Hikmicro HM-TD3117T-1/Q User manual

Thermographic Cube Camera
User Manual

Legal Informaon
©2022 Hangzhou Microimage Soware Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the HIKMICRO website ( hp://
www.hikmicrotech.com ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other HIKMICRO's trademarks and logos are the properes of
HIKMICRO in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKMICRO MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKMICRO
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKMICRO SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKMICRO WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Thermographic Cube Camera User Manual
i

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Thermographic Cube Camera User Manual
ii

Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note Provides addional informaon to emphasize or supplement
important points of the main text.
Thermographic Cube Camera User Manual
iii

Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
Laws and Regulaons
●In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
Transportaon
●Keep the device in original or similar packaging while transporng it.
●Keep all wrappers aer unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original wrapper. Transportaon without the original
wrapper may result in damage on the device and the company shall not take any responsibilies.
●DO NOT drop the product or subject it to physical shock. Keep the device away from magnec
interference.
Power Supply
●Please purchase the charger by yourself. Input voltage should meet the Limited Power Source
(12 VDC) according to the IEC62368 standard. Please refer to technical specicaons for detailed
informaon.
●Make sure the plug is properly connected to the power socket.
●The socket-outlet shall be installed near the equipment and shall be easily accessible.
●DO NOT connect mulple devices to one power adapter, to avoid over-heang or re hazards
caused by overload.
●DO NOT touch the bare metal contacts of the inlets aer the circuit breaker is turned o.
Electricity sll exists.
●+ idenes the posive terminal(s) of equipment which is used with, or generates direct current.
- idenes the negave terminal(s) of equipment which is used with, or generates direct current.
Baery
●Risk of explosion if the baery is replaced by an incorrect type. Dispose of used baeries
according to the instrucons. Il y a risque d'explosion si la baerie est remplacée par une
baerie de type incorrect. Mere au rebut les baeries usagées conformément aux instrucons.
●The built-in baery cannot be dismantled. Please contact the manufacture for repair if
necessary.
●For long-term storage of the baery, make sure it is fully charged every half year to ensure the
baery quality. Otherwise, damage may occur.
●This equipment is not suitable for use in locaons where children are likely to be present.
●Improper replacement of the baery with an incorrect type may defeat a safeguard (for
example, in the case of some lithium baery types).
Thermographic Cube Camera User Manual
iv

●DO NOT dispose of the baery into re or a hot oven, or mechanically crush or cut the baery,
which may result in an explosion.
●DO NOT leave the baery in an extremely high temperature surrounding environment, which
may result in an explosion or the leakage of ammable liquid or gas.
●DO NOT subject the baery to extremely low air pressure, which may result in an explosion or
the leakage of ammable liquid or gas.
Installaon
●Never place the equipment in an unstable locaon. The equipment may fall, causing serious
personal injury or death.
●This equipment is for use only with corresponding brackets. Use with other (carts, stands, or
carriers) may result in instability causing injury.
System Security
●You acknowledge that the nature of Internet provides for inherent security risks, and our
company shall not take any responsibilies for abnormal operaon, privacy leakage or other
damages resulng from cyber aack, hacker aack, however, our company will provide mely
technical support if required.
●Please enforce the protecon for the personal informaon and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Please contact us when the device might exist network security risks.
●Please understand that you have the responsibility to congure all the passwords and other
security sengs about the device, and keep your user name and password.
Maintenance
●If the product does not work properly, please contact your dealer or the nearest service center.
We shall not assume any responsibility for problems caused by unauthorized repair or
maintenance.
●A few device components (e.g., electrolyc capacitor) require regular replacement. The average
lifespan varies, so periodic checking is recommended. Contact your dealer for details.
●Wipe the device gently with a clean cloth and a small quanty of ethanol, if necessary.
●If the equipment is used in a manner not specied by the manufacturer, the protecon provided
by the device may be impaired.
●To reduce the risk of re, replace only with the same type and rang of fuse.
●The serial port of the equipment is used for debugging only.
Using Environment
●Make sure the running environment meets the requirement of the device. The operang
temperature shall be -20°C to 50°C (-4°F to 122°F), and the operang humidity shall be 95% or
less.
●DO NOT expose the device to high electromagnec radiaon or dusty environments.
●DO NOT aim the lens at the sun or any other bright light.
Thermographic Cube Camera User Manual
v

