Highland MY-CS6004W User manual
6 QT Pressure Cooker
MODEL #MY-CS6004W
HIGHLAND and logo design are trademarks or
registered trademarks of LF, LLC. All rights reserved.
888-251-1024
ITEM #3846376
TM
TM
SM21491
20
120V~
A
B
C
Lid
Seal ring
Water box(note)
1
1
1
PART DESCRIPTION QUANTITY
D
Contro Panel 1
E
Float valve 1
F
Exhaust valve(note) 1
G
Sealing ring 1
H
Block proof cover 1
I
Inner pot 1
J
Cooker body handle 1
K
Cooker body 1
L
M
Spoon
Soup Spoon
1
1
PART DESCRIPTION QUANTITY
N
Measuring cup 1
A
B
C
D
G
F
H
I
K
J
E
L
M
N
1. If the supply cord is damaged, it must be replaced by a special cord or assembly
available from the manufacture or its service agent.
2. This appliance is for household use only. Do not use outdoors.
3. Keep electrical appliance out of reach from children or inform person. Do not let them
use the appliances.
4. This appliance shall not be used by children. Keep the appliance and its cord out of
reach of children.
5. Appliances can be used by persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the
hazards involved.
6. Children shall not play with the appliance.
7. Do not immerse any part of the appliance in water or other liquid.
8. Please turn off and unplug the appliance before cleaning, maintenance or relocation
and whenever it is not in use.
9. This appliance is intended to be used in household and similar applications such as:
-Staff kitchen areas in shops, offices and other working environments;
-farm houses;
-by clients in hotels, motels and other residential type environments;
-bed and breakfast type environments;
10. The pressure regulator allowing the escape of steam should be checked regularly to
ensure that they are not blocked.
11. State that the container must not be opened until the pressure has decreased
sufficiently.
12. The appliance is not intended to be operated by means of an external timer or a
separate remote-control system.
13. Cooking appliances should be positioned in a stable situation with the handles
positioned to void spillage of the hot liquids.
14. The heating element surface is subject to residual heat after use, do not touch.
15. The cooker cannot gain pressure when the lid is not well closed and the lid cannot be
opened when the inner pressure is too high.
16. Do not let children near the pressure cooker when in use.
17. Do not put the pressure cooker into a heated oven.
18. Move the pressure cooker under pressure with the greatest care. Do not touch hot
surfaces. Use the handles and knobs. If necessary, use protection.
19. Do not use the pressure cooker for a purpose other than the one for which it is
intended.
20. This appliance cooks under pressure. Scalds may result from inappropriate use of the
pressure cooker. Make sure that the cooker is property closed before applying heat,
see “instructions for use”.
21. Never forces open the pressure cooker. Do not open before making sure that its
internal pressure has completely dropped. See the “instructions for use”.
22. Never use your pressure cooker without adding water or food, except the Sauté
function, this would seriously damage it.
Read all instructions.
23. Do not fill the cooker beyond 2/3 of its capacity. When cooking foodstuffs which
expand during cooking, such as rice or dehydrate vegetables, do not fill the cooker to
more than half of its capacity.
24. Use the appropriate heat source(s) according to the instructions for use.
25. After cooking meat with a skin (e.g. ox tongue) which may swell under the effect of
pressure, do not prick the meat which the skin is swollen; you might be scalded.
26. When cooking doughy food, gently shake the cooker before opening the lid to avoid
food ejection.
27. Before each use, check that the valves are not obstructed. See the instructions for
use.
28. Never use the pressure cooker in its pressurized mode for deep or shallow frying of
food.
29. Do not tamper with any of the safety systems beyond the maintenance instructions
specified in the instructions for use.
30. Only use manufacturer's spare parts in accordance with the relevant model. In
particular, use a body and a lid from the same manufacturer indicated as being
compatible.
31. KEEP THESE INSTRUCTIONS.
32. Warning: Avoid spillage on the connector.
33. Warning: Misuse may cause potential injury.
1. When discharging keep your face or hand away from the relief pipe and from the lid
during operation to avoid scald.
2. Unplug appliance from mains electricity supply before taking food.
3. Don't touch the lid during cooking procedure or in heating status.
4. Never block the periphery of the clamping position to ensure safety.
5. Never attempt to uncover the cooker when floating valve is flopping or pressure inside.
6. Please mind of flowing hot water from the pressure discharging valve when open the
cover.
