hestan KWC User manual

Use and Care Manual
INDOOR PRESERVATION
Wine Storage
KWC / KRW

READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY
BEFORE INSTALLING OR USING YOUR APPLIANCE TO REDUC
E
THE RISK OF FIRE, BURN HAZARD, OR OTHER INJURY. KEEP
THIS MANUAL FOR FUTURE REFERENCE.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed by a qualified installer or service agency.
DO NOT REPAIR, REPLACE OR REMOVE ANY PART OF THE APPLIANCE UNLESS
SPECIFICALLY RECOMMENDED IN THE MANUAL. IMPROPER INSTALLATION,
SERVICE OR MAINTENANCE CAN CAUSE INJURY OR PROPERTY DAMAGE. REFER
TO THIS MANUAL FOR GUIDANCE. ALL OTHER SERVICING SHOULD BE DONE BY A
QUALIFIED TECHNICIAN.
INSTALLER: LEAVE THIS MANUAL WITH THE OWNER OF THE APPLIANCE.
HOMEOWNER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH.
SAFETY DEFINITIONS
THIS INDICATES THAT DEATH OR SERIOUS INJURY MAY
OCCUR AS A RESULT OF NOT OBSERVING THIS WARNING
THIS INDICATES THAT MINOR OR MODERATE INJURY MAY
OCCUR AS A RESULT OF NOT OBSERVING THIS WARNING.
THIS INDICATES THAT DAMAGE TO THE APPLIANCE OR
PROPERTY MAY OCCUR AS A RESULT OF NOT OBSERVING
THIS WARNING.

Message from Hestan:Message from Hestan:
Hestan’s award-winning culinary innovations and purpose-built features
reinvented the restaurant kitchen and redefined culinary experience in some
of America’s most acclaimed restaurants. Hestan now takes this performance
from the back of the house and puts it front and center in yours. Thoughtfully
designed and meticulously built, Hestan will serve you beautifully for years to
come.
Hestan is the only residential brand born from the dreams and demands of
professional chefs. From ranges to refrigeration, every detail is designed to
deliver the performance and reliability expected in a restaurant – now available
for you.
We appreciate you choosing Hestan, and we promise to deliver the very best to
you.
Welcome to HestanWelcome to Hestan
©2020 Hestan Commercial Corporation
1
EN

TABLE OF CONTENTS
3 SAFETY PRECAUTIONS - BEFORE YOU BEGIN
7 MODEL NUMBERS
7 RATING LABEL
7 REGULATORY / CODE REQUIREMENTS
8 GETTING TO KNOW YOUR APPLIANCE
11 CONTROLS AND OPERATION
24 INTERNAL LAYOUT
25 WINE PRESERVATION
28 FOOD PRESERVATION
31 CARE AND CLEANING
32 TROUBLESHOOTING
35 PARTS / SERVICE
35 LIMITED WARRANTY
SAFETY PRECAUTIONS - BEFORE YOU BEGIN
When properly cared for, your Hestan appliance will provide safe, reliable service for many years.
When using this appliance, basic safety practices must be followed as outlined below.
IMPORTANT: Save these instructions for the local Utility Inspector’s use.
INSTALLER: Please leave these instructions with the owner.
OWNER: Please retain these instructions for future reference.
This appliance is NOT designed for installation in manufactured (mobile) homes or recreational park
trailers. Do NOT install this appliance outdoors.
ELECTRICAL SHOCK HAZARDELECTRICAL SHOCK HAZARD
Disconnect power before installing or servicing appliance. Failure to do
so can result in death or electrical shock.
ELECTRICAL GROUNDINGELECTRICAL GROUNDING
• This appliance must be grounded. Grounding reduces the
risk of electric shock in the event of a short circuit. Read the
CONNECTIONS section of the Installation Manual for complete
instructions.
• DO NOT ground to a gas pipe.
• DO NOT use an extension cord with this appliance.
• DO NOT have a fuse in the NEUTRAL or GROUNDING circuit. A fuse in the NEUTRAL or
GROUNDING circuit could result in an electrical shock.
©2020 Hestan Commercial Corporation
3
EN

