HERBORNER pumpentechnik UNIVERS-T User manual

Operating manual
The single-stage submerged motor pump for sewage:
compact, powerful and effective at the same time.
UNIVERS-T
Translation of the original
operating manual
A-RT 33 GB
Herborner Pumpentechnik GmbH & Co KG | Littau 3-5 | DE-35745 Herborn | Phone: [phone] / 933-0
Fax: [phone] / 933-100 | E-mail: [email protected] | www.herborner-pumpen.de

Copyright
The transfer and duplication of this document and utilisation
and communication of its content is prohibited, unless expli-
citly stated otherwise. Non-compliance with this stipulation
will result in compensation for damages.
All rights reserved.

Herborn, 20/04/2016 ....................................................................
Signature
(Management)
EC Declaration of Conformity
Herborner Pumpentechnik GmbH & Co KG
Littau 3-5, DE-35745 Herborn
Ms J. Weygand is authorised to create the technical documentation.
Herborner Pumpentechnik GmbH & Co KG
J. Weygand
Littau 3-5, DE-35745 Herborn
We hereby declare that the
submerged motor pump for sewage
UNIVERS-T / -SG / -PO
complies with all the pertinent provisions of EC Machinery Directive 2006/42/EC.
The machine also complies with all pertinent provisions of the following EC directives:
Directive 2014/30/EU
- Directive 2014/34/EU (for explosion protection version)
Original
Herborner Pumpentechnik GmbH & Co KG | Littau 3-5 | DE-35745 Herborn | Phone: [phone] / 933-0
Fax: [phone] / 933-100 | E-mail: [email protected] | www.herborner-pumpen.de

Table of contents
4
Table of contents
1 General Information.................................... 6
1.1 Intended use ................................................. 6
1.2 Exploded view............................................... 8
1.3 Wear parts..................................................... 9
1.4 Technical data ............................................. 10
1.4.1 Model designation....................................... 10
1.4.2 Impellers...................................................... 10
1.4.3 Installation................................................... 10
1.4.4 Shaft sealing ............................................... 11
1.4.5 Drive............................................................ 11
1.4.6 Dimensions, weights, performance data..... 12
1.4.7 General data ............................................... 12
2 Safety ......................................................... 13
2.1 Notes/explanations...................................... 13
2.1.1 Machine identification.................................. 13
2.2 Integrated safety systems (optional) ........... 14
2.3 Connections on the pump ........................... 15
2.4 Safety measures ......................................... 15
2.5 Obligations of the operating company......... 15
3 General Hazard Warnings ........................ 17
3.1 Dangers....................................................... 17
3.2 Danger zones on the pump......................... 17
3.3 Assembly, operation and maintenance perso-
nnel ............................................................. 17
3.4 Installation of replacement parts and wear
parts ............................................................ 17
3.5 Shut-off procedures..................................... 18
4 Transport.................................................... 19
4.1 Scope of delivery......................................... 19
4.2 Transport and packaging ............................ 19
4.2.1 Delivery (including spare parts and replace-
ment parts).................................................. 19
4.2.2 Intermediate storage ................................... 19
4.3 Transportation to the site of installation (by the
customer) .................................................... 19
4.3.1 Transportation with a forklift truck ............... 20
4.3.2 Transportation with a crane......................... 20
5 Installation/Fitting ..................................... 21
5.1 Installation................................................... 21
5.1.1 UNISCHACHT installation example ............ 22
5.2 Dimensions ................................................. 23
5.2.1 Dimensions wet-well installation ................. 23
5.3 Technical data ............................................. 27
5.3.1 Technical data UNIVERS-T......................... 27
5.3.2 Motor data UNIVERS-T-SG ........................ 32
5.3.3 Motor data UNIVERS-T-PO ........................ 33
5.4 Cable connection ........................................ 34
5.5 Electrical connection ................................... 36
5.6 Motor protection .......................................... 36
5.7 Direction of rotation check........................... 37
5.7.1 Changes in direction of rotation .................. 38
5.8 Motor connection diagrams......................... 38
5.8.1 PTC thermistor connection (option) ............ 39
5.9 Frequency converter operation ................... 39
5.10 Laying the pipelines .................................... 39
5.11 Frost protection ........................................... 39
6 Commissioning ......................................... 41
6.1 Operating modes and connecting frequency41
6.2 Starting up................................................... 42
7 Maintenance/Cleaning .............................. 43
7.1 Maintenance................................................ 43
7.2 Maintenance instructions during prolonged
periods of inactivity...................................... 44
7.3 Bearing lubrication ...................................... 45
7.4 Seals ........................................................... 45
7.5 Cleaning...................................................... 45
7.6 Tightening torques for bolts and
nuts 46
7.7 Casing aeration........................................... 46
7.8 Filling and changing the oil.......................... 46
7.9 Disposal ...................................................... 47
8 Disturbance/Cause/Trouble Shooting ..... 48
9 Disassembly/Assembly ............................ 50
9.1 Disassembly................................................ 50
9.2 Assembly..................................................... 53
Table of figures
Figure 1a Exploded view (installation T) ....................... 8
Figure 1b Exploded view (installation S) ....................... 8
Figure 1c Exploded view (installation H)....................... 8
Figure 2 Name plate.................................................. 14
Figure 3 Connections on the pump .......................... 15
Figure 4 Transporting with a crane............................ 20
Figure 5 Unischacht .................................................. 22
Figure 6a Dimensions (S model)................................. 23
Figure 6b Dimensions (Individual pump station) ......... 23
Figure 6c Dimensions (T model)................................. 23
Figure 6d Dimensions (H model)................................. 26