5
6
PRODUCT STRUCTURE
Tips:
1. Please move the product with the handle of the cooker body;
2. Please remove the water from the housing cover with cloth.
Note
Disassemble and install the block proof cover and seal ring
1. Exhaust valve: Pull out the exhaust valve from the lid. Clean the internal side of the
exhaust valve and the exhaust valve and float valve of the lid with brush and cloth at
least once a month.
2. Sealing gate: Please remove oil and dirt from the sealing gate with detergent and
brush. The remained oil and dirt in it may appear in yellowish. After washing, it may
recover to the original color as stainless steel. It is suggested to clean the sealing gate
once every 2 months.
3. Water box: After cooking, the steam may stay in the water box of the external pot as
water. Water in the box should be removed for avoiding bad odor, please clean it with
clean cloth.
1. Check if the seal ring (B) and block proof
cover (H) are correctly installed in the upper
cover before use each time.
2. A fter use, please clean the seal ring (B) and
around of block proof cover (H) for avoiding
jamming the cover, keep it clean to avoid
bad odor.
1. Please do not pull the seal ring (B),
otherwise, the distorted seal ring may
influence the seal ring (B) and pressure
effect.
2. Do not use the damaged seal ring (B),
please replace it at the authorized repair
office.
Disassemble
Install
Disassemble
and install the
block proof
cover
Pull it out upwards
Press it down to install
Disassemble
Disassemble
and install the
seal ring
H
B
B
B
B
H
H
H
Porridge
7
Use and maintain the stainless inner pot
Use and maintain the stainless inner pot
1. Do not empty.
It may cause yellowish and spotted inner pot or distorted bottom if it is empty for a
long time.
2. Do not use it to store the acid, alkali and preserved foods for a long period.
Although the inner pot has excellent anti-corrosion performance, it may cause
corrosion of certain degree, the suggested time of keep warm shall not exceed 2h.
3. Keep it clean to prolong the service life.
Do not immerse it in water for a long period.
Clean the inner pot with soap, weak detergent or warm water to remove dust, oil and
dirt.
4. Do not scratch it with steel shovel.
Soften the burnt foods on the bottom with water and then remove it.
Tips:
The bright inner pot has smooth and polished surface before use. After using for a long
period, the surface will become unclear with signs after it is washed with hard object. It is
normal and won't influence the function of the product.
(User shall read this function selectively according to the product model and
configuration.)
Optional pressure maintaining function
This function allows adjusting the pressure level according to the personal requirement by
pressing “Pressure Level” button, it requires entering into the “Manual Setting” state.
Cooking Timer Function
If the pressure maintaining time is adjusted by pressing “+”/“-”button, it requires entering
into the “Manual Setting” state
Delay Timer Function
Set the time of finishing cooking by pressing the “+”/“-” button
Menu Function Panel
Keep Warm Button
Cooking Timer Button
“+”Button
Menu Button
Delay Timer Button
Pressure Level Button
“-”Button
Manual Setting Button
Display Screen
PREPARE FOR COOKING
8
1. Opening the lid (A) correctly
• Hold the handle of upper cover, turn it
anticlockwise for about 30° till the “ ” mark on
the edge of the upper cover aiming at the“ ”
mark on the edge of the housing cover, and then
lift the upper cover.
2. Check if the parts and accessories of lid are well
installed
• Check if the floater valve and exhaust valve are
jammed, confirm if the sealing ring and block
proof cover are well installed.
3. Take out the inner pot (I), put the foods and water
into the inner pot
• The total amount of foods and water shall not
exceed the Max marked on the inner pot.
• The max rice and water amount when cooking
should not exceed the Max on the inner pot.
4. Put the inner pot into the cooker body (K)
• Wipe to clean the external surface of inner pot,
foreign object and water are not allowed on the
inner surface of electric pressure cooker;
• Turn the inner pot to left and right to ensure
good contact with the heating plate.
5. Safely close the lid (A)
• Before closing the lid (A), check if the sealing
ring is well installed.
• Hold the handle of upper cover, aim the “ ”
mark on the edge of the upper cover aiming at
the “ ” mark on the edge of the housing cover,
put the top cover horizontally on the cooker
body, turn the upper cover clockwise for about
30°to the lock place, and aim the “ ” mark on
the edge of the housing cover at the “ ” mark
on the lid (A).
