Herman Miller Canvas Vista T-Light Installation instructions

Tools Required
Parts Included
HermanMiller
Canvas Vista T-Light Installation and
Disassembly for Recycling Instructions
How to assemble T-Light
FG197 - Cable Management Clip
FG600 - T-Light Assembly
FG199 - Wire Manager
Step Step 
. Connect the Barrel Connector from the Top Reflector Assembly into
the receptacle in the top of the support post.
. Attach the Top Light Reflector Assembly to the Support Post
using the two self-tapping machine screws and the nylon washer
as shown.
Be careful not to break zip tied cord inside.
Nylon Washer
Underneath metal
Metal Washer
Power Driver T25 Torx Bit Metric Allen
Wrench
1HermanMiller Installation Instructions1BMYW4 rev C

2HermanMiller Installation Instructions1BMYW4 rev C
Step Step 
. Push the Base back into the Support post and partially thread
the T-Nut on to the bottom of the draw rod. Note: If the light is to be
installed parallel to the Chase, the rib on the bottom of the base will be
installed parallel to the reflector assembly. If the light is to be installed
perpendicular to the Chase, the rib on the bottom of the base will be
installed perpendicular to the reflector assembly.
*Very Important: Rib on base will point in same
direction as the light assembly.
. Insert the Draw Rod through the bellville washer and into the
hole in the Stiener Plate in the Reflector Assembly (note the washer
orientation) and carefully push the draw rod in until it reaches the
bottom.
. The Plastic T-Light Base at the bottom of the Support Post Assembly
may need to be pulled slightly out of the bottom of the post in order to
align the end of the draw rod with the hole in the center of the base.
Step Step 
. Place the T-Light Cover over the Reflector Assembly. The Cover is
secured with magnets in the Reflector assembly.
. Center the Light over the slot in the Chase and make sure the rib on
the base of the unit is engaged in the slot.
. Make sure the power cord runs into the center channel and out the
side of the unit and is not pinched in the Chase. Tighten the draw rod
to secure the light to the chase - snug plus / - / turn ( to 
in-lb). Do not over-tighten. Pull up on the light to make sure it is secure
in the slot.

3HermanMiller Installation Instructions1BMYW4 rev C
For more information about our products and services please visit us at
hermanmiller.com or call ()  .
© Herman Miller, Inc., Zeeland, Michigan Printed in U.S.A. Part No. BMYW  C
Disassembly and Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling
codes. Use these codes to identify material type for recycling. Non
marked components should be treated as mixed plastic. Ferrous metals
can be identied using a small magnet for recycling. Non-ferrous metals
should be separated and recycled separately.
To disassemble product, reverse the above installation steps:
Step 
Step 
. The power supply may be suspended from the bottom of the Chase
using the Under-Chase wire manager. The wire manager also helps to
control any extra cord from the T-Light.
. Route the power cable along the bottom side of the Chase (Cable
Management Clip is available to help with this) and plug the barrel
connector into the T-Light Power Supply. Plug the AC Cord from the
Power supply into an outlet.
Step 
. Thread the power cable through the slots in the bottom of the cord
cover. Place the Cord Cover next to the Support Post and hook the
bottom of the cord cover under the bottom edge of the Chase and then
rotate the cover down to snap the cover into the slots of the Chase.