General information
5
Danger!
Pumping flammable or explosive li-
quids is life-threatening.
Only use pumps of explosion-proof
design (Ex) in potentially explosive
atmospheres in accordance with the
corresponding specifications.
Caution!
Pumping any liquid which is chemically
aggressive to the pump material or
contains abrasive components can
destroy the pump.
Use bronze or stainless steel as the
pump material for these media.
The media used for the intended operation of the pump and
the associated hazards are the sole responsibility of the
operating company.
Danger!
Air bubbles or accumulations of gas
around the mechanical seal create a
potentially fatal explosive atmosphere.
Provide a constant supply of pumped
media to the supply and pressure pipes
as well as to the interior of the pump
that is in contact with the liquid.
Provide appropriate monitoring
measures to ensure this.
1 General Information
1.1 Intended use
The close coupled sewage pump UNIVERS-T is predomi-
nantly used in process engineering plants. It is especially
suitable for delivering uncleaned waste water and sewage.
Close coupled sewage pumps also contribute to the unin-
terrupted operation of wastewater transport systems, pump
stations and treatment plants in hazardous areas with the
highest possible degree of operational safety.
Model: UNIVERS-T
Wastewater containing long fibre and solid materials, media
containing gas and air, sludge, sewerage and water supply
(see section 1.4.2 Impellers).
Model: UNIVERS-T-SG
Pumping media with erratic and extreme contamination due
to abrasive contents.
Model: UNIVERS-T-PO
Pumping media with components and the requirement to
crush them (fishing industry, vegetable production, etc.).
Each pump is solely intended for the purpose previously
specified. Any other application or applications extending
beyond the stated purpose or alterations made to the pump
without prior written agreement with the manufacturer are
not permitted. The manufacturer is not liable for damages
resulting from unintended use. The operating company bears
sole responsibility.
Notice!
Missing safety devices can damage the pump.
The pumping station must conform to the respective di-
rectives and all safety devices must be installed and fully
operational.
Only then should the pump be put into service.

General information
6
Important!
Intended use also includes complying with the operating
and maintenance conditions specified by the manufacturer.
The explosion-proof centrifugal pumps satisfy the require-
ments of electrical equipment for use in potentially explosive
atmospheres in accordance with
Directive 94/9/EC of the European Council dated 23 Mar-
ch, 1994, for intended use in potentially explosive atmos-
pheres for
device group II category 2.
Operational conditions for Zone I and Zone II.
II 2G EExd IIB T4
Explosion protection symbol
Device group
Device category
Explosive gas atmosphere
Explosion-proof device
Pressure-proof encapsulation
Explosion group
Temperature class (max. surface
temperature 135°C)
Temperature class T4 means that the pumps also meet the
requirements of temperature classes T1 to T3.
Danger!
Exceeding the limit values specified in
the order and on the name plate can
result in a potentially fatal explosive
atmosphere.
Comply with the limit values.
The explosion protection marking on the pump refers only to
the pumping component. The motor has its own explosion
protection marking.