●The equipment shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on the equipment.
●No naked ame sources, such as lighted candles, should be placed on the equipment.
●Provide a surge suppressor at the inlet opening of the equipment under special condions such
as the mountain top, iron tower, and forest.
●Burned ngers when handling the parts with symbol . Wait one-half hour aer switching o
before handling the parts.
Emergency
●If smoke, odor, or noise arises from the device, immediately turn o the power, unplug the
power cable, and contact the service center.
Thermographic Cube Camera User Manual
vi

Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Brief Descripon .................................................................................................................... 1
1.2 Funcon ................................................................................................................................. 1
1.3 Typical Applicaon ................................................................................................................. 1
Chapter 2 Device Acvaon and Accessing ................................................................................. 4
2.1 Acvate the Device via SADP ................................................................................................. 4
2.2 Acvate the Device via Browser ............................................................................................. 4
2.3 Login ...................................................................................................................................... 5
2.3.1 Plug-in Installaon ........................................................................................................ 5
2.3.2 Illegal Login Lock ........................................................................................................... 6
Chapter 3 Temperature Measurement ........................................................................................ 7
3.1 Noce ..................................................................................................................................... 7
3.2 Thermometry Flow Chart ....................................................................................................... 7
3.3 Automac Thermography ...................................................................................................... 8
3.3.1 Set Thermometry Parameters ....................................................................................... 9
3.3.2 Set Normal Mode ........................................................................................................ 10
3.3.3 Set Expert Mode ......................................................................................................... 11
3.3.4 Set Thermography Rule ............................................................................................... 11
3.3.5 Set Shielded Region .................................................................................................... 14
3.4 External Temperature Sensor ............................................................................................... 14
3.4.1 Set 433 MHz Transmission .......................................................................................... 14
3.4.2 Connect Temperature Sensors to Device .................................................................... 14
3.4.3 Set External Temperature Sensor ................................................................................ 15
3.5 Upload Temperature Alarm to Center ................................................................................. 16
Chapter 4 Event and Alarm ....................................................................................................... 17
4.1 Set Excepon Alarm ............................................................................................................. 17
Thermographic Cube Camera User Manual
vii

Chapter 5 Arming Schedule and Alarm Linkage ......................................................................... 18
5.1 Set Arming Schedule ............................................................................................................ 18
5.2 Linkage Method Sengs ...................................................................................................... 18
5.2.1 Nofy Surveillance Center .......................................................................................... 18
Chapter 6 Live View .................................................................................................................. 19
6.1 Live View Parameters ........................................................................................................... 19
6.1.1 Window Proporon .................................................................................................... 19
6.1.2 Live View Stream Type ................................................................................................ 19
6.1.3 Enable and Disable Live View ...................................................................................... 19
6.1.4 Start Digital Zoom ....................................................................................................... 19
6.2 Quick Set Live View .............................................................................................................. 20
6.3 Set Transmission Parameters ............................................................................................... 20
Chapter 7 Video and Audio ....................................................................................................... 22
7.1 Video Sengs ...................................................................................................................... 22
7.1.1 Stream Type ................................................................................................................ 22
7.1.2 Video Type .................................................................................................................. 22
7.1.3 Resoluon ................................................................................................................... 22
7.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 22
7.1.5 Video Quality .............................................................................................................. 23
7.1.6 Frame Rate .................................................................................................................. 23
7.1.7 Video Encoding ........................................................................................................... 23
7.1.8 Smoothing ................................................................................................................... 24
7.1.9 Display VCA Info .......................................................................................................... 24
7.2 Display Sengs .................................................................................................................... 25
7.2.1 Image Adjustment (Thermal Channel) ........................................................................ 25
7.2.2 Set Palee ................................................................................................................... 25
7.2.3 DDE ............................................................................................................................. 26
7.3 OSD ...................................................................................................................................... 26
Thermographic Cube Camera User Manual
viii

