HAUNTED LIVING 60476 User manual

ITEM #5267929
BLUETOOTH®REAPER
WITH DRUMS
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 888-251-1006 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also
contact us at [email protected].
MODEL #60476
HAUNTED LIVING and logo design are trademarks
or registered trademarks of LF, LLC. All rights reserved.
SS23315

SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
ADULT ASSEMBLY REQUIRED
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
No tools required for assembly.
Estimated Assembly Time: 8 minutes
PREPARATION
WARNING
• Warning Risk of injury to persons. Read and understand instruction manual before use.
• Warning: CHOKING HAZARD! Small parts. This item is not a toy. For decoration only.
• Do not turn item on until you have completely nished assembly.
• Stay clear of item while operating.
• Do not place item on uneven ground.
• Do not place weight on item while in operation.
Page 1
BATTERY INSTRUCTIONS:
1. Contains (4) AA 1.5-volt alkaline batteries. Batteries are not rechargeable.
2. Battery installation and removal should be performed by an adult. Batteries are harmful if swallowed.
Keep away from young children.
3. Remove batteries when not in use.
4. Use only batteries recommended in the instructions.
5. Do not mix new and used batteries.
6. Do not mix alkaline, carbon-zinc, nickel-cadmium, rechargeable or dierent types of batteries.
7. Be mindful to insert batteries with the correct polarity (+/-) as indicated.
8. Remove all exhausted batteries.
9. Rechargeable batteries are only to be charged under adult supervision.
10. Rechargeable batteries are to be removed from the item before being charged.
11. Non-rechargeable batteries are not to be recharged.
12. The supply terminals are not to be short-circuited.
13. Always dispose of exhausted batteries properly.
14. DO NOT dispose of batteries in re, they may leak or explode.

PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Body and Head 1
B Right Arm 1
C Left Arm 1
D Waist and Control Box 1
E 6V 2A Adapter 1
F Lower Drum 1
G Upper Drum 1
H Lower poles 4
I Upper poles 2
J Fabric legs and frame 1
K Metal Stand 1
L Input Output wire 1
M AA Alkaline batteries 4
A. B. C. D. E.
F. G. H. I. J. K. L. M.
Page 2

ASSEMBLY INSTRUCTIONS
1. Insert and snap lock 4 lower poles into the base.
(Match A to A)
2. Insert and snap lock the waist and control box to the
lower poles. (Match B to B)
3. Insert and snap lock the two upper poles to both sides
of the waist and control box. (Match C to C)
1
2
3
Page 3

ASSEMBLY INSTRUCTIONS
5. Lift the fabric and connect the body and head to the
upper poles. (Match D to D)
5
Page 4
4. Insert the fabric legs and frame into the waist
and control box. Match, blue to blue, yellow
to yellow. - PROCEED to 4A
4A. Match red to red and green to green.
4
4A

ASSEMBLY INSTRUCTIONS
8. Connect the wire from the control box to the LED eye
wires from the body and head. (Connect G to G)
8
Page 5
6. Insert and snap lock the left arm to the body and head.
(Match E to E)
7. Insert and snap lock the right arm to the body and head.
(Match F to F)
6
7

ASSEMBLY INSTRUCTIONS
11. Insert the upper drum into the lower drum.
Adjust the height on the upper drum by twisting
the knob located on the lower drum.
Turn the knob left to loosen and right to tighten once
the upper drum is at desired height.
11
Page 6
9. Connect the wire from the control box to the wire
located on the left arm. (Connect H to H)
10. Connect the wire from the control box to the wire
located on the right arm. (Connect I to I)
9
10

ASSEMBLY INSTRUCTIONS
14. Secure the hook and loop fasteners located on
the wrists of both right and left arms.
14
Page 7
12. Connect the wire from the control box to the wire
located on the lower drum. (Connect J to J)
13. Connect the wire from the upper drum to the
lower drum. (Connect K to K)
12
13

ASSEMBLY INSTRUCTIONS
OPERATING/BLUETOOTH PAIRING INSTRUCTIONS
15. Replace and insert 4 fresh AA batteries into the
battery compartment or insert the 6V2A adapter
(included) into the adapter jack located on the
control box.
15
Page 8
BLUETOOTH®LEADER SWITCH POSITION
Move the switch to the BLUETOOTH®LEADER position on the
control box to play your own music/playlist. Locate the name
REAPER BAND on your phone/device and pair.
When your music is playing the item will automatically activate.
FOLLOWER SWITCH ONLY USED WITH ADDITIONAL ITEM.
FORGET/UNPAIR YOUR DEVICE TO CONNECT TO A NEW DEVICE.
ON SWITCH POSITION
Move the switch to the ON position located on the
control box.
Move in front of the item or make a loud sound (clap) to activate the
item. This mode will play the Reaper Band song and also send a signal
to a follower device/additional band member (Guitarist) when wired
together on the control box. (Guitarist sold separately)
Turn item to DEMO/OFF position when not in use.
LEADER SWITCH POSITION FOLLOWER SWITCH POSITION

