HIK VISION DS-D6043FN-B User manual

Digital Signage
Quick Start Guide

Legal Informaon
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
: The terms HDMI and HDMI High-Denion Mulmedia Interface, and the HDMI
Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH
ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS,
AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
Digital Signage Quick Start Guide
i

INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Digital Signage Quick Start Guide
ii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucon manual, may cause harmful
interference to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with
"CE" and comply therefore with the applicable harmonized European
standards listed under the EMC Direcve 2014/30/EU, the RoHS Direcve
2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collecon points.
For more informaon see: hp://www.recyclethis.info .
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the
product documentaon for specic baery informaon. The baery is
marked with this symbol, which may include leering to indicate cadmium
(Cd), lead (Pb), or mercury (Hg). For proper recycling, return the baery to
your supplier or to a designated collecon point. For more informaon see:
hp://www.recyclethis.info .
Digital Signage Quick Start Guide
iii

Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
Digital Signage Quick Start Guide
iv

Preface
Applicable Models
This manual is applicable to Digital Signage.
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note Provides addional informaon to emphasize or supplement
important points of the main text.
Digital Signage Quick Start Guide
v

Contents
Chapter 1 Product Introducon .................................................................................................. 1
Chapter 2 Typical Applicaon ..................................................................................................... 2
Chapter 3 Acvaon ................................................................................................................... 5
3.1 Acvaon for Scene One ....................................................................................................... 5
3.1.1 Acvate on the Client .................................................................................................... 5
3.1.2 Acvate on the Terminal ............................................................................................... 6
3.1.3 Reset Password on the Client ........................................................................................ 7
3.2 Acvaon for Scene Two ....................................................................................................... 7
3.2.1 Acvate on the Client .................................................................................................... 7
3.2.2 Acvate on the Terminal ............................................................................................... 8
3.3 Acvaon for Scene Three ..................................................................................................... 8
3.3.1 Acvate on the Client .................................................................................................... 8
3.3.2 Acvate on the Mobile Phone ...................................................................................... 9
3.3.3 Acvate on the Terminal ............................................................................................. 10
Chapter 4 Registraon .............................................................................................................. 11
4.1 Register Terminals for Scene One ........................................................................................ 11
4.1.1 Register on the Client .................................................................................................. 11
4.1.2 Register on the Terminal ............................................................................................. 12
4.2 Register Terminals for Scene Two ........................................................................................ 13
4.2.1 Register on the Client .................................................................................................. 13
4.2.2 Register on the Terminal ............................................................................................. 15
4.3 Register Terminals for Scene Three ...................................................................................... 15
4.3.1 Register on the Client .................................................................................................. 15
4.3.2 Register on the Mobile Phone .................................................................................... 16
4.3.3 Register on the Terminal ............................................................................................. 17
Chapter 5 FocSign Player Operaons ........................................................................................ 18
Digital Signage Quick Start Guide
vi

Chapter 6 Face Aendance App Operaon ............................................................................... 19
6.1 Add a Face Aendance Camera ........................................................................................... 19
6.1.1 Add on the Client ........................................................................................................ 19
6.1.2 Add on the Terminal .................................................................................................... 20
6.2 Edit Homepage Title ............................................................................................................. 21
Chapter 7 System Sengs ........................................................................................................ 22
Chapter 8 Remote Control Operaons ...................................................................................... 23
8.1 Remote Control (Type One) ................................................................................................. 23
8.1.1 Funcons of Remote Control Keys .............................................................................. 23
8.1.2 Operaon of Remote Control ..................................................................................... 24
8.2 Remote Control (Type Two) ................................................................................................. 24
8.2.1 Funcons of Remote Control Keys .............................................................................. 25
8.2.2 Bind a Remote Control to a Terminal .......................................................................... 25
8.2.3 Unbind a Remote Control from a Terminal ................................................................. 27
Chapter 9 Get More Informaon .............................................................................................. 29
Digital Signage Quick Start Guide
vii