7.4 Set Manual DPC (Defecve Pixel Correcon) ....................................................................... 26
7.5 Metadata ............................................................................................................................. 27
Chapter 8 Video Recording and Picture Capture ........................................................................ 28
8.1 Video Recording ................................................................................................................... 28
8.1.1 Record Manually ......................................................................................................... 28
8.2 Capture Conguraon .......................................................................................................... 28
8.2.1 Capture Manually ........................................................................................................ 28
Chapter 9 Network Sengs ...................................................................................................... 29
9.1 TCP/IP ................................................................................................................................... 29
9.1.1 Mulcast Discovery ..................................................................................................... 30
9.2 Port ...................................................................................................................................... 30
9.3 Port Mapping ....................................................................................................................... 31
9.3.1 Set Auto Port Mapping ................................................................................................ 31
9.3.2 Set Manual Port Mapping ........................................................................................... 31
9.3.3 Set Port Mapping on Router ....................................................................................... 32
9.4 Access to Device via Domain Name ..................................................................................... 33
9.5 Set HTTP Listening ............................................................................................................... 33
Chapter 10 System and Security ................................................................................................ 34
10.1 View Device Informaon .................................................................................................... 34
10.2 Search and Manage Log ..................................................................................................... 34
10.3 Import and Export Conguraon File ................................................................................ 34
10.4 Export Diagnose Informaon ............................................................................................. 35
10.5 Reboot ............................................................................................................................... 35
10.6 Restore and Default ........................................................................................................... 35
10.7 Upgrade ............................................................................................................................. 35
10.8 View Open Source Soware License .................................................................................. 36
10.9 Time and Date .................................................................................................................... 36
10.9.1 Synchronize Time Manually ...................................................................................... 36
Thermographic Cube Camera User Manual
ix

10.9.2 Set NTP Server .......................................................................................................... 36
10.9.3 Set DST ...................................................................................................................... 37
10.10 Set RS-232 ........................................................................................................................ 37
10.11 Set RS-485 ........................................................................................................................ 37
10.12 Set Same Unit .................................................................................................................. 38
10.13 Security ............................................................................................................................ 38
10.13.1 Authencaon ........................................................................................................ 38
10.13.2 Set IP Address Filter ................................................................................................ 38
10.13.3 Set HTTPS ................................................................................................................ 39
10.13.4 Set QoS .................................................................................................................... 40
10.14 User and Account ............................................................................................................. 40
10.14.1 Set User Account and Permission ........................................................................... 40
Chapter 11 Appendix ................................................................................................................ 42
11.1 Common Material Emissivity Reference ............................................................................ 42
11.2 Device Command ............................................................................................................... 42
11.3 Device Communicaon Matrix .......................................................................................... 43
Thermographic Cube Camera User Manual
x

Chapter 1 Overview
1.1 Brief Descripon
The Thermographic Cube Camera is a temperature measurement device which is equipped with a
thermal lens.
It is equipped with high-sensivity IR detector and high-performance sensor. The device is able to
measure object's temperature at a high accuracy in real me. It is applied to electric system, and
industrial automaon, etc, for re prevenon. The pre-alarm system helps you discover
unexpected events immediately and protects your property.
1.2 Funcon
This secon introduces main funcons of the device.
Temperature Measurement
Device detects the real-me temperature all the day, and display it on liveview.
Temperature Excepon Alarm
Device outputs alarm when the temperature is higher than the seng alarm threshold value.
Image Adjustment
Device can correct the nonuniformity of the image and improve the image quality.
433 Wireless Network Transmission
Device can receive the thermometry informaon of the sensors through the 433 module, and
upload the informaon to the wireless gateway.
1.3 Typical Applicaon
Thermographic Cube Camera supports 433MHz wireless transmission, which makes it more
friendly to use in the applicaon scenarios where cable roung is inconvenient.
The device receives temperature data and alarm from external temperature detectors with
433MHz wireless transmission and uploads the data to the center.
When sending data to the center client (iVMS-4200), the device supports a wireless way (with the
help of a gateway that supports 433MHz transmission) and a wired way.
Thermographic Cube Camera User Manual
1