EXTERNAL SPEAKER IS NOT INCLUDED. MUST BE PURCHASED SEPARATELY.
1. Plug speaker cord into the jack labeled SPEAKER JACK
located on the CONTROL BOX.
2. Use volume knob on external speaker to control volume levels.
OPTIONAL EXTERNAL SPEAKER SET UP
OPTIONAL DEMO SET UP
1. Insert the cable from optional footpad/push button into the
jack labeled DEMO on the CONTROL BOX.
2. Place the switch in the DEMO position to enable
DEMO activation.
3. Step on the footpad or press push button to activate the
scary sequence!
Footpads and push buttons are sold separately and can be
purchased at www.tekkyaccessories.com
*
FOOTPAD/PUSH BUTTON IS NOT INCLUDED. MUST BE PURCHASED SEPARATELY.
OPTIONAL DEMO AND EXTERNAL SPEAKER SET UP
Page 9
CARE AND MAINTENANCE
• STORE IN A COOL AND DRY ENVIRONMENT.
• IN INCLEMENT WEATHER BRING ITEM INDOORS.
• SURFACE WASHABLE ONLY. DO NOT USE ANY HARSH OR ABRASIVE CLEANING AGENTS.
• REMOVE BATTERIES WHEN STORING ITEM FOR LONG PERIODS OF TIME.
1. Insert the INPUT/OUTPUT WIRE into the OUTPUT jack.
2. Move the switch into the BLUETOOTH
®
LEADER postion.
3. Insert the INPUT/OUTPUT WIRE into the INPUT jack on the second
band member.
4. Move the switch on the second band member to FOLLOWER.
OPTIONAL MULTIPLE ITEM BAND SETUP
LEADER SWITCH POSITION FOLLOWER SWITCH POSITION
LEADER
FOLLOWER

Page 10
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Item will not
activate.
• 6V 2A adapter is not plugged in.
• Switch on control box is not in the DEMO/OFF
position.
• Batteries are not inserted correctly.
• Check 6V 2A adapter is plugged
in and securely inserted into the
control box.
• Move switch to Bluetooth
®
/Leader or
ON positions
• Install batteries with positive and
negative in the correct positions.
Item has no sound while
operating. • Volume knob is turned all the way down. • Adjust volume knob to desired volume.
You only hear
item sound but no
item activation.
• Control Box wires to the arms are not
connected.
• Make sure the control box wires
labeled H and I are both securely
connected.
You cannot connect to
Bluetooth
®
on NEW
device.
• Prior device is still connected to
REAPER BAND Bluetooth
®
.
• Unpair/forget prior Bluetooth
®
device

FCC REGULATION
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This device must not be co-located or operating in conjunction with any other antenna or transmitter.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC ID: 2AAAI-REAPER-BAND

To comply with FCC’s RF radiation exposure limits for general population/uncontrolled exposure, this device
must be installed to provide a separation distance of at least 20cm from all persons.
WARNING: Any changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Page 11
Printed in China

Artículo #5267929
LA MUERTE BLUETOOTH
CON BATERÍA
¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a nuestro
Departamento de Servicio al Cliente al 888-251-1006, de lunes a domingo, de 8 a.m. a 8
p.m., hora estándar del Este. También puede ponerse en contacto con nosotros en
[email protected].
Modelo #60476
SS23315
HAUNTED LIVING y el diseño del logotipo son marcas
comerciales o marcas registradas de LF, LLC. Todos los
derechos reservados.
Página 12