Chapter 1 Product Introducon
Digital signage (hereinaer referred to as the terminal) displays are used to broadcast informaon,
release news, and adverse products, etc, working together with other related products, such as
informaon release servers and informaon release system, or the digital signage lite. Digital
signage displays are divided into two types according to the appearance: wall-mounted displays
and standing displays, which are widely applied to industries such as entertainment, nance, and
transportaon. The adapted display connected to the is equivalent to the digital signage. The
following instrucons are subject to the digital signage.
Digital Signage Quick Start Guide
1

Chapter 2 Typical Applicaon
This chapter describes two typical applicaon scenes for your reference. The two scenes are
dierent and require dierent conguraon of your terminals. Please strictly follow the operaon
instrucons described in the following secons.
Scene 1
Refer to the following table for the detailed descripon of the scene 1.
Table 2-1 Scene 1 Descripon
Item Descripon
Components Server: Informaon Release Server (DS-D60S-B)
Client: Informaon Release System Client
Terminal: Digital Signage
Terminals Supported ≥ 30
Key Funcons •Mulple users are allowed for the server.
• Access the server through the client.
• Manage terminals through the server.
• Upload materials to the server.
•Edit programs.
• Create and schedules to terminals.
Figure 2-1 Scene 1
Digital Signage Quick Start Guide
2

Scene 2
Refer to the following table for the detailed descripon of the scene2.
Table 2-2 Scene 2 Descripon
Item Descripon
Components Client: Digital Signage Lite
Terminal: Digital Signage
Terminals Supported ≤ 30
Key Funcons • Only one user is allowed for the client.
• Manage terminals on the client.
• Edit programs on the client.
• Create and schedules to terminals.
Figure 2-2 Scene 2
Scene 3
Refer to the following table for the detailed descripon of the scene 3.
Table 2-3 Scene 3 Descripon
Item Descripon
Components Server: FocSign Server
Client: FocSign Client, FocSign Web, or FocSign Mobile
Digital Signage Quick Start Guide
3

Item Descripon
Terminal: Digital Signage
Terminals Supported ≥ 30
Key Funcons •Mulple users are allowed for the client.
• Upload materials to the server.
• Manage terminals on the server.
• Edit programs on the client.
•Create schedules to terminals.
• Face recognion and check-in funcons with intelligent
cameras.
Note
Some types of terminals have built-in cameras, while others
require connecon to external cameras.
Figure 2-3 Scene 3
Digital Signage Quick Start Guide
4

Chapter 3 Acvaon
This chapter describes acvaon methods in three scenes. The way of acvaon in three scenes is
dierent. Please select acvaon methods according to the scenes.
3.1 Acvaon for Scene One
3.1.1 Acvate on the Client
Before You Start
Your computer used for running the client is on the same network segment with the terminal.
Steps
1. Run client soware.
Figure 3-1 Login
2. Click Online Device.
Digital Signage Quick Start Guide
5

Figure 3-2 Online Device
3. Select terminal to acvate and click Security Status.
Figure 3-3 Network Informaon
4. Enter Password, enter the same password in Conrm Password text-eld, and click Apply.
Figure 3-4 Terminal Acvaon
3.1.2 Acvate on the Terminal
Steps
1. Power on the terminal.
Digital Signage Quick Start Guide
6

2. Click ACTIVATE on acvaon interface.
3. Enter password and conrm password.
4. Click ACTIVATE.
3.1.3 Reset Password on the Client
Steps
Note
You are highly recommended to reset password with the help of our technical support.
1. Click Export to export the restoraon le and send the le to our technical support.
Figure 3-5 Reset Password
2. Technical support will send you back a le. Click Import and select the le.
3. Enter Password, enter the same password in Conrm Password text-eld, and click OK.
3.2 Acvaon for Scene Two
3.2.1 Acvate on the Client
Before You Start
• Your computer used for running the client is on the same network segment with the terminal.
• Your terminal is powered on.
Steps
1. Go to Terminal Management.
2. Click on the lower-right corner.
3. Select the terminals to acvate.
4. Click Acvate.
Digital Signage Quick Start Guide
7