Figure 1-1 Temperature Data Transmission among sensors, Cube Camera, and Center
Table 1-1 Sengs for Temperature Data Transmission
Data Transmission Main Sengs
From External
Temperature Sensors
to Thermographic
Cube Camera
1. Install sensors and the device. Refer to the installaon guide of the
sensors and the device.
Note
The distance between a sensor and a device should be within the
433MHz transmission distance limitaon.
2. Acvate and log in to the device. See Device Acvaon and Accessing
for instrucons.
3. Enable 433MHz data transmission on device. See Set 433 MHz
Transmission for instrucons.
4. Connect temperature sensor to device. See Connect Temperature
Sensors to Device for instrucons.
5. Set alarm rules for each temperature detector. See Set External
Temperature Sensor for instrucons.
From Thermographic
Cube Camera to
Center (Wireless
Way)
1. Enable 433MHz data transmission on device. See Set 433 MHz
Transmission for instrucons.
2. Set up the gateway to connect the device to a network. See the manual
of your gateway for instrucons.
Note
The gateway should support 433MHz transmission.
3. Set the temperature alarm Transmission Mode to 433 Wireless
Network Transmission at Conguraon → Temperature Measurement
→ Alarm Sengs . See Upload Temperature Alarm to Center for
instrucons.
4. Add the device to the center client (iVMS-4200). See the user manual of
the client soware for instrucons.
Thermographic Cube Camera User Manual
2

Data Transmission Main Sengs
Access hps://www.hikmicrotech.com/en/download/5 to get
iVMS-4200 soware.
From Thermographic
Cube Camera to
Center (Wired Way)
1. Connect the device to network with network cable.
2. Add the device to the center client (iVMS-4200). See the user manual of
the client soware for instrucons.
Access hps://www.hikmicrotech.com/en/download/5 to get
iVMS-4200 soware.
Thermographic Cube Camera User Manual
3

Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate the Device via SADP
Search and acvate the online devices via SADP soware.
Before You Start
Access hps://www.hikmicrotech.com/en/download/5 to get SADP soware to install.
Steps
1. Connect the device to network using the network cable.
2. Run SADP soware to search the online devices.
3. Check Device Status from the device list, and select Inacve device.
4. Create and input the new password in the password eld, and conrm the password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including upper case leers, lower case leers, numbers, and special characters) in
order to increase the security of your product. And we recommend you reset your password
regularly, especially in the high security system, reseng the password monthly or weekly can
beer protect your product.
5. Click OK.
Device Status changes into Acve.
6. Oponal: Change the network parameters of the device in Modify Network Parameters.
2.2 Acvate the Device via Browser
You can access and acvate the device via the browser.
Steps
1. Connect the device to the PC using the network cables.
2. Change the IP address of the PC and device to the same segment.
Thermographic Cube Camera User Manual
4