GENERAL SAFETY PRECAUTIONSGENERAL SAFETY PRECAUTIONS
If this appliance is replacing an existing appliance which must be removed or
disposed of, make sure that it does not become a dangerous trap for children
by cutting its power supply cable and rendering it impossible to close the door.
Use the same caution at the end of the lifespan of the new appliance.
• This appliance is designed to refrigerate beverages and foods and is
intended for domestic use.
• The appliance must be installed by following the instructions in the
Installation Manual, particular care should be taken not to obstruct the
vent openings of the appliance and of the built-in units.
• The appliance features a concentrated lighting system with LED lamps. Do not stare into
these lamps when they are on to avoid possible eyesight damage. This warning is also
contained on the label attached to the inside of the refrigerator door.
• When the freezer is functioning do not touch the inner surfaces in stainless steel with wet
or damp hands, since skin may stick to the very cold surfaces.
• Do not use any type of electrical equipment inside of the food conservation compartments.
• When positioning the shelves, do not place fingers in the shelf slide guides.
• Do not position containers of flammable liquids near the appliance.
• Completely switch off the appliance and unplug the power supply cable during cleaning
operations. If the plug is not easily reached, it is a good idea to turn off the breaker or
remove the fuse that controls the socket that the appliance is connected to.
• The packaging parts can be dangerous for children: do not allow children to play with the
plastic bags, plastic film or Styrofoam.
• Any repairs must be performed by a qualified Hestan Service technician.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or lack of experience and knowledge unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Do not damage the appliance refrigerant circuit pipes.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
• If the power cord of this appliance is damaged, it must be replaced by the manufacturer,
customer service or a similarly qualified person. Improper installations and repairs may put
the user at considerable risk.
• Repairs may be performed by the manufacturer, customer service or a similarly qualified
person only.
• Plug into a grounded 3 prong outlet.
• Do not remove ground prong.
• Do not use an adapter.
• Do not use an extension cord.
• Disconnect power to all units before servicing.
• Children should be supervised to ensure that they do not play with the appliance
IMPORTANT INFORMATION WHEN USING THE APPLIANCEIMPORTANT INFORMATION WHEN USING THE APPLIANCE
• Never use electrical appliances inside the appliance (e.g. heater, electric ice maker, etc.).
Explosion hazard!
• Never defrost or clean the appliance with a steam cleaner! The steam may penetrate
electrical parts and cause a short-circuit. Risk of electric shock!
SAFETY PRECAUTIONS - BEFORE YOU BEGIN (CONT.)
©2020 Hestan Commercial Corporation
4
EN

• Do not use pointed and sharp-edged implements to remove frost or layers of ice. You could
damage the refrigerant tubes. Leaking refrigerant may cause eye injuries or ignite.
• Do not store products which contain flammable propellants (e.g. spray cans) or explosive
substances in the appliance. Explosion hazard!
• Do not stand on or lean heavily against base of appliance, drawers or doors, etc.
• Before cleaning the appliance, pull out the power cord plug or switch off the fuse. Do not
pull out the power cord plug by tugging on the power cord.
• Store high-percentage alcohol tightly closed and standing up.
• Keep plastic parts and the door seal free of oil and grease. Otherwise these parts will
become porous.
• Never cover or block the ventilation openings for the appliance.
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a significant increase of the temperature in the
compartments of the appliance.
• Clean regularly surfaces that can come in contact with food and accessible drainage systems.
• Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact
with or may drip onto other foods.
• If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mold developing within the appliance.
INSTALLATIONINSTALLATION
Make sure installation of this refrigeration appliance is performed correctly by a qualified
installer using the instructions in the Installation Manual provided with the appliance.
CONNECTION TO THE ELECTRICAL POWER SUPPLYCONNECTION TO THE ELECTRICAL POWER SUPPLY
The appliance operates at 115 VAC, 60 Hz and is equipped with a
power supply cord with a 3-prong grounded plug, which must be
connected to a corresponding 3-prong (15 Amp) grounding-type wall
receptacle.
A circuit breaker or suitable fuse should be easily accessible so that
it can be easily switched off before performing any installation or
maintenance.
• DO NOT ground to a gas pipe.
• DO NOT have a fuse in the NEUTRAL or GROUNDING circuit. A
fuse in the NEUTRAL or GROUNDING circuit could result in an
electrical shock.
• Do not use extension cords and/or multiple adapters for the power supply
connection.
SAFETY PRECAUTIONS - BEFORE YOU BEGIN (CONT.)
©2020 Hestan Commercial Corporation
5
EN

