Helios Outland Firebowl FMPPC2B-875 User manual

From the Backyard to the Backwoods®
OWNER’S MANUAL
MANUFACTURED BY FMI BRANDS INC. 101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5
USA, Canada Toll Free: 1-888-514-1663 | Tel: [phone] | Email: [e-mail]
Hours of Operation: 8:30AM - 4:00PM (Pacific Time) | Customer Service in English only
58,000 Btu/h
Model number FMPPC2B-875
® Registered trademark of FMI Brands Inc.
The OUTLAND flame is a registered trademark of FMI Brands Inc.
D.875.000.V0

WARNING:
Don’t burn yourself! Do not touch or handle the firebowl when hot! To avoid injury always allow
the firebowl to cool down for at least 30 minutes before moving and handling the appliance.
DANGER:
If you smell gas:
1 Shut off gas to the appliance.
2 Extinguish any open flame.
3 If odor continues, leave the area immediately.
4 After leaving the area, call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion, which could cause
property damage, personal injury, or death.
WARNING:
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
WARNING: For outdoor use only.
Installation and service must be performed by a qualified installer, service agency, or the gas
supplier.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which
has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such
as a camper, tent, car, or home.
Model number FMPPC2B-875 - Tested by CSA International
ANS Z21.97-2017/CSA 2.41-2017 Outdoor Decorative Gas Appliances
En-1 D.875.000.V0
OUTLAND FIREBOWL®OKANAGAN - OWNER & SAFETY MANUAL
Owner & Safety Manual

En-2
1-888-514-1663 | WWW.OUTLANDLIVING.COM
LP SAFETY:
a. Do not store a spare LP-gas cylinder under or near this
appliance.
b. Never fill the cylinder beyond 80 percent full.
c. If the information in “(a)” and “(b)” is not followed exactly, a
fire causing death or serious injury may occur.
Do not use this appliance under overhead combustible surfaces.
MINIMUM CLEARANCES:
• Bottom: Non-Combustible Surface
• Top: 2 m / 80 in
• Sides: 0.91 m / 36 in
• For Installation on (or over) non-combustible floors only
Input: 58,000 Btu/h (17 kW) and manifold pressure:
11 in wc (2.74 kPa)
Min. gas supply for input adj. 11 in wc (2.74 kPa)
Max. gas supply: 11 in wc (2.74 kPa)
Injector Size* 2.32 mm
* Injector size marked clearly on the gas valve orifice.
Type of Gas: Propane (LP)
This appliance shall be used only outdoors in a well-ventilated
space and shall not be used in a building, garage or any other
enclosed area.
The gas supply must be turned off at the LP-gas supply cylinder
when this appliance is not in use.
Indoor storage of this appliance is permissible only if the cylinder
is disconnected and removed from the appliance.
Cylinders must be stored outdoors in a well-ventilated area out of
the reach of children.
Disconnected cylinders must have threaded valve plugs tightly
installed and must not be stored in a building, garage or any other
enclosed area.
The gas pressure regulator provided with this appliance must be
used and must be the same model as supplied with the unit.
The cylinder supply system must be arranged for vapor
withdrawal.
Cylinders used with this unit must have a collar to protect the
cylinder valve.
An approved LP-Cylinder stabilizer, such as the stabilizer ring
included, must be used when the appliance is in use.
Replacement parts and a list of such parts are available from FMI
Brands Inc. through the contact information provided on the last
page of this Manual.
WARNING:
Please ensure that all adults and children which use or are
near a unit in use are aware of the hazard of high-surface
temperatures present on the unit during use and should use
caution and stay away to avoid burns or clothing ignition.
Carefully supervise young children in the area of this
appliance. Clothing or other flammable materials should
not be hung from the appliance or placed on or near the
appliance. Any guard or other protective device removed for
servicing the appliance must be replaced prior to operating
the appliance.
Installation and repair should be done by a qualified
service person. The appliance should be inspected before
use and at least annually by a qualified service person.
More frequent cleaning may be required as necessary. It is
imperative that control compartment, burners and circulating
air passageways of the appliance be kept clean.
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read
the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
WARNING:
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.

