Hawksmoor Toolstation SLM32F-ZE User manual

SKU: 62767
1200W Electric Lawnmower
Original User’s Instructions
READ BEFORE USE
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER REFERENCE

2
CONTENT
∫WHAT’S IN THE BOX ---------------------------------------------------------- 3
∫TOOLS REQUIRED --------------------------------------------------------- 4
∫SPECIFICATIONS -------------------------------------------------------------- 4
∫EXPLANATIONS AND SYMBOLS, CAUTIONS AND WARNINGS ---------- 5
∫IMPORTANT SAFETY WARNINGS -------------------------------------------- 8
∫PRODUCT DESCRIPTION AND IDENTIFICATIONS ------------------------ 13
∫ASSEMBLY AND OPERATING INSTRUCTIONS -----------------------------14
∫CARE AND CLEANING ------------------------------------------------------- 22
∫TROUBLE SHOOTING -------------------------------------------------------- 25
∫DECLARATION OF CONFORMITY / PERFORMANCE -------------------- 26
∫ENVIRONMENTAL INFORMATION ------------------------------------------27
∫GUARANTEE -------------------------------------------------------------------28
∫CUSTOMER SUPPORT ------------------------------------------------------- 28

3
WHAT'S IN THE BOX
If you do not have all these items, please contact:
www.coreservice.co.uk
Hotline: [phone]
Email [email protected]
Lawn mower x 1
Upper half grass box x 1 Lower half grass box x 1
Cord clip x 2 Upper handle
locking knob x 2
Upper handle
locking bolt x 2
Screw x 2
Lower handle x 2
Grass box handle

4
TOOLS REQUIRED
SPECIFICATION
Technical Data
Model SLM32F-ZE
Input voltage rating 230-240V~,50Hz
Input power 1200 W
No load speed 3500/min
Max. cutting width 320mm
Cutting height 25/45/65mm, 3 adjustments
Grass catcher volume 30L
Safety class Class II /
Weight Approx. 8.2kg
Protection degree IPX4
Sound values
Sound pressure level LpA: 73.7dB(A) K=1.12 dB(A)
Sound power level LWA: 93.7dB(A) K=1.12 dB(A)
Guaranteed sound power level LWA: 96dB(A)
Emission pressure level: 87dB(A) K=3dB
Vibration values
Hand arm vibration ah: ≤2.5 m/s2
Uncertainty K: 1.5m/s2
Cable H05VV-F, 2x0.75mm² , 10m, BS plug
The sound values have been determined according to noise test code given in EN 60335-2-77, using
the basic standards EN ISO 11201 and EN ISO 3744.
The sound intensity level for the operator may exceed 80 dB(A) and ear protection measures are
necessary.
The declared vibration value has been measured in accordance with a standard test method (according
to EN 60335-2-77) and may be used for comparing one product with another. The declared vibration
value may also be used in a preliminary assessment of exposure.

5
WARNING! Depending on the actual use of the product the vibration values can differ
from the declared total! Adopt proper measures to protect yourself against vibration
exposures! Take the whole work process including times the product is running under
no load or switched off into consideration!
Proper measures include among others regular maintenance and care of the product
and cutting attachments, keeping hands warm, periodical breaks and proper planning
of work processes!
EXPLANATIONS AND SYMBOLS, CAUTIONS AND WARNINGS
This instruction manual accompanies this lawnmower. It contains important information
concerning assembly, start-up and handling. Before using the lawnmower, read the
instruction manual carefully. This particularly applies to the safety notes. Failure to heed this
instruction manual may result in severe injury or damage to the lawnmower. The instruction
manual is based on the standards and rules in force in the European Union. Store the
instruction manual for future use. If you pass the lawnmower on to third parties, please be
absolutely sure to include this instruction manual.
You can request an electronic version of these instructions from our customer service centre.
Explanation of symbols
The following symbols and signal words are used in this instruction manual, on the lawnmower or on
the packaging.
Read the user manual before operating the machine.
Warning! Danger!
Wear correct Personal Protective Equipment (PPE) when operating this machine such
as eye protection, ear protection and respiratory equipment where necessary.
IMPORTANT! Wear gloves to protect your hands.

6
Wear safety boots to protect your feet.
Guaranteed sound power level value in 96dB.
The product complies with the applicable European directives and an evaluation
method of conformity for these directives was carried out.
UK Conformity Assessed
WEEE symbol. Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local Authority or local
store for recycling advice.
Do not expose the product to rain or wet conditions.
Double insulation.
Objects thrown out by the product could hit the user or other bystanders. Always
ensure that other people and pets remain at a safe distance from the product when it
is in operation. In general, children should be kept away
from the area where the product is being operated.
Beware of sharp blades. Blades continue to rotate after the motor is switched off.
Remove the plug from the mains before performing any maintenance or if the cord is
damaged.
The cutting device will continue to rotate after the product is switched off. Wait until
all components have
completely stopped before performing any work on the product.