General information
7
1.2 Exploded view
Installation T
Figure 1a Exploded view (T model)
1)
Special construction
2) With closed multi vane impeller only
3)
Not available with mechanical seal with locking screws
Accessories 4
5) depending on size
181 4)
162
512 2)
900.1
930
550
230
400.1
903.2
903.1
412.3
1)
004 1)
400.2
412.1
551.1
932.1
113
433.1
007 1)
903.3
903.6
903.4
903.5
932.2 3)
412.2
551.2 3)
420
433.2
940
819
805
320.2
164 1) 101
320.1
900.2 1)
011
4)
013 4)
410.1 4)
710 4)
410.2
4)
012
4)
400.3
4)
182
4)
183
4) 5)
Installation S
DN 50/150
Figure 1b Exploded view (S model)
Installation H
Figure 1c Exploded view (H model)
DN 200/300

General information
8
Individual components
004 Star handle
007 Seal electrode
011 duck foot
012 retainer
013 pipe support
014 flange bend
101 Pump casing
113 Intermediate casing
162 suction cover
164 Cleaning cover
181 Pump support
182 foot
183 Support foot
230 Impeller
320.1 Anti-friction bearing(non-drive side)
320.2 Anti-friction bearing(drive side)
400.1 Gasket
400.2 Gasket
400.3 Gasket
400.4 Gasket
400.5 Gasket
410.1 Profile seal
410.2 Profile seal
412.1 O-ring
412.2 O-ring
412.3 O-ring
420 Shaft seal ring
433.1 Mechanical seal
433.2 Mechanical seal
512 wear ring
550 Disc
551.1 spacer disc
551.2 spacer disc
710 pipe
805 submersible motor
819 Motor shaft
897 guide piece
900.1 Screw
900.2 Screw
903.1 Screwed plug
903.2 Screwed plug
903.3 Screwed plug
903.4 Screwed plug
903.5 Screwed plug
903.6 Screwed plug
930 screw locking device
932.1 circlip
932.2 circlip
940 Key
1.3 Wear parts
The specifications relating to the selection of wear parts are
based on the demand for a two-year operation in accordance
with DIN 24296 (pump and pump units for liquids - spare
parts - selection and procurement).
Wear parts Number of pumps
(if available) 1 2 3 4 5 6-7 8-9 10-...
Impeller 1 1 1 1 2 2 2 20%
suction cover 1 1 1 1 2 2 2 20%
mechanical seal on
pump side
1 1 1 2 2 2 3 25%
mechanical seal on drive
side
1 1 1 2 2 2 3 25%
Anti-friction bearing set 1 1 1 2 2 2 3 25%
shaft seal ring on drive
side
1 1 1 2 2 2 3 25%
wear ring 1 2 2 2 3 3 4 50%
Seal set (without motor) 2 4 6 8 8 9 12 150%

General information
9
1.4 Technical data
1.4.1 Model designation
Example:
TWRH/101/2-6SP-240-PO-C-EX-T-W1-S
design sub-
merged motor
pump for se-
wage
Impeller type
Q = Open single
and twin vane
impeller
K = Closed multi
vane impeller
W = Vortex impeller
Construction series
UNIVERS
Pump model
S = small
H = medium
= large
X = 2-pole
Nominal diameter
DN [mm]
Impeller version e.g. 2,
A, B (if different than
standard)
Number of blades
Impeller version (if different
than standard)
Impeller diameter [mm]
Version
= UNIVERS Standard
PO = UNIVERS with slitting wheel
SG = UNIVERS with rubber coating
Motor model
= Standard
C = Cooling jacket version
Permitted use
= Standard
EX = Explosion protection
Installation
stationary wet installation
transportable wet installation
horizontal dry installation
vertical dry installation
Materials
W0 = Mixed materials
W1 = All castings made from
EN-GJL-250
W2 = all castings apart from the
impeller manufactured from EN-
GJL-250, impeller manufactured
from G-CuSn10
W3 = all castings manufactured from G-
CuSn10
W4 = All castings made from 1.4408
W5 = All castings made from EN-
GJS-400-15
W6 = All castings made from 1.4439
Construction
= Standard
S = Special construction

