HealTech Electronics Speedohealer v4 User manual

SHv4_KT1_InstallGuide_en.pdf [rev. 002] - 1 -
http://www.speedohealer.com
Install Guide for SH-KT1 Harness Kit
For use with the following KTM motorcycles:
950 (2003-2007), 690 (2008-2010), 990 (2005-2010), 1190 RC8 (2008-2010)

- 2 –
Disclaimer: Donotattempttoinstalltheproductifyoudon’thavebasicmechanicalskills.
The SpeedoHealer is intended to improve speedometer accuracy. However, HealTech
Electronics Ltd. and its distributors shall not be liable for any loss, damage or penalties
caused by improper installation or inaccurate speed readings.
1. Lift down/remove the front fairing with headlight.
2. Locate the Speed Sensor coupler. It is behind the instrument cluster: 3-pole,
white, triangular connector.
If in doubt, trace the cable from the front wheel sensor until you find the coupler.
Confirmation:
Separate the Speed Sensorcoupler(youmightneedtouseasmallflathead
screwdrivertogetthecouplerapart).Rotate the front wheel while the ignition is
on. Does the speedometer show 0, turn the ignition off and proceed to the next
step. Otherwise, try again since you have disconnected something else.
3. After separating the Speed Sensor coupler, plug in boththemaleandfemale
3-pole SH harness connectors. Make sure the connectors are fully seated.
4. Connect the 4-pole SH harness connector to the SH box.
5. Check whether the SH is installed and working properly:
- Have the ignition OFF.
- Press SEL and keep it depressed while you turn ignition ON.
[t] (test) is now indicated. Release the button.
The speedo should indicate a number other than zero.
- Rotate the frontwheel.
[t] should be blinking as the wheel turns.
- Press SEL to exit from Test mode.
The speedometer should work the same way as with no SH installed.
If the tests fail, disconnect the 3-poleand4-pole connectors and check
whether the connector pins are bent or pushed out of position.
6. Mount the SH box behind the instrument cluster.
Secure the unit with the supplied cable ties and Velcro strips.
Do not bend the SH harness near the SHconnector.Otherwisethepinsmaybreak
over time.
To minimize cable stress, use thesuppliedcabletiestofastentheunitandthe
harness to a solid part of the bike. Make sure that the SH switches won’t be hit
accidentally.
7. IfyouwishtousetheTopSpeedRecallfeature,connect the 2-pole plug of the
remote button. Secure the remote button at the dashboard with the supplied cable
ties.
Ifyouwish,youcaneasilychangetheharnesslengthorreplacetheremotebutton
per your liking (any SPST momentary “push-to-make” switch can be used).
8. Please visit www.speedohealer.com and use our on-line calculator to generate
set-up instructions for your SH. Alternatively, refer to the User’s Guide for
instructions.