INFORMACIÓN DE SEGURIDAD
Lea y comprenda completamente este manual antes de intentar ensamblar, usar o instalar el
producto.
SE REQUIERE UN ADULTO PARA EL ENSAMBLAJE.
Antes de comenzar a ensamblar el producto, asegúrese de tener todas las piezas. Compare las
piezas con la lista del contenido
del paquete y de los aditamentos. Si faltan piezas o alguna está dañada, no intente
ensamblar el producto.
No se necesitan herramientas para el ensamblaje.
Tiempo estimado de ensamblaje: 8 minutos
PREPARACIÓN
ADVERTENCIA
• Advertencia de riesgo potencial de lesiones para las personas. Lea y comprenda el
manual de instrucciones antes de usar el producto.
• Advertencia: RIESGO DE ASFIXIA. Piezas pequeñas. Este artículo no es un juguete. Solo para
decoración.
• No encienda el artículo hasta que haya completado el ensamblaje.
• Manténgase alejado del artículo mientras está en funcionamiento.
• No coloque el artículo sobre el piso desparejo.
- No coloque peso sobre el artículo mientras está en funcionamiento.
Página 13
INSTRUCCIONES DE LA BATERÍA:
1. Contiene (3) baterías alcalinas AA de 1,5 voltios. Las baterías no son recargables.
2. La instalación y el retiro de las baterías deben estar a cargo de un adulto. Las baterías son dañinas
si se tragan. Mantenga las baterías alejadas de los niños.
3. Retire las baterías cuando la bombilla no esté en uso.
4. Utilice únicamente las baterías recomendadas en las instrucciones.
5. No mezcle baterías nuevas con baterías usadas.
6. No mezcle batería alcalinas, cinc-carbono, níquel cadmio, recargables o diferentes tipos de baterías.
7. Tenga cuidado de insertar las baterías con la polaridad correcta (+/-) como se indica.
8. Retire todas baterías agotadas.
9. Las baterías recargables se deben recargar solo con la supervisión de un adulto.
10. Las baterías recargables deben retirarse del artículo antes de cargarlas.
11. Las baterías que no son recargables no deben recargarse.
12. Los terminales de alimentación no deben hacer corto circuito.
13. Deseche siempre las baterías agotadas de forma adecuada.
14. NO incinere las baterías, ya que podrían ltrarse o explotar.

CONTENIDO DEL PAQUETE
PIEZA DESCRIPCIÓN CANTIDAD
A Cuerpo y cabeza 1
B Brazo derecho 1
C Brazo izquierdo 1
D Cintura y caja de control 1
E Adaptador de 6V 2A 1
F Batería inferior 1
G Batería superior 1
H Varillas inferiores 4
I Varillas superiores 2
J Piernas y marco de tela 1
K Soporte de metal 1
L Cable de entrada y salida 1
M
Baterías alcalinas AA 4
Página 14
A. B. C. D. E.
F. G. H. I. J. K. L. M.

INSTRUCCIONES DE ENSAMBLAJE
1. Inserte y trabe las 4 varillas inferiores en la base.
(Emparejar A con A)
2. Inserte y trabe la cintura y la caja de control en las
varillas inferiores. (Emparejar B con B)
3. Inserte y trabe las dos varillas superiores a ambos lados
de la cintura y caja de control. (Emparejar C con C)
1
2
3
Página 15

INSTRUCCIONES DE ENSAMBLAJE
5. Levante la tela y conecte el cuerpo y la cabeza a las
varillas superiores. (Emparejar D con D)
5
Página 16
4. Inserte las piernas de tela y el marco en la cintura
y la caja de control. (Emparejar azul con azul y amarillo
con amarillo). - CONTINÚE con 4A.
4A. Emparejar rojo con rojo y verde con verde.
4
4A

INSTRUCCIONES DE ENSAMBLAJE
8. Conecte el cable de la caja de control a los cables del
ojo LED del cuerpo y la cabeza. (Conectar G con G)
8
Página 17
6. Inserte y trabe el brazo izquierdo al cuerpo y la cabeza.
(Emparejar E con E)
7. Inserte y trabe el brazo derecho al cuerpo y la cabeza.
(Emparejar F con F)
6
7

INSTRUCCIONES DE ENSAMBLAJE
11. Inserte la batería superior en la inferior.
Ajuste la altura en la batería superior al girar
la perilla ubicada en la batería inferior.
Gire la perilla hacia la izquierda para aflojar y hacia
la derecha para ajustar una vez la batería superior
a la altura deseada.
11
Página 18
9. Conecte el cable de la caja de control al cable
ubicado en el brazo izquierdo. (Conectar H con H)
10. Conecte el cable de la caja de control al cable
ubicado en el brazo derecho. (Conectar I con I)
9
10

INSTRUCCIONES DE ENSAMBLAJE
14. Asegure los sujetadores de velcro ubicados en
las muñecas de ambos brazos derecho e izquierdo.
14
Página 19
12. Conecte el cable de la caja de control al cable
ubicado en la batería inferior. (Conectar J con J)
13. Conecte el cable de la batería superior a la
batería inferior. (Conectar K con K)
12
13
