Havells FD5002 User manual
MULTIPURPOSE FACIAL
HAIR REMOVER
FD5002
Operating Instructions
& Guarantee Card
4
GUARANTEE*
Havells Personal Grooming products are guaranteed against manufacturing
defect for a period of Two Years from the date of purchase. The defective
product will be repaired/replaced within guarantee period free of cost
provided it is sent (freight paid), securely packed to our nearest authorized
dealer/service center along with the purchase bill and guarantee card duly
filled in and stamped by the selling dealer. Damaged/broken or worn-out
parts will be charged basis company’s list price.
The guarantee is valid subject to the following:
1. The product is used and maintained properly and the damage is not
due to negligence, mishandling, toppling or falling off of the product,
distorted/damaged blades, accident and attempted repairs by
unauthorized persons.
2. The product is purchased from Havells authorized dealers/retailers
only.
3. The serial number of the product is not missing, deleted, defaced or
altered.
4. The product is used for personal/ domestic purpose only.
The guarantee shall not apply:
Havells India Ltd. shall, however, be liable up to the maximum of the price
charged for the product and shall have no responsibility for any indirect or
consequential damage.
Customer Name
GUARANTEE CARD
Customer Address
Pin Code
Date of Purchase
Dealer’s Name &
Address
Dealer’s Stamp:
Product Model
MULTIPURPOSE FACIAL HAIR REMOVER
FD5002
serial number sticker to pasted Size: 40x5mm
Havells India Ltd.
QRG Towers, 2D, Sector -126, Expressway, Noida - 201 304 (UP), Ph. +91-120-3331000,
Customer Care No.: 08045 77 1313
Join us on Facebook at www.facebook.com/havells and share your ways to save the planet!
- Copyright Subsists. Imitation of trade dress, graphics and color scheme of this document is a punishable offence.
- Diagrams/figures in this document are for illustrative purposes only.
- Due to continuous product improvement, the product illustrated on this document may vary slightly from the actual product.
2. Clean the main body of product using only a cloth slightly dampened with
water or a mild soap solution.
3. Never use a caustic solution for cleaning.
4. The trimmer heads can be cleaned under water.
5. After cleaning, let the product and attachments completely dry and only
then power it ON.
6. Cleaning brush can also be used to clean the attachment heads.
7. After cleaning add 1-2 drops of oil onto the blades. Regular oiling
enhances the runtime.
8. Use the pouch to store the product and attachments.
9. This product may become warm during operation and/or charging, this
is normal.
10. Never tamper with moving parts.
Product Serial No.
IM_FD5002.indd 1-3 12-10-2020 17:26:03
Thank you for purchasing Multipurpose Facial Hair Remover. In order to make
you more comfortable while using the product, please read this user manual
carefully and keep it for future reference.
WARNINGS:
1. This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.Children shall not play with the appliance.Cleaning
and user maintenance shall not be made by children
without supervision.
2. Do not use in a bath or shower( Product should not come
in contact with water).
3. Do not use steel wool, abrasive cleaning agents or
aggressive liquids (such as alcohol, petrol or acetone) to
clean the product. Always clean the product with a damp cloth and non-
corrosive liquid cleaners.
4. Do not use the product near wound, inflammatory or allergic areas.
5. Do not make any alteration to the product or give it to any unauthorized
person for maintenance.
OPERATING INSTRUCTIONS
1. Round trimmer head
2. Eyebrow trimmer head
3. Touch switch
4. Main Power switch
5. Charge interface
6. Protective cap
7. Charging cable.
8. Cleaning brush
9. Lubricating oil
1 2 3
CHARGING
1. Before using the product for the first time, please charge it completely by
plugging it in for 8 hours. Connect the Micro USB Plug of the USB cable to the
charge interface situated at the bottom of the product and then plug the other
end of cable to a standard USB power adaptor (Rated charging Voltage 5 V DC/
Rated charging Current 1 A DC)
OPERATION
FIRST WAY
1. Please turn on the power switch at the bottom, and the white light is
long and bright.
2. Touch the sensing area of the front horizontal line with the finger for
2 seconds, and the product enters the working state.
3. In the working state, double tap the sensing area within 1 seconds and
the product will stop working.
4. In any of the above states, as long as you press the bottom power switch
button, it will turn off and enter the initial state.
Note: Cover the touch line completely with the finger, for quick sensing.
SECOND WAY
1. Press the power switch for 2 seconds to force the product to start (if
the touch function fails, the user can still use the power switch to use
the product).
INSTRUCTIONS FOR ATTACHMENT
1. Turn off the power switch of the machine.
2. Hold the trimmer head and twist counter clockwise and pull it out
upward.
3. Replace the new head and twist clockwise until the lock is tight.
HOW TO USE
1. Place the appropriate tool head components.
2. Use the round trimmer head close to nostril and ear hole, slowly insert in
nostril and ear and trim excessive nose hair and ear hair.
3. Use the eyebrow trimmer head against the hair growth direction, trim
eyebrows, sideburns, upper lips and facial hair.
4. After use, press the power switch at the bottom to turn off the product,
clean and wipe the trimmer head, and keep it properly.
CLEANING AND MAITENANCE
1. Before cleaning, disconnect the trimmer from the supply. Power button
should be OFF.
BATTERY INDICATIONS WHILE OPERATION BATTERY INDICATIONS WHILE CHARGING
STATE LED INDICATOR STATE LED DISPLAY
FULL BATTERY WHITE FULL CHARGE WHITE
LOW BATTERY RED BLINKING LOW BATTERY RED (LONG & BRIGHT)
2. If you are using a charger that meet all the requirements, the charging time is
around 8 hours, it may shift a little bit under different circumstances. The run time
after full charge is approx.90 minutes. (Twice a week, about 3 minutes each time,
and about two months after being fully charged).
Note: If you do not use this product for a long time, please charge it regularly for about
three months to keep the charging function of the trimmer normal.
6. Do not expose the product to fire and high temperature to avoid
malfunction, fire, or fire hazard caused by heat.
7. For additional protection, we advise you to install a leakage current
protection device (RCCB/ELCB) in the electrical circuit that supplies
the bathroom. This RCCB/ELCB must have a rated residual operating
current not higher than 30 mA.
8. The battery is designed specifically for this product. It undergoes internal
chemical reaction and expansive deformations. Besides, the product
may be deformed under the situation of high temperature or humidity.
Please stop using if the product is deformed or overheated to avoid
electric shock and fire hazard.
9. Please do not use the broken adapter and loose socket with loose jack,
to avoid electric shock, short circuit, fire, etc.
10. Please ensure the input power supply of adaptor to be
100 V-240 V AC voltages, to avoid fire, electric shock, etc.
11. The product should only be supplied with an adaptor output of
5 V DC / 1 A DC.
12. This product is a personal product. It is recommended not to be shared.
13. Do not insert the eyebrow head into the ear hole. The hole is more
than 5cm deep and may cause damage to the eardrum and mucous
membranes of the nose.
14. Please do not leave the product in an environment below 10 °C or above
40 °C for a long time.
15. Battery disassembly process - Remove the bottom housing cover
from the product. Take out the inner circuit out from the product body.
Remove the golden sensing film and cushion and cut off the battery
connection from the PCB. Then dispose the battery at stores that have
public recycling stations for discarded rechargeable batteries.
1
9
8
7
3
2
6
4
5
IM_FD5002.indd 4-6 12-10-2020 17:26:09