En-3 D.875.000.V0
OUTLAND FIREBOWL®OKANAGAN - OWNER & SAFETY MANUAL
Owner & Safety Manual
LP Cylinder
Appliance Tank Ring
Minimum
0.91 m / 36 in
LEAK TEST: Apply the solution to the LP gas
delivery system at points:
1. Firebowl Valve Coupling
2. Gas Hose Regulator
3. Cylinder Valve Coupling
Tank Ring
LEAK TEST: Apply the solution to the LP gas delivery system at points.
Valve coupling regulator & Cylinder Coupling.
2. Gas Hose
Regulator
Heat Sensitive
Hand Wheel
Cylinder
Shut Off
Valve
Check Valve
Nipple with Flow
Limiting Device
3. Cylinder Valve
Coupling
!
Caution:
Trip Hazard!
All LP cylinders to be used with this appliance must be:
a. Constructed and marked in accordance with the U.S.
Department of Transportation (DOT) Specifications for LP-
Gas Cylinders, or the Standard for Cylinders, Spheres and
Tubes for Transportation of Dangerous Goods, CAN/CSA
B339, as applicable.
b. Provided with a listed overfilling prevention device.
c. Provided with a cylinder connection device compatible with
the connection for the appliance.
d. Only a 9 kg / 20 lb LP gas cylinder is to be used for this
appliance, approximately 46 cm / 18 in high & 30 cm / 12 in
diameter.
e. The use of an approved LP gas cylinder stabilizer, such as the
one included, must be used when using this appliance in order
to prevent the LP gas cylinder from tipping over.
CONNECTION:
1. Be sure the cylinder valve and appliance valves
ar e “o f f”.
2. Place full LP gas cylinder on tank stabilizer ring.
3. Center the nipple in the cylinder valve and hold in place.
4. Using the other hand, turn the hand wheel clockwise until there
is a positive stop. Do not use tools.
5. Hand tighten only. When making the connection,
hold the regulator in a straight line with the cylinder valve, so
as not to cross thread the connection.
6. Leak test the connection. See section named “LEAK TEST”.
LEAK TEST:
1. DO NOT USE OR PERMIT SOURCES OF IGNITION
IN THE AREA WHILE DOING THE LEAK TEST.
THIS INCLUDES SMOKING.
2. Leak testing should be done once per year or whenever the
LP gas cylinder or any other gas system part is taken apart,
serviced or replaced, whichever is more frequent.
3. Ensure all gas system coupling joints are tight and properly
attached.
4. Prepare a leak testing solution of half liquid detergent
and half water.
5. Apply the solution to the LP gas delivery system at points as
shown in illustration indicated on page 3.
6. If parts of the fitting begin to produce bubbles, spray liquid, or
if you smell liquid propane gas, immediately close the valve on
the tank.
7. Wait 5 minutes for any gas to dissipate.
8. After waiting for 5 minutes, the leak(s) must be stopped by
tightening the loose joints, if possible, or by replacing the
faulty parts(s) with the part(s) recommended by the appliance
manufacturer.
WARNING:
Ensure that the appliance is kept at a minimum distance of
0.91 m / 36 in from the gas cylinder.

En-4
1-888-514-1663 | WWW.OUTLANDLIVING.COM
THE APPLIANCE IS NOT TO BE USED UNTIL
ANY LEAK IS CORRECTED.
A gas appliance repairman or LP gas dealer should be called if
attempts to stop the leak(s) are unsuccessful and, in such case, the LP
gas supply must be shut off at the cylinder valve or the cylinder must
be removed from the appliance until the leak(s) is corrected.
Should any part of this appliance (including the burner) become
soiled or dirty, wipe lightly with a damp cloth. Do not use flammable
or corrosive cleaning products on or near this unit.
Ensure the gas hose is placed in an area where it is unlikely to be
tripped over (such as pathways or trails) or subject to other accidental
damage.
Keep the appliance area clear and free from combustible materials,
gasoline and other flammable vapors and liquids.
Solid fuels shall not be burned in this appliance.
Installation must conform with local codes or, in the absence of local
codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54,
Natural Gas and Propane Installation Code, CSA B149.1 or Propane
Storage and Handling Code, B149.2, or the Standard for Recreational
Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV Series,
Recreational Vehicle Code, as applicable.
PRE-IGNITION INSPECTIONS
GAS HOSE INSPECTION
Clean and inspect the hose before each use of the appliance.
Attention: If there is evidence of abrasion, wear, cuts, or leaks,
the hose must be replaced prior to the appliance being put into
operation.
Only use a replacement hose by OUTLAND Living.
BURNER & ORIFICE INSPECTION
Inspect the burner prior to each use. Ensure the orifice holes are
not plugged and the burner tube is not damaged, or compromised.
The burner must be replaced prior to the appliance being put into
operation if there is evidence of damage. Replacement burners are
available from FMI Brands Inc.
BURNER TUBE INSPECTION
Inspect the burner tube under the appliance and ensure the mesh
screen is in place, prior to each use.
ATTENTION: If the screen is dislodged perform an insect nest
inspection, prior to ignition. See section ‘REMOVING INSECT
NESTS’.