Note
The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from
192.168.1.2 to 192.168.1.253 (except 192.168.1.64). For example, you can set the IP address of
the PC to 192.168.1.100.
3. Input 192.168.1.64 in the browser.
4. Set device acvaon password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including at least three of the following categories: upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
5. Click OK.
6. Input the acvaon password to log in to the device.
7. Oponal: Go to Conguraon → Network → Basic → TCP/IP to change the IP address of the
device to the same segment of your network.
2.3 Login
Log in to the device via Web browser.
2.3.1 Plug-in Installaon
Certain operaon systems and web browser may restrict the display and operaon of the device
funcon. You should install plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Operang System Web Browser Operaon
Windows Internet Explorer 10+ Follow pop-up prompts to
complete plug-in installaon.
Google Chrome 57+
Mozilla Firefox 52+
Click to
download and install plug-in.
Go to Conguraon →
Network → Advanced Sengs
→ Network Service to enable
WebSocket or WebSockets for
normal view if plug-in
installaon is not required.
Thermographic Cube Camera User Manual
5

Operang System Web Browser Operaon
Display and operaon of
certain funcons are restricted.
For example, Playback and
Picture are not available. For
detailed restricted funcon,
refer to the actual device.
Mac OS 10.13+ Mac Safari 12+ Plug-in installaon is not
required.
Go to Conguraon →
Network → Advanced Sengs
→ Network Service to enable
WebSocket or WebSockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted funcon, refer to the
actual device.
Note
The device only supports Windows and Mac OS system and does not support Linux system.
2.3.2 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go to Conguraon → System → Security → Security Service , and enable Enable Illegal Login
Lock. Illegal Login Aempts and Locking Duraon are congurable.
Illegal Login Aempts
When your login aempts with the wrong password reach the set mes, the device is locked.
Locking Duraon
The device releases the lock aer the seng duraon.
Thermographic Cube Camera User Manual
6

Chapter 3 Temperature Measurement
When you enable this funcon, the device measures the actual temperature of the scene. It alarms
when temperature exceeds the temperature threshold value.
3.1 Noce
This part introduces the noces of conguring temperature measurement funcon.
●The target surface should be as vercal to the opcal axis as possible. It is recommended that
the angle of oblique image plane should be less than 45°.
●The target image pixels should be more than 5 × 5.
●Please select line thermography or area thermography for a certain area temperature
measurement. The point thermography is not recommended in case of deviaon occurred
during device movement to aect the accuracy of temperature measurement.
3.2 Thermometry Flow Chart
This part introduces the process of conguring temperature measurement.
Thermographic Cube Camera User Manual
7

Figure 3-1 Thermometry Flow Chart
3.3 Automac Thermography
Congure the temperature measurement parameters and temperature measurement rules. The
device can measure the actual temperature and output alarms when temperature exceeds the
alarm threshold value.
Thermographic Cube Camera User Manual
8

3.3.1 Set Thermometry Parameters
Congure the parameters of temperature measurement.
Steps
1. Go to Conguraon → Local , enable Display Temperature Info. .
Display Temperature Info.
Select Yes to display temperature informaon on live view.
Enable Rules to display the rules informaon on live view.
2. Click Save.
3. Go to Conguraon → Temperature Measurement → Basic Sengs to congure parameters.
Enable Temperature Measurement
Check to enable temperature measurement funcon.
Enable Color-Temperature
Check to display Temperature-Color Ruler in live view.
Display Temperature Info. on Stream
Check to display temperature informaon on the stream.
Display Max./Min./Average Temperature
Check to display maximum/minimum/average temperature informaon on live view when
the temperature measurement rule is line or area.
Posion of Thermometry Info
Select the posion of temperature informaon showed on the live view.
●Near Target: display the informaon beside the temperature measurement rule.
●Top Le: display the informaon on the top le of screen.
Unit
Display temperature with Degree Celsius (°C)/Degree Fahrenheit (°F)/Degree Kelvin (K).
Temperature Range
Select the temperature measurement range.
Opcal Transmissivity
Set the opcal transmissivity of external opcal material (e.g.: germanium window) to
improve the temperature measuring accuracy.
Calibraon Coecient
Check to enable it and set the value of calibraon coecient to get the temperature of the
external window or opcal material automacally. The seng range is 0 to 30.
Note
You can get the seng value from SDK soware.
Thermographic Cube Camera User Manual
9
