lack of experience and knowledge unless they are
instructed about safe use of the appliance by a person responsible for their safety or are
supervised during use.
• Never place any potentially explosive substances that contain combustible gases into the
appliance.
• Suitable specialist personnel should connect the appliance to the power supply system.
Use a power socket compliant with the current safety guidelines.
• Never touch non-insulated cables and wires.
• Repairs may only be carried out by specialists. Improper repairs are a source of significant
hazard potential and lead to the guarantee being rendered invalid.
1 | NOTES ON PUTTING INTO OPERATION AND SAFE USE
4
!

HARTMANN TRESORE
1.
2.
3.
4.
3.
5.
6.
PLEASE NOTE! Risk of damage!
• Compare the voltage available from the power supply with the voltage specification
on the rating plate.
• Never cover the appliance’s ventilation openings. If the appliance is installed in a
cupboard or two appliances are set up next to one another, air circulation must always be
guaranteed. Otherwise there is a risk of overheating (see chapter 5)!
• Avoid contact of the appliance surface with oils, greases and substances containing
solvent.
• Never use any gaseous, fuel-containing or similar materials for cleaning (see chapter 9).
• The shelves in models HTM T30-02 and HTM T40-01 are made of glass. Please handle
them with appropriate care.
5
!
2 | TECHNICAL SPECIFICATIONS
1. Door hinge
2. Shelves
3. Door inserts (with rails)
4. LED lighting (position can vary depending on model)
5. Bases
6. Door seal
Sketch may differ from the product.

HARTMANN TRESORE
!
The appliance has been designed exclusively for use indoors, e.g.
• in hotels, bed & breakfast establishments or other accommodation facilities
• in business and offices
The appliance must not be used outdoors.
• Please check whether the appliance shows signs of any defects.
• Install the appliance in accordance with section 5.
• We recommend screwing the appliance to a firm surface by the bases to prevent tilting.
• Plug the minibar plug into the socket.
• Depending on the model, the controller for temperature setting is either on the light or on
the back of the appliance and is either a rotary or slide control (see sketches).
• Set the required temperature by sliding the slide control to the right or turning the
control knob to the right to increase appliance cooling.
• The setting is either in steps (4 positions in the case of the slide control) or gradual
(control knob).
3 | RANGE OF USE
4 | PUTTING THE PRODUCT INTO OPERATION
8
Controller inside
Control knob up
HTM T40-02

HARTMANN TRESORE
5 | INSTALLATION NOTES
9
min. 40 mm
min. 40 mm
(80 mm recommended)
The clearance between the furniture walls
and the minibar should be at least 40 mm
on all sides. However, a clearance of 80 mm
is recommended at the back.
Air inlet
Minibars withdraw heat from the
interior to cool it. This heat is
discharged again via the back. For
this reason, the air must be able to
circulate freely around the minibar.
To achieve this, a free ventilation
cross-section of at least 200 cm2
must be guaranteed during installation
for inlet and discharge air. Generally
speaking, the following applies: The
better the hot discharge air can be
dissipated away from the minibar,
the better its efficiency, i.e. energy
consumption drops. The inlet air for
the minibar is supplied from below.
The hot discharge air must always
be discharged from the top (chimney
effect).
min. 40 mm
(80 mm recommended)
40 mm
80 mm
150 mm
Air outlet

HARTMANN TRESORE
The hinge required for
changeover is included
with the delivery.
10
Door hinge on the right
(state on delivery)
Door hinge on the left
6 | CHANGING THE DOOR HINGE
!Please ensure that
the door is correctly
aligned when changing
the door hinge.

