Hi Sharp CH Series User manual

HD Analog Camera Manual _CH Series
Product Feature
1. 1080P
2. 4 in 1 Output
3. Built-in IR Cut Filter, accurate focus for Day & Night
4. 2DNR & 3DNR
5. OSD language: English/Chinese ~ support up to 12 languages
6. IR distance according to the ship model
7. COC funtion (UTC)
SAFETY PRECAUTIONS
Please read before using
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of insulated dangerous Voltage within the product’s enclosure that
may be sufficient magnitude to constitute risk of electrical shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operation and maintenance (servicing) instructions in the literature
accompanying the appliance.
1. Please read the service manual in details before using.
2. Don't try to disassemble the chassis or the part easily, in case that touch the power by mistake,
is shocked by electricity the danger or caused inside parts to be damaged,
3. Do not attempt to service this unit yourself unless you are authorized to do so. Opening cover
may exposure you to dangerous voltage or other hazards. Refer all servicing to qualified
personnel only.
4. When being regular, please lock the parts firmly first to prevent the machine damage.
5. Please connect correctly in accordance with the regulation, prevent the machine from using, or
striking improperly.
6. Please don't use any organic solution or the corrosively sanitizer to insert and wipe away the
chassis outside. While inserting and wiping away, please turn off the power, and use the clean
cloth is stained with letting a small amount of branch water, insert and wipe away appearance.
7. Please don't use the camera under the following abominable environments: Temperature is
lower than -10 degrees Centigrade, or is higher than +50 degrees Centigrade.
8. The contents of this manual are subject to change without notice.

2
Specification
Pick up device
1/2.9” SONY CMOS : 2.0 Mega
Resolution
1920(H) x 1080(V)
Video Output
AHD / CVBS / TVI / CVI
Synchronization
Internal
Scanning System
2:1 interlace
S/N Ratio
More than 60dB ( AGC OFF)
Electronic Shutter
Auto 1/60(1/50)~1/100,000 sec
Min. Illumination
0.01Lux
COC
Yes (control OSD)
IR Cut
Yes
Lens Type
Vari-focal Lens : 5mm~50mm / 6mm~50mm
Adaptor
Optional
Power bracket
Optional
Coxial Cable Transmition
Distance(3C/5C)
300M/500M
Twisted Cable Transmition
Distance (Cat5e standard)
200M
Operating Temperature
-10℃~ 50℃(14℉~ 122℉)
Please use suitable adapter DC12V ± 10 %,1A. Otherwise, this product will be damaged.

3
COC (control over coaxial) function
①Enable the channel which you want to configure, and choose COC
(control over coaxial) function under PTZ Protocol page.
②Click the right button of the mouse, choose PTZ Control.
③Click ” Iris + “ to open OSD menu.
※Notice : When you are inside the camera OSD, if there is suddenly power
shortage, the setting will not be saved in the memory. You must exit the OSD
or wait the OSD disappears to validate the modified setting in the memory.
Icon
Description
Open the OSD menu of camera / Enter
Adjustment parameter options
Direction button, in order to choose the
item that you want to config.

4
Function
Description
LENS
MANUAL or DC
EXPOSURE
SHUTTER, AGC, SENS-UP, BRIGHTNESS, D-WDR, DEFOG
BACKLIGHT
Default is “OFF”, user can press right or left button to choose “OFF、BLC、HSBLC”
WHITEBAL
User can press right or left button to choose “ATW、AWC→SET、INDOOR、
OUTDOOR、MANUAL、AWB”
DAY & NIGHT
User can press right or left button to choose “EXT、AUTO、COLOR、B/W”
NR
Here can adjust 2DNR & 3DNR “LOW、MIDDLE、HIGH、OFF”
SPECIAL
CAMERA TITLE、D-EFFECT、MOTION、PRIVACY、LANGUAGE、DEFECT、
RS485 functions can be set under this menu.
※Language support: ENG, CHN1, CHN2, GER, FRA, ITA, SPA, POL, RUS, POR,
NED, TUR
ADJUST
SHARPNESS、MONITOR、LSC、VIDEO.OUT.
EXIT
SAVE & END OSD menu、RESET to factory default or NOT SAVE OSD menu
OSD Operation
MAIN MENU
1. LENS
MANUAL
2. EXPOSURE
↲
3. BACKLIGHT
OFF
4. WHITE BAL
ATW
5. DAY&NIGHT
EXT↲
6. NR
↲
7. SPECIAL
↲
8. ADJUST
↲
9. EXIT
SAVE&END↲
85-CH0000-A502G-A
Suppose you buy a product with OSD function
(1) Push direction RIGHT button about 5 sec to switch to AHD mode
(2) Push direction LEFT button about 5 sec to switch to CVBS mode
(3) Push direction DOWN button about 5 sec to switch to CVI mode
(4) Push direction UP button about 5 sec to switch to TVI mode