General information
10
Installation H = Horizontal installation for
fully submersible spaces
with or without cooling
jacket
Installatin V = Vertical installation for fully
submersible spaces with
or without cooling jacket
1.4.4 Shaft sealing
The shaft sealing on the pump side is effected in all models
via a maintenance-free mechanical seal, which is indepen-
dent of the direction of rotation and made from wear-resistant
silicon carbide (SiC). Depending on the pump model, either a
shaft seal ring or a mechanical seal made of carbon/chromi-
um molybdenum cast seals the drive side. The intermediate
casing is filled with lubricating oil to lubricate and cool the
mechanical seals. This oil even enables a short-term dry
run. The intermediate casing can be optionally monitored
for leaks using a sealing electrode.
Caution!
Dry running the pump will destroy the
mechanical seal!
Ensure there is adequate cooling and
lubrication for the sliding surfaces.
1.4.2 Impellers
Open single vane impeller (Q) with automatic
non-clogging system for pumped media with
the roughest solids and for an operationally
reliable supply output (practically clog-free).
Open twin vane impeller (Q) with automatic
non-clogging system for pumped media
with rough solids and for a gentle supply
output. High running smoothness due to
symmetrical form.
Vortex impeller (W) for pumped media with
very rough solids and gas pockets and
trapped air.
Closed multi vane impeller (K) for dirty pum-
ping media contaminated with solids.
Rubber coated vortex impeller (W) for ab-
rasive pumping media (UNIVERS-T-SG).
Vortex impeller (W) with attached slitters for
pumping media that contain substances to
be crushed (UNIVERS-T-PO).
1.4.3 Installation
The pumps can be delivered in various installations:
Installation S = Stationary installation with
suspension device with or
without cooling jacket
Installation T= Transportable installation
with adjustable foot with
or without cooling jacket
for changing installation
locations

General information
11
The exact motor data can be found on the name plate.
Caution!
Impermissible heating will damage the
three-phase motor.
Comply with the voltage tolerance of
± 10% according to DIN EN 60034-1.
the highest possible deviation of
the operating voltage is ± 5%, in the
explosion-proof model ± 2% of the
referende voltage.
Motor data
Motor connection Manufacturer-specific
Protection type IP 68
Speed 960 (1160) min
-1
1450 (1750) min
-1
2900 (3600) min
-1
Frequency 50 (60) Hz
Connection ≤ 3.6 kW 400 3(460 3) V
Connection ≥ 4.0 kW 400 5/690 3(460 5) V
Insulation class VDE 0530 F
Cable length 10 m (standard)
Max. immersion depth 30 m
Installation regulation executed according to VDE
Customer-specific solutions may differ from this standard
data.
1.4.6 Dimensions, weights, performance data
The measurements and installation dimensions can be found
in section 5.2 'Dimensions'; for weight details; refer to section
5.3 'Technical data'. The instruction documents and the name
plate data specify the performance and connection data of
the respective pump type.
Performance verification of the pumps is carried out accor-
ding to DIN EN ISO 9906 (Rotodynamic pumps - Hydraulic
performance acceptance tests), Class 2.
Danger!
Air bubbles or accumulations of gas
around the mechanical seal create a
potentially fatal explosive atmosphere.
Provide a constant supply of pumped
media to the supply and pressure pipes
as well as to the interior of the pump
that is in contact with the liquid.
Provide appropriate monitoring
measures to ensure this.
1.4.5 Drive
A three-phase A.C motor, impermeable to presswater drives
the pump. The motor is cooled directly by the medium pas-
sing through the motor (wet- well installation) By the clog-free
by-pass cooling system the pumped medium flows through
the cooling jacket (cooling jacket design).
Danger!
Impermissible heating of the three-
phase motor can create a potentially
fatal explosive atmosphere.
Explosion proof pumps must always
remain completely submerged
Important!
Observe the limit temperatures specified in section 1.4.7
‘General data’.