CARING FOR THE ENVIRONMENTCARING FOR THE ENVIRONMENT
Pay special attention to correct disposal procedure for all the packaging materials.
The appliance must not be disposed of with urban waste. Contact local waste
disposal centers on how to dispose of recyclable waste.
Prior to disposal, cut the power supply cord and make it impossible to close
the door, as stated in “GENERAL SAFETY PRECAUTIONS” on page 4. During
disposal, avoid damage to the electronics.
The appliance does not contain hazardous substances for the atmospheric ozone
layer, neither in the electronics nor in the insulation.
USING THE CONTROL MENUSUSING THE CONTROL MENUS
The unit features a touch-screen control. Many features and settings are only accessible
through the control menus. Here are the basics for the control panel:
1) Touch the (power) button to turn on the unit.
2) Touch the (home) button as needed to return to the main menu.
3) Touch the actual blue screen itself to access control menus. Some menus are extensive and
can be scrolled left or right to see other menu items.
4) Touch the (alarm) button to deactivate any warning tones.
5) Touch the (back) button to return to the previous menu.
See CONTROLS AND OPERATION” on page 11 for details.
SAFETY PRECAUTIONS - BEFORE YOU BEGIN (CONT.)
©2020 Hestan Commercial Corporation
6
EN

MODEL NUMBERS
RATING LABEL
The rating label contains important information about
your Hestan appliance such as the model and serial
number and electrical rating.
The rating label is located on the inside wall of the
refrigerator.
REGULATORY / CODE REQUIREMENTS
Installation of this refrigeration appliance must be made in accordance with local codes. In the
absence of local codes, this unit should be installed in accordance with the National Electrical
Code and local codes.
This appliance must be electrically grounded in accordance with local codes or in the absence
of local codes with the National Electrical Code ANSI/NFPA 70, or Canadian Electrical code
CSA C22.1.
ozFridge Gas Fill Charge
Quantité de Gaz Réfrigerateur
Freezer Gas Fill Charge
Quantité de Gaz Congélateur
Total Absorbed Current
Courant Absorbée Totale
Voltage
Tension
Frequency
Frequence
Refrigerant Gas Type
Type de Gaz Rèfrigerant
MODEL
Made in Italy
CODE
SER.NO./N° SERIE
ETL LISTED
CONFORMS TO
ANSI/UL STD 250
CERTIFIED TO CAN/CSA
STD C22.2 NO.63
A
V
Hz
HESTAN COMMERCIAL CORP.
ANAHEIM, CA - USA
4,5
115
60
R134a
KRPR36
F20200000000001
oz4,2
4,8
TYPICAL RATING LABEL
NOTE
: -XX indicates color model.
-BK for Stealth - Black
-YW for Sol - Yellow
-PP for Lush - Purple
-GG for Pacific Fog - Graphite Gray
-WH for Froth - White
-OR for Citra - Orange
-BU for Prince - Blue
-RD for Matador - Red
-BG for Tin Roof - Burgundy
-GR for Grove - Green
-TQ for Bora Bora - Turquoise
Model No. Description
KWCL24 Wine Column, Left Hinged, 24”
Wine Column, Overlay, Right Hinged, 24”KWCR24-OV
KWCR24-XX Wine Column, Color, Right Hinged, 24”
KRWR24 Refrigerator with Wine, Right Hinged, 24”
KRWL24 Refrigerator with Wine, Left Hinged, 24”
KRWR24-OV Refrigerator with Wine, Overlay, Right Hinged, 24”
KRWL24-OV Refrigerator with Wine, Overlay, Left Hinged, 24”
KRWR24-XX Refrigerator with Wine, Color, Right Hinged, 24”
KRWL24-XX Refrigerator with Wine, Color, Left Hinged, 24”
KWCR24 Wine Column, Right Hinged 24”
KWCL24-OV Wine Column, Overlay, Left Hinged, 24”
KWCL24-XX Wine Column, Color, Left Hinged, 24”
KWCL18 Wine Column, Left Hinged, 18”
Wine Column, Overlay, Right Hinged, 18”KWCR18-OV
KWCR18-XX Wine Column, Color, Right Hinged, 18”
KWCR18 Wine Column, Right Hinged, 18”
KWCL18-OV Wine Column, Overlay, Left Hinged, 18”
KWCL18-XX Wine Column, Color, Left Hinged, 18”
KWCR24
©2020 Hestan Commercial Corporation
7
EN