7
Switch the lawnmower off and disconnect it from the power supply before
assembling, cleaning, making adjustments, performing maintenance, storing or
transporting the machine.
Keep supply flexible cord away from cutting device.
Always make sure the rear flap is closed in position when working
the mower.
WARNING!
This appliance should be connected to your mains supply using an RCD (Residual
Current Device). The operating current of this device must be less than 30mA.
Contact an electrician if you are unsure on how to proceed.
For safety reasons, this lawnmower is not to be used by children, young people
under the age of 16 or any other people who are not acquainted with these operating
instructions.

8
IMPORTANT SAFETY WARNINGS
Proper use
1. Operate the product only in daylight or in good artificial light.
2. Avoid operating the product in wet grass.
3. Always be sure of your footing on slopes.
4. Walk, never run.
5. Do not use this appliance in wet conditions.
6. Mow across the face of slopes, never up and down.
7. Exercise extreme caution when changing direction on slopes.
8. Do not mow excessively steep slopes.
9. Use extreme caution when reversing or pulling the product
towards you.
10.Stop the blades if the product has to be tilted for transportation,
when crossing surfaces other than grass and when transporting
the product to and from the area to be mowed.
11.Switch on the motor carefully according to the instructions and
with your feet well away from the blades.
12.Do not tilt the product when switching on the motor except if
the product has to be tilted for starting. In this case do not tilt
it more than absolutely necessary and lift only the part which is
furthest away from the operator.
13.Do not put hands or feet near or under rotating parts. Keep clear
of the discharge opening at all times.
14.Do not transport the product while the mains power is
connected.
15.Stop the product and remove the plug from the socket. Make
sure that all moving parts have come to a complete stop:
− Whenever you leave the product unattended.
− Before clearing blockages or unclogging the chute.

9
− Before checking, cleaning or working on the product.
− After striking a foreign object. Inspect the product for
damages and replace or repair any damaged parts before
restarting the product.
16.If the product starts to vibrate abnormally:
− Inspect for damage.
− Replace or repair any damaged parts.
− Check and tighten any loose parts.
Safety notes
WARNING!
DO NOT TOUCH ROTATING BLADES.
− This machine can cause serious injury. Read the instruction
manual carefully for the correct handling, preparation,
maintenance, starting and stopping of the appliance. Be familiar
with the controls and the proper use of the appliance.
Read and understand the operator’s manual and observe the
warnings and instruction labels affixed to the appliance.
− Never allow children or people unfamiliar with these instructions
to use the appliance. Never operate this appliance when tired or
under the influence of alcohol, medication or drugs.
− Use appropriate tools. This product is intended for private use
only, not for any commercial applications. It may not be used for
any purposes other than those described in this manual.

10
Work Area Safety
− Keep work areas clean. Cluttered areas can cause accidents.
− Keep all bystanders, children and pets at least 5 metres away.
The operator or user is responsible for any accidents or hazards
occurring to other people or their property.
Personal Safety
− Wear the correct personal protective equipment (PPE). Always
wear eye protection. Protective equipment such as a dust mask,
non-skid safety shoes or gloves used for appropriate conditions
will reduce the risk of personal injury.
− Dress appropriately. Do not wear loose clothing or jewellery, as
these can be caught in moving parts. Preferably wear nonslip
footwear when working outdoors. Long hair should be tied back
out of the way.
− Stay alert and use caution and common sense when operating
the lawnmower. A moment of lapsed concentration while
operating the lawnmower may result in serious personal injury.
− This appliance can be used by persons aged 18 years and
above and people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved.
− Children should be supervised to ensure that they do not play
with the machine.
− Read the instructions carefully. Be familiar with the controls and
the correct use of the product.
− Never allow children or people unfamiliar with these instructions
to use the product. Local regulations can restrict the age of the
operator.
− Never operate the product while children, other people or pets
are nearby.

11
− Keep in mind that the operator or user is responsible for any
accidents or hazards occurring to other people or their property.
Operational Safety
− Be certain that all parts of the machine are fully tightened before
operating the machine. Check periodically for tightness during
use to avoid serious injury.
− While operating the product always wear substantial footwear
and long trousers. Do not operate the product when barefoot
or wearing open sandals. Avoid wearing clothing that is loose
fitting or that has hanging cords or ties.
− Thoroughly inspect the area where the product is to be used
and remove all objects which could be thrown by the product.
− Before use, always visually inspect to see that the blade, blade
bolt and the blade assembly are not worn or damaged.
− Replace worn or damaged components in sets to preserve
balance. Replace damaged or unreadable labels.
− Before use, check the supply and extension cord for signs of
damage or aging. If the cord becomes damaged during use,
disconnect the cord from the mains power immediately. DO
NOT TOUCH THE CORD BEFORE DISCONNECTING THE
MAINS POWER.
− Do not use the product if the cord is damaged or worn. If the
cord requires replacement this should only be carried out by the
service agent or a similarly qualified person.
− Keep all nuts, bolts and screws tight to be sure the product is in
a safe working condition.
− Check the grass collector frequently for wear or deterioration.
− Be careful during the adjustment of the product to prevent
entrapment of the fingers between moving blades and fixed
parts of the product.