HARTMANN TRESORE
Middle of the door
60 mm
7 | INSTALLATION OF THE SLIDING DOOR
The sliding door fitting included as standard in the scope of delivery (not with glass door mini-
bars) can be used as an option. Make sure the appliance is firmly screwed to the cupboard to
guarantee optimum functionality.
11
View from above
Position of the guide piece

HARTMANN TRESORE
8 | TIPS AND HELP
PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTION
Appliance is not working.
There is no power supply to the
appliance. Check the appliance power supply.
Cable or power supply unit is
faulty.
Contact a service employee at
Hartmann Tresore AG*.
Fault in the electronics Contact a service employee at
Hartmann Tresore AG*.
Appliance has a poor
cooling performance.
The room temperature is not in
the optimum range.
Adapt the room temperature
accordingly.
The door has been opened
too often.
Try to reduce the number of times
the door is opened.
The appliance door does not
close properly.
See the section
“The door does not close properly.”
The temperature controller is not
set properly. Set as required.
The appliance has not been
installed properly (wrong
clearance dimensions).
Correct the clearance dimensions.
The appliance has been exposed
to heat or direct sunlight.
Position the appliance in a cool spot
and avoid direct sunlight.
The interior lighting is
not working.
There is no power supply to the
appliance. Check the appliance power supply.
The LED lighting is faulty. Contact a service employee at Hart-
mann Tresore AG*.
The door does not close
properly.
The door hinge has not been
installed correctly.
Correct the installation in accordan-
ce with section 6 (p. 10).
The door seal is soiled. Clean the door seal in accordance
with section 9 (p. 13).
The shelves, brackets or baskets
are not in the correct position. Adjust the components again.
Temperature control is
not working. Fault in the control electronics Contact a service employee at Hartmann Tresore AG*.
*Tel. [phone] | Fax [phone] | Mail: [e-mail]
12

HARTMANN TRESORE
Warning! Danger to life!
• Always disconnect the appliance from the power supply before carrying out any
cleaning work.
Please note! Risk of damage!
• Never clean the appliance under running water
• Do not use any strong detergents or hard objects for cleaning.
• Please use a soft cloth and mild household detergent to clean the inside and outside of
the appliance before putting it into operation. Do not use soap or aggressive cleaning
agents for cleaning.
• Make sure that the appliance seals do not come into contact with grease or grease-like
substances.
• Rub the seals and hinges with talcum powder from time to time. This guarantees that
they will remain supple and have a long service life.
• Please clean dust and any other dirt off the back of the appliance once a year in order to
guarantee proper appliance function.
9 | CLEANING AND CARE
10 | SAVING ENERGY
!
!
• The appliance should not be set up in direct sunlight or near a source of heat
(e.g. radiator). Use an insulating panel if necessary.
• Set the appliance up in a dry, ventilated room.
• Only open the appliance briefly to take things out.
• Fill the appliance with pre-cooled beverages if possible.
• Clean the back of the appliance occasionally.
13

HARTMANN TRESORE
The guarantee period begins with product purchase and lasts 12 months.
Please note! The guarantee is rendered invalid if
• the installation and operating instructions are not followed correctly and lead to
malfunctions.
• the appliance is modified in any way.
• no original spare parts are used.
The guarantee is not applicable for any personal injury or property damage caused by
non-observance of the operating manual or incorrect use of the appliance.
IMPORTANT: Product characteristics may be changed without advance notice.
PLEASE NOTE!
This appliance is marked in accordance with the European Directive 2002/96/EC on
waste electrical and electronic equipment!
The appliance packaging is made of reusable materials!
• The correct separate collection of these appliances and its eco-friendly treatment and
disposal contribute to preventing potential negative impact on the environment and
health.
• The packaging materials can be hazardous for children. For this reason, keep these
materials out of the reach of children and dispose of them in accordance with the waste
instructions.
• Do not dispose of the packaging materials together with normal waste.
• If necessary, contact your authorised sales agent or the waste collection centre in your
region for information on disposing of your minibar.
• Remove the mains plug and any locks before disposal to protect children from possible
hazards.
11 | DISPOSAL
This symbol, which you can see on the product itself and in the
product documents, means that the minibar must not be disposed of
with normal household waste. The product must be taken to a special
waste collection centre to guarantee the regulation-compliant disposal
required for electronic appliances. If necessary, contact the waste
collection centre or your sales agent for further information.
12 | GUARANTEE
!
14

HARTMANN TRESORE AG
Pamplonastraße 2
33106 Paderborn
Deutschland
[phone]
[e-mail]
INSTALLATION AND OPERATING INSTRUCTIONS | Minibar HTM T40-02 | Stand 10/23 EN
www.hartmann-tresore.de