GETTING TO KNOW YOUR APPLIANCE
FEATURES OF THE WINE REFRIGERATORFEATURES OF THE WINE REFRIGERATOR
7
10
8
1
6
4
2
3
5
11
12
9
FreshSelectTM Dual Wine Zones
KRW Models
1
2
3
4
5
6
7
8
9
10
11
12
Stainless steel grille,
aluminum trim
Dual zone control panel
with display
Slide-out wooden wine racks
Upper wine zone
Temperature display
Sound signals
Lower wine zone
Automatic drawer closing
system
FreshSelectTM compartment
convertible to refrigerator,
freezer, or ExtendFresh. Set
to freezer mode by default.
Dual refrigeration system
LED lighting - multiple
locations in each compartment
Automatic door closing
system
©2020 Hestan Commercial Corporation
8
EN

GETTING TO KNOW YOUR APPLIANCE (CONT.)
FEATURES OF THE WINE CELLARFEATURES OF THE WINE CELLAR
7
6
4
1
8
3
2
5
9
1
2
3
4
5
6
7
8
9
KWC Models
10
10
Stainless steel grille,
aluminum trim
Dual zone control panel
with display
Slide-out wooden wine
racks
Upper wine zone
Lower wine zone
Temperature
display
Sound signals
Automatic door closing
system
Dual refrigeration system
LED lights, multiple
locations each
compartment
Lower Wine Zone
Upper Wine Zone
©2020 Hestan Commercial Corporation
9
EN

GETTING TO KNOW YOUR APPLIANCE (CONT.)
CONTROL PANEL (ALL MODELS)CONTROL PANEL (ALL MODELS)
The electronic touch-screen control system of your Hestan refrigeration product maintains
constant temperature in all compartments and displays the measured temperature on the
control panel. It also allows the user to personalize settings of the various functions and
provides alerts should a malfunction occur.
Many features and settings are only accessible through the control menus (Functions and
Settings). See CUSTOM FUNCTIONS AND SETTINGS on page 15 for details.
FRESHSELECTFRESHSELECT™™/ FREEZER COMPARTMENT (KRW MODEL ONLY)/ FREEZER COMPARTMENT (KRW MODEL ONLY)
The KRW model has a FreshSelect™feature which allows you to operate the bottom drawer in
one of three different modes.
• Classic refrigerator mode: From 34 to 46°F [+1 to +7°C], recommended pre-set temperature
is 42°F [+6ºC].
• ExtendFresh mode preserves fresh food longer: From 28 to 36°F [-2 to +2°C], recommended
pre-set temperature is 32°F [0ºC].
• Freezer mode: From -9 to +9°F [-23 to -13°C], recommended pre-set temperature is -1°F
[-18ºC].
Switches the appliance between ON and
Stand-by (Press for 3 seconds).
Touch this home icon to return to the main
control panel menu.
Shows the temperature of the compartment(s),
allows access to control panel menu (Functions
and Settings), and displays other messages.
Flashes to signal user alerts such as door
being left open in combination with a warn-
ing tone. Tap this icon to deactivate the
warning tone.
Touch this arrow icon to go back to the
previous display screen.
On/Off
Menu
Display
Alarm
1 2 3 4 5
Back
Settings
Functions
46
°F
+
54
°F
+
°F
1
-
Settings
Functions
46
°F
+
54
°F
+
°F
1
-
Settings
Functions
46
°F
+
54
°F
+
°F
1
-
1
2
3
5
4
©2020 Hestan Commercial Corporation
10
EN