12
− When servicing the blades be aware that, even though the
power source is switched off, the blades can still move.
− Replace worn or damaged parts for safety. Use only genuine
replacement parts and accessories.
Checking the lawnmower and product contents
WARNING!
RISK OF DAMAGE!
If you are not cautious when opening the packaging with
a sharp knife or other pointed objects, you may easily
damage the lawnmower. Therefore, be very careful when
opening.
1. Take the lawnmower out of the packaging and check whether
the appliance or the individual parts show any signs of damage.
If any parts are missing or damaged, do not use the lawnmower.
Contact the manufacturer at the service address specified on
the warranty card.
2. Check to make sure that the delivery is complete (see WHAT'S
IN THE BOX).

13
PRODUCT DESCRIPTION AND IDENTIFICATIONS
4
11
1
2
3
5
8
6
7
14
15
10
9
12
13
1617
1 Upper handle
2 Upper handle locking knob
3 Lower handle
4 Transportation handle
5 Motor housing
6 Grass collection box
7 Grass full indicator
8 Cord clip
9 Cable
Not all the accessories illustrated or described are included in standard delivery.
10 Lock off button
11 Switch lever
12 Collection box handle
13 Safety rear flap
14 Rear wheel
15 Front wheel
16 Wheel shaft slot
17 Blade

14
ASSEMBLY AND OPERATING INSTRUCTIONS
Assembly
Mounting the lower handle
1. Insert the lower handle into the supports. Ensure the mounting holes in the lower handle are
aligned with the ones in the supports (See Fig A).
A
2. Secure the lower handle with the screws and tighten them with a suitable crosshead screwdriver.
Mounting the upper handle bar
1. Remove the bolts from the knobs and keep them handy.
2. Attach the upper handle to the lower handle and align the holes in the upper handle with the ones
in the lower handle (See Fig B).
B
A
B

15
3. Secure the upper handle with the knobs and bolts to the lower handle and tighten the knobs
clockwise.
4. Fix the power cord using the cord clips to the handle (See Fig C).
C
Mounting the grass collection box
1. Fit the upper part of the grass collection box onto the lower part by fixing all the outer clips
correctly (See Fig D).
D
2. Fit the grass box handle onto the top of the grass catcher so that it clicks into place (See Fig E).
E
C
D
E

16
3. Lift the safety rear flap with one hand and hook in the grass collection box. Release the rear flap
to secure the grass collection box in position. (See Fig F& G).
F
G
F
G

17
Connecting to the power supply
WARNING! For your safety, the extension cord must be suitable for outdoor use with
sockets that are protective against splashing water!
Extension cords that are safe to use are:
- if rubber insulated, ordinary tough rubber sheathed flexible cord (code designation 60245 IEC53);
- if polyvinyl chloride insulated, ordinary polyvinyl chloride sheathed flexible cord (code designation
60227 IEC 53).
Ensure the extension cord is of the proper size and type for your product(≥ 1.5mm2)!
Always use a residual current supply (RCD) protected supply!
1. Connect the plug to the main socket. (See Fig I)
I
I

18
Operation
Cutting height adjustment
Adjust the cutting height according to the needs of your lawn.
The cutting height depends on the kind of lawn and its actual height. When mowing high grass, start
with the maximum cutting height and make a second cut with a lower cutting height.
1. Release the start lever and disconnect the product from the power supply.
2. Pull the rear and front shafts out and place them into the correct slot for the desired cutting
height. (See Fig J&K)
3. Make sure that the rear and front shafts are at the same level. (See Fig J&K)
J
K
NOTE! Always ensure the shafts clicks back into the slot.
J
K

19
Grass collection box
Always attach the grass collection box when using the product for grass collection. Always carry the
grass collection box by its handle.
Empty the grass collection box frequently during use. Do not wait until it is completely full. We
recommend emptying it when it is half full.
If the collection box is empty or not filled with grass, the grass full indicator will be in a status of flap-
floats. (See Fig L)
L
If the collection box is full of grass the grass full indicator will in a status of flap-falls-down. (See Fig M)
M
NOTE! A full grass collection box will reduce the performance of this product.
1. Lift the safety rear flap and lift the grass collection box off the hooks.
2. Remove the grass clippings from the discharge chute into the grass collector. Use a proper tool
such as a brush.
3. Remove the grass collection box.
4. Empty the grass clippings onto a compost heap.
5. Re-fit the grass collection box on to the hooks.
L
M

20
Switching on/off
1. Ensure the switch lever is released.
2. Press the lock-off button(1). (See Fig N)
3. Pull the switch lever (2) towards the handle and hold in position. (See Fig N)
N
2
1
4. Release the lock-off button once the product is running.
5. Release the switch lever to switch the product off. (See Fig O)
O
NOTE! The product can only be started by pressing the lockoff button first, followed by squeezing
the start lever. Reverse operation will not start the product.
NOTE! The cutting device will continue to rotate for a short period after the product has been
switched off.
N
O