Safety
12
1.4.7 General data
Media temperature range for:
Lower limit temperature: - 5 °C
Upper limit temperature: + 40°C
Density and viscosity of the pumped medium:
Density: max. 1000 kg/m3
Kinematic viscosity: max. 1 mm2/s (1 cST)
Customer-specific solutions may differ from this standard
data.
Power correction:
Reduce the power according to the specifications of the mo-
tor manufacturer if motors are used at ambient temperatures
> 40 °C or at altitudes > 1000 m above sea level.
A different density or viscosity changes the hydraulic perfor-
mance of the pump. Pay attention to the motor performance
with these media.
Sound pressure level:
The sound pressure level dB(A) of the pump during cavita-
tion-free operation lies within the range of Qoptimum below the
limit values specified in EC Machinery Directive 2006/42/EC.

Safety
13
The following signal words represent
Danger!
This indicates an imminent danger. If it is not
avoided, it will result in fatal injury or serious
personal injuries.
Warning!
This indicates a potentially dangerous situa-
tion. If it is not avoided, it may result in fatal
injury or serious personal injuries.
Caution!
This indicates a potentially dangerous situa-
tion. If it is not avoided, it may result in slight
or minor injuries or damage to property.
Notice!
This indicates a potentially hazardous situa-
tion. If it is not avoided the product or items
in its vicinity may be damaged.
Important!
This indicates tips for usage and other par-
ticularly useful information. It is not a signal
word for a dangerous or hazardous situation.
2.1.1 Machine identification
The information contained in this operating manual is only
applicable to the pump that is indicated on the title page.
Stick the supplied pump name plate into the operating manu-
al or on the control panel. This will ensure that the relevant
data is available at all times.
2 Safety
2.1 Notes/explanations
The following symbols represent
Warning of a hazardous area
Warning of hand injuries
Warning of dangerous electrical voltage
Warning of explosive atmospheres
Warning of a biohazard
Warning of hot surfaces
Command to wear protective gloves
Command to refer to the operating instruc-
tions
General information

Safety
14
Figure 2 Name plate
Key to figure 2
1. Order No.
2. Model designation
3. Item No.
4. Frequency [Hz]
5. Power output
1)
[kW]
6. Protection type
7. Impermeable to presswater at 1 bar
8. Maximum median temperature range [°C]
9. Continous operation with a submerged motor
component or cool jacket version
10. Explosion protection marking (for explosion
protection pumps only)
11. Minimum efficiency index
12. CE mark
13. Nominal head [m]
14. Nominal flow rate [m3/h]
15. Speed [rpm]
16. Operating voltage [V]
17. Year/month of manufacture
18. Observe the direction of rotation!
Important!
When making any enquiries or ordering spare parts, please
make sure you specify the pump type and the order number.
Also observe additional name plates on the motor.
The name plate is attached to the fan hood.
2.2 Integrated safety systems (optional)
Check the integrated safety devices at regular intervals j=
annually.
The inspection methods applied here are:
S= Visual inspection, F= Functional check.
Winding protection
The pump is also equipped with thermal winding protection
with direct temperature monitoring. This switches off the
pump's motor if it starts to get too hot.
Inspection
Interval Method
j S, F
Leak monitoring
GD pumps are available with a seal electrode in the inter-
mediate casing. A sealing module is to be integrated into
the control system. This converts the signal from the seal
electrode into a visual or audible signal. An inspection display
then reproduces these signals in the event of any leakage
of the shaft sealing.
Inspection
Interval Method
j S, F
Caution!
Impermissible heating will damage the
three-phase motor.
Do not deactivate safety devices or
change their mode of operation.
1)
Either power input of the pump in the duty point or power output
of the motor (check by comparing with the motor name plate)
Typ
Q:
U: V
n:
Bj.
Drehrichtung beachten!
H:
Hz
IP 68
II 2G T4EExd IIB
1 bar
kW
m
min-1
m/h
3
Tmax. 40 °C S1
2
3
4
6
5
7
9
1
8
10
13
14
15
16
17
11 12
18
Herborner Pumpenfabrik
J.H. Hoffmann GmbH&Co. KG
Littau 3-5, DE-35745 Herborn
Pumpe
Auftr.-Nr.:
Art.-Nr.:

Safety
15
Important!
A trained person is understood to be someone who
- has been instructed by a specialist about the tasks they
are assigned and the possible dangers associated with
improper conduct,
- has received practical training, if necessary, and
- has been informed about the necessary protective equip-
ment and precautions.
Important!
According to EN 60204-1, a person is understood to be a
specialist if they
- are able to use their professional training, knowledge and
experience as well as knowledge of the relevant standards
to assess the work they have been tasked with and
- are also able to identify any potential dangers.
2.5 Obligations of the operating company
The operating company is obliged to:
- instruct their operating and maintenance personnel with
regard to the pump's safety equipment and
- monitor compliance with the safety measures.
Important!
In the European Economic Area, observe and comply with
- the national implementation of framework directive
(89/391/EEC) with regard to implementing measures
for improving the protection of the health and safety of
workers at work,
- as well as the associated specific directives and particu-
larly the directive (89/655/EEC) concerning the minimum
requirements for the protection of the health and safety of
workers when using equipment at work and
- occupational safety regulations.
2.3 Connections on the pump
Figure 3 Connections on the pump
The following connections are located on the pump:
1. Inlet connecting flange
2. Outlet connecting flange
3. Electric connection (terminal box)
4. Seal electrode (optional)
2.4 Safety measures
This operating manual is part of the machine and must
always be available to operating personnel.
Please make sure that
- you observe the safety precautions it contains,
- you retain this operating manual for future use,
- you adhere to the frequency of inspections and control
measures.
The work described in this operating manual is specified in
such a way that enables
- a trained person to understand and im-
plement instructions associated with the
section entitled ‘Commissioning’,
- a specialist to understand and implement
instructions associated with the sections
entitled ‘Transport’, ‘Installation/fitting’,
‘Maintenance/cleaning’ and ‘Disturbance/
cause/trouble shooting’
- a specialist to understand and implement instructions
associated with the sections entitled ‘Transport’, ‘Installati-
on/fitting’, ‘Maintenance/cleaning’ and ‘Disturbance/cause/
trouble shooting’
3.
2.
1.
4.

Safety
16
The operating company has to obtain local operating licences
and observe the associated conditions.
In addition, they must comply with the local statutory pro-
visions for
- the safety of personnel (accident preven-
tion regulations)
- the safety of operating equipment (protec-
tive equipment and maintenance)
- product disposal (waste management
legislation)
- material disposal (waste management
legislation)
- cleaning (cleaning agents and their dispo-
sal)
- and relevant environmental constraints.
Connections:
Observe local regulations (e.g. for electrical connections)
when carrying out fitting, installation and commissioning.

General hazard warnings
17
3 General Hazard Warnings
3.1 Dangers
Warning!
Maintenance and repair work can cau-
se hand injuries.
Observe all of the safety precautions.
Observe the safety systems and safety precautions that are
described in this manual. The pump is operated by the control
elements or the higher-level system. Keep the access area
free from any clutter while operating the pump in order to
ensure unrestricted access at all times.
3.2 Danger zones on the pump
A radius of approximately 1 m around the pump is desi-
gnated a danger zone when carrying out maintenance and
cleaning work. The operating area is only located on the
control elements.
Caution!
Pumped medium escaping from the
pump can cause injuries.
Install or secure the pump so that the
direction of pumping is away from
areas in which people may be located.
3.3 Assembly, operation and maintenance personnel
Assembly, operation and maintenance personnel are re-
sponsible for the transportation, fitting, installation, operation,
cleaning and trouble shooting of the pump.
1. Only trained and authorised persons are
allowed to install and operate the pump.
2. Clearly define and observe responsibili-
ties when operating the pump.
3. Observe the shut-off procedures speci-
fied in the operating manual when car-
rying out all work processes (operation,
maintenance, repair, etc.)
4. The operator should not impair the safety
of the pump.
5. The operator must ensure that only
authorised persons work with the pump.
6. The operator must notify the operating
company immediately of any alterations
to the pump which affect safety.
7. The operating company may only ope-
rate the pump if it is in perfect condition.
8. The operating company must provide
operating staff with protective equipment
that meets statutory requirements and is
appropriate to the pumped medium.
3.4 Installation of replacement parts and wear parts
Replacement parts and accessories that are not supplied by
the manufacturer have not been checked and, as such, are
not approved. The installation and/or use of such products
may adversely affect the specified properties of your pump.
The manufacturer accepts no responsibility whatsoever for
any damage caused by the use of non-original parts and
accessories.

