Hi Sharp CE Series User manual

HD Analogue Camera Manual _ CE Series
Product Feature
1. 1080P
2. 4 in 1 Output
3. Built-I IR Cut, accurate focus for Day & Night
4. 2DNR & 3DNR function (Digital Noise Reduce).
5. OSD menu & control cable(Optional)
6. OSD menu language: English / Chinese ~support up to 16 languages
SAFETY PRECAUTIONS
Please read before using
1. Please read the service manual in details before using.
2. Don't try to disassemble the chassis or the part easily, in case that touch the power by mistake,
is shocked by electricity the danger or caused inside parts to be damaged.
3. Do not attempt to service this unit yourself unless you are authorized to do so. Opening cover
may exposure you to dangerous voltage or other hazards. Refer all servicing to qualified
personnel only.
4. When being regular, please lock the parts firmly first to prevent the machine damage.
5. Please connect correctly in accordance with the regulation, prevent the machine from using, or
striking improperly.
6. Please don't use any organic solution or the corrosively sanitizer to insert and wipe away the
chassis outside. While inserting and wiping away, please turn off the power, and use the clean
cloth is stained with letting a small amount of branch water, insert and wipe away appearance.
7. Please don't use the camera under the following abominable environments: Temperature is
lower than -10 degrees Centigrade, or is higher than +50 degrees Centigrade.
8. The contents of this manual are subject to change without notice.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of insulated dangerous Voltage within the product’s
enclosure that may be sufficient magnitude to constitute risk of electrical shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operation and maintenance (servicing) instructions in
the literature accompanying the appliance.

2
Specification
Image unit
1/3” SONY CMOS : 2.0 Mega
Resolution
1920(H) x 1080(V) @ 25/30FPS
Video Output
AHD / CVI / TVI / CVBS
Synchronization
Internal
Scanning System
2:1 interlace
S/N Ratio
More than 55dB ( AGC OFF)
Lens Type
Board Lens: 3.6mm/6mm or Vari-focal Lens:2.8~12mm/7~22mm or C/CS
IR Distance
According to the different model
Electronic Shutter
Auto 1/60 (1/50) ~ 1/100,000 sec
Min. Illumination
0.04Lux ( F2.0 , AGC ON)
Coxial Cable Transmition
Distance(3C/5C)
300M/500M
Twisted Cable Transmition
Distance (Cat5e standard)
200M
Power Source
DC12V ± 10% / 1A
Operating Temperature
-10℃~ 50℃(14℉~ 122℉)
Storage Temperature
-20℃~ 60℃(-4℉~ 140℉)
Please use suitable adapters DC12V ± 10%≧1A . Otherwise, this product will be damaged.

3
COC (control over coaxial) function
a. Enable the channel which you want to configure, and choose COC
(control over coaxial) function under serial port setting page.
b. Click the right button of the mouse, choose PTZ. Press Iris 〝＋〞to open
OSD menu.
Icon
Description
Open the OSD menu of camera / Enter
Direction button, in order to choose the item that you want
to config.
Adjustment parameter options

4
OSD Operation
Function
Description
LENS
Default Lens is Manual
EXPOSURE
Defog default is “OFF”
BACKLIGHT
Default is “OFF”, user can press right or left button to choose “OFF、BLC、HSBLC”
WHITEBAL
User can press right or left button to choose “ATW、AWC→SET、INDOOR、
OUTDOOR、MANUAL、AWB”
DAY & NIGHT
“EXT、AUTO、COLOR、B/W”
NR
2DNR & 3DNR “LOW、MIDDLE、HIGH、OFF”
SPECIAL
CAMERA TITLE、D-EFFECT、MOTION、PRIVACY、LANGUAGE、DEFECT、
RS485 functions can be set under this menu.
※Language support: ENG, JPN, CHN1, CHN2, KOR, GER, FRA, ITA, SPA,
POL, RUS, POR, NED, TUR, HEB, ARB
ADJUST
SHARPNESS、MONITOR、LSC、VIDEO.OUT.
EXIT
SAVE & END OSD menu or RESET to factory default.
MAIN MENU
1. LENS MANUAL
2. EXPOSURE ↲
3. BACKLIGHT OFF
4. WHITE BAL ATW
5. DAY&NIGHT EXT↲
6. NR ↲
7. SPECIAL ↲
8. ADJUST ↲
9. EXIT SAVE&END↲
9. EXIT ↲
85-CE0000-A502G-C
Suppose you buy a product with OSD function
(1) Push direction RIGHT button about 5 sec to switch to AHD mode
(2) Push direction LEFT button about 5 sec to switch to CVBS mode
(3) Push direction DOWN button about 5 sec to switch to CVImode
(4) Push direction UP button about 5 sec to switch to TVI mode