CONTROLS AND OPERATION
TURN APPLIANCE ON AND OFFTURN APPLIANCE ON AND OFF
First time start up.
Touch the ON/OFF button for 3 seconds.
The display shows the following launch screens:
Shutdown.
Touch the ON/OFF button for 3 seconds to
shutdown the unit.
Hestan logo.
Settings
Functions
Initial test …
please wait.
Initial test
(lasts 3 minutes).
The display shows the Home screen with the
temperature measured from inside the various
compartments. The unit automatically starts
to cool down until reaching these factory set
temperatures.
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
As seen above, the FreshSelect™compartment is
set in the freezer mode (-1°F).
* The Home screen varies depending on
the models. See ADJUSTING VARIOUS
TEMPERATURE SETTINGS on page 13 for
details.
When the appliance is first switched on, it is
recommended to wait at least 12 hours without
opening the doors and before placing any food
inside the unit. During such period deactivate
any error message by touching the Alarm button.
Each time the unit is turned on, it goes through
a self-diagnostic procedure lasting 3 minutes
before completely starting up.
During the first startup, it will not be possible to
use the menu to modify the factory settings until
the preset temperatures have been reached.
Touch the YES icon.
Are you sure you want to
power o this compartment?
YesNo
Confirm shutdown
by touching YES
again.
Are you sure?
YesNo
When the appliance is off, there are no warning
signs that prove the unit is unplugged from the
power source (wall outlet).
Switching off for long periods.
During long absence periods, it is recommended
to switch off the appliance by touching the ON/
OFF button for 3 seconds and disconnecting the
electrical plug or shutting off the breaker at your
electrical panel.
Completely empty the appliance, clean and dry it,
and leave the doors and drawers slightly open to
prevent the formation of unpleasant odors and
mold.
Home screen*:
- Upper Wine Zone
+54°F
- Lower Wine Zone
+46°F
- FreshSelect™/Freezer
compartment -1°F
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
©2020 Hestan Commercial Corporation
11
EN

Turning off the Wine and FreshSelect™
compartment. (Model KRW)
The wine compartments can be shutdown
individually, whereas the freezer (FreshSelect™)
drawer cannot be turned off unless through the
complete shutdown of the unit.
At the Home screen,
touch the icon for the
compartment you wish
to shut off.
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
Touch the OFF icon.
+ 54 °F
+ 52
+ 53
+ 56
+ 55
OK
OFF
CONTROLS AND OPERATION (CONT.)
Turn Compartment
OFF?
Ye
sN
o
Touch the YES icon.
Are you sure?
Ye
sN
o
Confirm shutdown by
touching YES again.
Turn back on individual compartments.
In case you wish to turn on again the Wine
compartments.
Turning on the Wine and FreshSelect™
compartment again. (Model KRW)
To turn on the unit again, touch the ON/
OFF button, the display will turn on; the
starting screen and the Home screen. The
temperature measured from the fridge inside
the compartments will appear again. The
fridge will start cooling off until reaching the
set temperatures.
Touch the YES icon.
Turn Compartment
ON?
Ye
sN
o
+ 54 °F
+ 52
+ 53
+ 56
+ 55
OK
ON
Touch the ON icon.
For example, at the
Home screen, to turn
back on the Upper
compartment, touch
the OFF icon.
Settings
Functions
46 °F
+
°F
1
-
Off
Are you sure?
Ye
sN
o
Confirm activation by
touching YES again.
For turning on the other compartment, follow
the same procedure.
If only the the upper or lower fridge
compartment is turned off, the specific fan will
continue to operate to prevent the formation of
unpleasant odors and mold.
Now the Upper
compartment will turn
back on. The Home
screen will appear again.
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
©2020 Hestan Commercial Corporation
12
EN

CONTROLS AND OPERATION (CONT.)
ADJUSTING VARIOUS TEMPERATURE SETTINGSADJUSTING VARIOUS TEMPERATURE SETTINGS
Modify the compartment temperatures
Example: How to modify the Upper Wine
compartment temperature.
The same procedure is required to set the
temperature in the Lower Wine compartment
and in the FreshSelect™bottom drawer.
Home screen in the various models:
+ 56 °F
+ 54
+ 55
+ 58
+ 57
OK
OFF
Scroll up or down
to select the desired
temperature.
+ 56 °F
+ 54
+ 55
+ 58
+ 57
OK
OFF
Touch the OK icon
to confirm the
desired temperature.
At the Home screen,
touch the icon of
desired compartment.
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
Each model has been carefully tested before
leaving the factory and is adjusted in such a
way to ensure high performance and low power
consumption.
Usually, it is not necessary to modify the
settings. Nevertheless, according to special
needs, it is possible to modify the set
temperatures within a certain range. The
“recommended” settings below are also the
factory presets for each of the zones and modes.
The temperature shown can vary slightly
in respect to the set temperature following
frequent openings of the doors or insertion of
room temperature foods or large quantities of
foods.
6 to 12 hours may be necessary to reach the
selected temperature.
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
Upper Wine
Compartment
Freezer
Drawer
(FreshSelect™)
Preset
temperatures
Model KRW
Lower Wine
Compartment
Upper Wine
compartment Preset
temperatures
Model KWC
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
Lower Wine
compartment
WINE CELLAR TEMPERATURESWINE CELLAR TEMPERATURES
In general, red wines need a warmer
temperature. Specific temperatures for
optimum wine preservation are discussed
in more detail in the section WINE
PRESERVATION on page 25.
Red Wine - from 50 to 64°F [+10 to +18°C]
White Wine - from 39 to 48°F [+4 to +9°C]
As an aid to visualization, when a temperature
higher than 48°F [+9°C] is set for white wine,
the display will change the bottle icon from
white wine to red wine.
+ 46 °F
+ 44
+ 45
+ 48
+ 47
OK
OFF
+ 54 °F
+ 52
+ 53
+ 56
+ 55
OK
OFF
©2020 Hestan Commercial Corporation
13
EN