General hazard warnings
18
3.5 Shut-off procedures
The following shut-off procedure must be complied with
before conducting any maintenance, cleaning and/or repair
work (by specialists only).
Warning!
Electric current can result in fatal injury.
Disconnect the block motor (805)
according to the 5 safety rules.
When cleaning, close any electrical
cabinets that are open to prevent dust
or water from entering.
The five safety rules are as follows:
1.Disconnect.
2.Secure against reactivation.
3.De-energise.
4.Earth and short-circuit.
5.Cover or shield any adjacent live parts.

Transport
19
Packaging for transportation by HGV
When the pump is transported by HGV, it is packed and
secured on a transport pallet.
4.2.2 Intermediate storage
The freight packaging of the pump and the spare parts is sui-
table for storage for a period of approximately three months.
Storage conditions
Enclosed and dry premises with a room temperature of
5 - 40 °C.
4.3 Transportation to the site of installation (by the
customer)
The pump should only be transported on a transport pallet
by specialist personnel in accordance with local conditions.
Warning!
An incorrectly secured pump can cause
severe injuries.
Make sure that lifting devices and stop
belts are adequate for the total weight
of the pump (see section 5.3 'Technical
specifications') .
If necessary, secure the pump during
transportation using appropriate sepa-
rate lifting accessories.
Only set down the pump on a suffici-
ently sturdy surface that is level in all
directions.
The submersible pump should not be
lifted by the electrical cable.
The motor connection cables above on the pump head in
certain motor sizes should be supported by a blick of wood
so that the smallest curve radius is greater than five times
the diameter of the connection cable.
Curve radius: rmin. > 5 x diameter of the connection cable
4 Transport
4.1 Scope of delivery
The detailed scope of delivery is in the order confirmation.
4.2 Transport and packaging
The pumps are carefully checked and packed before being
shipped. However, damage in transit cannot be ruled out.
4.2.1 Delivery (including spare parts and replacement
parts)
Receiving inspection
Check that the order is complete using the delivery note.
In case of damage
Carry out a visual inspection to check the delivery for signs
of damage.
In case of complaints
If the delivery has been damaged in transit:
- Contact the last shipping agent immedia-
tely.
- Keep the packaging (for possible inspec-
tion by the shipping agent or for return
shipment).
Packaging for return shipment
If possible, use the original packaging and the original pa-
ckaging material.
If neither is available:
- Contact a packaging company with speci-
alist staff if necessary.
Place the pump on a pallet (which must
be capable of supporting the weight).
- Please contact the manufacturer if you
have any queries regarding packaging and
transport safety.

Transport
20
4.3.1 Transportation with a forklift truck
- The forklift must be designed to support
the weight of the pump.
- The driver must be authorised to operate
the forklift truck.
4.3.2 Transportation with a crane
- The crane must be able to support the full
weight of the pump.
- The operator must be authorised to ope-
rate the crane.
- Attach the pump to the crane at the spe-
cified attachment points using appropriate
separate lifting accessories (e.g. cross bar,
stop belt, ropes, etc.) and transport the
pump.
Figure 4 Transporting with a crane
The measurements and installation dimensions can be found
in section 5.2 'Dimensions'; for weight details; refer to section
5.3 'Technical data'.
