JVC GY-HM600U User manual

LST1579-001A
The following are additions/changes made to the features as well as changes made to the displays. Please read through it together with the
AInstruction ManualB.
Addition of Operation Lock Feature
An Operation Lock feature has been added to prevent inadvertent operation of the camera.
While in the Camera mode, pressing and holding the [CANCEL] button on the camera body for 5 seconds or longer each time toggles the
Operation Lock feature to AOn/OffB.
When the Operation Lock feature is AOnB, the following icon is displayed.
Memo :
●The Operation Lock feature can only be enabled in the Camera mode.
●Turning off the power of the camera turns off the Operation Lock too.
●The [CANCEL] button on the LCD monitor cannot be used to switch the Operation Lock feature to AOn/OffB.
●The following remote operations are possible even when the Operation Lock feature is set to AOnB.
•Operation from a wired remote control connected to the [REMOTE] terminal.
•Remote operation of the camera through a browser on a smartphone, tablet device, computer, etc.
Operation Lock does not apply to the following buttons and switches.
●[POWER ON/OFF(CHG)] switch
●[ND FILTER] selection switch
●TC [IN/OUT] selection switch
●All switches inside the LCD monitor door (Operation Lock will be applied to the [CH1/CH2] adjustment knob.)
●Focus ring
●Grip zoom lever, handle zoom lever, zoom ring at the lens section
●[ZOOM SERVO/MANUAL] selection switch
●[FIX/VAR/OFF] zoom speed switch
●Iris ring
●[REC] button (located at the top of the handle, on the grip and at the bottom of the lens)
TOperation Lock will not be applied to the [REC] button at the bottom of the lens when [Camera Function] menu B[User Switch Set] B[Front
REC] is set to other than ARECB.
Addition of Contour Adjustment Feature during Playback
A [PEAKING(Playback)] item has been added to the [LCD/VF] menu.
Setting to AOnBenables you to adjust the contour of the playback image displayed in the LCD monitor or viewfinder using the [PEAKING +/-]
button.
Addition of Grid Display Feature
A [Grid Marker] item has been added to the [Marker Settings] menu.
Setting to AOnBdisplays a 3x3 grid over the image on the screen.
Setting to AOffBenables you to select [Aspect Ratio], [Aspect Marker], or [Safety Zone].
Memo :
●When [Grid Marker] is set to AOnB, the following items in the [Marker Settings] menu will be disabled.
•[Aspect Ratio]
•[Aspect Marker]
•[Safety Zone]
Changes/Additions to GY-HM600/GY-HM650 Instruction Manual
P13000K 1/100
F1. 6
0dB
AE+6
ND 1 / 64
12 : 34:56
Jan 24,2012
00:00: 00.00
403020 10 0
5 . 6 f t
GY-HM600_650_Sheet_a4.fm 1 ページ ２０１３年９月２４日 火曜日 午前１１時４４分

LST1579-001A©2013 JVC KENWOOD Corporation
Addition of Fixed Time (Timer Operation) Mode to the Magnified Focus Feature
A [Limited Time] (timer operation) option has been added to the [Expanded Focus] item.
Operation (in the ALimited TimeBsetting)
●
Auto focus : Switches the magnified focus to A Off B approximately 3 seconds after it is set to A On B .
● Manual focus : Switches the magnified focus to A Off B approximately 3 seconds after operation of the focus ring stops.
Changes in Display during Clip Cutter Recording
During clip cutter recording, the message display is now changed into a 3-second icon display.
Changes in Display during Dual Rec/Backup Rec
ADUALBduring Dual Rec and ABACKUPBin the Backup Rec mode used to be displayed on Display 0 and Display 1 only when there is a warning.
It now appears on all display screens.
TNot displayed during clip review.
Changes in the Display of Slot Icon
The slot icon used to be displayed on Display 0 and Display 1 only when there is a warning. It now appears on all display screens in the following
cases.
●During recording with only one of the slots when B[Slot Mode] of the [Record Set] menu is set to ADualB.
●During recording with only one of the slots when [Record Format]B[System] is set to AHD+SDBor AHD+WebB.
Addition of and Changes to Live Streaming Bitrates (GY-HM650U/GY-HM650E Only)
Streaming bitrate options have been newly added (in bold), and display of the bitrate options has been changed to the video bitrate (Mbps)
format.
Wider Range of Recording Formats that Support Live Streaming (GY-HM650U/GY-HM650E Only)
Distribution of live videos used to be supported only when [Record Format]B[System] is set to AHDB. This is now supported too in the ASDB
setting.
Addition of [REC] Feature to the [Camera control] Screen (GY-HM650U/GY-HM650E Only)
A [REC] button and a [STBY] button has been added to the [Camera control] screen during access via a smartphone, tablet device, computer,
etc.
No. of Frames for
WFrame & Bit
Rate
Resolution
Setting before Change
(R: Default Value)
Setting after Change
(R: Default Value)
60i, 60p, 30p 1920x1080 R60i(H), 60i(L) R60i(8.0 Mpbs), 60i(5.0 Mpbs), 60i(2.5 Mbps)
1280x720 R30p(H), 30p(L) R30p(5.0 Mpbs), 30p(3.0 Mpbs), 30p(1.5 Mbps)
720x480 R60i 60i(5.0 Mpbs), R60i(3.0 Mpbs), 60i(1.5 Mbps), 60i(0.8 Mbps), 60i(0.3 Mbps)
50i, 50p, 25p 1920x1080 R50i(H), 50i(L) R50i(8.0 Mpbs), 50i(5.0 Mpbs), 50i(2.5 Mbps)
1280x720 R25p(H), 25p(L) R25p(5.0 Mpbs), 25p(3.0 Mpbs), 25p(1.5 Mbps)
720x576 R50i 50i(5.0 Mpbs), R50i(3.0 Mpbs), 50i(1.5 Mbps), 50i(0.8 Mbps), 50i(0.3 Mbps)
P13000K 1/100
F1. 6
0dB
AE+6
ND 1 / 64
12 : 34:56
Jan 24,2012
00:00: 00.00
403020 10 0
5 . 6 f t
Clip Cut
Before After