Display Information and Malfunction Messages
An integrated control system provides
information through light signals or text
messages visualized on the display. Problems
that cannot be solved by the user are reported
through a fault code. Some messages or alarms
frequently appear for particular conditions of
use or during start-up. In these cases, deactivate
the audible alarm by touching the Alarm button
and leave the appliance running, and limit
the opening of the doors for about 10-12 hours.
A list of malfunction messages is located at the
end of this manual.
If a malfunction message continues after repeated
attempts, contact Hestan Customer Care.
Padlock icon
The padlock icon shows up when the
temperatures are set up. The icon shows
that it is or is not possible to modify the
compartment's temperatures anymore.
Usually an open yellow padlock means you can
scroll up or down with a finger on the display to
select the desired temperature and touch OK for
confirming.
Whereas a closed padlock can be seen if the
user has activated some functions (described
later) that modify the settings of the Fridge,
ExtendFresh and Freezer Compartment.
Therefore the user will not be able to change the
temperature of the compartments anymore.
If a special function is set (for example Holiday,
MaxCool, FreshSelect™, etc.), the yellow
padlock will be seen closed and it will not be
possible to change the temperature of the
compartments as long as the function is active,
or if it is manually deactivated.
+ 54 °F
+ 52
+ 53
+ 56
+ 55
OK
OFF
+ 54 °F
+ 52
+ 53
+ 56
+ 55
OK
OFF
CONTROLS AND OPERATION (CONT.)
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
©2020 Hestan Commercial Corporation
14
EN

CONTROLS AND OPERATION (CONT.)
CUSTOM FUNCTIONS AND SETTINGSCUSTOM FUNCTIONS AND SETTINGS
It is possible to personalize the operation of
your Hestan unit in order to adapt it to the
different ways you might want to use it.
FUNCTIONSFUNCTIONS
After touching the Function icon
Settings
Functions
46 °F
+
°F
1
-
Off
on the
Home screen, the following available functions
will be seen. A small white dot at the bottom of
these screens indicate further choices which can
be accessed by scrolling left or right.
Beverage Cooler
Holiday Mode
Beverage Cooler
MaxCool Mode:
FreshSelect
MaxCool Mode - FreshSelect™
(KRW model)
Holiday Mode
Beverage Cooler
MaxCool Mode:
FreshSelect
Holiday Mode
Holiday Mode
Beverage Cooler
MaxCool Mode:
FreshSelect
Humidity Control
Humidity Control
Light 12h
Light 12h
Humidity Control
Light 12h
Holiday Mode
Beverage Cooler
MaxCool Mode:
FreshSelect
Holiday Mode
This function is recommended in case of
prolonged absences since it allows considerable
energy savings. This function brings the
refrigerator compartment temperature to 57°F
[+14°C].
It is possible to program the duration, or it can
be manually deactivated upon re-entry after a
period of absence. This function remains active
even if during the period of absence there is a
prolonged power outage.
It is possible to program a duration of 1 to 90
days.
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
At the Home
screen, touch the
Function icon.
Holiday Mode
Beverage Cooler
MaxCool Mode:
FreshSelect
Touch the Holiday
Mode icon.
25day
27
26
23
24
OK
Scroll up or down
to set the desired
time and then
touch OK.
Touch the YES
icon to activate
the function.
Activate Holiday
Mode ?
Ye
sN
o
©2020 Hestan Commercial Corporation
15
EN