I
K
A
A
6. Put the exhaust valve well
• When working, please turn the exhaust valve to
the sealing place, which means the electric
pressure cooker keeps at sealing state;
• For manual exhaust, please turn the exhaust
valve handle to the exhaust place, the electric
pressure cooker keeps at the exhaust state;
when exhausting, do not keep the hands or face
above the exhaust opening;
• Check if the floater valve drops down before
working (before heating, the floater valve is
down).
FUNCTION SELECTION
General Function
Tips:
1. Prepare for cooking according to the method listed on Page 8
2. Switch on If the buttons are inactive when use, please confirm if the lid is closed at the
right place, the buttons are inactive if the lid is not closed correctly for product of this
series.
3. Select the required function under the standby state, press the “Menu” button to select
function, press the “+”/“-” button to switch the function; Different function requires
different cooking time, the more the foods, the longer the cooking time.
4. Press one function button, 10s later, the electric pressure cooker starts to select the
program of corresponding function 10s after selecting the function, the electric pressure
cooker starts working. When the cooker is working, press the "Keep Warm/ ” button
to cancel the current work state and return standby state.
5. After cooking, the cooker may automatically enter into the keep warm state. The time of
keep warm shall not exceed 2h! After cooking, the indicator of corresponding function
lights off, the keep warm indicator lights on, the cooker makes sound and enters into
the keep warm state. Under the standby state, press the "Keep Warm/ ” button, the
keep warm indicator lights on, the cooker makes sound and enters into the keep warm
state.
Under any state, press the “Keep Warm/ ” button to cancel the current work state and
return standby state. When the cooker is working, it is normal that it makes "cluck" sound,
please set your heart at relax when use. To cook a small amount of foods, the inner pot
may possibly be lifted when opening the lid, please shake the lid to drop the inner pot in
the cooker body and then remove the lid.
9
Safely open the lid
1.Cut off power supply or remove the power plug.
2.Exhaust method.
A. Quickly open the lid.
Turn the exhaust valve to the exhaust place for exhausting,till the float valve drops down.
(For nonfluid foods)
B. Generally open the lid.
Keep the electric pressure cooker cool naturally till the float valve drops down.
3.Open the lid.
Turn the upper cover anticlockwise with the left hand, turn it to the cover open limit place,
lift the upper cover with the right hand to open the lid.
Do not open the lid before the pressure in the pot has been completely released, do not
open the lid fiercely if it is difficult to open.
Do not pull out the exhaust valve when turning the exhaust valve.
After cooking fluid foods (porridge and soup), do not turn the exhaust valve, please cut off
power supply to make it cool naturally till the float drops before opening the lid.
After cooking a large amount of foods, please do not immediately exhaust, it is suggested
to keep warm for a certain moment before opening the lid.
10
Function Operation Guidelines
After supplying power, the default is standby state, the digital screen flashes“----”
1. Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital screen
flashes “P01”, 10s later if no button is pressed, the product automatically starts cooking at “Meat”, the digital
screen displays ” P01”, and starts countdown when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the“Menu” button, press the “Delay Timer” button again,
“Delay Timer” indicator flashes, the digital screen flashes the time, start to adjust the preset time, press the
“+''/“-” button to adjust minute, press it once to adjust by 10min. 10s after setting, the product automatically
starts preset cooking at “Meat”, the digital screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
Meat
Poultry
Vegetable
Steam
Saute
Slow Cook
Standby
1. Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital screen
flashes “P01”, then press “+” one time, the digital screen displays“P02”. 10s later if no button is pressed, the
product automatically starts cooking at “Poultry”, the digital screen displays “P02”, and starts countdown
when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” one time, the digital screen
displays “P02”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital screen
flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Meat”, the digital
screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Menu” button,“ ”indicator lights on, the digital screen
flashes “P01”, then press “+” two times, the digital screen displays“P03”. 10s later if no button is pressed,
the product automatically starts cooking at “Vegetable”, the digital screen displays “P03”, and starts
countdown when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” two times, the digital screen
displays “P03”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital screen
flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Vegetable”, the digital
screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital screen
flashes “P01”, then press “+” three times, the digital screen displays “P04”. 10s later if no button is pressed,
the product automatically starts cooking at “Steam”, the digital screen displays “P04”, and starts countdown
when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” three times, the digital
screen displays “P04”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital
screen flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once
to adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Steam”, the digital
screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Menu” button,“ ”indicator lights on, the digital screen
flashes “P01”, then press “+” four times, the digital screen displays“P05”. 10s later if no button is pressed,
the product automatically starts cooking at “Saute”, the digital screen displays countdown “0:30”.
2. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Menu” button, “ ”indicator lights on, the digital screen
flashes “P01”, then press “+” five times, the digital screen displays “P06”. 10s later if no button is pressed,
the product automatically starts cooking at “Slow Cook”, the digital screen displays countdown “8:00”.
2. Exit work state: Press the “Keep Warm” button to exit the current work state.
OPERATION GUIDELINES
11
White Rice
Brown Rice
Beans
Broth
Curry
1. Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital screen
flashes “P01”, then press “+” six times, the digital screen displays “P07”. 10s later if no button is pressed,
the product automatically starts cooking at “White Rice”, the digital screen displays “P07”, and starts
countdown when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” six times, the digital screen
displays “P07”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital screen
flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts preset cooking at “White Rice”, the digital
screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital screen
flashes “P01”, then press “+” seven times, the digital screen displays “P08”. 10s later if no button is pressed,
the product automatically starts cooking at “Brown Rice”, the digital screen displays “P08”, and starts
countdown when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” seven times, the digital
screen displays “P08”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital
screen flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once
to adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Brown Rice”, the
digital screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital screen
flashes “P01”, then press “+” eight times, the digital screen displays “P09”. 10s later if no button is pressed,
the product automatically starts cooking at “Beans”, the digital screen displays “P09”, and starts countdown
when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” eight times, the digital
screen displays “P09”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital
screen flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once
to adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Beans”, the digital
screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Menu” button,“ ”indicator lights on, the digital screen
flashes “P01”, then press “+” nine times, the digital screen displays “P10”. 10s later if no button is pressed,
the product automatically starts cooking at “Broth”, the digital screen displays “P10”, and starts countdown
when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” nine times, the digital
screen displays “P10”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital
screen flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once
to adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Broth”, the digital
screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Menu” button,“ ”indicator lights on, the digital screen
flashes “P01”, then press “+” ten times, the digital screen displays “P11”. 10s later if no button is pressed,
the product automatically starts cooking at “Curry”, the digital screen displays “P11”, and starts countdown
when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” ten times, the digital screen
displays “P11”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital screen
flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Curry”, the digital
screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
12
Function Operation Guidelines
13
Multigrain
Manual
Setting
1. Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital screen
flashes “P01”, then press “+” twelve times, the digital screen displays “P13”. 10s later if no button is pressed,
the product automatically starts cooking at “Soup”, the digital screen displays “P13”, and starts countdown
when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” twelve times, the digital
screen displays “P13”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital
screen flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once
to adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Multigrain”, the
digital screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
1. Normal cooking: Under standby state, press the “Manual Setting” button,“Manual Setting” and “High”
indicators lights on, the digital screen displays “30”. 10s later if no button is pressed, the product
automatically starts cooking at “Manual Setting”, the digital screen displays “ ”, and starts countdown
when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Manual Setting” button,“Manual Setting” and “High”
indicators lights on, the digital screen displays “30”. Press the “Delay Timer” button again,“Delay Timer”
indicator flashes, the digital screen flashes the time, start to adjust the preset time, press the “+''/“-” button to
adjust minute, press it once to adjust by 10min. 10s after setting, the product automatically starts preset
cooking at “Manual Setting”, the digital screen displays the finishing time and starts countdown.
3. Pressure selection: Under standby state, press the “Manual Setting” button,“Manual Setting” and “High”
indicators lights on, the digital screen displays “30”. Adjust the pressure with “Pressure Level”, the “High”
lights off,“Low” lights on. 10s later if no button is pressed, the product automatically starts cooking at
“Manual Setting”, the digital screen displays“ ” , and starts countdown when pressure rises in the
cooker.
4. Exit work state: Press the “Keep Warm” button to exit the current work state.
Soup
1. Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital screen
flashes “P01”, then press “+” eleven times, the digital screen displays “P12”. 10s later if no button is pressed,
the product automatically starts cooking at “Soup”, the digital screen displays “P12”, and starts countdown
when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” eleven times, the digital
screen displays “P12”, press the “Delay Timer” button again,“Delay Timer” indicator flashes, the digital
screen flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once
to adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Soup”, the
digital screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
Function Operation Guidelines
Porridge
1. Normal cooking: Under standby state, press the “Menu” button, “ ” indicator lights on, the digital screen
flashes “P01”, then press “+” thirteen times, the digital screen displays “P14”. 10s later if no button is
pressed, the product automatically starts cooking at “Porridge”, the digital screen displays “P14”, and starts
countdown when pressure rises in the cooker.
