HeroSpeed RT811 series User guide

Thank you for using our PoE Switch products, please read this manual carefully before use.
POE
RT812 series
RT811 series
RT412 series
Quick Operation Guide
Power over Ethernet Switch
Network
Switch
Power Over
Ethernet
Transmission
Distance
Transmission
Medium
WAN1/WAN2 port: 100m WAN: 100m
Extend switch is default OFF
state（1~4 port）：100m
Extend switch is ON
state:(1~4 port:): 250m
Cat5/5e/6 standard network cable
Network
Standard
Maximum
Frame Size
MAC address list
Backplane
bandwidth
PoE
Standard
IEEE802.3/10BASE-T
IEEE802.3u/100BASE-TX
IEEE802.3x Flow Control, IEEE802.3az
IEEE802.3x Flow Control
IEEE802.3af
1536 Bytes
2K
1Gbps
IEEE802.3af/at
PoE Power
Supply Type End-Span(4/5+;7/8-)
IEEE802.3af
PoE Power
Consumption af,at Adaptive (every port)
LED Status
Indicator
Environmental
Mechanical
Stability
PoE Ethernet
Working
temperature
Storage
temperature
Working
humidity
Storage
humidity
0℃~55℃
-40℃~70℃
10%-90% non-condensing
5%-95% non-condensing
200*118*40 197*73.5*29
Dimension
(L x W x H)
mm 132*66*32
Material
Color
MTBF
SECC
Dark grey
>30000h
When the PoE is powered, 1-8 LEDs are green When the PoE power supply
is used, 1-4 LEDs are green
When accessing Ethernet, ports 1-8 are yellow 1-4 ports are yellow when
Ethernet is connected
Installation Precautions
① Connect one end of the network cable to the switch port and the other end to a
computer or other network device.
Note: Please connect all the computers or network devices to be connected to the
switch before connecting the power adapter.
② Connect the supplied power cord and adapter. Connect the other end of the
adapter to the switch and plug it into an external AC power outlet.
③ Power on the device connected to the switch. The corresponding indicator will light
up. The installation is complete.
Please install it in a well-ventilated room. Do not block the vents of the equipment.
Do not place and install the switch in direct sunlight or near a heating device.
Allow enough space (more than 10cm) to allow the device to dissipate heat properly.
Do not install the device in a place exposed to moisture, dust, or soot.
Please keep the equipment horizontally installed or installed in a stable place, and
take care to prevent the product from falling.
Do not place heavy objects on the device.
Do not dribble or spill liquid on the device, and ensure that no liquid filled items
can be placed on the device to prevent liquid from flowing into the device.
The interface cables of the device must be routed indoors and outdoors cables
must not be routed to prevent overvoltage and overcurrent caused by lightning.
Please use the power adapter supplied with the product. Do not use other
non-supported products. The grid voltage must meet the input voltage range of
the dedicated power adapter.
Do not disassemble the device at will.
Please transport, use and store the equipment within the allowable humidity and
temperature range.
To ensure the normal operation and service life of the switch, observe the following
precautions.
Specifications
Item RT812 Series description RT811 Series description RT412 Series description
Power
Power Adapter
Voltage
Overload protection
Input：110-240V/AC 50-60Hz 5
Output：48V-52V/DC
100W 60W
Protection level Mould：+-4KV
Differential mode：+-1KV
Network Port
Network Port
Network
Connector
Transmission
Distance
1~8 port: :10/100Mbps PoE Ethernet LAN port. 1~4 口 :10/100Mbps PoE
Ethernet LAN port.
WAN1/WAN2 port :
10/100/1000Mbps
Ethernet WAN port
WAN port:
10/100Mbps
Ethernet WAN port
WANport:10/100Mbps
Ethernet WAN port
1~8 口: 100m 1~8 口: 100m 1~4 口: 100m
Connection cable
45Related tools and documents of products, please download from
www.herospeed.net.

③ RT412 Series
Front Panel
Rear Panel
◆ The front panel has 5 network ports:
◆ The rear panel has 1 network ports:
1~4 ports: 10/100Mbps PoE Ethernet ports;
5 port (WAN port on the front panel): 10/100M/1000Mbps Ethernet port;
6 port (WAN port on the rear panel): 10/100M/1000Mbps Ethernet port;
◆ LED status indicator：
1~4 ports indicator green: The switch provides PoE power.
1~4 ports indicator orange: The switch only accesses Ethernet.
① RT812 Series
② RT811 Series
③ RT412 Series
Installation application diagram
Note: The picture is for reference only; the final product shall prevail in kind.
Thank you for using our products, please read this manual carefully before use.
This manual is applicable to RT812 series, RT811 series, RT412 series Power over
Ethernet Switch. It is an unmanaged Ethernet power supply switch and can be
used without any configuration.
The Company will update the content of this manual according to the enhancement
of product features. The updated content will be added in the new version of this
manual without notice. If there is manual description of the product does not match
with the physical, all in kind prevail.
Statement
Packing List
Open the box, there should be some accessories inside the box:
RT812 series/ RT811 series/ RT412 series switches - 1 sets
Dedicated power adapter*1
Dedicated power cord (conventional national power cord) *1
Quick Operation Guide*1
If you find any damage or shortage of parts, please contact your local dealer or seller.
① RT812 Series
◆ The front panel has 10 network ports:
1~8 ports: 10/100Mbps PoE Ethernet ports;
9~10 ports: WAN1/WAN2 port: 10/100M/1000Mbps Ethernet port;
◆ LED status indicator：
1~8 ports indicator green: The switch provides PoE power.
1~8 ports indicator orange: The switch only accesses Ethernet.
② RT811 Series
◆ The front panel has 9 network ports:
1~8 ports: 10/100Mbps PoE Ethernet ports;
9 port ( WAN port): 10/100Mbps Ethernet port;
◆ LED status indicator：
1~8 ports indicator green: The switch provides PoE power.
1~8 ports indicator orange: The switch only accesses Ethernet.
Product appearance description
1 2 3
Note: The picture is for reference only; the final product shall prevail in kind.
Note: The picture is for reference only; the final product shall prevail in kind.