CONTROLS AND OPERATION (CONT.)
Beverage Cooler
This function can be activated when it is
necessary to cool off beverages quickly, by
placing them inside the freezer compartment.
It is possible to select a duration of 1 to 45
minutes. A sound signal will indicate when the
optimal temperature has been reached.
After removing the beverages, deactivate the
sound signal by touching the Alarm button .
Activate Rapid
Beverage Cooler?
Ye
sN
o
Touch the YES
icon to activate the
function.
Holiday Mode
Beverage Cooler
MaxCool Mode:
FreshSelect
Touch the
Beverage Cooler
icon.
37min
39
38
35
36
OK
Scroll up or down
to set the desired
time and then
touch OK.
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
At the Home
screen, touch the
Function icon.
MaxCool Mode - FreshSelect™
(KRW model)
This function lowers the refrigerator temperature
to 36°F [+2°C] for 12 hours, permitting more rapid
cooling of food that has just been placed inside.
The more quickly an item can be cooled or frozen,
the better it will be preserved.
This mode can also be effective at maintaining
compartment temperatures while entertaining,
when higher than average door and drawer
openings are anticipated.
This must be activated at least 24 hours before
inserting room temperature items into the freezer,
or several hours before placing into the freezer
previously frozen items which have been subject
to a slight temperature rise.
Once the 12 hours have expired, the function
deactivates automatically, returning to the
previously set temperature. It is possible to
program a delayed activation of 1-12 hours for the
function.
If a power outage occurs while this mode is active,
the unit will default to normal operation.
Activate MaxCool
Mode: FreshSelect?
(up to 24 hours)
Ye
sN
o
Touch the YES
icon to activate
the function.
Holiday Mode
Beverage Cooler
MaxCool Mode:
FreshSelect
Touch the icon
MaxCool Mode
FreshSelectTM.
10hour
12
11
8
9
OK
Scroll up or down
to set the desired
delay time and
then touch OK.
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
At the Home
screen, touch the
Function icon.
©2020 Hestan Commercial Corporation
16
EN

Light 12h
This function allows the interior lighting to stay
on for 1 to 12 hours when the wine cellar door is
closed.
Scroll left until
reaching the Light
12h icon.
Humidity Control Light 12h
Scroll up or down
to set how many
hours the lighting
will stay on, then
touch OK to
confirm.
10hour
12
11
8
9
OK
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
At the Home
screen, touch the
Function icon.
CONTROLS AND OPERATION (CONT.)
Humidity Control
The function enables the user to set the
humidity level of the wine compartments in
order to improve the conservation of the wines
and food.
Scroll left until
reaching the
Humidity Control
icon.
Humidity Control Light 12h
Scroll up or down
to set the desired
humidity, then
touch OK to
confirm.
Medium
Low
High
OK
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
At the Home
screen, touch the
Function icon.
©2020 Hestan Commercial Corporation
17
EN

CONTROLS AND OPERATION (CONT.)
CUSTOM FUNCTIONS AND SETTINGSCUSTOM FUNCTIONS AND SETTINGS
It is possible to personalize the operation of
your Hestan unit in order to adapt it to the
different ways you might want to use it.
SETTINGSSETTINGS
After touching the Settings icon
Settings
Functions
46 °F
+
°F
1
-
Off
on the
Home screen, the following available settings will
be seen. A small white dot at the bottom of these
screens indicate further choices which can be
accessed by scrolling left or right.
Date
The display will show the date in the format
(day:month:year). By touching the display
you can modify the settings.
TimeDate
Language°C / °F
Date
TimeDate
Language°C / °F
Time
TimeDate
Language
°C / °F
Set Temperature °C / °F
TimeDate
Language°C / °F
Language
Sabbath
FreshSelect
Demo ModeReset
FreshSelect™
Sabbath
FreshSelect
Demo ModeReset
Sabbath
SabbathFreshSelect
Demo Mode
Reset
Reset
SabbathFreshSelect
Demo Mode
Reset
Demo Mode
Maintenance
Service
Info System
Service
Maintenance Service
Info System
Info System
Maintenance
Maintenance
Service
Info System
Settings
Functions
46 °F
+
54 °F
+
°F
1
-
At the Home
screen, touch the
Settings icon.
TimeDate
Language°C / °F
Touch the Date
icon.
25day
27
26
23
24
OK
Scroll up or down
to select the
desired day and
touch OK.
9month
11
10
7
8
OK
Scroll up or down
to select the
desired month and
touch OK.
2020year
2022
2021
2018
2019
OK
Scroll up or down
to select the
desired year and
touch OK.
©2020 Hestan Commercial Corporation
18
EN