2. Preset cooking: Under standby state, press the “Menu” button, then press “+” thirteen times, the digital
screen displays “P14”, press the “Delay Timer” button again, “Delay Timer” indicator flashes, the digital
screen flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it once
to adjust by 10min. 10s after setting, the product automatically starts preset cooking at “Porridge”, the digital
screen displays the finishing time and starts countdown.
3. Exit work state: Press the “Keep Warm” button to exit the current work state.
Normal cooking: Under standby state, press the “Menu” button,“ ” indicator lights on, the digital
screen flashes “P01”, then press “+” fourteen times, the digital screen displays “P15”. 10s later if no button
is pressed, the product automatically starts cooking at “ ”, the digital screen displays “P15”, and starts
countdown when pressure rises in the cooker.
Preset cooking: Under standby state, press the “Menu” button, then press “+” fourteen times, the digital
screen displays “P15”, press the “Delay Timer” button again, “Delay Timer” indicator flashes, the digital
screen flashes the time, start to adjust the preset time, press the “+''/“-” button to adjust minute, press it
once to adjust by 10min. 10s after setting, the product automatically starts preset cooking at “ ”, the
digital screen displays the finishing time and starts countdown.
Exit work state: Press the “Keep Warm” button to exit the current work state.
14
KEEP WARM FUNCTION
DAILY CHECK AND MAINTENANCE
SAFETY PRECAUTIONS
• After cooking, the electric pressure cooker automatically enters into the keep warm state; Under
keep warm state, keep warm indicator lights on;
• Under standby state, you may also press the “Keep Warm” button to keep warm;
• Keep warm temperature is 140°F~176°F;
If followings occur Solutions
There's dust or dirt on the plug or socket.
Stop using, and repair it by the
authorized repair center.
Remove the dust or dirt.
Power cord and plug is expanded, deformation, damaged
One part of the power cord and plug are hotter.
Power cord is flexible with discontinuous power supply.
The electric pressure cooker has abnormal heating and
generates bad odor.
There's abnormal noise or vibration when supply power.
To use the product safely with a longer service life, please carefully check and maintain it.
To avoid personal injury and property loss, be sure to observe the following safety
precautions.
It may possibly cause death or serious injury if the warning items are disobeyed.
The danger caused by mistaken use if following warnings are neglected includes to two grades
Meanings of the marks:
Means “Forbidden”
items
Means “Mandatory” items
General Forbid Disassemble
Forbidden Wet hands Forbidden
Contact Forbidden Spray Water
Forbidden
Must be executed Remove the
power plug
WARNING
It may cause physical injury or property damage if the caution items are disobeyed.
CAUTION
and the color is changed.
SAFETY PRECAUTIONS
Modification is prohibited
Warning on Opening the lid
Modification or repair by
non-professionals is
prohibited.
Violation may cause a
fire or electric shock.
Repair or replacement of
parts shall be made in a
designated service
center.
Doing so could cause
electric shock and
electrical short circuits.
When the electric pressure cooker is not
working, there isn't pressure in the pot,
the float valve is down;
When the electric pressure cooker is
working, pressure in the cooker rises,
float valve ascends; do not fiercely open
the lid before the pressure has been
completely released;
If it is difficult to open the lid, please do
not open it fiercely, otherwise, it may
cause scalding or physical injury.
Be sure to check
periodically the block
proof cover and
exhaust valve core to
make sure that they
are not be blocked;
Do not cover the
exhaust valve with
heavy object or
replace it with other
object.
Warning
Use 120V~ power outlet
Failure to use AC 120V
electricity can cause
fire or electric shock.
Danger of fire if the
bad socket is
adopted.
A socket shall be used alone
A socket of more than
10A rated current with
grounding wire shall be
used alone;
If shared with other
electrical appliances, the
socket may cause
abnormal heat and
result in fire.
Place the appliance in a
location out of reach of
infants.
To avoid electric shock
and scald.
Do not put foreign objects
It is prohibited to insert
metal shavings, needles
and other foreign matter
in the gap.