Figure 3-6 Acvate Terminal
5. Set the terminal password and conrm password.
6. Click OK.
7. Oponal: Edit network parameters of the terminal.
1) Select Terminal → Terminal Conguraon → Terminal Network .
2) Enter and edit network parameters such as IP Address, Subnet Mask and Gateway.
3) Click OK.
3.2.2 Acvate on the Terminal
The way of acvaon on the terminal is the same as in Scene One. To acvate on the terminal,
refer to Acvate on the Terminal .
3.3 Acvaon for Scene Three
There are three ways to acvate the terminals in Scene Three.
•Acvate the terminal on the client. Please get FocSign Client in the company website.
•Acvate the terminal on the mobile phone. Please download FocSign Mobile in the company
website or App Store.
•Acvate on the terminal.
3.3.1 Acvate on the Client
Before You Start
• Your computer used for running the client is on the same network segment with the terminal.
• Your terminal is powered on.
Digital Signage Quick Start Guide
8

Steps
1. Log into FocSign Client.
2. Click Terminal in the menu bar.
3. Click in Online Device to view online terminals.
4. Select the terminal to be acvated.
5. Click Acvaon.
Figure 3-7 Acvate Terminal
6. Set the terminal password and conrm password.
7. Click OK.
8. Oponal: Edit network parameters of the terminal.
1) Select Terminal → Terminal Conguraon → Terminal Network .
2) Enter and edit network parameters such as IP Address, Subnet Mask and Gateway.
3) Click OK.
3.3.2 Acvate on the Mobile Phone
Steps
Note
• Before acvang terminals, please ensure that SADP is enabled on the terminals. When the
SADP is disabled, there are no QR code on the terminal.
• The APP and the terminal must be in the same network segment. If a router exists, and the
terminal is connected to the router with the network cable, the mobile phone must be in the Wi-
Fi network environment provided by the same router.
• Please refer to FocSign Client user manual to acvate or register terminals in dierent network
segments with the APP.
1. Log into FocSign Mobile.
2. Tap on the upper right corner of the Terminal interface to scan the QR code of the terminal.
Digital Signage Quick Start Guide
9

3. Enter the New Password and conrm it.
Figure 3-8 Acvate Terminal
4. Tap Acvate.
3.3.3 Acvate on the Terminal
The way of acvaon on the terminal is the same as in Scene One. To acvate on the terminal,
refer to Acvate on the Terminal .
Digital Signage Quick Start Guide
10

Chapter 4 Registraon
This chapter describes registraon methods in three scenes. The way of registraon in three
scenes is dierent. Please select registraon methods according to the scenes.
4.1 Register Terminals for Scene One
4.1.1 Register on the Client
To register terminals to the informaon release server (hereinaer referred to as the server).
Before You Start
• You have acvated your terminals.
• Your computer used for running the client is on the same network segment with the server.
Steps
1. Run the client soware.
2. Click Online Device.
Figure 4-1 Online Device
3. Select an acvated terminal and click Registraon.
Digital Signage Quick Start Guide
11

Figure 4-2 CMS Register
4. Enter server informaon, including Server IP Address, Server Port, server User Name, and
Server Password.
Note
The server port is 7660 by default. You can change the server port as needed.
5. Enter a custom Terminal Name.
6. Enter the Terminal Password.
7. Click OK.
8. Oponal: Click Register status and enter Terminal Password to check registraon status.
4.1.2 Register on the Terminal
You can register your terminals on themselves.
Steps
Note
If your terminal is touchscreen, you can operate the terminal with your gure and skip Step 1.
1. Aach a mouse.
2. Click on the side of the screen.
3. Enter screen-saving password.
4. Click Conrm.
5. Click on the sidebar.
6. Set server parameters.
Digital Signage Quick Start Guide
12