As this may cause
electric shock or
movement anomalies.
Replace the damaged
power cord with special
soft cord or replace it
with special assembly
purchased from the
manufacturer or
authorized repair
center.
It is strictly prohibited to use other lid
It is strictly prohibited to
use other lid for heating,
and in the (switching on)
process, the use of non-
original lid is not
allowed.
As this may cause
electric shock or safety
hazards.
15
Place the appliance in a location out of reach
of infants
Products may not be immersed or sprinkled
in water
Check periodically
Stop using if the power cord is damaged
ENVIRONMENT FOR STORING THE PRODUCT
CLEAN AFTER USE
1. Clean after each use.
2. Before cleaning and maintenance, please unplug the power cord until the product
cools.
3. Remove the lid and inner pot, clean with detergent first, then rinse well with water, and
wipe dry with a soft cloth.
4. Clean the internal side of the lid with water, the seal ring, block proof cover, exhaust
valve core and float valve can be removed for washing, timely and correctly install them
after washing, and then dry the internal side of lid with cloth.
5. Wipe clean the cooker body with a rag, and it is prohibited to soak the cooker body in
water or spray water to it.
• Periodically clean the cooker and remove oil and dirt if it is stored on the table.
• Put the electric pressure cooker 30cm away from other kitchen appliances.
17
When the following occur, it is not the cooker's fault, please carefully check once before
sending it for repair.
TROUBLESHOOTING
S/N Problem Reason Solution
Difficult to close the lid
Sealing ring not installed properly
The floater valve clamps the push rod
Position the sealing ring well
Lightly push the push rod
Float valve in the popped-up position
Pressure exists inside the cooker
Sealing ring installed improperly
Food debris attached to the sealing ring
Sealing ring damaged
The lid is not closed correctly
Steam leaks from the lid
Press the float valve lightly
with a chopstick.
Open the lid after the pressure is
completely released.
Install the sealing ring as required
Clean the sealing ring
Replace the sealing ring
Close the lid correctly
Add water and food according
to the recipe
Send to the service center for repair
Turn the exhaust valve to the
sealing position
Send to the service center for repair
Please check the power socket
Send to the service center for repair
Add water according to the
requirement
Put the inner pot correctly
Send to the service center for repair
Add water accordingly
After cooking cycle completes,
leave the lid on for 5 more minutes.
Reduce water accordingly
Too much water
Lid opened prematurely
Too litter water
Pressure switch fault
High temperature since there isn't
water in the inner pot
High temperature since there isn't
water in the inner pot
Bottom sensor fault
Power socket bad contact
Pressure control fails
Exhaust valve not in sealing position
Steam leaks from the lid or exhaust valve
Too little food and water in inner pot
Float valve gasket worn-out
Food debris on the float valve gasket
Steam leaks from float valve
Float valve unable to rise
Steam comes out from
exhaust valve non-stop
Power indicator doesn't light on
Display screen displays E1
Display screen displays E2
Display screen displays C1
Display screen displays E8
Rice half cooked or too hard
Rice too soft
All indicators flash
——If the fault is not removed after above check, please contact our authorized service center for repair.
Difficult to close the lid
18
WARRANTY
19
ONE YEAR LIMITED WARRANTY. The manufacturer warrants this product to be free
from manufacturing defects in material and workmanship. This one year warranty does not
cover transit damages.
This warranty does not apply to the finish on any portion of the product. Serving performed
by unauthorized persons shall render the warranty invalid. For warranty service, contact
Customer Service at 888-251-1024, 8 a.m.-8 p.m., EST, Monday – Sunday.Some states
do not allow the limitation or exclusion of certain damages. Therefore, these limitations
and exclusions may not apply to you. This warranty gives the consumer specific legal
rights. You may have other rights that vary from state to state.
Printed in China
Olla de presión de
5,67 litros
MODELO #MY-CS6004W
HIGHLAND y el diseño del logotipo son marcas
comerciales o marcas registradas de LF, LLC.
Todos los derechos reservados.
ARTÍCULO #3846376
TM
TM
SM21491
¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a nuestro
Departamento de Servicio al Cliente al 888-251-1024, de lunes a domingo, de 8 a.m. a
8 p.m., hora estándar del Este. También puede comunicarse con nosotros a través de
Fecha de compra
Número de serie
20
This manual suits for next models
1
Table of contents
Languages:
